Product 78BD4695-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073146229
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4695-2
Weight (gr.)
15070
Measures
Ø290x16x61
Brake Disc Type: solid
Minimum thickness [mm]: 14.8
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 118
Wheel Hub Diameter [mm]: 73
Reference applications
Brand OE Reference
AUVERLAND 4246A0
CITROËN 75 386 82
CITROËN ZF 9 350 0521
FIAT 7 173 963 8
FIAT 7 538 682
FIAT 9 350 052 1
PEUGEOT 4246.A0
PEUGEOT 4246.H3
TALBOT 075 386 82
Maker Cross reference
ATE 24.0116-0106.1
BENDIX BRAKING-TMD BDS1899
BOSCH 0 986 478 234
BREMBO 08.3136.10
BREMBO 08.3136.14
ROAD HOUSE 6334.00
TRW DF1119
AUVERLAND
A3 () Closed Off-Road Vehicle 07/1987-12/2011
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 10/1991-07/1996 1580 68 92 2
1.9 D 2 07/1987-07/1996 1905 47 64 2
1.9 D 4WD 2 07/1987-07/1996 1905 47 64 3
2.1 D 2 10/1991-07/1996 2138 60 82 2
2.1 D 4WD 2 10/1991-07/1996 2138 60 82 3
CITROËN
C25 (280_, 290_) Bus 07/1981-02/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 D Turbo

CRD93LS (U25/673)

 2 08/1987-02/1994 2500 70 95 1
2.5 D Turbo 4x4

CRD93LS (U25/673)

 2 08/1987-02/1994 2500 70 95 3
C25 (280_, 290_) Platform/Chassis 07/1981-03/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 DT

CRD93LS (U25/673)

 2 01/1987-01/1994 2498 70 95 1
C25 (280_, 290_) Van 07/1981-07/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 D

CRD93L (U25/661)

 2 02/1985-07/1994 2498 54 73 1
2.5 DT

CRD93LS (U25/673)

 2 08/1991-01/1994 2498 70 95 1
2.5 DT 4x4

CRD93LS (U25/673)

 2 08/1991-01/1994 2498 70 95 3
C35 () Bus 11/1973-01/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B20614

 1 11/1973-01/1994 1985 65 88 1
2.2 D

B22615

 2 11/1973-01/1980 2175 45 61 1
2.5 D

B25637

 2 02/1980-01/1994 2498 51 69 1
C35 () Van 11/1973-01/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B20614

 1 11/1973-01/1994 1985 65 88 1
2.2 D

B22615

 2 11/1973-01/1980 2175 45 61 1
2.5 D

B25637

 2 02/1980-01/1994 2498 51 69 1
C35 () Platform/Chassis 11/1973-01/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B20614

 1 11/1973-01/1994 1985 65 88 1
2.2 D

B22615

 2 11/1973-01/1980 2175 45 61 1
2.5 D

B25637

 2 02/1980-01/1994 2498 51 69 1
FIAT
DUCATO (280_) Van 01/1982-02/1991
Vehicle Engine Fuel Date CC KW CV Traction
1.8

XM7T

 1 07/1982-12/1988 1796 51 69 1
2.4 D

8144.61

 2 01/1982-08/1990 2445 53 72 1
2.5 D

8140.61

 2 09/1986-05/1990 2445 55 75 1
2.5 D 4x4

8140.61

 2 09/1986-10/1987 2445 53 72 3
2.5 D 4x4

8140.61

8144.61

 2 09/1986-05/1990 2445 55 75 3
2.5 TD 2 02/1987-02/1991 2445 68 92 1
2.5 TD 2 09/1986-05/1990 2499 68 92 1
DUCATO (280_) Bus 07/1982-08/1990
Vehicle Engine Fuel Date CC KW CV Traction
2.4 D

8144.61

 2 07/1982-12/1985 2445 53 72 1
2.5 D

8140.27

 2 09/1986-05/1990 2499 68 92 1
2.5 D 4x4

8140.27

 2 09/1986-05/1990 2499 68 92 3
DUCATO (280_) Platform/Chassis 07/1982-08/1990
Vehicle Engine Fuel Date CC KW CV Traction
2.5 TD

8140.27

 2 09/1986-05/1990 2499 68 92 1
2.5 TD 4x4

8144.21

 2 01/1986-08/1990 2445 68 92 3
DUCATO (290_) Van 03/1989-05/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 D

8144.67

 2 06/1990-05/1994 2499 55 75 1
2.5 D 4x4

8144.67

 2 07/1990-03/1994 2500 55 75 3
2.5 TD

8140.27

 2 07/1990-03/1994 2500 70 95 1
2.5 TD 4x4

8140.27

 2 07/1990-03/1994 2500 70 95 3
DUCATO (290_) Platform/Chassis 03/1989-05/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 D

8144.67

 2 03/1989-03/1994 2500 55 75 1
2.5 D 4x4

8144.67

 2 07/1990-03/1994 2500 55 75 3
2.5 TD

8140.27

 2 07/1990-03/1994 2500 70 95 1
2.5 TD 4x4

8140.27

 2 07/1990-03/1994 2500 70 95 3
DUCATO (290_) Bus 01/1990-05/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 D

8144.67

 2 07/1990-03/1994 2500 55 75 1
2.5 D 4x4

8144.67

 2 07/1990-03/1994 2500 55 75 3
2.5 TD

8140.27

 2 06/1990-05/1994 2499 70 95 1
2.5 TD 4x4

8140.27

 2 06/1990-05/1994 2499 70 95 3
2.5 TD 4x4

8140.27

 2 01/1991-03/1994 2500 70 95 3
PEUGEOT
J5 (280P) Bus 09/1981-09/1990
Vehicle Engine Fuel Date CC KW CV Traction
2.0

