Product 78BD4296-2
- Description
- Brake disc
- Axe
- Rear
- No. of Pieces
- 2
- Barcode
-
8424073145833
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4296-2
- Weight (gr.)
- 8192
- Measures
- Ø265x10.5x44.4
-
Brake Disc Type:
solid -
Minimum thickness [mm]:
9.5 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
108 -
Wheel Hub Diameter [mm]:
66
| Brand | OE Reference |
|---|---|
| RENAULT | 77 00 800 003 |
| RENAULT | 77 01 204 296 |
| RENAULT | 77 01 205 845 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0110-0220.1 |
| BENDIX BRAKING-TMD | BDS2077 |
| BOSCH | 0 986 478 757 |
| BREMBO | 08.5645.50 |
| ROAD HOUSE | 6239.02 |
| TRW | DF1029 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 |
N7Q 700 N7Q 704 |
1 | 06/1995-02/2001 | 1948 | 103 | 140 | 1 |
| 2.0 (556A) |
F4R 780 |
1 | 09/1999-02/2001 | 1998 | 102 | 139 | 1 |
| 2.0 16V (556A/B) |
F4R 780 |
1 | 09/1999-03/2001 | 1998 | 103 | 140 | 1 |
| 2.0 16V (B56D, B56M) |
N7Q 700 N7Q 704 |
1 | 06/1995-03/2001 | 1948 | 102 | 139 | 1 |
| 2.9 24V (B56V) | 1 | 03/1997-03/2001 | 2946 | 140 | 190 | 1 | |
| 3.0 (B56E, B565, B56R) |
Z7X 760 Z7X 765 |
1 | 11/1993-03/2001 | 2963 | 123 | 167 | 1 |
| 3.0 24V (B56V) |
L7X 700 L7X 701 |
1 | 03/1997-03/2001 | 2946 | 140 | 190 | 1 |
| 2.2 dT (B569) |
G8T 760 |
2 | 03/1996-03/2001 | 2188 | 83 | 113 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.0 (K56R, K565) |
Z7X 765 |
1 | 02/1996-03/2001 | 2963 | 123 | 167 | 1 |
| 3.0 24V (K56V) |
L7X 700 L7X 701 |
1 | 03/1997-03/2001 | 2946 | 140 | 190 | 1 |
| 2.2 D (K56F/2, S56F) |
G8T 706 G8T 752 G8T 790 G8T 794 |
2 | 09/1995-03/2001 | 2188 | 61 | 83 | 1 |
| 2.2 dT (K569) |
G8T 760 |
2 | 03/1996-03/2001 | 2188 | 83 | 113 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 12V (B542, B54E) |
J7R 734 J7R 735 |
1 | 04/1992-07/1996 | 1995 | 97 | 132 | 1 |
| 2.2 (B541) |
J7T 762 |
1 | 04/1992-07/1996 | 2165 | 79 | 107 | 1 |
| 2.2 (B543) |
J7T 760 J7T 761 |
1 | 04/1992-07/1996 | 2165 | 101 | 137 | 1 |
| 3.0 |
Z7X 721 |
1 | 03/1993-10/1996 | 2963 | 125 | 170 | 1 |
| 3.0 |
Z7X 723 |
1 | 02/1993-06/1996 | 2975 | 125 | 170 | 1 |
| 3.0 V6 (B54B, B544) |
Z7X 721 Z7X 722 Z7X 723 Z7X 753 |
1 | 12/1992-07/1996 | 2975 | 123 | 167 | 1 |
| 2.5 dT (B548) |
S8U 762 S8U 763 |
2 | 12/1992-07/1996 | 2499 | 83 | 113 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V (B54L) |
N7Q 710 N7Q 711 |
1 | 07/1996-12/2000 | 1948 | 100 | 136 | 1 |
| 2.5 20V (B54F) |
N7U 700 N7U 701 |
1 | 07/1996-12/2000 | 2435 | 121 | 165 | 1 |
| 2.9 24V (B54N) |
L7X 713 |
1 | 03/1999-12/2000 | 2946 | 140 | 190 | 1 |
| 3.0 V6 (B54M) |
Z7X 755 |
1 | 07/1996-12/2000 | 2963 | 123 | 167 | 1 |
| 2.2 dT (B54G) |
G8T 740 |
2 | 07/1996-12/2000 | 2188 | 83 | 113 | 1 |
