Product 78BD4744-1 - Web Catalogo

Product 78BD4744-1

Description: Brake disc
Axe: Rear
No. of Pieces: 1
Barcode: 8424073146328
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4744-1
Weight (gr.): 5220

R90 Homologation: 90R-02C0559/0102
Measures: Ø249x9x67
: Brake Disc Type: solid; Minimum thickness [mm]: 7; Hole Arrangement/Number: 4; Bolt Hole Circle Ø [mm]: 108; Wheel Hub Diameter [mm]: 56

Reference applications

Brand	OE Reference
PEUGEOT	4246.Z9
PEUGEOT	4249.34
PEUGEOT	96 435 738 80

Maker	Cross reference
ATE	24.0109-0149.1
ATE	24.0109-0150.2
BENDIX ANTIGUO	562373B
BREMBO	08.9512.17
DELPHI LOCKHEED	BG3962
FERODO	DDF1523
FERODO	DDF1561
GIRLING	6044526
HELLA-PAGID	54333
LETEC	LBC026S
MINTEX	MDC1763
MINTEX	MDC1860
NECTO	WN1449
ROAD HOUSE	61014.00
ROAD HOUSE	61014.20
SANLI	SL28199
TEXTAR	92133300
TEXTAR	92133303
TEXTAR	98200 1333 0 1
TRW	DF4452BS
VALEO	186899
VALEO	675405

CITROËN

C4 (LC_) Hatchback 11/2004-12/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	KFU (ET3J4)	1	11/2004-07/2011	1360	65	88	1
1.6 16V	NFU (TU5JP4)	1	11/2004-07/2011	1587	80	109	1
2.0 16V	RFN (EW10J4)	1	11/2004-07/2007	1997	100	136	1
2.0 16V	RFJ (EW10A)	1	11/2004-07/2011	1997	103	140	1
2.0 16V	RFJ (EW10A)	1	09/2006-07/2009	1997	105	143	1
2.0 16V	RFK (EW10J4S)	1	11/2004-07/2008	1997	130	177	1
1.6 HDi	9HX (DV6ATED4)	2	11/2004-07/2011	1560	66	90	1
1.6 HDi	9HY (DV6TED4) 9HZ (DV6TED4)	2	11/2004-07/2011	1560	80	109	1
1.6 HDi		2	07/2006-07/2011	1560	85	116	1
2.0 HDi	RHZ (DW10ATED)	2	04/2007-07/2008	1997	81	110	1
2.0 HDi	RHR (DW10BTED4)	2	11/2004-07/2011	1997	100	136	1

C4 (LA_) Coupe 11/2004-12/2013

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	KFU (ET3J4)	1	11/2004-07/2011	1360	65	88	1
1.6 16V	NFU (TU5JP4)	1	11/2004-07/2011	1587	80	109	1
1.6 THP	5FT (EP6DT)	1	06/2008-07/2011	1598	103	140	1
2.0 16V	RFN (EW10J4)	1	11/2004-07/2007	1997	100	136	1
2.0 16V	RFK (EW10J4S)	1	11/2004-12/2010	1997	130	177	1
2.0 VTR	RFJ (EW10A)	1	10/2006-12/2007	1997	103	140	1
1.6 HDi	9HX (DV6ATED4)	2	11/2004-07/2011	1560	66	90	1
1.6 HDi	9HY (DV6TED4) 9HZ (DV6TED4)	2	11/2004-07/2011	1560	80	109	1
2.0 HDi	RHR (DW10BTED4)	2	11/2004-12/2010	1997	100	136	1

C4 (LR_) Hatchback Van 02/2005-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 HDi	RHR (DW10BTED4)	2	02/2005-12/2010	1997	100	136	1

C4 / C4 PALLAS () Saloon 07/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6		1	03/2011-11/2014	1587	81	110	1
1.6 16V	NFU (TU5JP4)	1	07/2006-07/2011	1587	80	109	1
2.0 16V		1	06/2007-11/2014	1997	101	138	1
2.0 16V	RFJ (EW10A)	1	07/2006-07/2011	1997	103	140	1
2.0 Exclusive 16V	RFJ (EW10A)	1	07/2007-11/2014	1997	105	143	1
1.6 HDi	9HY (DV6TED4) 9HZ (DV6TED4)	2	07/2006-07/2011	1560	80	109	1
1.6 HDi		2	07/2006-08/2013	1560	85	116	1

