Product 78BD4696-1

Description: Brake disc
Axe: Rear
No. of Pieces: 1
Barcode: 8424073146236
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4696-1
Weight (gr.): 7584

Measures: Ø280x16x82
: Brake Disc Type: solid; Minimum thickness [mm]: 14; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 130; Wheel Hub Diameter [mm]: 79

Reference applications

Brand	OE Reference
CITROËN	4246.Z1
FIAT	4 683 380 7
FIAT	5 174 024 8
FIAT	5 174 927 5
FIAT	5 177 492 74
FIAT	5 177 492 75
FIAT	5 185 641 1
FIAT	7 174 011 7
PEUGEOT	4246.Z3
PEUGEOT	4249.39
PEUGEOT	4249.40
PEUGEOT	4249.K8

Maker	Cross reference
ATE	24.0116-0114.1
ATE	24.0116-0125.1
BOSCH	0 986 479 066
BOSCH	0 986 479 316
BREMBO	08.8094.40
BREMBO	08.8094.60
DELPHI LOCKHEED	BG4099
FERODO	DDF1574
LETEC	LBP012S
ROAD HOUSE	6741.00
SANLI	SL10459
TRW	DF4245
TRW	DF4752

CITROËN

JUMPER II / RELAY (230P) Bus 02/1994-04/2002

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 D	T9A (DJ5)	2	08/1994-04/2002	2446	63	86	1
2.5 D 4x4	T9A (DJ5)	2	08/1996-04/2002	2446	63	86	3

JUMPER II / RELAY (230L) Van 02/1994-08/2002

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	RFW (XU10J2U)	1	03/1994-04/2002	1998	80	109	1
1.9 D	D9B (XUD9A/U)	2	02/1994-04/2002	1905	51	69	1
1.9 TD	D8C (XUD9UTF)	2	03/1994-04/2002	1905	68	92	1
2.0 HDi	RHV (DW10TD)	2	11/2001-04/2002	1997	62	84	1
2.5 D	T9A (DJ5)	2	03/1994-04/2002	2446	63	86	1
2.5 D 4x4	T9A (DJ5)	2	03/2000-04/2002	2446	63	86	3
2.8 HDI	8140.43S	2	09/2000-04/2002	2798	94	128	1
2.8 HDi 4x4	8140.43S	2	09/2000-04/2002	2798	94	128	3

JUMPER II / RELAY (230) Platform/Chassis 03/1994-04/2002

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 D	T9A (DJ5)	2	03/1994-04/2002	2446	63	86	1
2.8 HDI	8140.43S	2	09/2000-04/2002	2798	94	128	1

JUMPER II / RELAY (244) Platform/Chassis 02/2002-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 HDi	RHV (DW10UTD)	2	04/2002-06/2006	1997	62	84	1
2.2 HDi	4HY (DW12UTED)	2	04/2002-06/2006	2179	74	101	1
2.2 HDi	4HY (DW12UTED)	2	02/2002-06/2006	2179	74	101	1
2.8 HDI	8140.43S	2	04/2002-06/2006	2798	94	128	1

JUMPER II / RELAY (244, Z_) Bus 04/2002-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	XU10J2	1	04/2002-06/2006	1998	81	110	1
2.0 bivalent	XU10J2	16	02/2003-06/2006	1998	81	110	1
2.0 HDi	RHV (DW10UTD)	2	04/2002-06/2006	1997	62	84	1
2.2 HDi	4HY (DW12UTED)	2	04/2002-06/2006	2179	74	101	1
2.8 HDI	8140.43S	2	04/2002-06/2006	2798	94	128	1
2.8 HDi A las 4 ruedas	8140.43S	2	04/2002-06/2006	2798	94	128	3

JUMPER II / RELAY (244) Van 04/2002-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	XU10J2	1	04/2002-06/2006	1998	81	110	1
2.0 bivalent	XU10J2	16	02/2003-06/2006	1998	81	110	1
2.0 HDi	RHV (DW10UTD)	2	04/2002-06/2006	1997	62	84	1
2.2 HDi	4HY (DW12UTED)	2	04/2002-06/2006	2179	74	101	1
2.8 HDI	8140.43S	2	04/2002-06/2006	2798	94	128	1
2.8 HDI	8140.43N	2	04/2004-06/2006	2798	107	146	1
2.8 HDi 4x4	8140.43S	2	04/2002-06/2006	2798	94	128	3

