Product 78BD5601-2

Description
Brake disc
Axe
Rear
No. of Pieces
2
Barcode
EAN13 Code
8424073147103
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5601-2
Weight (gr.)
5500
R90 Homologation
R90 90R-02C0415/0006
Measures
Ø232x9x39
Brake Disc Type: solid
Minimum thickness [mm]: 7
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 100
Wheel Hub Diameter [mm]: 65
Reference applications
Brand OE Reference
SEAT 1J0 615 601 N
VW 1J0 615 601
VW 1J0 615 601 C
VW 1J0 615 601 P
VW 1J0 615 601 Q
Maker Cross reference
ATE 24.0109-0123.1
ATE 409123
BENDIX ANTIGUO 562053B
BOSCH 0 986 478 868
BREMBO 08.7165.10
BREMBO 08.7165.11
BREMBO 08.7165.14
DELPHI LOCKHEED BG3034
FERODO DDF929
LETEC LBA016S
ROAD HOUSE 6547.00
SANLI SL10931
TRW DF2805
AUDI
A1 (8X1, 8XK) Hatchback 05/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TFSI

CHZE

 1 01/2016-10/2018 999 60 82 1
1.0 TFSI

CHZB

DKLD

 1 03/2015-10/2018 999 70 95 1
1.4 TFSI

CZCA

CZDD

 1 11/2014-10/2018 1395 92 125 1
1.4 TSI

CZEA

 1 11/2014-10/2018 1395 110 150 1
1.8 TFSI

DAJB

 1 02/2015-10/2018 1798 141 192 1
1.4 TDI

CUSB

 2 11/2014-10/2018 1422 66 90 1
1.6 TDI

CXMA

 2 11/2014-10/2018 1598 85 115 1
2.0 TDI

CFHB

 2 05/2012-04/2015 1968 100 136 1
A1 Sportback (8XA, 8XF) Hatchback 09/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TFSI

CHZE

 1 01/2016-10/2018 999 60 82 1
1.0 TFSI

CHZB

DKLD

 1 03/2015-10/2018 999 70 95 1
1.4 TFSI

CZCA

CZDD

 1 11/2014-10/2018 1395 92 125 1
1.4 TSI

CZEA

 1 11/2014-10/2018 1395 110 150 1
1.8 TFSI

DAJB

 1 02/2015-10/2018 1798 141 192 1
1.4 TDI

CUSB

 2 11/2014-10/2018 1422 66 90 1
1.6 TDI

CXMA

 2 11/2014-10/2018 1598 85 115 1
2.0 TDI

CFHB

 2 05/2012-04/2015 1968 100 136 1
A1 II Sportback (GBA) Hatchback 07/2018-
Vehicle Engine Fuel Date CC KW CV Traction
25 TFSI

DKLA

DLAC

 1 11/2018- 999 70 95 1
30 TFSI

DLAA

 1 09/2020- 999 81 110 1
30 TFSI

DKJA

DKRF

 1 07/2018- 999 85 116 1
35 TFSI

DADA

DPCA

 1 09/2018- 1498 110 150 1
40 TFSI

CZPC

DKZC

 1 09/2018- 1984 147 200 1
40 TFSI 1 04/2021- 1984 152 207 1
A1 CITY CARVER (GBH) Hatchback 07/2019-
Vehicle Engine Fuel Date CC KW CV Traction
25 TFSI

DKLA

 1 07/2019-06/2022 999 70 95 1
30 TFSI

DLAA

 1 09/2020-06/2022 999 81 110 1
30 TFSI

DKJA

DKRF

 1 07/2019-06/2022 999 85 116 1
35 TFSI

DPCA

 1 07/2019-06/2022 1498 110 150 1
A1 II Allstreet (GBH) Hatchback 07/2019-
Vehicle Engine Fuel Date CC KW CV Traction
25 TFSI 1 07/2022- 999 70 95 1
30 TFSI 1 07/2022- 999 81 110 1
35 TFSI 1 07/2022- 1498 110 150 1
A3 (8L1) Hatchback 09/1996-09/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.6

AEH

AKL

APF

 1 09/1996-05/2003 1595 74 101 1
1.6

AVU

BFQ

 1 08/2000-05/2003 1595 75 102 1
1.8

AGN

APG

 1 09/1996-05/2003 1781 92 125 1
1.9 TDI

AGR

ALH

 2 09/1996-07/2001 1896 66 90 1
1.9 TDI

ATD

AXR

 2 10/2000-05/2003 1896 74 100 1
1.9 TDI

AHF

ASV

 2 08/1997-07/2001 1896 81 110 1
1.9 TDI

ASZ

 2 08/2000-05/2003 1896 96 130 1
TT (8N3) Coupe 10/1998-02/2007
Vehicle Engine Fuel Date CC KW CV Traction
1.6 T 1 09/2002-06/2006 1598 134 182 1
1.8 T

AUM

 1 09/2002-06/2006 1781 110 150 1
1.8 T

BVP

 1 09/2005-06/2006 1781 120 163 1
1.8 T

AJQ

APP

ATC

AUQ

 1 10/1998-06/2006 1781 132 180 1
1.8 T

BVR

 1 09/2005-06/2006 1781 140 190 1
TT (8N9) Convertible 10/1999-02/2007
Vehicle Engine Fuel Date CC KW CV Traction
1.8 T

