Product 78BD4668-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073193476
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4668-2
- Weight (gr.)
- 15880
- Measures
- Ø295.9x26x43.9
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
23.4 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
114.3 -
Wheel Hub Diameter [mm]:
68
| Brand | OE Reference |
|---|---|
| RENAULT | 402060002R |
| RENAULT | 402064408R |
| RENAULT | 402066813R |
| RENAULT | 402067023R |
| Maker | Cross reference |
|---|---|
| BREMBO | 09.B353.10 |
| TEXTAR | 92195600 |
| TEXTAR | 92195603 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 TCe (JZ11, JZ28) |
H5F 400 |
1 | 04/2012-09/2016 | 1197 | 85 | 116 | 1 |
| 1.2 TCe (JZ16) |
H5F 404 |
1 | 01/2013-09/2016 | 1197 | 97 | 132 | 1 |
| 1.2 TCe (JZ28) |
H5F 408 |
1 | 07/2014-09/2016 | 1197 | 96 | 131 | 1 |
| 1.4 16V (JZ0F) |
H4J 700 |
1 | 02/2009-09/2016 | 1397 | 96 | 131 | 1 |
| 1.6 16V (JZ0U) |
K4M 858 |
1 | 02/2009-09/2016 | 1598 | 81 | 109 | 1 |
| 2.0 16V (JZ0G) |
M4R 711 |
1 | 02/2009-09/2016 | 1997 | 103 | 140 | 1 |
| 1.6 16V Bifuel (JZ1Y) |
K4M 866 |
18 | 04/2012-09/2016 | 1598 | 79 | 107 | 1 |
| 1.6 16V Bifuel (JZ1Y) |
K4M 866 |
18 | 02/2009-09/2016 | 1598 | 81 | 110 | 1 |
| 1.6 E85 (JZ03, JZ1Y) |
K4M 866 |
19 | 02/2009-09/2016 | 1598 | 81 | 110 | 1 |
| 1.5 dCi (JZ02, JZ0R) |
K9K 846 |
2 | 11/2010-09/2016 | 1461 | 70 | 95 | 1 |
| 1.5 dCi (JZ09, JZ0D, JZ10, JZ14, JZ1G, JZ29, JZ2C) |
K9K 636 K9K 836 K9K 837 |
2 | 04/2009-09/2016 | 1461 | 81 | 110 | 1 |
| 1.5 dCi (JZ0A) |
K9K 830 |
2 | 04/2009-09/2016 | 1461 | 63 | 86 | 1 |
| 1.5 dCi (JZ0B, JZ07) |
K9K 832 |
2 | 02/2009-09/2016 | 1461 | 78 | 106 | 1 |
| 1.6 dCi (JZ00, JZ12) |
R9M 402 R9M 404 R9M 414 |
2 | 04/2011-09/2016 | 1598 | 96 | 130 | 1 |
| 1.9 dCi (JZ0J, JZ0N, JZ1K, JZ1S) |
F9Q 870 F9Q 872 |
2 | 02/2009-09/2016 | 1870 | 96 | 131 | 1 |
| 2.0 dCi (JZ0L) |
M9R 610 |
2 | 04/2009-09/2016 | 1995 | 118 | 160 | 1 |
| 2.0 dCi (JZ0Y, JZ26) |
M9R 615 |
2 | 02/2009-09/2016 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V (BT05, BT0F, BT0W) |
M4R 704 |
1 | 10/2007-12/2012 | 1998 | 103 | 140 | 1 |
| 2.0 16V Turbo |
F4R 811 |
1 | 10/2007-12/2015 | 1998 | 125 | 170 | 1 |
| 2.0 16V Hi-Flex (BT1H, BT1G, BT1K) |
M4R 726 |
19 | 10/2007-12/2015 | 1997 | 103 | 140 | 1 |
| 2.0 dCi (BT01, BT08, BT09, BT0E, BT0K, BT12, BT1C, BT1D,... |
M9R 742 M9R 744 M9R 746 M9R 748 M9R 754 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 110 | 150 | 1 |
| 2.0 dCi (BT07, BT0J, BT14, BT1A, BT1S) |
M9R 742 M9R 744 M9R 802 M9R 814 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 96 | 131 | 1 |
| 2.0 dCi (BT0M, BT0N, BT0S, BT19, BT1F) |
M9R 800 M9R 806 M9R 809 M9R 815 M9R 854 M9R 857 M9R 858 |
2 | 01/2008-12/2015 | 1995 | 127 | 173 | 1 |
| 2.0 dCi GT (BT11, BT1E, BT1N) |
M9R 816 M9R 820 M9R 828 |
2 | 03/2008-12/2015 | 1995 | 131 | 178 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V (KT0F, KT0W) |
