Product 78BD4609-2
- Description
- Brake disc
- Axe
- Rear
- No. of Pieces
- 2
- Barcode
-
8424073145925
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4609-2
- Weight (gr.)
- 10072
- R90 Homologation
-
90R-02C0415/0014
- Measures
- Ø290x12x35
-
Brake Disc Type:
solid -
Minimum thickness [mm]:
10 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
108 -
Wheel Hub Diameter [mm]:
71
| Brand | OE Reference |
|---|---|
| CITROËN | 4249.72 |
| PEUGEOT | 4246.P9 |
| PEUGEOT | 4249-C1 |
| PEUGEOT | 4249.14 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0112-0162.1 |
| BENDIX ANTIGUO | 562253B |
| BENDIX BRAKING-TMD | BDS2121 |
| BOSCH | 0 986 479 194 |
| BREMBO | 08.8682.10 |
| DELPHI LOCKHEED | BG3836 |
| LETEC | LBP015S |
| ROAD HOUSE | 6690.00 |
| SANLI | SL10457 |
| TRW | DF4351 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 (RD5FMA) |
5FM (EP6DT) |
1 | 03/2011-06/2014 | 1598 | 120 | 163 | 1 |
| 1.8 16V (RD6FXC) |
6FY (EW7A) |
1 | 02/2008-10/2010 | 1749 | 92 | 125 | 1 |
| 2.0 16V (RDRFJC, RDRFJF) |
RFJ (EW10A) |
1 | 02/2008-10/2014 | 1997 | 103 | 140 | 1 |
| 3.0 | 1 | 02/2008- | 2946 | 152 | 207 | 1 | |
| 3.0 V6 (RDXFVJ) |
XFU (ES9A) XFV (ES9A) |
1 | 02/2008-12/2010 | 2946 | 155 | 211 | 1 |
| 2.0 16V BioFlex (RDRFJF) |
RFJ (EW10A) |
19 | 02/2008-12/2012 | 1997 | 103 | 140 | 1 |
| 1.6 HDi 110 (RD9HZC) |
9HZ (DV6TED4) |
2 | 02/2008-10/2010 | 1560 | 80 | 109 | 1 |
| 2.0 HDi (RDRHD8, RDRHDJ, RDRHR8, RDRHRJ) |
RHF (DW10BTED4) RHR (DW10BTED4) |
2 | 02/2008-06/2014 | 1997 | 100 | 136 | 1 |
| 2.0 HDi (RDRHR8) |
RHR (DW10BTED4) |
2 | 10/2014-05/2017 | 1997 | 101 | 138 | 1 |
| 2.0 HDi 180 (RDAHWT) |
AHW (DW10FC) |
2 | 03/2015-05/2017 | 1997 | 133 | 181 | 1 |
| 2.2 HDi (RD4HTH, RD4HPH, RD4HRH, RD4HSH) |
4HP (DW12BTED4) 4HR (DW12BTED4) |
2 | 04/2009-12/2011 | 2179 | 120 | 163 | 1 |
| 2.2 HDi (RD4HTH) |
4HT (DW12BTED4) |
2 | 02/2008-12/2011 | 2179 | 125 | 170 | 1 |
| 2.2 HDi 200 (RD4HLA) |
4HL (DW12C) |
2 | 07/2010-06/2015 | 2179 | 150 | 204 | 1 |
| 2.7 HDi (RDUHZJ) |
UHZ (DT17TED4) |
2 | 02/2008-12/2009 | 2720 | 150 | 204 | 1 |
| 3.0 HDi 240 (RDX8CA) |
DT20C |
2 | 04/2009-10/2014 | 2992 | 177 | 241 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 i 16V (RW6FYC) |
6FY (EW7A) |
1 | 02/2008-10/2010 | 1749 | 92 | 125 | 1 |
| 2.0 i 16V (RWRFJC, RWRFJF) |
RFJ (EW10A) |
1 | 02/2008-10/2014 | 1997 | 103 | 140 | 1 |
