Product 78BD5600-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073193537
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5600-2
Weight (gr.)
9010
Measures
Ø287x17x46.2
Brake Disc Type: Vented
Minimum thickness [mm]: 15
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 139.7
Wheel Hub Diameter [mm]: 107.1
Reference applications
Brand OE Reference
SUZUKI 5521156B00000
SUZUKI 5521156B00A00
SUZUKI 5521156B00L00
SUZUKI 5521156B01
SUZUKI 5521176J10
SUZUKI 5521176J11
SUZUKI 5521185C00
SUZUKI 9998556B00
Maker Cross reference
BENDIX BRAKING-TMD BDS1998
BREMBO 09.6859.10
HELLA-PAGID 8DD 355 132-911
MINTEX MDC2943C
TEXTAR 92076400
TEXTAR 92314103
GEO
TRACKER () Closed Off-Road Vehicle 01/1988-12/1998
Vehicle Engine Fuel Date CC KW CV Traction
1.6 i 16V

G16B

 1 01/1988-12/1998 1590 71 97 3
2.0 i 16V

J20A

 1 01/1988-12/1998 1995 97 132 3
2.0 i V6

H 20 A

 1 12/1994-12/1998 1998 100 136 3
1.9 D

XUD9

 2 12/1994-12/1998 1905 50 68 3
SANTANA
300/350 () Closed Off-Road Vehicle 09/1998-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

G16B

 1 11/2004-09/2006 1590 71 97 3
1.6 D 4x4

DV6ATED4

 2 09/1998- 1560 66 90 3
1.6 HDi 4x4

DV6ATED4

 2 07/2006-02/2011 1560 66 90 3
2.0 TDI 4x4 2 11/2004-08/2007 1997 64 87 3
SUZUKI
JIMNY III / JIMNY SIERRA (SN) Closed Off-Road Vehicle 07/1998-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 DDiS 4WD (SN415D)

K9K 700

 2 12/2003- 1461 48 65 3
1.5 DDiS 4x4

K9K 266

 2 08/2005- 1461 63 86 3
VITARA / ESCUDO (ET, TA) Open Off-Road Vehicle 07/1988-10/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (TA01, SE416)

G16A (8V)

 1 07/1988-01/1995 1589 59 80 3
1.6 i 16V (TA02, SE416)

G16B

 1 07/1990-03/1999 1590 71 97 3
2.0 16V (TA51, SV420)

J20A

 1 12/1996-03/1999 1995 97 132 3
1.9 D (SE419TD)

XUD9A

 2 01/1995-03/1998 1905 50 68 3
1.9 D (SE419TD)

XUD9SD

 2 08/1996-03/1999 1905 55 75 3
VITARA / ESCUDO / SIDEKICK (ET, TA, TD) Closed Off-Road Vehicle 07/1988-12/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (SE416)

G16B

 1 02/1991-03/1998 1590 70 95 3
1.6 A las 4 ruedas (SE416, TA01)

G16A (8V)

 1 07/1988-12/1995 1589 60 82 3
1.6 A las 4 ruedas (SE416, TA01)

G16A (8V)

 1 10/1988-12/1998 1590 55 75 3
1.6 A las 4 ruedas (SE416, TA01)

G16B

 1 02/1991-03/1998 1590 70 95 3
1.6 A las 4 ruedas (TA, TA01, SE416)

G16A (8V)

 1 07/1988-03/1998 1590 59 80 3
1.6 i 16V

G16B

 1 01/1990-12/1998 1590 71 97 2
1.6 i 16V A las 4 ruedas (ET, TA02, SE416)

G16B

 1 07/1990-03/1998 1590 71 97 3
1.9 D A las 4 ruedas (SE419TD)

XUD9A

 2 01/1995-03/1998 1905 50 68 3
1.9 D A las 4 ruedas (SE419TD)

XUD9SD

 2 08/1996-03/1998 1905 55 75 3