JUMPER III / RELAY () Bus 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 BlueHDi 110	AHM (DW10FUE)	2	07/2015-09/2019	1997	81	110	1
2.0 BlueHDi 130	AHN (DW10FUD)	2	07/2015-09/2019	1997	96	130	1
2.0 BlueHDi 160	AHP (DW10FUC)	2	07/2015-09/2019	1997	120	163	1
2.2 HDi 100	4HV (P22DTE)	2	04/2006-	2198	74	101	1
2.2 HDi 110	4HG (P22DTE)	2	07/2011-12/2020	2198	81	110	1
2.2 HDi 120	4HU (P22DTE)	2	04/2006-12/2016	2198	88	120	1
2.2 HDi 130	4HH (P22DTE)	2	07/2011-	2198	96	130	1
2.2 HDi 150	4HJ (P22DTE)	2	07/2011-	2198	110	150	1
3.0 HDi 155	F1CE0481D (F30DT)	2	07/2010-	2999	115	157	1
3.0 HDi 180	F1CE3481E (F30DTE)	2	07/2011-	2999	130	177	1

JUMPER III / RELAY () Van 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 BlueHDi 110	AHM (DW10FUE)	2	11/2015-09/2019	1997	81	110	1
2.0 BlueHDi 130	AHN (DW10FUD)	2	11/2015-09/2019	1997	96	130	1
2.0 BlueHDi 160	AHP (DW10FUC)	2	11/2015-09/2019	1997	120	163	1
2.0 BlueHDi 160 4x4	AHP (DW10FUC)	2	11/2015-09/2019	1997	120	163	3
2.2 HDi 100	4HV (P22DTE)	2	04/2006-12/2012	2198	74	101	1
2.2 HDi 110	4HG (P22DTE)	2	07/2011-12/2020	2198	81	110	1
2.2 HDi 120	4HU (P22DTE)	2	04/2006-12/2016	2198	88	120	1
2.2 HDi 130	4HH (P22DTE)	2	07/2011-	2198	96	130	1
2.2 HDi 150	4HJ (P22DTE)	2	07/2011-	2198	110	150	1
3.0 HDi 145	F30DTE (F1CE3481N)	2	07/2010-12/2013	2999	107	146	1
3.0 HDi 155	F1CE0481D (F30DT)	2	07/2010-12/2015	2999	115	156	1
3.0 HDi 180	F1CE3481E (F30DTE)	2	07/2011-	2999	130	177	1

JUMPER III / RELAY () Platform/Chassis 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 BlueHDi 110	AHM (DW10FUE)	2	11/2015-09/2019	1997	81	110	1
2.0 BlueHDi 130	AHN (DW10FUD)	2	11/2015-09/2019	1997	96	130	1
2.0 BlueHDi 130 4x4	AHN (DW10FUD)	2	11/2015-09/2019	1997	96	130	3
2.0 BlueHDi 160	AHP (DW10FUC)	2	11/2015-09/2019	1997	120	163	1
2.0 BlueHDi 160 4x4	AHP (DW10FUC)	2	11/2015-09/2019	1997	120	163	3
2.2 HDi 100	4HV (P22DTE)	2	04/2006-	2198	74	101	1
2.2 HDi 120	4HU (P22DTE)	2	04/2006-12/2016	2198	88	120	1
2.2 HDi 130	4HH (P22DTE)	2	07/2011-	2198	96	130	1
2.2 HDi 150	4HJ (P22DTE)	2	07/2011-	2198	110	150	1
3.0 HDi 145	F30DTE (F1CE3481N)	2	07/2010-12/2013	2999	107	146	1
3.0 HDi 160	F1CE0481D (F30DT)	2	09/2006-12/2015	2999	116	157	1
3.0 HDi 180	F1CE3481E (F30DTE)	2	07/2011-	2999	130	177	1

FIAT

DUCATO II (230_) Bus 03/1994-05/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 TD 4x4	8140.47	2	06/1994-09/2001	2499	85	116	3
2.5 TDI 4x4	8140.47	2	04/1997-04/2002	2500	85	116	3