| 3.0 | 1 | 02/2008- | 2946 | 152 | 207 | 1 | |
| 3.0 V6 (RWXFVA, RWXFUA) |
XFU (ES9A) XFV (ES9A) |
1 | 02/2008-12/2010 | 2946 | 155 | 211 | 1 |
| 2.0 16V BioFlex |
RFJ (EW10A) |
19 | 02/2008-06/2010 | 1997 | 103 | 140 | 1 |
| 1.6 HDi 110 (RW9HZC) |
9HZ (DV6TED4) |
2 | 02/2008-10/2010 | 1560 | 80 | 109 | 1 |
| 2.0 HDi |
RHR (DW10BTED4) |
2 | 02/2008-06/2014 | 1997 | 100 | 136 | 1 |
| 2.0 HDi 180 |
AHW (DW10FC) |
2 | 03/2015-05/2017 | 1997 | 133 | 181 | 1 |
| 2.2 HDi (RW4HTH) |
4HT (DW12BTED4) |
2 | 02/2008-12/2011 | 2179 | 125 | 170 | 1 |
| 2.2 HDi 165 |
4HP (DW12BTED4) |
2 | 02/2008-08/2009 | 2179 | 120 | 163 | 1 |
| 2.2 HDi 200 |
4HL (DW12C) |
2 | 07/2010-06/2015 | 2179 | 150 | 204 | 1 |
| 2.7 HDi |
UHZ (DT17TED4) |
2 | 02/2008-10/2009 | 2720 | 150 | 204 | 1 |
| 3.0 HDi 240 (RWX8CA) |
DT20C |
2 | 04/2009-10/2014 | 2992 | 177 | 241 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 (6D6FZB) |
6FZ (EW7J4) |
1 | 03/2004-07/2005 | 1749 | 85 | 116 | 1 |
| 1.8 16V (6D6FYC) |
6FY (EW7A) |
1 | 08/2005-12/2010 | 1749 | 92 | 125 | 1 |
| 2.0 (6DRFNB, 6DRFNE) |
RFN (EW10J4) |
1 | 03/2004-07/2005 | 1997 | 100 | 136 | 1 |
| 2.0 16V (6DRFJC, 6DRFJE, 6DRFJF) |
RFJ (EW10A) |
1 | 09/2005-12/2010 | 1997 | 103 | 140 | 1 |
| 2.2 (6D3FZE, 6D3FZH) |
3FZ (EW12J4) |
1 | 03/2004-10/2006 | 2230 | 116 | 158 | 1 |
| 2.2 16V (6D3FYH, 6D3FYE) |
3FY (EW12J4) |
1 | 08/2005-12/2010 | 2230 | 120 | 163 | 1 |
| 3.0 (6DXFVJ) |
XFV (ES9A) |
1 | 03/2004-12/2010 | 2946 | 155 | 211 | 1 |
| 3.0 V6 (6DXFVJ) | 1 | 11/2005-10/2010 | 2946 | 158 | 215 | 1 | |
| 2.0 Flex (6DRFJB) |
RFJ (EW10A) |
19 | 10/2005-02/2011 | 1997 | 103 | 140 | 1 |
| 1.6 HDi 110 (6D9HZC, 6D9HYC) |
9HZ (DV6TED4) |
2 | 05/2004-12/2010 | 1560 | 80 | 109 | 1 |
| 2.0 HDi (6DRHHA) |
RHH (DW10CTED4) |
2 | 06/2009-12/2010 | 1997 | 120 | 163 | 1 |
| 2.0 HDi (6DRHRH) |
RHR (DW10BTED4) |
2 | 06/2009-12/2010 | 1997 | 103 | 140 | 1 |
| 2.0 HDi 135 (6DRHRH, 6DRHRE, 6DRHRG, 6DRHRJ) |
RHR (DW10BTED4) |
2 | 05/2004-10/2010 | 1997 | 100 | 136 | 1 |
| 2.2 HDi (6D4HPH) |
4HP (DW12BTED4) |
2 | 03/2006-12/2010 | 2179 | 120 | 163 | 1 |
| 2.2 HDi 170 (6D4HTH) |
4HT (DW12BTED4) |
2 | 03/2006-12/2010 | 2179 | 125 | 170 | 1 |
| 2.7 HDi (6DUHZJ, 6DUHZF) |
UHZ (DT17TED4) |
2 | 10/2005-12/2010 | 2720 | 150 | 204 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 |
6FZ (EW7J4) |
1 | 05/2004-07/2005 | 1749 | 85 | 116 | 1 |
| 1.8 16V |
