Product 78BD5017-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073146526
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5017-2
Weight (gr.)
15520
Measures
Ø302x26x34.5
Brake Disc Type: Vented
Minimum thickness [mm]: 24
Hole Arrangement/Number: 4
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 66
Reference applications
Brand OE Reference
PEUGEOT 4249.64
PEUGEOT 4249.80
PEUGEOT 4249.81
PEUGEOT 4249.86
PEUGEOT 4249.J8
Maker Cross reference
ATE 24.0126-0159.1
ATE 426159
BENDIX ANTIGUO 562641BC
BOSCH 0 986 479 548
BREMBO 09.A185.11
BREMBO 09.A195.14
DELPHI LOCKHEED BG4166
FERODO DDF1676
GIRLING 6049625
HELLA-PAGID 8DD 355 114-721
LETEC LBP028V
MINTEX MDC2032
SANLI SL36827
TEXTAR 92168500
TEXTAR 92168503
TRW DF4962S
VALEO 197315
CITROËN
C4 (LC_) Hatchback 11/2004-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V

RFK (EW10J4S)

 1 11/2004-07/2008 1997 130 177 1
2.0 HDi

RHR (DW10BTED4)

 2 11/2004-07/2011 1997 100 136 1
2.0 HDi

RHF (DW10BTED4)

 2 07/2008-07/2011 1997 103 140 1
C4 (LA_) Coupe 11/2004-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V

RFK (EW10J4S)

 1 11/2004-12/2010 1997 130 177 1
2.0 HDi

RHR (DW10BTED4)

 2 11/2004-12/2010 1997 100 136 1
2.0 HDi

RHF (DW10BTED4)

 2 07/2008-07/2011 1997 103 140 1
C4 II (NC_) Hatchback 02/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP 155

5FV (EP6CDT)

 1 11/2009-12/2016 1598 115 156 1
2.0 HDi / BlueHDi 150

AHR (DW10FD)

RHE (DW10CTED4)

 2 11/2009- 1997 110 150 1
2.0 HDi / BlueHDi 160

RHH (DW10CTED4)

 2 10/2010- 1997 120 163 1
C4 III (BA_, BB_, BC_) Hatchback 10/2020-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 PureTech 100 (BAHNEA, BAHNKA) 1 04/2021- 1199 74 101 1
1.2 PureTech 130 (BAHNSA, BAHNSB) 1 10/2020- 1199 96 130 1
1.2 PureTech 155 (BAHNNB, BAHNJD) 1 01/2021- 1199 114 155 1
1.5 BlueHDi 130 (BBYHZB) 2 10/2020- 1499 96 131 1
BLUEHDI 110 (BBYHSA) 2 12/2020- 1499 81 110 1
ë-C4 (BCZKXC, BZCKSC) 11 10/2020- 100 136 1
DS4 (NX_) Hatchback 03/2011-07/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP 150

5FE (EP6CDTMD)

 1 04/2011-07/2015 1598 110 150 1
1.6 THP 155

5FV (EP6CDT)

 1 04/2011-07/2015 1598 115 156 1
1.6 THP 165

5FM (EP6CDTM)

5GZ (EP6FDT)

 1 01/2012-07/2015 1598 121 165 1
1.6 THP160

5FM (EP6CDTM)

 1 04/2012-07/2015 1598 120 163 1
2.0 HDi / BlueHDi 135

AHS (DW10FD)

AHV (DW10FD)

RHD (DW10CB)

RHD (DW10CTED4)

 2 09/2011-07/2015 1997 100 136 1
2.0 HDi 165

RHH (DW10CTED4)

 2 04/2011-07/2015 1997 120 163 1
DS5 () Hatchback 09/2011-12/2016
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP 150

5FE (EP6CDTMD)

 1 11/2011-07/2015 1598 110 150 1
1.6 THP 155

5FV (EP6CDT)

 1 11/2011-07/2015 1598 115 156 1
1.6 THP 165

5FM (EP6CDTM)

5FM (EP6DT)

5GZ (EP6FDT)

 1 01/2012-07/2015 1598 121 165 1
1.6 THP200

5FU (EP6DTX)

 1 11/2011-07/2015 1598 147 200 1
1.6 THP 165 Hybrid

5GZ (EP6FDT)

 13 06/2012-07/2015 1598 121 165 1
2.0 HDi 135 Hybrid4 13 12/2011- 1997 100 136 3
1.6 HDi 110