DUCATO II (230_) Van 03/1994-05/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.8 JTD 4x4	8140.43S	2	11/2000-04/2002	2798	94	128	3

DUCATO II (244_) Van 12/2001-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	RFL	1	12/2001-07/2006	1998	81	110	1
2.3 JTD	F1AE0481C	2	12/2001-07/2006	2286	81	110	1
2.8 JTD	8140.43S	2	12/2001-12/2011	2798	94	128	1
2.8 JTD 4x4	8140.43S	2	12/2001-07/2006	2798	94	128	3

DUCATO II (244_) Bus 12/2001-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	RFL	1	12/2001-07/2006	1998	81	110	1
2.0 4x4	RFL	1	05/2002-07/2006	1998	81	110	3
2.3 JTD	F1AE0481C	2	12/2001-07/2006	2286	81	110	1
2.8 JTD	8140.43S	2	12/2001-	2798	94	128	1

DUCATO II (244_) Platform/Chassis 12/2001-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 JTD	RHV	2	12/2001-07/2006	1997	62	84	1
2.3 JTD	F1AE0481C	2	12/2001-07/2006	2286	81	110	1
2.8 JTD	8140.43S	2	12/2001-07/2006	2798	94	128	1
2.8 JTD 4x4	8140.43S	2	12/2001-07/2006	2798	94	128	3

DUCATO III (250_) Bus 07/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
100 Multijet 2,2 D	4HV	2	07/2006-05/2011	2198	74	100	1
110 Multijet 2,3 D	F1AE3481G	2	10/2011-	2287	83	113	1
120 Multijet 2,3 D	F1AE0481D	2	07/2006-	2287	88	120	1
130 Multijet 2,3 D		2	01/2010-	2287	93	126	1
130 Multijet 2,3 D	F1AE0481N F1AE3481D F1AGL411D	2	01/2007-	2287	96	131	1
140 Multijet 2,2 D		2	07/2021-	2184	103	140	1
150 Multijet 2,3 D	F1AGL411A F1AGL411C	2	04/2015-	2287	110	150	1
150 Multijet 3,0 D	F1CE3481N	2	04/2010-	2999	107	146	1
160 Multijet 3,0 D	F1CE0481D	2	10/2006-	2999	115	156	1
160 Multijet 3,0 D	F1CE0481D F1CE3481M	2	07/2006-	2999	116	158	1
180 Multijet 2,3 D		2	12/2015-	2287	130	177	1

DUCATO III (250_) Platform/Chassis 07/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
100 Multijet 2,2 D	4HV	2	07/2006-	2198	74	100	1
110 Multijet 2,3 D	F1AE3481G	2	10/2011-	2287	83	113	1
120 Multijet 2,2 D		2	09/2021-	2184	88	120	1
120 Multijet 2,3 D	F1AE0481D F1AGL4114	2	07/2006-	2287	88	120	1
120 Multijet 2,3 D 4x4	F1AE0481D	2	03/2010-	2287	88	120	3
130 Multijet 2,3 D		2	08/2006-	2287	93	126	1
140 Multijet 2,2 D		2	09/2021-	2184	103	140	1
150 Multijet 2,3 D	F1AGL411C	2	12/2015-	2287	110	150	1
150 Multijet 3,0 D	F1CE3481N	2	04/2010-	2999	107	146	1
160 Multijet 2,2 D		2	09/2021-10/2023	2184	118	160	1
160 Multijet 3,0 D	F1CE0481D	2	07/2006-	2999	116	158	1
180 Multijet 2,2 D		2	09/2021-	2184	132	179	1
180 Multijet 2,3 D	F1AGL4111 F1AGL411B	2	12/2015-	2287	130	177	1
140 Natural Power	F1CE0441A F1CFA401A	8	04/2009-	2999	100	136	1

