Product 78BD4392-2

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073145888
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4392-2
Weight (gr.): 7448

Measures: Ø236x12.5x35.5
: Brake Disc Type: solid; Minimum thickness [mm]: 9.7; Hole Arrangement/Number: 4; Bolt Hole Circle Ø [mm]: 102; Wheel Hub Diameter [mm]: 86

Reference applications

Brand	OE Reference
DAEWOO	9628 4392
DAEWOO	9632 0531
DAEWOO	9645 5424

Maker	Cross reference
ATE	24.0113-0195.1
BOSCH	0 986 478 712
BREMBO	08.7822.10
LETEC	LBD022S
ROAD HOUSE	6606.00
SANLI	SL10334
TRW	DF4123

CHEVROLET

MATIZ II / SPARK (M200, M250) Hatchback 03/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8		1	10/2010-	796	37	50	1
0.8	LBF(49CUL3) LQ2(49CUL3)	1	03/2005-12/2013	796	38	52	1
1.0	B10S	1	01/2008-12/2013	995	46	62	1
1.0	LQ4(61CUL4)	1	03/2005-12/2007	995	47	64	1
1.0	B10S1 LA2	1	01/2007-	995	48	65	1
1.0	LQ4(61CUL4)	1	03/2005-	995	49	67	1
1.0 LPG		1	01/2007-	995	44	60	1
0.8 LPG	LBF(49CUL3) LQ2(49CUL3)	18	03/2005-12/2007	796	38	52	1
1.0 LPG	LA2 LQ4(61CUL4)	18	03/2005-03/2011	995	49	67	1

SPARK II (M200, M250) Hatchback Van 01/2005-08/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8		1	01/2007-08/2014	796	38	52	1

SPARK II (M200,M250) Hatchback 05/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8	LBF(49CUL3) LQ2(49CUL3)	1	05/2005-02/2010	796	37	50	1
1.0 LPG		1	05/2005-	995	46	63	1
1.0 SX	LA2	1	06/2009-	995	44	60	1

SPARK III / BEAT / MATIZ (M300) Hatchback 12/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0		1	07/2010-	995	48	65	1

CHEVROLET (SGMW)

SPARK (KSC) Hatchback 11/2002-12/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8		1	11/2002-	796	38	52	1
1.0		1	05/2005-	995	46	63	1
1.0		1	04/2010-	995	51	69	1

DAEWOO

MATIZ (KLA4) Hatchback Van 08/1998-08/2002

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8	F8CV	1	08/1998-08/2002	796	38	52	1

MATIZ (M100, M150) Hatchback 09/1998-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8		1	09/1998-04/2003	796	27	37	1
0.8	F8CV	1	09/1998-	796	38	52	1
1.0	B10S	1	04/2003-12/2004	995	46	63	1
1.0	B10S	1	01/2003-	995	47	64	1

MATIZ II (M200, M250) Hatchback 01/2005-12/2018

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8		1	01/2005-06/2010	796	38	52	1
1.0	LA2(61CUL4) LQ4(61CUL4)	1	03/2005-12/2008	995	49	67	1

MATIZ III (M300) Hatchback 01/2010-11/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0		1	01/2010-11/2012	995	51	69	1

FSO

MATIZ () Hatchback 06/2000-04/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8	F8CV	1	06/2000-04/2005	796	38	52	1
1.0	B10S	1	06/2000-04/2005	995	47	64	1

PONTIAC

MATIZ G2 () Hatchback 10/2003-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0		1	10/2003-12/2009	995	49	67	1

RAVON

MATIZ () Hatchback 10/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8		1	10/2015-	796	38	52	1

UZ-DAEWOO

MATIZ () Hatchback 09/1998-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.8	F8CV	1	09/1998-	796	38	52	1
1.0	B10S	1	04/2003-	995	46	63	1
