Product 78BD5347-2

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073146991
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5347-2
Weight (gr.): 12670

R90 Homologation: 90R-02C0074/1183
Measures: Ø282x24x38
: Brake Disc Type: Vented; Minimum thickness [mm]: 22.4; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 114.3; Wheel Hub Diameter [mm]: 73.5

Reference applications

Brand	OE Reference
CHRYSLER	4721820
CHRYSLER	4721820 AE
DODGE	4815797
PLYMOUTH	4 815 797

Maker	Cross reference
ATE	24.0124-0178.1
BOSCH	0 986 478 983
BREMBO	09.7367.14
ROAD HOUSE	6564.10
TEXTAR	92108700
TRW	DF2678
TRW	DF4508

CHRYSLER

CARAVAN () MPV 09/1994-12/2000

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	01/1995-12/2000	2429	110	150	1
2.4		1	01/1995-08/2000	2429	111	151	1

GRAND VOYAGER III VAN (GS) Box Body/MPV 01/1995-12/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	01/1998-12/2001	2429	111	151	1
3.3		1	01/1995-03/2001	3301	116	158	1
2.5 TD		2	01/1995-03/2001	2499	85	116	1

PROWLER () Convertible 09/1998-12/2002

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.5	EGJ	1	09/2000-12/2002	3518	189	257	2

VOYAGER III / GRAND VOYAGER III (GS_, NS_) MPV 01/1995-03/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 i	C00	1	01/1995-03/2001	1995	98	133	1
2.4 AWD	EDZ	1	02/1997-03/2001	2429	111	151	3
2.4 i	B00	1	01/1995-03/2001	2429	111	151	1
3.0	EFA	1	01/1995-03/2001	2972	112	152	1
3.3 i	R00	1	01/1995-03/2001	3301	116	158	1
3.3 i		1	01/1995-03/2001	3301	134	180	1
3.8	EGH	1	01/1995-09/2000	3778	121	165	1
3.8	EGH	1	10/1997-09/2000	3778	131	178	1
3.8	EGH	1	09/1997-12/2000	3778	134	182	1
3.8 AWD		1	09/1997-12/2000	3778	134	182	3
3.8 i AWD	L00	1	01/1995-03/2001	3778	122	166	3
3.8 i AWD	EGH	1	01/1995-03/2001	3778	131	178	3
2.5 TD	425 CLIRS/X ENC	2	01/1995-03/2001	2499	85	116	1
2.5 TDiC AWD	ENC	2	10/1995-03/2001	2499	85	116	3

VOYAGER III VAN (GS_) Box Body/MPV 01/1995-12/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 (GSHY52)		1	01/1995-03/2001	2429	111	151	1
3.3 (GSHY52)		1	01/1995-03/2001	3301	116	158	1
3.8 AWD (GSHC52)		1	10/1995-09/1997	3778	122	166	3
2.5 TD (GSHY52, GSHZ52)		2	01/1995-03/2001	2499	85	116	1

VOYAGER IV / GRAND VOYAGER IV / TOWN & COUNTRY IV (RG, RS) MPV 09/1999-12/2008

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.0		1	09/1999-12/2000	2972	112	152	1

DODGE

CARAVAN III () MPV 01/1995-03/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 i		1	01/1995-03/2001	1995	98	133	1
2.4 i	EDZ	1	01/1995-03/2001	2429	111	151	1
3.0	EFA	1	01/1995-06/2000	2972	112	152	1
3.3 i	EGP	1	01/1995-03/2001	3301	116	158	1
3.8 i	EGH	1	01/1995-03/2001	3778	122	166	1
3.8 i	EGH	1	01/1995-03/2001	3778	131	178	1
3.8 i AWD	EGH	1	01/1995-03/2001	3778	122	166	3
3.8 i AWD	EGH	1	01/1995-03/2001	3778	131	178	3
2.5 TD	ENC	2	01/1995-03/2001	2499	85	116	1

CARAVAN III VAN (NS) Box Body/MPV 01/1995-03/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.8		1	10/1995-06/2000	3778	122	166	1
3.8		1	10/1995-06/2000	3778	131	178	1

PLYMOUTH

PROWLER (U.S.A.) Convertible 09/1996-12/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.5	EGJ	1	09/1998-12/2001	3518	189	257	2

VOYAGER III () MPV 01/1995-03/2001

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 i		1	01/1995-03/2001	1996	98	133	1
2.4 i	EDZ	1	01/1995-03/2001	2429	111	151	1
3.0	EFA	1	01/1995-03/2001	2972	112	152	1
3.3 i	EGM	1	01/1995-03/2001	3301	116	158	1
3.3 Flex-Fuel	EGM	19	01/1998-03/2001	3301	116	158	1
2.5 TD	ENC	2	01/1995-03/2001	2499	85	116	1
