Product 78BD4693-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073146205
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4693-2
Weight (gr.)
11990
R90 Homologation
R90 90R-02C0100/1488
Measures
Ø256x16x64
Brake Disc Type: solid
Minimum thickness [mm]: 13.5
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 118
Wheel Hub Diameter [mm]: 73
Reference applications
Brand OE Reference
ALFA ROMEO 7 568 44
AUVERLAND 424695
CITROËN 4246.N3
CITROËN 75 318 19
CITROËN 75 684 40
CITROËN ZF 0 445 0931
CITROËN ZF 0 756 8501
CITROËN ZF 9 350 0520
FIAT 7 174 011 6
FIAT 7 531 819
FIAT 7 568 440
FIAT 9 350 052 0
PEUGEOT 4246.85
PEUGEOT 4246.93
PEUGEOT 4246.95
PEUGEOT 4246.96
PEUGEOT 4246.B3
PEUGEOT 4246.B4
Maker Cross reference
ATE 24.0116-0105.1
BOSCH 0 986 478 200
BREMBO 08.3069.10
BREMBO 08.3069.14
ROAD HOUSE 6169.00
SANLI SL10268
TRW DF1118
ALFA ROMEO
AR 6 (280_) Bus 04/1985-12/1989
Vehicle Engine Fuel Date CC KW CV Traction
1.9 D (280)

160 D100

 2 04/1985-12/1989 1929 51 69 1
AR 6 (280_) Van 04/1985-12/1989
Vehicle Engine Fuel Date CC KW CV Traction
1.9 D (280)

160 D100

 2 04/1985-12/1989 1929 51 69 1
2.4 D (280)

8144.61.200

 2 04/1985-02/1986 2445 53 72 1
2.4 TD (280)

8144.21.220

 2 09/1986-12/1989 2445 68 92 1
2.5 D (280)

8144.67.220

 2 03/1986-12/1989 2499 55 75 1
AUVERLAND
A3 () Open Off-Road Vehicle 07/1987-12/2011
Vehicle Engine Fuel Date CC KW CV Traction
1.9 D 2 07/1987-07/1996 1905 47 64 2
1.9 D 4WD 2 07/1987-07/1996 1905 47 64 3
CITROËN
C25 (280_, 290_) Bus 07/1981-02/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169 (XM7T)

 1 11/1981-01/1994 1796 50 68 1
1.8 E

169 (XM7T)

 1 07/1987-02/1994 1796 51 69 1
2.0

170C (XN1T)

 1 02/1991-02/1994 1971 62 84 1
2.0 E

170A (XN1T)

170B (XN1T)

 1 09/1981-02/1994 1971 58 79 1
1.9 D

D9B (XUD9A/U)

 2 07/1987-02/1994 1905 51 69 1
1.9 TD

M705

 2 04/1992-02/1994 1930 60 82 1
2.5 D

CRD93L (U25/661)

 2 10/1985-02/1994 2498 54 73 1
2.5 D

CRD93L (U25/661)

 2 11/1981-01/1994 2498 55 75 1
2.5 D 4x4

CRD93L (U25/661)

 2 01/1987-02/1994 2498 54 73 3
C25 (280_, 290_) Van 07/1981-07/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169 (XM7T)

 1 11/1981-01/1994 1796 50 68 1
2.0

170A (XN1T)

170B (XN1T)

 1 11/1981-12/1986 1971 57 78 1
2.0

170C (XN1T)

 1 02/1991-03/1994 1971 62 84 1
2.0 4x4

170C (XN1T)

 1 01/1990-01/1994 1971 62 84 3
2.0 E

170A (XN1T)

170B (XN1T)

 1 09/1981-03/1994 1971 58 79 1
1.9 D 2 01/1988-01/1994 1905 51 69 2
1.9 D 1400

DJY (XUD9A)

 2 01/1988-01/1994 1905 51 69 1
1.9 DT 2 10/1991-01/1994 1929 60 82 2
2.5 D

CRD93L (U25/661)

