Product 78BD4211-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073193438
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4211-2
- Weight (gr.)
- 14196
- R90 Homologation
-
90R-02C0452/0127
- Measures
- Ø297x25x67.4
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
23 -
Hole Arrangement/Number:
6 -
Bolt Hole Circle Ø [mm]:
139.7 -
Wheel Hub Diameter [mm]:
108
| Brand | OE Reference |
|---|---|
| TOYOTA | 435120K060 |
| TOYOTA | 435120K070 |
| TOYOTA | 435120K071 |
| Maker | Cross reference |
|---|---|
| BREMBO | 09.A634.10 |
| BREMBO | 09.A634.1X |
| HELLA-PAGID | 8DD 355 134-011 |
| TEXTAR | 92222600 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.7 (TGN61_, TGN61R) |
2TR-FE |
1 | 06/2004-05/2015 | 2694 | 118 | 160 | 2 |
| 2.7 (TGN61_) |
2TR-FE |
1 | 03/2009-05/2015 | 2694 | 116 | 158 | 2 |
| 2.7 4WD (TGN51_, TGN51R) |
2TR-FE |
1 | 06/2004-05/2015 | 2694 | 118 | 160 | 3 |
| 2.5 D-4D (KUN60, RZN205) |
2KD-FTV |
2 | 06/2004-05/2015 | 2494 | 75 | 102 | 2 |
| 2.5 D-4D (KUN60) |
2KD-FTV |
2 | 01/2009-05/2015 | 2494 | 106 | 144 | 2 |
| 2.5 D-4D 4WD (KUN50) |
2KD-FTV |
2 | 01/2009-05/2015 | 2494 | 75 | 102 | 3 |
| 2.5 D-4D 4WD (RZN215, KUN50) |
2KD-FTV |
2 | 07/2011-05/2015 | 2494 | 106 | 144 | 3 |
| 3.0 D | 2 | 08/2009-05/2015 | 2982 | 120 | 163 | 2 | |
| 3.0 D (KUN61_) | 2 | 01/2005-05/2015 | 2982 | 126 | 171 | 2 | |
| 3.0 D (KUN61) | 2 | 08/2009-05/2015 | 2982 | 125 | 170 | 2 | |
| 3.0 D 4WD (KUN51_) |
1KD-FTV |
2 | 08/2009-05/2015 | 2982 | 126 | 171 | 3 |
| 3.0 D 4WD (KUN51) |
1KD-FTV |
2 | 06/2004-05/2015 | 2982 | 120 | 163 | 3 |
| 3.0 D 4WD (KUN51) |
1KD-FTV |
2 | 08/2009-05/2015 | 2982 | 125 | 170 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.7 VVTi 4WD (TGN26) |
2TR-FE |
1 | 08/2005-05/2015 | 2694 | 118 | 160 | 3 |
| 4.0 V6 VVTi (GGN15) | 1 | 08/2005-02/2016 | 3956 | 175 | 238 | 2 | |
| 4.0 V6 VVTi 4WD (GGN25) |
1GR-FE |
1 | 08/2005-02/2016 | 3956 | 175 | 238 | 3 |
| 2.5 D 4WD (KUN25) |
2KD-FTV |
2 | 03/2005-05/2015 | 2494 | 75 | 102 | 3 |
| 2.5 D-4D (KUN15_, KUN15R) |
2KD-FTV |
2 | 06/2006-05/2015 | 2494 | 88 | 120 | 2 |
| 2.5 D-4D (KUN15, KUN10) |
2KD-FTV |
2 | 03/2005-05/2015 | 2494 | 75 | 102 | 2 |
| 2.5 D-4D (KUN15, KUN35) |
2KD-FTV |
2 | 01/2010-05/2015 | 2494 | 106 | 144 | 2 |
| 2.5 D-4D 4WD (KUN25_, KUN25R) |
2KD-FTV |
2 | 06/2006-05/2015 | 2494 | 88 | 120 | 3 |
| 2.5 D-4D 4WD (KUN25) |
2KD-FTV |
2 | 12/2007-05/2015 | 2494 | 106 | 144 | 3 |
| 3.0 D (LAN25_) | 2 | 07/2005-12/2014 | 2986 | 70 | 95 | 3 | |
| 3.0 D-4D (KUN16) |
1KD-FTV |
2 | 08/2006-05/2015 | 2982 | 126 | 171 | 2 |
| 3.0 D-4D 4WD (KUN26) |
1KD-FTV |
2 | 03/2005-05/2015 | 2982 | 120 | 163 | 3 |
| 3.0 D-4D 4WD (KUN26) | 2 | 08/2005-05/2015 | 2982 | 124 | 169 | 3 | |
| 3.0 D-4D 4WD (KUN26) |
1KD-FTV |
2 | 08/2005-09/2015 | 2982 | 126 | 171 | 3 |
| 3.0 D-4D 4WD (KUN26) |
1KD-FTV |
2 | 05/2008-12/2012 | 2982 | 145 | 197 | 3 |
| 3.0 Tdi 4x4 (KUN26) | 2 | 06/2013-05/2015 | 2982 | 130 | 177 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 4.0 V6 VVTi (GGN15R) | 1 | 02/2005- | 3956 | 175 | 238 | 2 | |
| 4.0 V6 VVTi 4WD (GGN25R) | 1 | 02/2005- | 3956 | 175 | 238 | 3 | |
| 3.0 D 4WD (KUN26) | 2 | 02/2005-08/2006 | 2982 | 120 | 163 | 3 | |
| 3.0 D 4WD (KUN26) |
1KD-FTV |
2 | 02/2005- | 2982 | 126 | 171 | 3 |
| 3.0 D-4D (KUN16R) | 2 | 02/2005- | 2982 | 126 | 171 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.4 D 4WD (GUN125_) |
2GD-FTV |
2 | 05/2015- | 2393 | 108 | 147 | 3 |
| 3.0 D 4WD (LAN125_) | 2 | 05/2015- | 2986 | 70 | 95 | 3 |