9HR (DV6C)

 2 11/2011-07/2015 1560 82 112 1
1.6 HDi 115

9HD (DV6C)

 2 06/2012-07/2015 1560 84 114 1
2.0 BlueHDi 150

AHX (DW10FD)

 2 07/2014-07/2015 1997 110 150 1
2.0 BlueHDi 180

AHW (DW10FC)

 2 08/2013-07/2015 1997 133 180 1
2.0 HDi 135

RHD (DW10CB)

 2 11/2011-07/2015 1997 100 136 1
2.0 HDi 165

RHH (DW10CTED4)

 2 11/2011-07/2015 1997 120 163 1
2.0 HDi 165 Hybrid4 4x4

RHC (DW10CTED4)

 14 12/2011-07/2015 1997 120 163 3
2.0 HDi 200 Hybrid4 A las 4 ruedas 14 12/2011-07/2015 1997 147 200 3
DS
DS 3 CROSSBACK (UR_, UC_, UJ_) Hatchback 10/2018-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 PureTech 100 (URHNKK, URHNEK)

HNK (EB2ADTD)

 1 10/2018- 1199 74 101 1
1.2 PureTech 130 (URHNSS)

HNS (EB2ADTS)

 1 10/2018- 1199 96 131 1
1.2 PureTech 155 (URHNNS)

HNN (EB2ADTX)

 1 10/2018-12/2022 1199 115 156 1
1.5 BlueHDi 100 (UCYHYJ)

YHY (DV5RD)

 2 10/2018-12/2022 1499 75 102 1
1.5 BlueHDi 110 (UCYHSK) 2 01/2021-12/2022 1499 81 110 1
1.5 BlueHDi 130 (UCYHZR)

YHZ (DV5RC)

 2 10/2018- 1499 96 131 1
E-TENSE (UZZKXZ)

ZKX

 11 05/2019-12/2022 100 136 1
DS 4 / DS 4 CROSSBACK (NX_) Hatchback 07/2015-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP 150

5FE (EP6CDTMD)

 1 10/2016-12/2018 1598 110 150 1
1.6 THP 165

5GZ (EP6FDT)

 1 07/2015-12/2018 1598 121 165 1
1.6 THP160

5FM (EP6CDTM)

 1 07/2015-12/2018 1598 120 163 1
2.0 BlueHDi 150

AHR (DW10FD)

 2 07/2015-12/2018 1997 110 150 1
DS 5 (KF_) Hatchback 01/2015-12/2018
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP 165 (KF5GZT)

5GZ (EP6FDT)

 1 07/2015-12/2018 1598 121 165 1
1.6 THP 210

5GM (EP6FDTX)

 1 04/2015-12/2018 1598 155 210 1
1.6 BlueHDi 115

BHX (DV6C)

 2 06/2015-12/2018 1560 85 116 1
1.6 BlueHDi 120

BHZ (DV6FC)

 2 06/2015-12/2018 1560 88 120 1
2.0 BlueHDi 135

AHV (DW10FDD)

 2 06/2015-12/2018 1997 100 136 1
2.0 BlueHDi 150

AHR (DW10FD)

 2 04/2015-12/2018 1997 110 150 1
2.0 BlueHDi 180

AHW (DW10FC)

 2 04/2015-12/2018 1997 133 180 1
DS (CAPSA)
DS 5 () Hatchback 09/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP160

5F06 10FJBZ (EP6CDTM)

 1 09/2013-12/2017 1598 120 163 1
1.6 THP200

5F03 (EP6CDTX)

 1 09/2013-12/2015 1598 147 200 1
1.8 THP 200

6G01 10UF51 (EP8FDT)

 1 09/2015-12/2020 1751 150 204 1
DS 5 LS () Saloon 01/2014-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP160

5F06 10FJBZ (EP6CDTM)

 1 03/2014- 1598 120 163 1
1.6 THP200

5F03 (EP6CDTX)

 1 03/2014- 1598 147 200 1
1.8 VTi 140

WFZ (EC8)

 1 01/2014-12/2015 1813 102 139 1
OPEL
CORSA F (P2JO) Hatchback 07/2019-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 (68)

F 12 XEL (EB2FAD)

 1 07/2019- 1199 55 75 1
1.2 (68)

F 12 XHL (EB2ADTD)

 1 07/2019- 1199 74 101 1
1.2 (68)

F 12 XHT (EB2ADTS)

 1 07/2019- 1199 96 131 1
1.5 (68)