AUM

 1 01/2001-06/2006 1781 110 150 1
1.8 T

BVP

 1 09/2005-06/2006 1781 120 163 1
1.8 T

AJQ

APP

ATC

AUQ

AWP

 1 10/1999-06/2006 1781 132 180 1
SEAT
ARONA (KJ7, KJP) SUV 07/2017-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI

CHZL

DKLA

 1 07/2017- 999 70 95 1
1.0 TSI

DLAA

 1 06/2020- 999 81 110 1
1.0 TSI

CHZJ

DKJA

DKRF

 1 07/2017- 999 85 115 1
1.5 TSI

DADA

DPCA

 1 07/2017- 1498 110 150 1
1.6 SRE

CWVA

 1 07/2017- 1598 81 110 1
1.0 TGI

DBYA

 16 11/2018- 999 66 90 1
1.6 TDI

DGTD

 2 11/2017- 1598 70 95 1
1.6 TDI

DGTA

 2 07/2017- 1598 85 115 1
CORDOBA III (6L2) Saloon 09/2002-11/2009
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

BBY

BKY

 1 09/2002-12/2007 1390 55 75 1
1.4 16V

BXW

 1 05/2006-11/2009 1390 63 86 1
1.4 16V

BBZ

 1 10/2002-11/2009 1390 74 100 1
1.6

BAH

 1 04/2003-11/2009 1598 74 101 1
1.6 16V

BTS

 1 11/2006-11/2009 1598 77 105 1
2.0

AZL

BBX

 1 09/2002-11/2009 1984 85 115 1
1.4 TDI

BNM

 2 05/2005-11/2009 1422 51 70 1
1.4 TDI

AMF

 2 10/2002-12/2005 1422 55 75 1
1.4 TDI

BMS

BNV

 2 06/2005-11/2009 1422 59 80 1
1.9 TDI

ATD

AXR

BMT

 2 09/2002-11/2009 1896 74 100 1
1.9 TDI

ASZ

BLT

 2 10/2002-11/2009 1896 96 131 1
IBIZA II (6K1) Hatchback 03/1993-05/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.8 T 20V Cupra R

AYP

 1 07/2000-02/2002 1781 132 180 1
IBIZA III (6L1) Hatchback 02/2002-11/2009
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

BXW

 1 05/2006-11/2009 1390 63 86 1
1.4 16V

AUB

BBZ

 1 02/2002-11/2009 1390 74 100 1
1.6

BAH

 1 02/2003-11/2009 1598 74 101 1
1.6 16V

BTS

 1 11/2006-11/2009 1598 77 105 1
1.8 T Cupra R

BBU

BLZ

 1 01/2004-02/2008 1781 132 180 1
1.8 T FR

BJX

BKV

 1 12/2003-05/2008 1781 110 150 1
2.0

AZL

BBX

 1 04/2002-11/2009 1984 85 116 1
1.4 TDI

BNM

 2 05/2005-11/2009 1422 51 70 1
1.4 TDI

AMF

 2 05/2002-12/2005 1422 55 75 1
1.4 TDI

BMS

BNV

 2 06/2005-11/2009 1422 59 80 1
1.9 TDI

ATD

AXR

BMT

 2 02/2002-11/2009 1896 74 100 1
1.9 TDI

ASZ

BLT

 2 02/2002-11/2009 1896 96 131 1
1.9 TDI Cupra R

BPX

BUK

 2 03/2004-02/2008 1896 118 160 1
IBIZA IV (6J5, 6P1) Hatchback 03/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYB

 1 05/2015-06/2017 999 55 75 1
1.0 TSI

CHZB

 1 05/2015-06/2017 999 70 95 1
1.0 TSI

CHZC

 1 05/2015-06/2017 999 81 110 1
1.2

CGPB

 1 07/2009-05/2011 1198 44 60 1
1.2

BZG

CGPA

CJLB

 1 03/2008-05/2015 1198 51 70 1
1.2 TSI

CBZA

 1 08/2012-05/2015 1197 63 86 1
1.2 TSI

CJZC

 1 05/2015-06/2017 1197 66 90 1
1.2 TSI

CBZB

 1 09/2010-03/2012 1197 77 105 1
1.2 TSI

CJZD

 1 09/2015-06/2017 1197 81 110 1
1.4

BXW

CGGB

 1 03/2008-05/2015 1390 63 85 1
1.4 TSI

CAVF

CNUB

CTHF

CTJB

 1 06/2009-05/2015 1390 110 150 1
1.4 TSI

CPTA

 1 10/2013-05/2015 1395 103 140 1
1.4 TSI

CZEA

 1 11/2015-06/2017 1395 110 150 1
1.6

BTS

 1 05/2008-03/2012 1598 77 105 1
1.6

CWVA

 1 07/2015-06/2017 1598 81 110 1
2.0

CEKA

 1 10/2008-05/2015 1984 85 115 1
1.2 LPG

BZG

 18 03/2008-05/2011 1198 51 70 1
1.4 LPG

BXW

 18 03/2008-05/2011 1390 63 85 1
1.6 LPG

CNKA

 18 05/2011-05/2015 1598 60 81 1
1.4 TDI

CUSA

 2 05/2015-06/2017 1422 55 75 1
1.4 TDI

BMS

 2 07/2008-06/2010 1422 59 80 1
1.4 TDI

CUSB

 2 05/2015-06/2017 1422 66 90 1
1.4 TDI

CUTA

CYZA

 2 05/2015-06/2017 1422 77 105 1
1.6 TDI

CAYA

 2 05/2009-06/2010 1598 55 75 1
1.6 TDI

CAYB

 2 05/2009-05/2015 1598 66 90 1
1.6 TDI

CAYC

CLNA

 2 05/2009-05/2015 1598 77 105 1
1.9 TDI

BXJ

 2 07/2008-06/2010 1896 66 90 1
1.9 TDI

BLS

 2 03/2008-06/2010 1896 77 105 1
2.0 TDI

CFHD

 2 01/2010-05/2015 1968 105 143 1
IBIZA IV (6J1) Hatchback Van 04/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.2

CGPA

 1 04/2008-05/2015 1198 51 69 1
1.2 TDI

CFWA

 2 05/2010-05/2015 1199 55 75 1
1.6 TDI

CAYB

 2 05/2009-05/2015 1598 66 90 1
IBIZA IV SC (6J1, 6P5) Coupe 06/2008-12/2018
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYB

 1 05/2015-12/2016 999 55 75 1
1.0 TSI

CHZB

 1 05/2015-12/2016 999 70 95 1
1.0 TSI

CHZC

 1 05/2015-12/2016 999 81 110 1
1.2

BZG

CGPA

 1 07/2008-05/2015 1198 51 70 1
1.2 TSI

CBZA

 1 08/2012-05/2015 1197 63 86 1
1.2 TSI

CJZC

 1 05/2015-12/2016 1197 66 90 1
1.2 TSI

CBZB

 1 09/2010-05/2015 1197 77 105 1
1.2 TSI

CJZD

 1 09/2015-12/2016 1197 81 110 1
1.4

BXW

CGGB

 1 07/2008-05/2015 1390 63 85 1
1.4 TSI

CAVF

CNUB

CTHF

CTJB

 1 01/2009-05/2015 1390 110 150 1
1.4 TSI

CPTA

 1 10/2013-05/2015 1395 103 140 1
1.4 TSI

CZEA

 1 11/2015-12/2016 1395 110 150 1
1.4 TSI Cupra

CAVE

CTHE

CTJC

 1 06/2009-05/2015 1390 132 180 1
1.6

BTS

 1 07/2008-05/2015 1598 77 105 1
1.6

CWVA

 1 07/2015-12/2016 1598 81 110 1
1.8 TSI Cupra

DAJA

 1 11/2015-12/2016 1798 141 192 1
2.0

CEKA

 1 10/2008-05/2015 1984 85 115 1
1.4 LPG 18 07/2008-05/2011 1390 63 85 1
1.6 LPG

CNKA

 18 05/2011-05/2015 1598 60 81 1
1.4 TDI

CUSA

 2 05/2015-12/2016 1422 55 75 1
1.4 TDI

BMS

 2 07/2008-06/2010 1422 59 80 1
1.4 TDI

CUSB

 2 05/2015-12/2016 1422 66 90 1
1.4 TDI

CUTA

CYZA

 2 05/2015-12/2016 1422 77 105 1
1.6 TDI

CAYA

 2 05/2010-06/2010 1598 55 75 1
1.6 TDI

CAYB

 2 05/2009-05/2015 1598 66 90 1
1.6 TDI

CAYC

 2 05/2009-05/2015 1598 77 105 1
1.9 TDI

BXJ

 2 06/2008-06/2010 1896 66 90 1
1.9 TDI

BLS

 2 07/2008-06/2010 1896 77 105 1
2.0 TDI

CFHD

 2 01/2010-05/2015 1968 105 143 1
IBIZA IV ST (6J8, 6P8) Estate 03/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYB

 1 05/2015-07/2016 999 55 75 1
1.0 TSI

CHZB

 1 05/2015-07/2016 999 70 95 1
1.0 TSI

CHZC

 1 05/2015-07/2016 999 81 110 1
1.2

BZG

CGPA

CJLB

 1 05/2010-05/2015 1198 51 70 1
1.2 TSI

CBZA

 1 09/2012-05/2015 1197 63 86 1
1.2 TSI

CJZC

 1 05/2015-07/2016 1197 66 90 1
1.2 TSI

CBZB

 1 09/2010-05/2015 1197 77 105 1
1.2 TSI

CJZD

 1 09/2015-07/2016 1197 81 110 1
1.4

CGGB

 1 03/2010-05/2015 1390 63 85 1
1.4 TSI

CAVF

CNUB

CTHF

CTJB

 1 02/2012-05/2015 1390 110 150 1
1.4 TSI

CPTA

 1 10/2013-05/2015 1395 103 140 1
1.4 TSI

CZEA

 1 11/2015-07/2016 1395 110 150 1
1.6

BTS

 1 02/2012-05/2015 1598 77 105 1
1.4 TDI

CUSA

 2 05/2015-07/2016 1422 55 75 1
1.4 TDI

CUSB

 2 05/2015-07/2016 1422 66 90 1
1.4 TDI

CUTA

CYZA

 2 05/2015-07/2016 1422 77 105 1
1.6 TDI

CAYB

 2 03/2010-05/2015 1598 66 90 1
1.6 TDI

CAYC

CLNA

 2 03/2010-05/2015 1598 77 105 1
IBIZA V (KJ1, KJG) Hatchback 01/2017-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYC

DFNB

 1 07/2017- 999 48 65 1
1.0

CHYB

 1 01/2017- 999 55 75 1
1.0 MPi

DFNA

DSGB

 1 07/2018- 999 59 80 1
1.0 TSI

CHZL

DKLA

 1 01/2017- 999 70 95 1
1.0 TSI

DLAA

 1 06/2020- 999 81 110 1
1.0 TSI

CHZJ

DKJA

DKRF

 1 01/2017- 999 85 115 1
1.5 TSI

DADA

 1 07/2017- 1498 110 150 1
1.6

CWVA

 1 05/2017- 1598 81 110 1
1.0 TGI

DBYA

 16 11/2017- 999 66 90 1
1.6 TDI

DGTC

 2 11/2017- 1598 59 80 1
1.6 TDI

DGTD

 2 09/2017- 1598 70 95 1
1.6 TDI

DGTA

 2 12/2017- 1598 85 115 1
LEON (1M1) Hatchback 11/1999-06/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AHW

APE

AXP

BCA

 1 11/1999-06/2006 1390 55 75 1
1.6

AEH

AKL

 1 11/1999-06/2006 1595 74 100 1
1.6

BFQ

 1 10/2005-06/2006 1595 75 102 1
1.6 16V

AUS

AZD

BCB

 1 09/2000-06/2006 1598 77 105 1
1.8 20V

AGN

APG

 1 11/1999-06/2006 1781 92 125 1
1.8 20V T 4

AJQ

ARY

 1 11/1999-06/2006 1781 132 180 3
1.8 20VT

APP

AUQ

 1 11/1999-06/2006 1781 132 180 1
1.9 SDI

AQM

 2 11/1999-06/2006 1896 50 68 1
1.9 TDI

AGR

ALH

 2 11/1999-06/2006 1896 66 90 1
1.9 TDI

AXR

 2 10/2005-06/2006 1896 74 100 1
1.9 TDI

AHF

ASV

 2 11/1999-06/2006 1896 81 110 1
1.9 TDI

ASZ

 2 05/2003-06/2006 1896 96 130 1
1.9 TDI

ARL

 2 09/2000-06/2006 1896 110 150 1
1.9 TDI Syncro

ARL

 2 05/2002-06/2006 1896 110 150 3
TOLEDO II (1M2) Saloon 10/1998-05/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AHW

APE

AXP

BCA

 1 01/2000-05/2002 1390 55 75 1
1.6

AEH

AKL

 1 10/1998-07/2004 1595 74 100 1
1.6 1 08/2005-05/2006 1595 75 102 1
1.6 16V

AUS

AZD

BCB

 1 06/2000-05/2006 1598 77 105 1
1.8 1 05/2001-04/2004 1781 132 179 1
1.8 1 05/2002-05/2003 1781 154 209 1
1.8 20V

AGN

APG

 1 10/1998-07/2004 1781 92 125 1
1.8 20VT

APP

ARY

AUQ

 1 09/2000-07/2004 1781 132 180 1
2.3 V5

AGZ

 1 10/1998-11/2000 2324 110 150 1
2.3 V5 20V

AQN

 1 09/2000-11/2003 2324 125 170 1
1.9 SDI 2 11/1999-06/2004 1896 50 68 2
1.9 TDI

AGR

ALH

 2 03/1999-07/2004 1896 66 90 1
1.9 TDI

AXR

 2 08/2005-05/2006 1896 74 101 1
1.9 TDI

AHF

ASV

 2 10/1998-07/2004 1896 81 110 1
1.9 TDI

ASZ

 2 05/2003-05/2006 1896 96 130 1
1.9 TDI

ARL

 2 10/2000-07/2004 1896 110 150 1
1.9 TDI 4Drive

ARL

 2 10/2000-10/2005 1896 110 150 3
TOLEDO IV (KG3) Hatchback 07/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI

CHZB

DKLD

 1 05/2017-04/2019 999 70 95 1
1.0 TSI

CHZC

DKRC

 1 05/2017-04/2019 999 81 110 1
1.2

CGPC

 1 07/2012-06/2015 1198 55 75 1
1.2 TSI

CBZA

 1 07/2012-06/2015 1197 63 86 1
1.2 TSI

CJZC

 1 05/2015-05/2017 1197 66 90 1
1.2 TSI

CBZB

 1 07/2012-06/2015 1197 77 105 1
1.2 TSI

CJZD

 1 05/2015-05/2017 1197 81 110 1
1.4 TSI

CAXA

 1 07/2012-06/2015 1390 90 122 1
1.4 TSI

CZCA

 1 05/2015-04/2019 1395 92 125 1
1.6

CFNA

 1 07/2013-06/2015 1598 77 105 1
1.6

CWVA

 1 05/2015-04/2019 1598 81 110 1
1.4 TDI

CUSB

 2 05/2015-04/2019 1422 66 90 1
1.6 TDI

CAYB

 2 06/2013-06/2015 1598 66 90 1
1.6 TDI

CAYC

CLNA

 2 07/2012-06/2015 1598 77 105 1
1.6 TDI

CXMA

 2 05/2015-04/2019 1598 85 115 1
SKODA
(545) Estate Van 12/2006-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
TDI 2 10/2013-11/2014 1598 55 75 1
(NJ5) Estate Van 08/2014-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 1 10/2014-12/2022 999 44 60 1
1.0 1 10/2014-12/2022 999 55 75 1
1.2 TSI 1 10/2014-12/2022 1197 66 90 1
1.2 TSI 1 10/2014-12/2022 1197 81 110 1
1.4 TDI 2 05/2015-12/2022 1422 55 75 1
1.4 TDI 2 10/2014-12/2022 1422 66 90 1
1.4 TDI 2 10/2014-12/2022 1422 77 105 1
FABIA (6Y2) Hatchback 08/1999-03/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.4 1 02/2006-10/2006 1390 59 80 1
1.4 16V

AUA

BBY

BKY

 1 12/1999-03/2008 1390 55 75 1
1.4 16V

AUB

BBZ

 1 12/1999-03/2008 1390 74 100 1
2.0

AZL

 1 12/1999-03/2008 1984 85 116 1
1.4 TDI

BNM

 2 10/2005-03/2008 1422 51 70 1
1.4 TDI

AMF

 2 04/2003-03/2008 1422 55 75 1
1.9 TDI

ATD

AXR

 2 01/2000-03/2008 1896 74 100 1
1.9 TDI RS

ASZ

BLT

 2 06/2003-03/2008 1896 96 130 1
FABIA (6Y3) Saloon 10/1999-12/2007
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AUA

BBY

BKY

 1 10/1999-12/2007 1390 55 75 1
1.4 16V

BUD

 1 04/2006-12/2007 1390 59 80 1
1.4 16V

AUB

BBZ

 1 12/1999-12/2007 1390 74 100 1
2.0

AZL

 1 12/1999-12/2007 1984 85 116 1
1.9 TDI

ATD

AXR

 2 01/2000-12/2007 1896 74 100 1
FABIA (6Y5) Estate Van 01/2000-12/2007
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BKY

 1 05/2004-12/2007 1390 55 75 1
1.4

AZE

AZF

 1 04/2000-03/2003 1397 44 60 1
1.4 TDI

BNM

 2 10/2005-12/2007 1422 51 70 1
1.4 TDI

AMF

 2 08/2004-10/2005 1422 55 75 1
1.9 TDI

ATD

AXR

 2 01/2000-12/2007 1896 74 101 1
FABIA Combi (6Y5) Estate 04/2000-12/2007
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AUB

BBZ

 1 04/2000-12/2007 1390 74 100 1
2.0

AZL

 1 04/2000-12/2007 1984 85 116 1
1.4 TDI

BNM

 2 10/2005-12/2007 1422 51 70 1
1.4 TDI

AMF

 2 04/2003-12/2007 1422 55 75 1
1.4 TDI

BNV

 2 10/2005-12/2007 1422 59 80 1
1.9 SDI

ASY

 2 04/2000-12/2007 1896 47 64 1
1.9 TDI

ATD

AXR

 2 04/2000-12/2007 1896 74 100 1
FABIA II (542) Hatchback 12/2006-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.2

BBM

CHFA

 1 12/2006-12/2014 1198 44 60 1
1.2

BZG

CEVA

CGPA

CHTA

 1 01/2007-12/2014 1198 51 70 1
1.2 12V 1 10/2010-12/2014 1198 55 75 1
1.2 TSI

CBZA

 1 03/2010-12/2014 1197 63 86 1
1.2 TSI

CBZB

 1 03/2010-12/2014 1197 77 105 1
1.4

BXW

CGGB

 1 01/2007-12/2014 1390 63 86 1
1.4 TSI RS

CAVE

CTHE

 1 05/2010-12/2014 1390 132 180 1
1.6

BTS

CFNA

CLSA

 1 04/2007-12/2014 1598 77 105 1
1.2 TDI

CFWA

 2 05/2010-12/2014 1199 55 75 1
1.4 TDI

BNM

 2 02/2007-03/2010 1422 51 70 1
1.4 TDI

BMS

BNV

 2 01/2007-03/2010 1422 59 80 1
1.6 TDI

CAYA

 2 04/2010-12/2014 1598 55 75 1
1.6 TDI

CAYB

 2 03/2010-12/2014 1598 66 90 1
1.6 TDI

CAYC

 2 03/2010-12/2014 1598 77 105 1
1.9 TDI

BLS

BSW

 2 04/2007-03/2010 1896 77 105 1
FABIA II Combi (545) Estate 10/2007-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.2