M4R 704 |
1 | 10/2007-12/2015 | 1998 | 103 | 140 | 1 |
| 2.0 16V Turbo |
F4R 811 |
1 | 10/2007-12/2015 | 1998 | 125 | 170 | 1 |
| 2.0 16V Hi-Flex (KT1H, KT1G, KT1K) |
M4R 704 M4R 726 |
19 | 10/2007-12/2015 | 1997 | 103 | 140 | 1 |
| 2.0 dCi (KT01, KT08, KT09, KT0K, KT12, KT1D, KT1W) |
M9R 742 M9R 744 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 110 | 150 | 1 |
| 2.0 dCi (KT07, KT0J, KT14, KT1A, KT1S) |
M9R 742 M9R 744 M9R 802 M9R 814 M9R 854 M9R 858 |
2 | 10/2007-12/2015 | 1995 | 96 | 131 | 1 |
| 2.0 dCi (KT0M, KT0N, KT0S, KT19, KT1F) |
M9R 800 M9R 806 M9R 809 M9R 815 M9R 849 M9R 854 M9R 857 M9R 858 |
2 | 01/2008-12/2015 | 1995 | 127 | 173 | 1 |
| 2.0 dCi GT (KT11, KT1E, KT1N) |
M9R 816 M9R 820 M9R 828 |
2 | 03/2008-12/2015 | 1995 | 131 | 178 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V Turbo |
F4R 811 F4RT 811 |
1 | 09/2008-12/2015 | 1998 | 125 | 170 | 1 |
| 3.5 V6 (DT0P) |
V4Y 713 |
1 | 09/2008-12/2015 | 3498 | 175 | 238 | 1 |
| 2.0 dCi (DT01, DT08, DT09, DT0K, DT12, DT1C, DT1D, DT1M,... |
M9R 744 M9R 748 M9R 754 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858 |
2 | 09/2008-12/2015 | 1995 | 110 | 150 | 1 |
| 2.0 dCi (DT0M, DT0N, DT0S, DT19, DT1F) |
M9R 800 M9R 806 M9R 809 M9R 815 M9R 849 M9R 854 M9R 857 |
2 | 09/2008-12/2015 | 1995 | 127 | 173 | 1 |
| 2.0 dCi GT (DT11, DT1E, DT1N) |
M9R 816 M9R 820 M9R 828 |
2 | 09/2008-12/2015 | 1995 | 131 | 178 | 1 |
| 3.0 dCi |
V9X 891 |
2 | 01/2012-12/2015 | 2998 | 177 | 241 | 1 |
| 3.0 dCi (DT03) |
V9X 791 V9X 891 |
2 | 09/2008-12/2015 | 2998 | 173 | 235 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V |
M4R 746 |
1 | 02/2011- | 1997 | 102 | 139 | 1 |
| 2.0 16V (L70B) |
M4R 746 |
1 | 02/2011- | 1997 | 103 | 140 | 1 |
| 2.5 V6 (L702, L703, L704, L707) |
2ZV 604 |
1 | 05/2011- | 2495 | 130 | 177 | 1 |
| 2.0 16V eco2 Flexfuel (L70B) |
M4R 746 |
19 | 02/2011- | 1997 | 103 | 140 | 1 |
| 1.5 dCi (L70R, L731) |
K9K 782 K9K 849 |
2 | 07/2010- | 1461 | 81 | 110 | 1 |
| 2.0 dCi 130 |
M9R 756 |
2 | 12/2013- | 1995 | 96 | 131 | 1 |
| 2.0 dCi 150 (L70H) |
M9R 824 M9R 846 |
2 | 02/2011- | 1995 | 110 | 150 | 1 |
| 2.0 dCi 175 (L70Y, L734) |
M9R 804 M9R 817 M9R 844 |
2 | 05/2011- | 1995 | 127 | 173 | 1 |
| 2.5 dCi | 2 | 05/2011- | 2496 | 133 | 181 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 TCe |
F4R 872 |
1 | 06/2012-08/2015 | 1998 | 140 | 190 | 1 |
| 2.0 TCe (BZ0K) |
F4R 870 |
1 | 11/2008-08/2015 | 1998 | 132 | 180 | 1 |
| 2.0 TCe 220 |
F4R 874 |
1 | 11/2013-01/2016 | 1998 | 162 | 220 | 1 |
| 2.0 dCi |
M9R 610 |
2 | 07/2012-08/2015 | 1995 | 120 | 163 | 1 |
| 2.0 dCi (BZ0L) |
M9R 610 |
2 | 04/2009-08/2015 | 1995 | 118 | 160 | 1 |
| 2.0 dCi (BZ0Y) |
M9R 615 |
2 | 10/2010-08/2015 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 TCe |
F4R 872 |
1 | 06/2012-08/2015 | 1998 | 140 | 190 | 1 |
| 2.0 TCe (DZ0K) |
F4R 870 |
1 | 11/2008-08/2015 | 1998 | 132 | 180 | 1 |
| 2.0 TCe 220 |
F4R 874 |
