Product 78BD4702-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073146281
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4702-2
Weight (gr.): 14950

R90 Homologation: 90R-02C0074/0630
Measures: Ø293x24x57
: Brake Disc Type: Vented; Minimum thickness [mm]: 22; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 100; Wheel Hub Diameter [mm]: 58

Reference applications

Brand	OE Reference
SAAB	32006171
SUBARU	23610AC040
SUBARU	26300 SA001
SUBARU	26300AE02A
SUBARU	26300AE02C
SUBARU	26300AE061
SUBARU	26300AG01A
SUBARU	26300FE010
SUBARU	26300FE011
SUBARU	26300FE040
SUBARU	26300SA000
TOYOTA	SU00300586

Maker	Cross reference
ATE	24.0124-0196.1
BOSCH	0 986 478 977
LETEC	LBS001V
SANLI	SL33292
TEXTAR	92139500
TRW	DF4104

SCION

FR (U.S.A.) Coupe 09/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 S		1	09/2012-	1998	149	203	2

SUBARU

BAJA (U.S.A.) Pickup 09/2002-12/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 AWD		1	09/2002-12/2006	2458	123	167	3

BRZ (ZC6) Coupe 06/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 (ZC6)	FA20D	1	06/2012-	1998	147	200	2
2.0 (ZC6)		1	08/2016-	1998	152	207	2

FORESTER (SF_) SUV 03/1997-09/2002

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 S Turbo AWD (SF5)	EJ205	1	06/1998-04/2001	1994	125	170	3
2.0 S Turbo AWD (SF5)	EJ205	1	04/2001-09/2002	1994	130	177	3

FORESTER II (SG_, S11SG) SUV 02/2002-12/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 AWD	EJ253	1	01/2005-10/2012	2457	129	175	3
2.5 AWD	EJ255	1	01/2004-12/2009	2457	171	232	3
2.5 AWD (SG9, S11SG, S12SH)	EJ255	1	06/2005-05/2008	2457	169	230	3
2.5 AWD (SG9)		1	06/2002-05/2005	2457	112	152	3
2.5 AWD (SG9)	EJ25D	1	06/2005-05/2008	2457	121	165	3
2.5 AWD (SG9)	EJ25	1	12/2003-05/2005	2457	155	211	3
2.5 Prodrive Performance Pack AWD	EJ255	1	05/2005-09/2005	2457	188	256	3

FORESTER III (SH_) SUV 12/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 AWD	EJ204	1	10/2010-12/2014	1994	118	160	3
2.0 AWD (SHJ)	FB20	1	01/2010-	1995	110	150	3
2.5 AWD (SH9)	EJ25	1	01/2009-09/2013	2457	126	171	3
2.5 AWD (SHM)	FB25	1	03/2011-09/2013	2498	126	171	3
2.5 Turbo AWD (SH9)	EJ255	1	02/2011-09/2013	2457	193	262	3
2.0 BiFuel AWD	EJ204	18	01/2009-12/2011	1994	110	150	3
2.0 D AWD (SHH, SHD, SHN)	EE20Z	2	09/2008-09/2013	1998	108	147	3

FORESTER IV (SJ_) SUV 11/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 i AWD (SJ5)	FB20	1	03/2013-	1995	110	150	3
2.5 AWD (SJ9)	FB25	1	11/2012-	2498	126	171	3
2.0 BiFuel AWD (S13, SJ5)	FB20B	18	03/2013-	1995	110	150	3

IMPREZA (GC) Saloon 08/1992-09/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 AWD (GC8, GM8)	EJ205P	1	09/1996-09/2000	1994	206	280	3
2.0 Turbo GT AWD (GC8)	EJ205	1	06/1998-12/2000	1994	160	218	3
2.0 WRX STi AWD (GC8)	EJ20G	1	10/1993-10/1994	1994	184	250	3

IMPREZA (GF) Estate 08/1992-12/2000

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 Turbo GT AWD (GF8)	EJ205	1	06/1998-12/2000	1994	160	218	3

IMPREZA (GFC) Coupe 01/1993-12/2000

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 AWD (GC8, GM8)		1	09/1998-09/2000	1994	206	280	3

IMPREZA II (GD) Saloon 09/1999-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 AWD (GDA)	EJ20 (TURBO)	1	10/2005-03/2007	1994	184	250	3
2.0 WRX STi AWD (GDB)	EJ207	1	11/2001-07/2005	1994	195	265	3
2.0 WRX Turbo AWD (GDA)	EJ205	1	12/2000-12/2005	1994	160	218	3
2.0 WRX Turbo AWD (GDA)	EJ205	1	12/2002-03/2007	1994	165	225	3
2.5 WRX STi AWD (GDF)	EJ257	1	09/2005-12/2007	2457	206	280	3

IMPREZA II () Hatchback 10/2000-12/2007

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 WRX AWD		1	09/2005-12/2007	2457	169	230	3

IMPREZA II (GG) Estate 10/2000-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 Turbo AWD (GGA)	EJ205	1	12/2000-12/2005	1994	160	218	3
2.0 WRX Turbo AWD (GGA)	EJ205	1	12/2002-09/2006	1994	165	225	3
2.5 GB270 AWD	EJ255	1	07/2007-12/2007	2457	198	269	3

IMPREZA III (GE, GV) Saloon 01/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 AWD	EJ25	1	08/2008-10/2010	2457	121	165	3
2.5 AWD	EJ255	1	10/2008-	2457	169	230	3
2.5 AWD	EJ255 EJ257	1	07/2007-	2457	199	270	3
2.5 AWD	EJ255	1	01/2007-12/2007	2457	200	272	3
2.5 WRX SE AWD (GVE, GEE)	EJ255	1	01/2009-12/2014	2457	195	265	3