 2 02/1985-07/1994 2498 54 73 1
2.5 D

CRD93L (U25/661)

 2 11/1981-01/1994 2498 55 75 1
2.5 D 4x4

CRD93L (U25/661)

 2 11/1983-12/1986 2498 55 75 3
C25 (280_, 290_) Platform/Chassis 07/1981-03/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8 1 07/1983-01/1994 1796 50 68 1
1.8 E

169 (XM7T)

 1 07/1987-02/1994 1796 51 69 1
2.0

170A (XN1T)

 1 11/1981-12/1986 1971 57 78 1
2.0

170C (XN1T)

 1 01/1987-03/1994 1971 62 84 1
1.9 2 01/1988-01/1994 1905 51 69 2
1.9 DT

M705

 2 10/1991-01/1994 1929 60 82 1
2.5 D

CRD93L (U25/661)

 2 11/1983-01/1994 2498 55 75 1
FIAT
DUCATO (280_) Van 01/1982-02/1991
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169 B

 1 01/1982-10/1988 1796 49 67 1
1.8

XM7T

 1 07/1982-12/1988 1796 51 69 1
2.0

170 B

 1 07/1985-08/1990 1971 55 75 1
2.0

XN 1T

 1 01/1982-08/1990 1971 58 79 1
2.0

170 D

 1 03/1989-08/1990 1971 62 84 1
1.9 D

149 B1.000

 2 01/1988-08/1990 1929 52 71 1
1.9 TD

280 A1.000

 2 03/1989-08/1990 1929 60 82 1
2.4 D

8144.61

 2 01/1982-08/1990 2445 53 72 1
2.5 D

8140.61

 2 09/1986-05/1990 2445 55 75 1
2.5 D

8144.67

CRD93L (U25-661)

 2 01/1982-08/1990 2500 55 75 1
2.5 D 4x4

8144.67

 2 03/1989-08/1990 2500 55 75 3
2.5 TD 2 09/1986-05/1990 2499 68 92 1
2.5 TD 2 09/1986-05/1990 2499 70 95 2
2.5 TD 4x4

8144.21

 2 09/1986-09/1990 2445 68 92 3
DUCATO (280_) Bus 07/1982-08/1990
Vehicle Engine Fuel Date CC KW CV Traction
1.8

XM7T

 1 07/1982-12/1988 1796 51 69 1
2.0

170 B

 1 01/1986-08/1990 1971 55 75 1
2.0

XN 1T

 1 07/1982-05/1985 1971 58 79 1
2.0

170 D

 1 09/1988-08/1990 1971 62 84 1
1.9 D

149 B1.000

 2 02/1987-08/1990 1929 52 71 1
1.9 TD

280 A1.000

 2 03/1989-08/1990 1929 60 82 1
2.4 D

8144.61

 2 07/1982-12/1985 2445 53 72 1
2.5 D

8144.67

CRD93L (U25-661)

 2 01/1986-08/1990 2500 55 75 1
2.5 D 4x4

8144.67

 2 01/1987-08/1990 2500 55 75 3
2.5 TD

8144.21

8144.21.220

 2 01/1987-08/1990 2445 68 92 1
2.5 TD 4x4

8144.21

 2 01/1986-08/1990 2445 68 92 3
DUCATO (280_) Platform/Chassis 07/1982-08/1990
Vehicle Engine Fuel Date CC KW CV Traction
2.0

170 B

XN 1T

 1 07/1985-08/1990 1971 55 75 1
2.0

170 D

 1 08/1988-08/1990 1971 62 84 1
1.9 D

149 B1.000

 2 01/1988-08/1990 1929 52 71 1
1.9 TD

280 A1.000

 2 03/1989-08/1990 1929 60 82 1
2.5 D

8144.67

CRD93L (U25-661)

 2 07/1982-08/1990 2500 55 75 1
2.5 D 4x4

8144.67

 2 03/1989-08/1990 2500 55 75 3
2.5 TD

8144.21

 2 01/1986-08/1990 2445 68 92 1
2.5 TD 2 09/1986-05/1990 2499 68 92 2
DUCATO (290_) Van 03/1989-05/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