1 | 11/2013-08/2015 | 1998 | 162 | 220 | 1 |
| 2.0 dCi |
M9R 610 |
2 | 07/2012-08/2015 | 1995 | 120 | 163 | 1 |
| 2.0 dCi (DZ0L) |
M9R 610 |
2 | 04/2009-08/2015 | 1995 | 118 | 160 | 1 |
| 2.0 dCi (DZ0Y) |
M9R 615 |
2 | 04/2009-08/2015 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 TCe |
F4R 872 |
1 | 09/2012-08/2015 | 1998 | 140 | 190 | 1 |
| 2.0 TCe |
F4R 874 |
1 | 09/2012-01/2016 | 1998 | 162 | 220 | 1 |
| 2.0 TCe (KZ0K, KZ1T) |
F4R 870 F4R 872 |
1 | 11/2008-08/2015 | 1998 | 132 | 180 | 1 |
| 2.0 dCi |
M9R 610 |
2 | 07/2012-08/2015 | 1995 | 120 | 163 | 1 |
| 2.0 dCi (KZ0L) |
M9R 610 |
2 | 04/2009-08/2015 | 1995 | 118 | 160 | 1 |
| 2.0 dCi (KZ0Y) |
M9R 615 |
2 | 10/2010-08/2015 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 TCe (EZ1T) |
F4R 870 F4R 872 |
1 | 06/2010-08/2015 | 1998 | 132 | 180 | 1 |
| 2.0 Turbo |
F4R 874 |
1 | 10/2011- | 1998 | 195 | 265 | 1 |
| 2.0 dCi (EZ0L) |
M9R 610 |
2 | 06/2010-08/2015 | 1995 | 118 | 160 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 TCe |
H5F 400 |
1 | 04/2012-09/2016 | 1197 | 85 | 116 | 1 |
| 1.2 TCe |
H5F 408 |
1 | 07/2014-09/2016 | 1197 | 96 | 131 | 1 |
| 1.2 TCe (JZ16) |
H5F 404 H5F 408 |
1 | 01/2013-09/2016 | 1197 | 97 | 132 | 1 |
| 1.4 16V (JZ0F, JZ1V) |
H4J 700 |
1 | 02/2009-09/2016 | 1397 | 96 | 131 | 1 |
| 1.6 16V (JZ0U, JZ1B) |
K4M 858 K4M R 858 |
1 | 02/2009-09/2016 | 1598 | 81 | 110 | 1 |
| 2.0 16V |
M4R 711 |
1 | 12/2008-09/2016 | 1997 | 101 | 137 | 1 |
| 2.0 16V (JZ0G, JZ0P, JZ1E, JZ1P) |
M4R 710 M4R 711 M4R 713 |
1 | 02/2009-09/2016 | 1997 | 103 | 140 | 1 |
| 1.6 16V Bifuel |
K4M 866 |
18 | 04/2012-12/2013 | 1598 | 79 | 107 | 1 |
| 1.6 16V Bifuel |
K4M 866 |
18 | 02/2009-09/2016 | 1598 | 81 | 110 | 1 |
| 1.6 E85 (JZ03, JZ1Y) |
K4M 866 |
19 | 02/2009-09/2016 | 1598 | 81 | 110 | 1 |
| 1.5 dCi |
K9K 830 |
2 | 04/2009-09/2016 | 1461 | 63 | 86 | 1 |
| 1.5 dCi |
K9K 832 |
2 | 02/2009-09/2016 | 1461 | 78 | 106 | 1 |
| 1.5 dCi |
K9K 636 K9K 656 K9K 657 K9K 836 K9K 837 |
2 | 04/2009-09/2016 | 1461 | 81 | 110 | 1 |
| 1.5 dCi (JZ02, JZ0R) |
K9K 846 |
2 | 11/2010-09/2016 | 1461 | 70 | 95 | 1 |
| 1.6 dCi (JZ00, JZ12) |
R9M 402 R9M 404 R9M 414 |
2 | 04/2011-09/2016 | 1598 | 96 | 130 | 1 |
| 1.9 dCi (JZ0J, JZ1J, JZ1K, JZ1S) |
F9Q 870 F9Q 872 |
2 | 02/2009-09/2016 | 1870 | 96 | 131 | 1 |
| 2.0 dCi (JZ0L) |
M9R 610 |
2 | 04/2009-09/2016 | 1995 | 118 | 160 | 1 |
| 2.0 dCi (JZ0Y, JZ26) |
M9R 615 |
2 | 02/2009-09/2016 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 TCe (JZ0F, JZ1V) | 1 | 01/2013-09/2016 | 1397 | 96 | 131 | 1 | |
| 1.6 VVT (JZ0U, JZ1B, JZ1H, JZ1U, JZ24) | 1 | 01/2013-09/2016 | 1598 | 81 | 110 | 1 | |
| 1.5 dCi (JZ02) | 2 | 01/2013-09/2016 | 1461 | 70 | 95 | 1 | |
| 1.5 dCi (JZ0D, JZ1M, JZ09, JZ14, JZ1G, JZ1W, JZ10) | 2 | 04/2009-09/2016 | 1461 | 81 | 110 | 1 | |
| 1.6 dCi (JZ00, JZ12, JZ2A) | 2 | 01/2013-09/2016 | 1598 | 96 | 131 | 1 | |
| 1.9 dCi (JZ0J, JZ1J, JZ1K, JZ1S) | 2 | 01/2013-09/2016 | 1870 | 96 | 131 | 1 |