PEUGEOT

307 (3A/C) Hatchback 08/2000-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	KFW (TU3JP)	1	08/2000-09/2003	1360	55	75	1
1.4 16V	KFU (ET3J4)	1	11/2003-07/2007	1360	65	88	1
1.6 16V	NFU (TU5JP4)	1	08/2000-11/2007	1587	80	109	1
2.0 16V	RFN (EW10J4)	1	08/2000-06/2005	1997	100	136	1
2.0 16V	RFJ (EW10A)	1	03/2005-11/2007	1997	103	140	1
2.0 16V	RFK (EW10J4S)	1	06/2005-11/2007	1997	130	177	1
1.4 HDi	8HX (DV4TD) 8HZ (DV4TD)	2	10/2001-06/2005	1398	50	68	1
1.6 HDi	9HV (DV6TED4B) 9HV (DV6TED4BU) 9HX (DV6ATED4)	2	04/2005-03/2009	1560	66	90	1
1.6 HDi 110	9HY (DV6TED4) 9HZ (DV6TED4)	2	02/2004-03/2009	1560	80	109	1
2.0 HDI 110	RHS (DW10ATED)	2	08/2000-03/2007	1997	79	107	1
2.0 HDi 135	RHR (DW10BTED4)	2	10/2003-11/2007	1997	100	136	1
2.0 HDI 90	RHY (DW10TD)	2	08/2000-03/2007	1997	66	90	1

307 (3E) Estate 03/2002-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	KFU (ET3J4)	1	11/2003-07/2007	1360	65	88	1
1.6 16V	NFU (TU5JP4)	1	03/2002-04/2008	1587	80	109	1
2.0	RFN (EW10J4)	1	03/2002-06/2005	1997	100	136	1
2.0 16V	RFJ (EW10A)	1	03/2005-04/2008	1997	103	140	1
2.0 16V	RFK (EW10J4S)	1	06/2005-04/2008	1997	130	177	1
1.4 HDi	8HZ (DV4TD)	2	03/2002-06/2005	1398	50	68	1
1.6 HDi	9HV (DV6TED4B) 9HV (DV6TED4BU) 9HX (DV6ATED4) 9HX (DV6AUTED4)	2	04/2005-04/2008	1560	66	90	1
1.6 HDi 110	9HY (DV6TED4) 9HZ (DV6TED4)	2	02/2004-04/2008	1560	80	109	1
2.0 HDI 110	RHS (DW10ATED)	2	03/2002-12/2009	1997	79	107	1
2.0 HDi 135	RHR (DW10BTED4)	2	02/2004-04/2008	1997	100	136	1
2.0 HDI 90	RHY (DW10TD)	2	03/2002-04/2008	1997	66	90	1

307 SW (3H) Estate 03/2002-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	KFU (ET3J4)	1	11/2003-07/2007	1360	65	88	1
1.6 16V	NFU (TU5JP4)	1	03/2002-04/2008	1587	80	109	1
2.0 16V	RFN (EW10J4)	1	03/2002-06/2005	1997	100	136	1
2.0 16V	RFJ (EW10A)	1	03/2005-04/2008	1997	103	140	1
1.4 HDi		2	04/2002-06/2005	1398	51	69	2
1.4 HDi 70		2	03/2002-06/2005	1398	50	68	1
1.6 HDi 110	9HY (DV6TED4) 9HZ (DV6TED4)	2	11/2003-12/2007	1560	80	109	1
2.0 HDI 110	RHS (DW10ATED)	2	03/2002-12/2009	1997	79	107	1
2.0 HDi 135	RHR (DW10BTED4)	2	02/2004-04/2008	1997	100	136	1
2.0 HDI 90	RHY (DW10TD)	2	03/2002-04/2008	1997	66	90	1

307 SW (3E_, 3H_) Estate Van 04/2002-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 HDi	8HZ (DV4TD)	2	04/2002-06/2005	1398	51	69	1

307 (3B) Convertible 03/2003-06/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V	NFU (TU5JP4)	1	03/2003-04/2009	1587	80	110	1
2.0 16V	RFN (EW10J4)	1	10/2003-06/2005	1997	100	136	1
2.0 16V	RFJ (EW10A)	1	12/2004-04/2009	1997	103	140	1
2.0 16V	RFK (EW10J4S)	1	10/2003-04/2009	1997	130	177	1
2.0 HDi 135	RHR (DW10BTED4)	2	06/2005-04/2009	1997	100	136	1