6FY (EW7A) |
1 | 08/2005-12/2010 | 1749 | 92 | 125 | 1 |
| 2.0 |
RFN (EW10J4) |
1 | 05/2004-07/2005 | 1997 | 100 | 136 | 1 |
| 2.0 16V |
RFJ (EW10A) |
1 | 08/2005-12/2010 | 1997 | 103 | 140 | 1 |
| 2.2 |
3FZ (EW12J4) |
1 | 05/2004-07/2005 | 2230 | 116 | 158 | 1 |
| 2.2 16V |
3FY (EW12J4) |
1 | 08/2005-12/2010 | 2230 | 120 | 163 | 1 |
| 3.0 |
XFV (ES9A) |
1 | 05/2004-12/2010 | 2946 | 155 | 211 | 1 |
| 2.0 Bioflex |
RFJ (EW10A) |
19 | 01/2008-12/2010 | 1997 | 103 | 140 | 1 |
| 1.6 HDi 110 |
9HZ (DV6TED4) |
2 | 05/2004-12/2010 | 1560 | 80 | 109 | 1 |
| 2.0 HDi |
RHR (DW10BTED4) |
2 | 08/2008-12/2010 | 1997 | 103 | 140 | 1 |
| 2.0 HDi |
RHH (DW10CTED4) |
2 | 06/2009-12/2010 | 1997 | 120 | 163 | 1 |
| 2.0 HDi 135 |
RHR (DW10BTED4) |
2 | 07/2004-12/2010 | 1997 | 100 | 136 | 1 |
| 2.2 HDi |
4HP (DW12BTED4) |
2 | 06/2008-12/2010 | 2179 | 120 | 163 | 1 |
| 2.2 HDi 170 |
4HT (DW12BTED4) |
2 | 03/2006-12/2010 | 2179 | 125 | 170 | 1 |
| 2.7 HDi |
UHZ (DT17TED4) |
2 | 10/2005-12/2010 | 2720 | 150 | 204 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 HDi |
RHH (DW10CTED4) |
2 | 06/2009-12/2010 | 1997 | 120 | 163 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.2 16V |
3FY (EW12J4) |
1 | 10/2005- | 2230 | 120 | 163 | 1 |
| 3.0 V6 |
XFV (ES9A) |
1 | 10/2005- | 2946 | 155 | 211 | 1 |
| 2.0 HDi |
RHR (DW10BTED4) |
2 | 10/2005- | 1997 | 100 | 136 | 1 |
| 2.0 HDi |
RHH (DW10CTED4) |
2 | 06/2009- | 1997 | 120 | 163 | 1 |
| 2.7 HDi |
UHZ (DT17TED4) |
2 | 10/2005- | 2720 | 150 | 204 | 1 |
| 3.0 HDi |
DT20C |
2 | 06/2009- | 2992 | 177 | 241 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.2 HDi |
4HX (DW12TED4) |
2 | 02/2000-02/2006 | 2179 | 98 | 133 | 1 |
| 2.2 HDi |
4HT (DW12BTED4) |
2 | 05/2006-06/2010 | 2179 | 125 | 170 | 1 |
| 2.7 HDi 24V |
DT17TED4 |
2 | 12/2004-07/2011 | 2721 | 150 | 204 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V |
5FV (EP6CDT) |
1 | 03/2010-12/2015 | 1598 | 115 | 156 | 1 |
| 1.6 16V |
5FM (EP6CDTM) |
1 | 01/2011-12/2015 | 1598 | 121 | 165 | 1 |
| 1.6 16V |
EP6CDTX |
1 | 06/2010-12/2015 | 1598 | 147 | 200 | 1 |
| 1.6 16V |
EP6CDTX |
1 | 06/2010-12/2015 | 1598 | 150 | 204 | 1 |
| 1.6 THP 150 |
5FE (EP6CDTMD) |
1 | 03/2011-12/2015 | 1598 | 110 | 150 | 1 |
| 1.6 THP 270 |
5FG (EP6CDTR) |
1 | 06/2013-12/2015 | 1598 | 199 | 270 | 1 |
| 2.0 HDi |
RHH (DW10CTED4) |
2 | 03/2010-12/2015 | 1997 | 120 | 163 | 1 |