BZG

CEVA

CGPA

CHTA

 1 10/2007-12/2014 1198 51 70 1
1.2 TSI

CBZA

 1 03/2010-12/2014 1197 63 86 1
1.2 TSI

CBZB

 1 03/2010-12/2014 1197 77 105 1
1.4

BXW

CGGB

 1 10/2007-12/2014 1390 63 86 1
1.4 TSI RS

CAVE

CTHE

 1 05/2010-12/2014 1390 132 180 1
1.6

BTS

CFNA

 1 10/2007-12/2014 1598 77 105 1
1.4 LPG

BXW

CGGB

 18 10/2007-11/2014 1390 63 86 1
1.2 TDI

CFWA

 2 05/2010-12/2014 1199 55 75 1
1.4 TDI

BNM

 2 10/2007-03/2010 1422 51 70 1
1.4 TDI

BMS

BNV

 2 10/2007-03/2010 1422 59 80 1
1.6 TDI

CAYA

 2 04/2010-12/2014 1598 55 75 1
1.6 TDI

CAYB

 2 03/2010-12/2014 1598 66 90 1
1.6 TDI

CAYC

 2 03/2010-12/2014 1598 77 105 1
1.9 TDI

BLS

BSW

 2 10/2007-03/2010 1896 77 105 1
FABIA III (NJ3) Hatchback 08/2014-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYA

CHYE

 1 08/2014-06/2021 999 44 60 1
1.0

CHYB

 1 08/2014-06/2021 999 55 75 1
1.0 TSI

CHZB

DKLD

 1 08/2014-06/2021 999 70 95 1
1.0 TSI

CHZC

DKRC

 1 08/2014-06/2021 999 81 110 1
1.2 TSI

CJZC

 1 08/2014-06/2021 1197 66 90 1
1.2 TSI

CJZD

 1 08/2014-06/2021 1197 81 110 1
1.4 TSI R5

CZCA

 1 02/2018-06/2021 1395 92 125 1
1.6

CWVA

 1 01/2015-06/2021 1598 81 110 1
1.4 TDI

CUSA

 2 05/2015-06/2021 1422 55 75 1
1.4 TDI

CUSB

 2 08/2014-06/2021 1422 66 90 1
1.4 TDI

CUTA

 2 08/2014-06/2021 1422 77 105 1
FABIA III (NJ5) Estate 08/2014-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYA

CHYE

 1 10/2014-12/2022 999 44 60 1
1.0

CHYB

 1 10/2014-12/2022 999 55 75 1
1.0 TSI

CHZB

DKLD

 1 08/2014-12/2022 999 70 95 1
1.0 TSI

CHZC

DKRC

 1 08/2014-12/2022 999 81 110 1
1.2 TSI

CJZC

 1 10/2014-12/2022 1197 66 90 1
1.2 TSI

CJZD

 1 10/2014-12/2022 1197 81 110 1
1.6

CWVA

 1 01/2015-12/2022 1598 81 110 1
1.4 TDI

CUSA

 2 05/2015-12/2022 1422 55 75 1
1.4 TDI

CUSB

 2 10/2014-12/2022 1422 66 90 1
1.4 TDI

CUTA

 2 10/2014-12/2022 1422 77 105 1
FABIA IV (PJ3) Hatchback 06/2021-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 MPi 1 08/2021- 999 48 65 1
1.0 MPi 1 06/2021- 999 59 80 1
1.0 TSI 1 06/2021- 999 70 95 1
1.0 TSI 1 06/2021- 999 81 110 1
1.5 TSI 1 11/2021- 1498 110 150 1
1.6 1 06/2021- 1598 81 110 1
KAMIQ (NW4) SUV 07/2019-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI

DKLA

 1 07/2019- 999 70 95 1
1.0 TSI

DLAA

 1 08/2020- 999 81 110 1
1.0 TSI

DKRF

 1 07/2019- 999 85 115 1
1.5 TSI

DPCA

 1 07/2019- 1498 110 150 1
1.6 SRE

CWVA

 1 07/2019- 1598 81 110 1
1.0 TGI CNG

DBYA

 16 11/2019- 999 66 90 1
1.6 TDI 2 09/2019- 1598 70 95 1
1.6 TDI

DGTA

 2 07/2019- 1598 85 115 1
OCTAVIA (1U2) Hatchback 09/1996-12/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.8

AGN

 1 09/1996-07/2000 1781 92 125 1
1.8 T

AGU

ARX

ARZ

AUM

 1 08/1997-12/2010 1781 110 150 1
1.8 T 4x4

ARX

 1 05/2001-05/2006 1781 110 150 3
2.0

AEG

APK

AQY

AZH

AZJ

 1 04/1999-05/2007 1984 85 116 1
1.9 SDI

AGP

AQM

 2 06/1997-12/2003 1896 50 68 1
1.9 TDI

AGR

ALH

 2 09/1996-03/2010 1896 66 90 1
1.9 TDI

AXR

 2 10/2005-12/2010 1896 74 100 1
1.9 TDI

AHF

ASV

 2 08/1997-01/2006 1896 81 110 1
1.9 TDI

ASZ

 2 09/2002-09/2004 1896 96 130 1
OCTAVIA Combi (1U5) Estate 07/1998-12/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.8 20V