DUCATO III (250_) Van 07/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
100 Multijet 2,2 D	4HV	2	07/2006-	2198	74	100	1
110 Multijet 2,3 D	F1AE3481G	2	10/2011-	2287	83	113	1
120 Multijet 2,2 D		2	07/2021-	2184	88	120	1
120 Multijet 2,3 D	F1AE0481D F1AGL4114	2	07/2006-	2287	88	120	1
120 Multijet 2,3 D 4x4	F1AE0481D	2	03/2010-	2287	88	120	3
130 Multijet 2,3 D		2	08/2006-12/2018	2287	93	126	1
140 Multijet 2,2 D		2	07/2021-	2184	103	140	1
150 Multijet 2,3 D	F1AGL411A F1AGL411C	2	12/2015-	2287	110	150	1
160 Multijet 2,2 D		2	07/2021-10/2023	2184	118	160	1
160 Multijet 3,0 D	F1CE0481D	2	07/2006-	2999	116	158	1
180 Multijet 2,2 D		2	07/2021-	2184	132	179	1
180 Multijet 2,3 D	F1AGL4111 F1AGL411B	2	12/2015-	2287	130	177	1

OPEL

MOVANO C (U9) Van 12/2021-

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.2 D	2	12/2021-10/2023	2179	88	120	1
2.2 D	2	12/2021-10/2023	2179	103	140	1
2.2 D	2	12/2021-10/2023	2179	121	165	1

MOVANO C (U9) Platform/Chassis 12/2021-

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.2 D	2	12/2021-10/2023	2179	88	120	1
2.2 D	2	12/2021-10/2023	2179	103	140	1
2.2 D	2	12/2021-10/2023	2179	121	165	1

PEUGEOT

BOXER II (ZCT_) Platform/Chassis 03/1994-04/2002

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	RFL (XU10J2U)	1	12/2001-04/2002	1998	81	110	1

BOXER II (244) Platform/Chassis 12/2001-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 HDi	RHV (DW10TD) RHV (DW10UTD)	2	12/2001-06/2006	1997	62	84	1
2.2 HDi	4HY (DW12UTED)	2	12/2001-06/2006	2179	74	101	1
2.8 HDI	8140.43S (F28DTCR)	2	12/2001-06/2006	2798	94	128	1
2.8 HDI	8140.43N	2	04/2004-06/2006	2798	107	146	1
2.8 HDi 4x4	8140.43S (F28DTCR)	2	12/2001-06/2006	2798	94	128	3

BOXER II (244) Van 12/2001-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	RFL (XU10J2U)	1	12/2001-06/2006	1998	81	110	1
2.8 HDI	8140.43S (F28DTCR)	2	12/2001-06/2006	2798	94	128	1
2.8 HDI	8140.43N	2	04/2004-06/2006	2798	107	146	1

BOXER II (244, Z_) Bus 12/2001-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.8 HDI	8140.43N	2	04/2004-06/2006	2798	107	145	1
2.8 HDi 4x4	8140.43S (F28DTCR)	2	12/2001-06/2006	2798	94	128	3

BOXER III / MANAGER () Bus 09/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 BlueHDi 110	AHM (DW10FUE)	2	07/2015-09/2019	1997	81	110	1
2.0 BlueHDi 130	AHN (DW10FUD)	2	07/2015-09/2019	1997	96	130	1
2.0 BlueHDi 160	AHP (DW10FUC)	2	07/2015-09/2019	1997	120	163	1
2.2 HDi 100	4HV (P22DTE)	2	04/2006-	2198	74	101	1
2.2 HDi 120	4HU (P22DTE)	2	04/2006-12/2016	2198	88	120	1
2.2 HDi 150	4HJ (P22DTE)	2	03/2011-	2198	110	150	1
2.8 HDI		2	09/2005-09/2009	2798	93	127	1
3.0 HDi 145	F1CE3481N (F30DTE)	2	04/2010-12/2013	2999	107	146	1
3.0 HDi 160	F1CE0481D (F30DT)	2	04/2006-12/2015	2999	115	156	1

