Product 78BD4623-2 - Web Catalogo

Product 78BD4623-2

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073193469
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4623-2
Weight (gr.): 11920

R90 Homologation: 90R-02C0415/0014
Measures: Ø290x14x49
: Brake Disc Type: solid; Minimum thickness [mm]: 12; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 108; Wheel Hub Diameter [mm]: 71.1

Reference applications

Brand	OE Reference
FIAT	940429918
FIAT	9467548487
PEUGEOT	1611841080
PEUGEOT	424922
PEUGEOT	424923
PEUGEOT	424991
TOYOTA	SU001A1062

Maker	Cross reference
BREMBO	08.A456.10
TEXTAR	92157100

CITROËN

JUMPY II / DISPATCH () Platform/Chassis 11/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 I (X_RFH)		1	11/2006-03/2016	1997	103	140	1
1.6 HDi 90 16V	9HU (DV6UTED4)	2	06/2007-03/2016	1560	66	90	1
1.6 HDi 90 8V	9HH (DV6DUM)	2	06/2007-03/2016	1560	66	90	1
2.0 HDI (X_RHG)		2	01/2009-03/2016	1997	88	120	1
2.0 HDI (X_RHH)		2	07/2010-03/2016	1997	120	163	1
2.0 HDI 100 (X_AHY)		2	07/2011-03/2016	1997	72	98	1
2.0 HDi 125	AHZ (DW10CD)	2	07/2011-	1997	94	128	1

JUMPY II / DISPATCH (VF7) Bus 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 i	RFH (EW10A) RFJ (EW10A)	1	01/2007-03/2016	1997	103	140	1
1.6 HDi 90 16V	9HU (DV6UTED4)	2	01/2007-03/2016	1560	66	90	1
1.6 HDi 90 8V	9HH (DV6DUM) 9HM (DV6UC)	2	01/2007-03/2016	1560	66	90	1
2.0 HDi 120	RHK (DW10UTED4)	2	01/2007-03/2016	1997	88	120	1
2.0 HDi 125	AHZ (DW10CD)	2	07/2011-03/2016	1997	94	128	1
2.0 HDi 140	RHR (DW10BTED4)	2	01/2007-03/2016	1997	100	136	1
2.0 HDi 165	RHH (DW10CTED4)	2	07/2010-03/2016	1997	120	163	1
2.0 HDi 95	AHY (DW10CE)	2	07/2011-03/2016	1997	72	98	1

JUMPY II / DISPATCH () Van 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 i	RFH (EW10A)	1	01/2007-03/2016	1997	103	140	1
1.6 HDi 90 16V	9HU (DV6UTED4)	2	01/2007-03/2016	1560	66	90	1
1.6 HDi 90 8V	9HH (DV6DUM) 9HM (DV6UC)	2	01/2007-03/2016	1560	66	90	1
2.0 HDi 120	RHK (DW10UTED4)	2	01/2007-03/2016	1997	88	120	1
2.0 HDi 120 4x4	RHK (DW10UTED4)	2	01/2010-03/2016	1997	88	120	3
2.0 HDi 125	AHZ (DW10CD)	2	07/2011-03/2016	1997	94	128	1
2.0 HDi 125 4x4	AHZ (DW10CD)	2	07/2011-03/2016	1997	94	128	3
2.0 HDi 140	RHR (DW10BTED4)	2	01/2007-03/2016	1997	100	136	1
2.0 HDi 165	RHH (DW10CTED4)	2	07/2010-03/2016	1997	120	163	1
2.0 HDi 95	AHY (DW10CE)	2	07/2011-03/2016	1997	72	98	1

FIAT

SCUDO II (270_, 272_) Van 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 D Multijet	9HU	2	01/2007-03/2016	1560	66	90	1
1.6 D Multijet	9H07 (DV6UC) 9HM (DV6UC)	2	02/2011-03/2016	1560	66	90	1
2.0 D Multijet	RHK	2	01/2007-03/2016	1997	88	120	1
2.0 D Multijet	RH02	2	05/2011-03/2016	1997	94	128	1
2.0 D Multijet	RHR	2	01/2007-03/2016	1997	100	136	1
2.0 D Multijet	RH02 RHH	2	07/2010-03/2016	1997	120	163	1
2.0 D Multijet 4x4	RHK	2	01/2007-03/2016	1997	88	120	3
2.0 D Multijet 4x4	RH02	2	05/2011-03/2016	1997	94	128	3
2.0 D Multijet 4x4	RHR	2	01/2007-03/2016	1997	100	136	3