170 D

 1 06/1990-05/1994 1971 63 86 1
1.9 D

149 B1.000

 2 07/1990-03/1994 1929 52 71 1
1.9 TD

280 A1.000

 2 03/1989-03/1994 1929 60 82 1
2.5 D

8144.67

 2 06/1990-05/1994 2499 55 75 1
2.5 D 4x4

8144.67

 2 07/1990-03/1994 2500 55 75 3
DUCATO (290_) Platform/Chassis 03/1989-05/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

170 D

 1 07/1990-03/1994 1971 62 84 1
2.0 4x4

170 D

 1 06/1990-05/1994 1971 63 86 3
1.9 D

149 B1.000

 2 06/1990-05/1994 1929 51 69 1
1.9 TD

280 A1.000

 2 03/1989-03/1994 1929 60 82 1
2.5 D

8144.67

 2 03/1989-03/1994 2500 55 75 1
2.5 D 4x4

8144.67

 2 07/1990-03/1994 2500 55 75 3
DUCATO (290_) Bus 01/1990-05/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

170 D

 1 07/1990-03/1994 1971 62 84 1
2.0 1 06/1990-05/1994 1971 63 86 1
2.0 4x4

170 D

 1 06/1990-05/1994 1971 63 86 3
1.9 D

149 B1.000

 2 07/1990-03/1994 1929 52 71 1
1.9 TD

280 A1.000

 2 07/1990-03/1994 1929 60 82 1
2.5 D

8144.67

 2 07/1990-03/1994 2500 55 75 1
2.5 D 4x4

8144.67

 2 07/1990-03/1994 2500 55 75 3
TALENTO (290_) Van 03/1989-03/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (290U4)

170 B

 1 03/1989-03/1994 1971 55 75 1
1.9 D (290UK)

149 B1.000

 2 03/1989-03/1994 1929 52 71 1
TALENTO (290_) Platform/Chassis 03/1989-03/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (290UA4)

170 B

 1 03/1989-03/1994 1971 55 75 1
1.9 D (290UAK, 290UTK)

149 B1.000

 2 03/1989-03/1994 1929 52 71 1
TALENTO (290_) Bus 03/1989-03/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (290UEH4)

170 B

 1 03/1989-03/1994 1971 55 75 1
1.9 D (290UEHK)

149 B1.000

 2 03/1989-03/1994 1929 52 71 1
PEUGEOT
J5 (280P) Bus 09/1981-09/1990
Vehicle Engine Fuel Date CC KW CV Traction
2.0

170B (XN1T)

 1 09/1981-09/1990 1971 55 75 1
2.0

170 (XN1T)

 1 01/1983-09/1990 1971 58 79 1
2.0 Super 4x4

XN1P

 1 09/1981-08/1990 1971 58 79 3
2.5 D

CRD93 (PSA)

 2 09/1981-09/1990 2498 54 73 1
2.5 DT

CRD93L

 2 01/1986-08/1990 2498 70 95 1
J5 (280L) Platform/Chassis 09/1981-09/1990
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169B (XM7T)

 1 09/1981-08/1990 1796 51 69 1
2.0

170B (XN1T)

 1 01/1986-11/1988 1971 55 75 1
2.0

170 (XN1T)

 1 01/1983-11/1988 1971 58 79 1
1.9 D 2 09/1987-08/1990 1905 51 69 2
2.5 D

CRD93 (PSA)

 2 09/1981-09/1990 2500 54 73 1
2.5 D 4x4

CRD93

 2 09/1981-08/1990 2498 54 73 3
2.5 DT

CRD93L

 2 09/1981-08/1990 2498 70 95 1
2.5 DT 2 09/1981-08/1990 2498 70 95 2
J5 (280L) Van 09/1981-09/1990
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169B (XM7T)

 1 01/1983-11/1988 1796 51 69 1
2.0

XN1T

 1 09/1987-08/1990 1971 55 75 1
2.0

XN1P

 1 09/1981-08/1990 1971 58 79 1
1.9 D

D9B (XUD9A)