AGN

 1 07/1998-07/2000 1781 92 125 1
1.8 T

AGU

ARX

ARZ

AUM

 1 07/1998-12/2010 1781 110 150 1
1.8 T 4x4

ARX

 1 05/2001-05/2006 1781 110 150 3
2.0

AEG

APK

AQY

AZH

AZJ

 1 04/1999-05/2007 1984 85 116 1
2.0 4x4

AZH

AZJ

 1 08/2000-09/2004 1984 85 116 3
2.0 4x4

ATF

 1 01/2000-12/2010 1984 88 120 3
1.9 TDI

AXR

 2 08/2000-12/2010 1896 74 100 1
1.9 TDI

AHF

ASV

 2 07/1998-01/2006 1896 81 110 1
1.9 TDI

ASZ

 2 09/2002-09/2004 1896 96 130 1
1.9 TDI 4x4

ATD

 2 09/2000-01/2006 1896 74 100 3
OCTAVIA (1U5) Estate Van 08/2000-03/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.9 TDI

ALH

 2 08/2000-03/2010 1896 66 90 1
OCTAVIA II / LAURA (1Z3) Hatchback 02/2004-06/2013
Vehicle Engine Fuel Date CC KW CV Traction
2.0 TDI

BMM

 2 11/2005-05/2010 1968 103 140 1
2.0 TDI 16V

BKD

CFHC

CLCB

 2 02/2004-04/2013 1968 103 140 1
RAPID III (NA2) Saloon 09/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI

DSHA

 1 05/2020- 999 81 110 1
RAPID III (NH3, NK3, NK6) Hatchback 07/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI

CHZB

DKLD

 1 06/2017-12/2019 999 70 95 1
1.0 TSI

CHZC

DKRC

 1 06/2017-12/2019 999 81 110 1
1.2

CGPC

 1 07/2012-06/2015 1198 55 75 1
1.2 TSI

CBZA

 1 07/2012-05/2015 1197 63 86 1
1.2 TSI

CJZC

 1 05/2015-12/2019 1197 66 90 1
1.2 TSI

CBZB

 1 07/2012-05/2015 1197 77 105 1
1.2 TSI

CJZD

 1 05/2015-12/2019 1197 81 110 1
1.4 TSI

CAXA

 1 07/2012-06/2015 1390 90 122 1
1.4 TSI

CZCA

 1 05/2015-03/2022 1395 92 125 1
1.6

CFNA

 1 07/2012-06/2015 1598 77 105 1
1.6

CWVA

 1 05/2015-03/2022 1598 81 110 1
1.6 SRE

CWVB

 1 06/2015-03/2022 1598 66 90 1
1.2 LPG

CBZA

 18 07/2012-05/2015 1197 63 86 1
1.2 LPG

CGPC

 18 07/2012-06/2015 1198 55 75 1
1.4 TDI

CUSB

 2 05/2015-12/2019 1422 66 90 1
1.6 TDI

CAYB

 2 08/2013-05/2015 1598 66 90 1
1.6 TDI

CAYC

CLNA

 2 07/2012-12/2019 1598 77 105 1
1.6 TDI

CXMA

 2 05/2015-12/2019 1598 85 115 1
RAPID III Spaceback (NH1) Hatchback 07/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI

CHZB

DKLD

 1 06/2017-12/2019 999 70 95 1
1.0 TSI

CHZC

DKRC

 1 06/2017-12/2019 999 81 110 1
1.2

CGPC

 1 07/2012-06/2015 1198 55 75 1
1.2 TSI

CBZA

 1 07/2012-05/2015 1197 63 86 1
1.2 TSI

CJZC

 1 05/2015-12/2019 1197 66 90 1
1.2 TSI

CBZB

 1 07/2012-05/2015 1197 77 105 1
1.2 TSI

CJZD

 1 05/2015-12/2019 1197 81 110 1
1.4 TSI

CAXA

 1 07/2012-06/2015 1390 90 122 1
1.4 TSI

CZCA

 1 05/2015-12/2019 1395 92 125 1
1.6

CFNA

 1 07/2012-06/2015 1598 77 105 1
1.6 SRE

CWVA

 1 05/2015-12/2019 1598 81 110 1
1.2 LPG

CBZA

 18 07/2012-05/2015 1197 63 86 1
1.2 LPG

CGPC

 18 07/2012-06/2015 1198 55 75 1
1.4 TDI

CUSB

 2 05/2015-12/2019 1422 66 90 1
1.6 TDI

CAYB

 2 08/2013-05/2015 1598 66 90 1
1.6 TDI

CAYC

CLNA

 2 07/2012-12/2019 1598 77 105 1
1.6 TDI

CXMA

 2 05/2015-12/2019 1598 85 115 1
ROOMSTER / PRAKTIK (5J7) MPV 03/2006-05/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.2

BME

 1 05/2006-01/2007 1198 47 64 1
1.2

BZG

CGPA

 1 01/2007-05/2015 1198 51 70 1
1.2 TSI

CBZA

 1 03/2010-05/2015 1197 63 86 1
1.2 TSI

CBZB

 1 03/2010-05/2015 1197 77 105 1
1.4 LPG

BXW

CGGB

 18 03/2010-05/2015 1390 63 86 1
1.6 LPG

BTS

 18 06/2006-07/2010 1598 77 105 1
1.2 TDI

CFWA

 2 03/2010-05/2015 1199 55 75 1
1.4 TDI

BNM

 2 07/2006-03/2010 1422 51 70 1
1.6 TDI

CAYC

 2 03/2010-05/2015 1598 77 105 1
1.9 TDI

AXR

 2 03/2006-05/2006 1896 74 101 1
1.9 TDI

BLS

BSW

 2 09/2006-03/2010 1896 77 105 1
ROOMSTER / PRAKTIK (5J) Estate Van 03/2007-05/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BXW