170B (XN1T)

 1 09/1981-09/1990 1971 55 75 1
2.0

170 (XN1T)

 1 01/1983-09/1990 1971 58 79 1
2.0 Super 4x4

XN1P

 1 09/1981-08/1990 1971 58 79 3
2.5 D

CRD93 (PSA)

 2 09/1981-09/1990 2498 54 73 1
2.5 DT

CRD93L

 2 01/1986-08/1990 2498 70 95 1
J5 (280L) Platform/Chassis 09/1981-09/1990
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169B (XM7T)

 1 09/1981-08/1990 1796 51 69 1
2.0

170B (XN1T)

 1 01/1986-11/1988 1971 55 75 1
2.0

170 (XN1T)

 1 01/1983-11/1988 1971 58 79 1
1.9 D 2 09/1987-08/1990 1905 51 69 2
2.5 D

CRD93 (PSA)

 2 09/1981-09/1990 2500 54 73 1
2.5 D 4x4

CRD93

 2 09/1981-08/1990 2498 54 73 3
2.5 DT

CRD93L

 2 09/1981-08/1990 2498 70 95 1
2.5 DT 2 09/1981-08/1990 2498 70 95 2
J5 (280L) Van 09/1981-09/1990
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169B (XM7T)

 1 01/1983-11/1988 1796 51 69 1
2.0

XN1T

 1 09/1987-08/1990 1971 55 75 1
2.0

XN1P

 1 09/1981-08/1990 1971 58 79 1
1.9 D

D9B (XUD9A)

XUD9

 2 09/1987-08/1990 1905 51 69 1
2.5 D

CRD93

 2 09/1981-08/1990 2498 54 73 1
2.5 D 2 09/1981-08/1990 2498 54 73 2
2.5 DT

CRD93L

CRD93LS (U25/673)

 2 09/1981-08/1990 2498 70 95 1
2.5 DT A las 4 ruedas

CRD93L

 2 09/1981-08/1990 2498 70 95 3
J5 (290P) Bus 09/1990-02/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

170D (XN1TACP)

 1 10/1990-02/1994 1971 62 84 1
1.9 D

D9B (XUD9A)

 2 10/1990-02/1994 1905 51 70 1
2.5 D

CRD93 (PSA)

 2 10/1990-02/1994 2500 54 73 1
2.5 D 4x4

CRD93 (PSA)

 2 10/1990-02/1994 2500 54 73 3
2.5 TD

CRD93LS (U25/673)

 2 10/1990-02/1994 2498 70 95 1
2.5 TD 4x4

CRD93LS (U25/673)

 2 10/1990-02/1994 2500 70 95 3
J5 (290L) Platform/Chassis 09/1990-02/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8 1 09/1990-01/1994 1796 51 69 1
2.0

170D (XN1TACP)

 1 10/1990-02/1994 1971 62 84 1
2.0

XN1TA

 1 09/1990-01/1994 1971 69 94 1
1.9 D

D9B (XUD9A)

 2 10/1990-02/1994 1905 51 70 1
2.5 D

CRD93 (PSA)

 2 10/1990-02/1994 2500 54 73 1
2.5 D 4x4

CRD93 (PSA)

 2 10/1990-02/1994 2500 54 73 3
2.5 TD

CRD93LS (U25/673)

 2 10/1990-02/1994 2500 70 95 1
2.5 TD 4x4

CRD93LS (U25/673)

 2 10/1990-02/1994 2500 70 95 3
J5 (290L) Van 09/1990-03/1994
Vehicle Engine Fuel Date CC KW CV Traction
1.8

169B (XM7T)

 1 09/1990-01/1994 1796 51 69 1
2.0

170D (XN1TACP)

XN1TA

 1 09/1990-01/1994 1971 62 84 1
2.0 1 09/1990-01/1994 1971 69 94 1
1.9 D

D9B (XUD9A)

 2 10/1990-03/1994 1905 51 70 1
2.5 D

CRD93

 2 09/1990-01/1994 2498 54 73 1
2.5 D 4x4

CRD93 (PSA)

 2 10/1990-03/1994 2500 54 73 3
2.5 DT

CRD93L

 2 09/1990-01/1994 2498 70 95 1
2.5 TD 4x4

CRD93LS (U25/673)

 2 10/1990-03/1994 2500 70 95 3
TALBOT
EXPRESS 1000 -1500 () Bus 07/1982-10/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 D

CRD93

 2 07/1982-10/1994 2498 54 73 1
2.5 TD

CRD93LS

 2 06/1987-10/1994 2498 70 95 1
EXPRESS 1000 -1500 () Platform/Chassis 07/1982-10/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 D

CRD93

 2 07/1982-10/1994 2498 54 73 1
2.5 D A las 4 ruedas

CRD93

 2 11/1988-10/1994 2498 54 73 3
2.5 TD

CRD93LS

 2 06/1987-10/1994 2498 70 95 1
2.5 TD A las 4 ruedas

CRD93LS

 2 11/1988-10/1994 2498 70 95 3
EXPRESS 1000 -1800 () Van 07/1981-10/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.5 D

CRD93

 2 07/1982-10/1994 2498 54 73 1
2.5 D A las 4 ruedas

CRD93

 2 11/1988-10/1994 2498 54 73 3
2.5 TD

CRD93LS

 2 06/1987-10/1994 2498 70 95 1
2.5 TD A las 4 ruedas

CRD93LS

 2 11/1988-10/1994 2498 70 95 3