IMPREZA III (GR, GH, G3) Hatchback 03/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 AWD (GHE)	EJ255	1	01/2008-09/2011	2457	169	230	3
2.5 WRX S AWD	EJ255	1	02/2009-12/2010	2457	188	255	3
2.5 WRX SE AWD (GRE)	EJ255	1	07/2010-08/2013	2457	195	265	3
2.5 WRX STI 330S AWD	EJ257	1	05/2009-12/2010	2457	243	330	3
2.0 D AWD	EE20Z	2	01/2009-03/2012	1998	110	150	3

IMPREZA IV / WRX (GJ_) Saloon 07/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 AWD (GJ3)	FB16	1	01/2015-	1599	85	115	3
1.6 AWD (GJ3)	FB16A FB16B	1	06/2012-09/2016	1600	84	114	3

IMPREZA IV / WRX (GP_) Hatchback 10/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 AWD (GP7)	FB20	1	01/2012-	1995	110	150	3
2.0 Hybrid AWD (GPE)		13	04/2016-09/2016	1995	110	150	3

LEGACY III / LIBERTY (BE) Saloon 10/1998-08/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.0 H6 AWD (BEE)		1	08/2000-08/2003	3000	154	209	3

LEGACY IV / LIBERTY (BP) Estate 09/2003-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 D AWD (BPD)	EE20Z	2	02/2008-12/2009	1998	110	150	3

LEGACY IV / LIBERTY (BL) Saloon 09/2003-12/2015

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 2WD	EJ20Y	1	08/2005-03/2012	1994	132	179	2
2.0 D AWD (BLD)	EE20Z	2	02/2008-12/2009	1998	110	150	3

LEGACY V / LIBERTY (BR) Estate 06/2008-12/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 i AWD (BR9)	EJ253	1	09/2009-12/2014	2457	123	167	3
2.5 i AWD (BR9)	EJ25	1	05/2009-12/2014	2457	125	170	3
2.5 i AWD (BRM)	FB25	1	07/2012-12/2014	2498	127	173	3
2.5 CNG AWD	FB25B	16	04/2013-12/2014	2498	127	173	3
2.0 D AWD	EE20 EE20Z	2	01/2013-12/2014	1998	108	147	3
2.0 D AWD (BRD)	EE20Z	2	09/2009-12/2014	1998	110	150	3

LEGACY V / LIBERTY (BM) Saloon 05/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 D AWD (BMD)	EE20Z	2	09/2009-12/2014	1998	110	150	3

OUTBACK / LIBERTY OUTBACK (BH) Estate 10/1998-08/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.0 H6 AWD (BHE)	EZ30	1	10/2000-08/2003	3000	154	209	3

OUTBACK III (BP) Estate 09/2003-06/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5		1	01/2005-12/2009	2457	186	253	1
2.5 AWD (BP9)	EJ251	1	09/2008-09/2009	2457	127	173	3
2.5 AWD (BP9)		1	09/2003-09/2009	2458	123	167	3
2.5 BiFuel AWD		18	09/2008-06/2009	2457	127	173	3
2.0 D AWD (BPD)	EE20Z	2	09/2008-09/2009	1998	110	150	3

OUTBACK IV (BR) Estate 06/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 i		1	01/2012-	2457	127	173	1
2.5 i AWD	EJ25	1	05/2009-12/2014	2457	125	170	3
2.5 i AWD	EJ253	1	01/2012-12/2014	2457	129	175	3
2.5 i AWD (BR9)	EJ253	1	09/2009-	2457	123	167	3
2.5 i AWD (BRM)	FB25	1	01/2013-	2498	125	170	3
2.5 i AWD (BRM)	FB25B	1	01/2013-	2498	127	173	3
3.6 AWD	EZ36D	1	06/2011-12/2014	3630	183	249	3
2.5 CNG AWD	FB25B	16	06/2014-12/2014	2498	127	173	3
2.5 BiFuel AWD	EJ253	18	01/2010-12/2014	2457	123	167	3
2.5 BiFuel AWD	FB25B	18	01/2013-12/2014	2498	127	173	3
2.0 D AWD		2	01/2013-	1998	108	147	3
2.0 D AWD (BRD)	EE20Z	2	09/2009-	1998	110	150	3

XV CROSSTREK (_GP_) SUV 09/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 i AWD (GP3, G33GP)	FB16A FB16B	1	03/2012-12/2017	1600	84	114	3
2.0 i AWD (GP7, G33GP)	FB20B	1	03/2012-12/2017	1995	110	150	3
2.0 Hybrid AWD (GPE)	FB20	13	01/2014-12/2017	1995	110	150	3
1.6 BiFuel AWD (G33GP, GP3)	FB16B	18	03/2012-12/2017	1600	84	114	3
2.0 BiFuel AWD (G33GP, GP7)	FB20B	18	03/2012-12/2017	1995	110	150	3
2.0 D AWD	EE20Z	2	03/2012-12/2017	1998	80	109	3
2.0 D AWD (GPD)	EE20Z	2	03/2012-12/2017	1998	108	147	3

TOYOTA

(ZN8) Coupe 09/2021-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 (ZN8)		1	05/2022-	2387	174	237	2
2.4 (ZN8BKE8)		1	04/2022-	2387	172	234	2

GT 86 / 86 / TOYOTA 86 (ZN6_) Coupe 03/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 (ZN6)	FA20D	1	10/2012-	1998	149	203	2
2.0 (ZN6AC_, ZN6BC_, ZN6K)	4U-GSE FA20 FA20D	1	03/2012-	1998	147	200	2