XUD9

 2 09/1987-08/1990 1905 51 69 1
2.5 D

CRD93

 2 09/1981-08/1990 2498 54 73 1
2.5 D 2 09/1981-08/1990 2498 54 73 2
2.5 DT

CRD93L

CRD93LS (U25/673)

 2 09/1981-08/1990 2498 70 95 1
2.5 DT A las 4 ruedas

CRD93L

 2 09/1981-08/1990 2498 70 95 3
J5 (290P) Bus 09/1990-02/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

170D (XN1TACP)

 1 10/1990-02/1994 1971 62 84 1
1.9 D

D9B (XUD9A)

 2 10/1990-02/1994 1905 51 70 1
2.5 D

CRD93 (PSA)

 2 10/1990-02/1994 2500 54 73 1
2.5 D 4x4

CRD93 (PSA)

 2 10/1990-02/1994 2500 54 73 3
2.5 TD

CRD93LS (U25/673)

 2 10/1990-02/1994 2498 70 95 1
2.5 TD 4x4

CRD93LS (U25/673)

 2 10/1990-02/1994 2500 70 95 3
J5 (290L) Platform/Chassis 09/1990-02/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8 1 09/1990-01/1994 1796 51 69 1
2.0

170D (XN1TACP)

 1 10/1990-02/1994 1971 62 84 1
2.0

XN1TA

 1 09/1990-01/1994 1971 69 94 1
1.9 D

D9B (XUD9A)

 2 10/1990-02/1994 1905 51 70 1
2.5 D

CRD93 (PSA)

 2 10/1990-02/1994 2500 54 73 1
2.5 D 4x4

CRD93 (PSA)

 2 10/1990-02/1994 2500 54 73 3
2.5 TD

CRD93LS (U25/673)

 2 10/1990-02/1994 2500 70 95 1
2.5 TD 4x4

CRD93LS (U25/673)

 2 10/1990-02/1994 2500 70 95 3
J5 (290L) Van 09/1990-03/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169B (XM7T)

 1 09/1990-01/1994 1796 51 69 1
2.0

170D (XN1TACP)

XN1TA

 1 09/1990-01/1994 1971 62 84 1
2.0 1 09/1990-01/1994 1971 69 94 1
1.9 D

D9B (XUD9A)

 2 10/1990-03/1994 1905 51 70 1
2.5 D

CRD93

 2 09/1990-01/1994 2498 54 73 1
2.5 D 4x4

CRD93 (PSA)

 2 10/1990-03/1994 2500 54 73 3
2.5 DT

CRD93L

 2 09/1990-01/1994 2498 70 95 1
2.5 TD 4x4

CRD93LS (U25/673)

 2 10/1990-03/1994 2500 70 95 3
TALBOT
EXPRESS 1000 -1500 () Bus 07/1982-10/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8

XM7T

 1 07/1983-10/1990 1796 51 69 1
2.0

XN1TA

 1 07/1982-10/1990 1971 57 78 1
1.9 D

XUD9A

 2 07/1987-10/1990 1905 51 69 1
2.5 D

CRD93

 2 07/1982-10/1994 2498 54 73 1
EXPRESS 1000 -1500 () Platform/Chassis 07/1982-10/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

XN1TA

 1 07/1982-10/1994 1971 57 78 1
2.5 D

CRD93

 2 07/1982-10/1994 2498 54 73 1
2.5 D A las 4 ruedas

CRD93

 2 11/1988-10/1994 2498 54 73 3
EXPRESS 1000 -1800 () Van 07/1981-10/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8

XM7T

 1 07/1981-10/1990 1796 51 69 1
2.0

XN1TA

 1 07/1982-10/1990 1971 57 78 1
1.9 D

XUD9A

 2 07/1987-10/1990 1905 51 69 1
2.5 D

CRD93

 2 07/1982-10/1994 2498 54 73 1
2.5 D A las 4 ruedas

CRD93

 2 11/1988-10/1994 2498 54 73 3