D 15 DT (DV5RD)

 2 07/2019- 1499 75 102 1
Corsa-e (68)

ZKX (ZK01)

 11 07/2019- 100 136 1
CORSA F Van () Hatchback Van 07/2019-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 (68)

F 12 XEL (EB2FAD)

 1 07/2019- 1199 55 75 1
1.5 (68)

D 15 DT (DV5RD)

 2 07/2019- 1499 75 102 1
MOKKA II () SUV 06/2020-
Vehicle Engine Fuel Date CC KW CV Traction
MOKKA-e (76) 11 06/2020- 100 136 1
PEUGEOT
208 (CA_, CC_) Hatchback 03/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 VTi

ZMZ (EB0)

 1 03/2012-12/2019 999 50 68 1
1.2 PureTech 82

HMR (EB2FA)

HMZ (EB2F)

 1 03/2018-12/2019 1199 61 82 1
1.2 THP 110

HNP (EB2ADT)

HNV (EB2DTM)

HNZ (EB2DT)

 1 01/2013-12/2019 1199 81 110 1
1.2 VTi 68 / PureTech 68

HMM (EB2FAD)

HMP (EB2FB)

 1 08/2016-12/2019 1199 50 68 1
1.2 VTI 82

HMZ (EB2)

HMZ (EB2F)

 1 03/2012-12/2019 1199 60 82 1
1.4 VTi

8FS (EP3)

EP3C

 1 03/2012-12/2019 1397 70 95 1
1.6

EC5F

 1 01/2013-12/2019 1587 85 116 1
1.6

5FS (EP6C)

 1 09/2016- 1598 89 121 1
1.6 GTI

5FU (EP6CDTX)

 1 08/2012-12/2019 1598 147 200 1
1.6 GTI

5GR (EP6FDTX)

 1 10/2014-12/2019 1598 153 208 1
1.6 THP

5FV (EP6CDT)

 1 03/2012-12/2019 1598 115 156 1
1.6 THP 165

5GZ (EP6FDT)

 1 03/2015-12/2019 1598 121 165 1
1.6 VTi

5FS (EP6C)

 1 03/2012-12/2019 1598 88 120 1
1.2 GPL

HMZ (EB2F)

 18 06/2015-12/2019 1199 60 82 1
1.4 GPL

EP3C

 18 10/2013-12/2019 1397 70 95 1
1.5 Flex 19 01/2013-12/2016 1449 68 92 1
1.4 HDi

8HP (DV4C)

8HR (DV4C)

 2 03/2012-12/2019 1398 50 68 1
1.5 BlueHDi 100

YHY (DV5RD)

 2 05/2018-12/2019 1499 75 102 1
1.6 BlueHDi 100

BHY (DV6FD)

 2 01/2015-12/2019 1560 73 100 1
1.6 BlueHDi 120

BHZ (DV6FC)

 2 01/2015-12/2019 1560 88 120 1
1.6 e-HDi

9HR (DV6C)

 2 07/2015-12/2019 1560 82 112 1
1.6 HDi

9HJ (DV6DTEDM)

9HP (DV6DTED)

 2 03/2012-12/2019 1560 68 92 1
1.6 HDi

9HP (DV6DTED)

 2 09/2016- 1560 69 94 1
1.6 HDi

9HD (DV6C)

 2 03/2012-12/2019 1560 84 114 1
1.6 HDi

BHX (DV6FC)

 2 01/2015-12/2019 1560 85 116 1
1.6 HDi / BlueHDi 75

9HK (DV6ETEDM)

BHW (DV6FE)

 2 01/2013-12/2019 1560 55 75 1
208 (CR_) Hatchback Van 02/2013-12/2019
Vehicle Engine Fuel Date CC KW CV Traction
1.2 VTI 68 / PureTech 68 (CRHMP6, CRHMM6)

HMM (EB2FAD)

HMP (EB2FB)

 1 06/2015-12/2019 1199 50 68 1
1.2 VTI 82 / PureTech 82 (CRHMZ6, CRHMRP)

HMR (EB2FA)

HMZ (EB2)

HMZ (EB2F)

 1 06/2015-12/2019 1199 60 82 1
1.4 HDi 68 (CR8HR0)

8HR (DV4C)

 2 02/2013-12/2019 1398 50 68 1
1.5 BlueHDi 100

YHY (DV5RD)

 2 05/2018-12/2019 1499 75 102 1
1.6 BlueHDi 75

BHW (DV6FE)

