Product 78BD4801-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073146427
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD4801-2
- Weight (gr.)
- 9000
- R90 Homologation
-
90R-02C0074/0506
- Measures
- Ø246x20x50
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
18 -
Hole Arrangement/Number:
4 -
Bolt Hole Circle Ø [mm]:
100 -
Wheel Hub Diameter [mm]:
60
| Brand | OE Reference |
|---|---|
| SUZUKI | 55311-62G00 |
| SUZUKI | 55311-62G01 |
| SUZUKI | 55311-62G02 |
| SUZUKI | 55311-62G03 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0120-0197.1 |
| ATE | 420197 |
| BENDIX ANTIGUO | 562179B |
| BENDIX BRAKING-TMD | BDS1951 |
| BOSCH | 0 986 478 841 |
| BREMBO | 09.9350.10 |
| DELPHI LOCKHEED | BG3341 |
| FERODO | DDF1396 |
| GIRLING | 6044351 |
| HELLA-PAGID | 8DD 355 107-391 |
| MINTEX | MDC1457 |
| NECTO | WN1358 |
| ROAD HOUSE | 6950.10 |
| SANLI | SL38015 |
| TEXTAR | 92104500 |
| TEXTAR | 92104503 |
| TRW | DF4435 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 GTX (SY418) |
J18A |
1 | 03/1996-05/2002 | 1839 | 89 | 121 | 1 |
| 1.8 i 4x4 (SY418) | 1 | 03/1996-05/2002 | 1839 | 89 | 121 | 3 | |
| 1.9 TD (SY419) |
DHW (XUD9SD) |
2 | 04/1998-05/2002 | 1905 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 GTX (SY418) |
J18A |
1 | 03/1996-05/2002 | 1839 | 89 | 121 | 1 |
| 1.8 i 4x4 (SY418) | 1 | 03/1996-05/2002 | 1839 | 89 | 121 | 3 | |
| 1.9 TD (SY419) |
DHV (XUD9BSD) DHW (XUD9SD) |
2 | 04/1998-05/2002 | 1905 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 i 16V (SY416) |
G16B |
1 | 08/1996-05/2002 | 1590 | 73 | 99 | 1 |
| 1.8 i 16V (SY418) |
J18A |
1 | 08/1996-05/2002 | 1839 | 89 | 121 | 1 |
| 1.8 i 16V 4x4 (SY418) | 1 | 08/1996-05/2002 | 1839 | 89 | 121 | 3 | |
| 1.9 TD (SY419) |
DHV (XUD9BSD) DHW (XUD9SD) |
2 | 04/1998-05/2002 | 1905 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.3 |
M13A |
1 | 07/2001-12/2007 | 1328 | 66 | 90 | 1 |
| 1.5 (RH415) | 1 | 04/2004-11/2007 | 1490 | 81 | 110 | 1 | |
| 1.6 |
M16A |
1 | 01/2005-08/2007 | 1586 | 79 | 107 | 1 |
| 1.6 (RH416) |
M16A |
1 | 07/2001-12/2007 | 1586 | 76 | 103 | 1 |
| 1.6 4WD |
M16A |
1 | 07/2001-12/2007 | 1586 | 76 | 103 | 3 |
| 1.6 4WD |
M16A |
1 | 04/2002-12/2007 | 1586 | 78 | 106 | 3 |
| 1.6 4WD |
M16A |
1 | 01/2005-12/2007 | 1586 | 79 | 107 | 3 |
| 1.6 i (RH416) |
M16A |
1 | 04/2002-12/2007 | 1586 | 78 | 106 | 1 |
| 2.3 |
J23A |
1 | 04/2004-11/2007 | 2290 | 114 | 155 | 1 |
| 2.3 AWD | 1 | 01/2004-11/2007 | 2290 | 114 | 155 | 3 | |
| 1.4 DDiS |
8HY |
2 | 04/2004-12/2007 | 1398 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.3 (RH 413) |
M13A |
1 | 03/2002- | 1328 | 66 | 90 | 1 |
| 1.5 (RH415) |
M15A |
1 | 04/2004-11/2007 | 1491 | 81 | 110 | 1 |
| 1.6 (RH416) |
M16A |
1 | 03/2002- | 1586 | 76 | 103 | 1 |
| 1.6 (RH416) |
M16A |
1 | 01/2005- | 1586 | 79 | 107 | 1 |
| 1.6 4WD (RH416) |
M16A |
1 | 03/2002- | 1586 | 76 | 103 | 3 |
| 1.6 4WD (RH416) |
M16A |
1 | 04/2002- | 1586 | 78 | 106 | 3 |
| 1.6 4WD (RH416) |
M16A |
1 | 01/2005-12/2007 | 1586 | 79 | 107 | 3 |
| 1.6 i (RH416) |
M16A |
1 | 04/2002- | 1586 | 78 | 106 | 1 |
| 2.0 | 1 | 10/2001-03/2004 | 1995 | 108 | 147 | 1 | |
| 2.3 | 1 | 04/2004- | 2290 | 114 | 155 | 1 | |
| 1.4 DDiS (RH 414D) |
8HY |
2 | 04/2004- | 1398 | 66 | 90 | 1 |