BOXER III / MANAGER () Van 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 BlueHDi 110	AHM (DW10FUE)	2	07/2015-09/2019	1997	81	110	1
2.0 BlueHDi 130	AHN (DW10FUD)	2	07/2015-	1997	96	130	1
2.0 BlueHDi 160	AHP (DW10FUC)	2	07/2015-12/2023	1997	120	163	1
2.2 HDi 100	4HV (P22DTE)	2	04/2006-	2198	74	101	1
2.2 HDi 110	4HG (P22DTE)	2	03/2011-12/2020	2198	81	110	1
2.2 HDi 120	4HU (P22DTE)	2	04/2006-12/2016	2198	88	120	1
2.2 HDi 130	4HH (P22DTE)	2	03/2011-	2198	96	131	1
2.2 HDi 150	4HJ (P22DTE)	2	03/2011-	2198	110	150	1
3.0 HDi 145	F1CE3481N (F30DTE)	2	04/2010-12/2013	2999	107	146	1
3.0 HDi 155	F1CE0481D (F30DT)	2	07/2006-12/2015	2999	115	156	1
3.0 HDi 175	F1CE3481E (F30DTE)	2	03/2011-	2999	130	177	1

BOXER III / MANAGER () Platform/Chassis 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 BlueHDi 110	AHM (DW10FUE)	2	07/2015-09/2019	1997	81	110	1
2.0 BlueHDi 130	AHN (DW10FUD)	2	07/2015-09/2019	1997	96	130	1
2.0 BlueHDi 160	AHP (DW10FUC)	2	07/2015-12/2023	1997	120	163	1
2.2 HDi 100	4HV (P22DTE)	2	04/2006-	2198	74	101	1
2.2 HDi 110	4HG (P22DTE)	2	03/2011-12/2020	2198	81	110	1
2.2 HDi 120	4HU (P22DTE)	2	04/2006-12/2016	2198	88	120	1
2.2 HDi 130	4HH (P22DTE)	2	03/2011-	2198	96	131	1
2.2 HDi 130		2	03/2011-	2198	96	130	3
2.2 HDi 150	4HJ (P22DTE)	2	03/2011-	2198	110	150	1
2.2 HDi 150		2	03/2011-	2198	110	150	3
3.0 HDi 145	F1CE3481N (F30DTE)	2	04/2010-12/2013	2999	107	146	1
3.0 HDi 155	F1CE0481D (F30DT)	2	04/2006-12/2015	2999	115	156	1
3.0 HDi 160	F1CE0481D (F30DT)	2	04/2006-12/2015	2999	116	156	1
3.0 HDi 175	F1CE3481E (F30DTE)	2	03/2011-	2999	130	177	1

VAUXHALL

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.2 D	2	12/2022-10/2023	2179	88	120	1
2.2 D	2	12/2021-10/2023	2179	103	140	1
2.2 D	2	12/2021-10/2023	2179	121	165	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 D		2	12/2021-10/2023	2179	103	140	1
2.2 D		2	12/2022-10/2023	2179	121	165	1

Return

CITROËN

JUMPER II / RELAY (230P) Bus 02/1994-04/2002

JUMPER II / RELAY (230L) Van 02/1994-08/2002

JUMPER II / RELAY (230) Platform/Chassis 03/1994-04/2002

JUMPER II / RELAY (244) Platform/Chassis 02/2002-

JUMPER II / RELAY (244, Z_) Bus 04/2002-

JUMPER II / RELAY (244) Van 04/2002-

JUMPER III / RELAY () Bus 04/2006-

JUMPER III / RELAY () Van 04/2006-

JUMPER III / RELAY () Platform/Chassis 04/2006-

FIAT

DUCATO II (230_) Bus 03/1994-05/2005

DUCATO II (230_) Van 03/1994-05/2005

DUCATO II (244_) Van 12/2001-

DUCATO II (244_) Bus 12/2001-

DUCATO II (244_) Platform/Chassis 12/2001-

DUCATO III (250_) Bus 07/2006-

DUCATO III (250_) Platform/Chassis 07/2006-

DUCATO III (250_) Van 07/2006-

OPEL

MOVANO C (U9) Van 12/2021-

MOVANO C (U9) Platform/Chassis 12/2021-

PEUGEOT

BOXER II (ZCT_) Platform/Chassis 03/1994-04/2002

BOXER II (244) Platform/Chassis 12/2001-

BOXER II (244) Van 12/2001-

BOXER II (244, Z_) Bus 12/2001-

BOXER III / MANAGER () Bus 09/2005-

BOXER III / MANAGER () Van 04/2006-

BOXER III / MANAGER () Platform/Chassis 04/2006-

VAUXHALL

MOVANO Mk III © (U9) Van 12/2021-

MOVANO Mk III © (U9) Platform/Chassis 12/2021-