SCUDO II (270_, 272_) Bus 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 D Multijet	9HU	2	01/2007-03/2016	1560	66	90	1
1.6 D Multijet	9H07 (DV6UC) 9HM (DV6UC)	2	02/2011-03/2016	1560	66	90	1
2.0 D Multijet	RHK	2	01/2007-03/2016	1997	88	120	1
2.0 D Multijet	RH02	2	04/2011-03/2016	1997	94	128	1
2.0 D Multijet	RHR	2	01/2007-03/2016	1997	100	136	1
2.0 D Multijet	RH02 RHH	2	07/2010-03/2016	1997	120	163	1
2.0 D Multijet 4x4	RHK	2	01/2007-03/2016	1997	88	120	3
2.0 D Multijet 4x4	RH02	2	04/2011-03/2016	1997	94	128	3
2.0 D Multijet 4x4	RHR	2	01/2007-03/2016	1997	100	136	3

SCUDO II (270_, 272_) Platform/Chassis 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 D Multijet	9HU	2	01/2007-03/2016	1560	66	90	1
2.0 D Multijet	RHK	2	01/2007-03/2016	1997	88	120	1
2.0 D Multijet	RH02	2	05/2011-03/2016	1997	94	128	1
2.0 D Multijet	DW10BTED4 RHR	2	01/2007-03/2016	1997	100	136	1
2.0 D Multijet	RH02 RHH	2	07/2010-03/2016	1997	120	163	1

PEUGEOT

EXPERT II (VF3A_, VF3U_, VF3X_) Van 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 16V	RFH (EW10A) RFJ (EW10A)	1	01/2007-	1997	103	140	1
1.6 HDi 90 16V	9HU (DV6UTED4)	2	01/2007-	1560	66	90	1
1.6 HDi 90 8V	9HH (DV6DUM) 9HM (DV6UC)	2	01/2007-	1560	66	90	1
2.0 HDi 100		2	03/2011-	1997	72	98	1
2.0 HDi 120	RHK (DW10UTED4)	2	01/2007-	1997	88	120	1
2.0 HDi 120 4x4	RHK (DW10UTED4)	2	01/2010-	1997	88	120	3
2.0 HDi 130	AHZ (DW10CD)	2	03/2011-	1997	94	128	1
2.0 HDi 130 4x4	AHZ (DW10CD)	2	01/2012-03/2016	1997	94	128	3
2.0 HDi 140	RHR (DW10BTED4)	2	01/2007-	1997	100	136	1
2.0 HDi 165	RHH (DW10CTED4)	2	09/2009-	1997	120	163	1

EXPERT II () Platform/Chassis 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 16V (X_RFH)		1	01/2007-03/2016	1997	103	140	1
1.6 HDi 90 16V	9HU (DV6UTED4)	2	01/2007-	1560	66	90	1
1.6 HDi 90 8V	9HH (DV6DUM) 9HM (DV6UC)	2	01/2007-	1560	66	90	1
2.0 HDi 120	RHK (DW10UTED4)	2	01/2007-	1997	88	120	1
2.0 HDi 130	AHZ (DW10CD)	2	03/2011-	1997	94	128	1
2.0 HDi 140	RHR (DW10BTED4)	2	01/2007-	1997	100	136	1
2.0 HDi 165	RHH (DW10CTED4)	2	09/2009-	1997	120	163	1

EXPERT II Tepee (VF3X_) Bus 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 16V	RFH (EW10A) RFJ (EW10A)	1	01/2007-03/2016	1997	103	140	1
1.6 HDi 90 16V	9HU (DV6UTED4)	2	01/2007-03/2016	1560	66	90	1
1.6 HDi 90 8V	9HH (DV6DUM) 9HM (DV6UC)	2	01/2007-03/2016	1560	66	90	1
2.0 HDi 100	AHY (DW10CE)	2	03/2011-03/2016	1997	72	98	1
2.0 HDi 120	RHK (DW10UTED4)	2	01/2007-03/2016	1997	88	120	1
2.0 HDi 120 4x4	RHK (DW10UTED4)	2	01/2007-03/2016	1997	88	120	3
2.0 HDi 130	AHZ (DW10CD)	2	03/2011-	1997	94	128	1
2.0 HDi 130 4x4	AHZ (DW10CD)	2	03/2011-03/2016	1997	94	128	3
2.0 HDi 140	RHR (DW10BTED4)	2	01/2007-	1997	100	136	1
2.0 HDi 165	RHH (DW10CTED4)	2	09/2009-	1997	120	163	1

PARTNER (5_, G_) Platform/Chassis 03/1997-07/2008

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 HDi 75		2	02/2006-07/2008	1560	55	75	1

TOYOTA

PROACE (MDX_) Van 06/2013-03/2016

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 D (MDX9)	3WZ-TV	2	06/2013-03/2016	1560	66	90	1
2.0 D (MDX3)	4WZ-FTW	2	06/2013-03/2016	1997	94	128	1
2.0 D (MDX6)	4WZ-FHV	2	06/2013-03/2016	1997	120	163	1
2.0 D 4x4 (MDX4)	4WZ-FTW	2	06/2013-03/2016	1997	94	128	3