 2 04/2015-12/2019 1560 55 75 1
1.6 HDI 92

9HP (DV6DTED)

 2 03/2014-12/2019 1560 68 92 1
308 (4A_, 4C_) Hatchback 09/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 01/2012-12/2015 1598 120 163 1
1.6 16V

5FY (EP6DTS)

 1 03/2008-10/2014 1598 128 174 1
1.6 THP 16V

5FV (EP6CDT)

 1 10/2009-10/2014 1598 115 156 1
2.0 HDi

RHR (DW10BTED4)

RHR (DW10CB)

 2 09/2007-10/2014 1997 100 136 1
2.0 HDi

RHR (DW10BTED4)

 2 07/2010-12/2012 1997 103 140 1
2.0 HDi

RHE (DW10CTED4)

 2 10/2011-10/2014 1997 110 150 1
2.0 HDi

RHH (DW10CTED4)

 2 04/2012-10/2014 1997 120 163 1
308 SW (4E_, 4H_) Estate 09/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V

5FT (EP6DT)

 1 09/2007-10/2014 1598 103 140 1
1.6 16V

5FX (EP6DT)

 1 09/2007-10/2014 1598 110 150 1
1.6 16V

5FY (EP6DTS)

 1 03/2008-10/2014 1598 128 174 1
1.6 THP 16V

5FV (EP6CDT)

 1 10/2009-10/2014 1598 115 156 1
1.6 HDi

9HV (DV6TED4BU)

9HX (DV6ATED4)

 2 09/2007-10/2014 1560 66 90 1
1.6 HDi

9HZ (DV6TED4)

 2 09/2007-10/2014 1560 80 109 1
2.0 HDi

RHR (DW10BTED4)

 2 09/2007-12/2012 1997 100 136 1
2.0 HDi

RHR (DW10BTED4)

 2 09/2007-10/2014 1997 103 140 1
2.0 HDi

RHE (DW10CTED4)

 2 04/2011-10/2014 1997 110 150 1
2.0 HDi

RHH (DW10CTED4)

 2 06/2009-10/2014 1997 120 163 1
308 CC (4B_) Convertible 02/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V

5FT (EP6DT)

 1 06/2009-12/2014 1598 103 140 1
1.6 16V

5FX (EP6DT)

 1 06/2009-12/2014 1598 110 150 1
1.6 16V

5FV (EP6CDT)

 1 06/2009-12/2014 1598 115 156 1
2.0 HDi

RHF (DW10BTED4)

 2 04/2009-12/2012 1997 103 140 1
2.0 HDi

RHH (DW10CTED4)

 2 06/2009-12/2014 1997 120 163 1
2.0 HDi (4BRHRH, 4BRHRJ)

RHR (DW10BTED4)

 2 04/2009-12/2014 1997 100 136 1
2008 II (UD_, US_, UY_, UJ_, UR_, UC_) SUV 08/2019-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 PureTech 100 (USHNK)

HNK (EB2ADTD)

 1 11/2019- 1199 74 101 1
1.2 PureTech 130 (USHNS, URHNS)

HNS (EB2ADTS)

 1 08/2019- 1199 96 130 1
1.2 THP / PureTech 155 (USHNNS, URHNNS, UXHNJP, URHNJP,...

HNJ (EB2ADTXM)

HNN (EB2ADTX)

HNR (EB2ADTXM)

 1 11/2019- 1199 114 155 1
1.5 BlueHDi 100

YHY (DV5RD)

 2 08/2019- 1499 75 102 1
1.5 BlueHDI 110 (UDYHSK) 2 01/2021- 1499 81 110 1
1.5 BlueHDi 130

YHZ (DV5RC)

 2 08/2019- 1499 96 131 1
e-2008 (UKZKXZ)

ZKX (ZK01)

 11 09/2019- 100 136 1
208 II (UB_, UP_, UW_, UJ_) Hatchback 06/2019-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 PureTech 100

HNK (EB2ADT)

 1 06/2019- 1199 74 101 1
1.2 PureTech 130

HNS (EB2ADTS)

HNY (EB2DTS)

 1 06/2019- 1199 96 131 1
1.2 PureTech 75

HMH (EB2FAD)

 1 06/2019- 1199 55 75 1
1.2 VTI 82 1 06/2019- 1199 60 82 1
1.6 VTi 115 (UWNFPW, UWNFJW) 1 11/2019- 1587 85 116 1
1.5 BlueHDi 100

YHY (DV5RD)

 2 06/2019- 1499 75 102 1
1.5 BlueHDi 130

YHZ (DV5RC)

 2 09/2019- 1499 96 131 1
1.6 HDI 90 (UB9HPA) 2 10/2019- 1560 68 92 1
e-208

ZKX (ZK01)

 11 06/2019- 100 136 1
3008 (0U_) MPV 05/2009-12/2017
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP

5FE (EP6CDTM)

5FE (EP6CDTMD)

5FX (EP6DT)

 1 06/2009-08/2016 1598 110 150 1
1.6 THP

5FV (EP6CDT)

 1 06/2009-08/2016 1598 115 156 1
2.0 HDi

RHD (DW10CB)

 2 09/2011-08/2016 1997 100 136 1
2.0 HDi

RHH (DW10CTED4)

 2 06/2009-08/2016 1997 120 163 1
2.0 HDi 150 / BlueHDi 150 (RWRHEJ, RWRHE8)

AHX (DW10FD)

RHE (DW10CTED4)

 2 06/2009-08/2016 1997 110 150 1
2.0 BlueHDi 135 Hybrid 14 01/2015-12/2016 1997 100 136 1
2.0 BlueHDi 135 Hybrid 14 09/2015-12/2016 1997 100 136 1
2.0 BlueHDi 150 Hybrid 14 01/2015-12/2016 1997 110 150 1
2.0 HDi Hybrid4

RHC (DW10CTED4)

 14 02/2011-08/2016 1997 120 163 3
2.0 HDi Hybrid4 (0URHCA)

RHC (DW10CTED4)

 14 02/2011-08/2016 1997 147 200 3
3008 (0U_) Box Body/MPV 05/2009-12/2017
Vehicle Engine Fuel Date CC KW CV Traction
HDi (0URHHT) 2 06/2009-08/2016 1997 120 163 1
HDi 150 (0URHEM) 2 06/2009-08/2016 1997 110 150 1
5008 (0U_, 0E_) MPV 06/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.2

HNY (EB2DTS)

 1 01/2015-03/2017 1199 96 131 1
1.6 16V

5FV (EP6CDT)

 1 09/2009-03/2017 1598 115 156 1
1.6 THP 150

5FX (EP6DT)

 1 02/2012-03/2017 1598 110 150 1
1.6 THP 163

5GZ (EP6FDT)

 1 02/2012-03/2017 1598 120 163 1
1.6 THP 165

5GZ (EP6FDT)

 1 02/2012-03/2017 1598 121 165 1
1.6 BlueHDi 115 2 11/2014-03/2017 1560 85 116 1
1.6 BlueHDi 120

BHZ (DV6FC)

 2 05/2014-03/2017 1560 88 120 1
2.0 HDi

RHH (DW10CTED4)

 2 09/2009-03/2017 1997 120 163 1
2.0 HDi 136 / BlueHDi 136

AHV (DW10FD)

RHD (DW10CB)

RHD (DW10CTED4)

 2 02/2012-03/2017 1997 100 136 1
2.0 HDi 150 / BlueHDi 150 (RWRHEJ, RWRHE8)

AHX (DW10FD)

RHE (DW10CTED4)

 2 06/2009-03/2017 1997 110 150 1
5008 (0U_) Box Body/MPV 06/2009-03/2017
Vehicle Engine Fuel Date CC KW CV Traction
HDi 136 (0URHEM) 2 02/2012-03/2017 1997 100 136 1
HDi 150 (0URHEM) 2 06/2009-03/2017 1997 110 150 1
HDi 165 (0URHHT) 2 06/2009-03/2017 1997 120 163 1
VAUXHALL
CORSA Mk V (F) () Hatchback 07/2019-
Vehicle Engine Fuel Date CC KW CV Traction
1.2

F 12 XEL (EB2FAD)

 1 07/2019- 1199 55 75 1
1.2

F 12 XHL (EB2ADTD)

 1 07/2019- 1199 74 101 1
1.2 1 11/2020- 1199 96 131 1
1.5

D 15 DT (DV5RD)

 2 07/2019- 1499 75 102 1
CORSA-e

ZKX (ZK01)

 11 07/2019- 100 136 1
MOKKA II () SUV 06/2020-
Vehicle Engine Fuel Date CC KW CV Traction
MOKKA-e (76) 11 06/2020- 100 136 1
Return