CGGB

 1 03/2007-05/2015 1390 63 86 1
1.2 TDI

CFWA

 2 03/2010-05/2015 1199 55 75 1
1.4 TDI

BMS

BNV

 2 03/2007-03/2010 1422 59 80 1
1.6 TDI

CAYB

 2 03/2010-05/2015 1598 66 90 1
SCALA (NW1) Hatchback 02/2019-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI

DKLA

 1 02/2019- 999 70 95 1
1.0 TSI

DLAA

 1 08/2020- 999 81 110 1
1.0 TSI

DKRF

 1 02/2019- 999 85 116 1
1.5 TSI

DADA

DPCA

 1 02/2019- 1498 110 150 1
1.6 SRE 1 02/2019- 1598 81 110 1
1.0 TGI CNG

DBYA

 16 11/2019- 999 66 90 1
1.6 TDI 2 09/2019- 1598 70 95 1
1.6 TDI

DGTA

 2 02/2019- 1598 85 116 1
SKODA (SVW)
FABIA (551) Hatchback 12/2008-12/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.4 1 12/2008-12/2015 1390 63 86 1
VW
BORA / JETTA IV (1J2) Saloon 10/1998-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AHW

AKQ

APE

AXP

BCA

 1 03/2000-05/2005 1390 55 75 1
1.6

AEH

AKL

APF

 1 10/1998-05/2005 1595 74 101 1
1.6

AVU

BFQ

 1 08/2000-05/2005 1595 75 102 1
1.6 1 06/2002-10/2004 1595 78 107 1
1.6 16V

ATN

AUS

AZD

BCB

 1 05/2000-05/2005 1598 77 105 1
1.6 FSI

BAD

 1 01/2002-05/2005 1598 81 110 1
1.8

AGN

BAF

 1 10/1998-05/2005 1781 92 125 1
1.8 1 10/2000-05/2001 1781 110 150 1
1.8 T

AGU

ARX

AUM

AWD

AWW

 1 05/2000-05/2005 1781 110 150 1
1.8 T

AUQ

AWP

 1 03/2002-05/2005 1781 132 180 1
2.0

AEG

APK

AQY

AVH

AZG

AZH

AZJ

BBW

BER

BEV

BHP

CBPA

CFEA

 1 10/1998-12/2013 1984 85 115 1
2.3 V5

AGZ

 1 10/1998-10/2000 2324 110 150 1
2.3 V5

AQN

 1 10/2000-05/2005 2324 125 170 1
2.3 V5 4motion

AGZ

 1 12/1998-10/2000 2324 110 150 3
2.8 VR6 1 11/1998-07/2005 2792 130 177 1
2.8 VR6 1 02/2002-07/2005 2792 147 200 1
1.9 SDI

AGP

AQM

 2 10/1998-05/2005 1896 50 68 1
1.9 TDI

AGR

ALH

 2 10/1998-05/2005 1896 66 90 1
1.9 TDI

ATD

AXR

BEW

 2 09/2000-05/2005 1896 74 101 1
1.9 TDI

AHF

ASV

 2 10/1998-06/2001 1896 81 110 1
1.9 TDI

AJM

AUY

 2 12/1998-01/2002 1896 85 115 1
BORA Variant / JETTA IV (1J6) Estate 05/1999-05/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AHW

AXP

BCA

 1 09/2001-05/2005 1390 55 75 1
1.6

AEH

AKL

APF

 1 05/1999-05/2005 1595 74 100 1
1.6

AVU

BFQ

 1 08/2000-05/2005 1595 75 102 1
1.6 16V

ATN

AUS

AZD

BCB

 1 02/2000-05/2005 1598 77 105 1
1.6 FSI

BAD

 1 01/2002-05/2005 1598 81 110 1
1.8 T

AGU

ARX

AUM

AWD

AWW

 1 05/2000-05/2005 1781 110 150 1
1.8 T

AUQ

AWP

 1 05/2002-05/2005 1781 132 180 1
2.0

APK

AQY

AVH

AZG

AZH

AZJ

BEV

 1 05/1999-05/2005 1984 85 115 1
2.3 V5

AGZ

 1 05/1999-10/2000 2324 110 150 1
2.3 V5

AQN

 1 10/2000-05/2005 2324 125 170 1
1.9 TDI

AGR

ALH

 2 07/2004-05/2005 1896 66 90 1
1.9 TDI

ATD

AXR

BEW

 2 09/2000-05/2005 1896 74 101 1
1.9 TDI

AHF

ASV

 2 05/1999-06/2001 1896 81 110 1
1.9 TDI

AJM

AUY

 2 05/1999-06/2001 1896 85 115 1
BORA / JETTA IV (9M2) Saloon 01/2005-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.8 Turbo 1 01/2005-12/2014 1781 132 179 1
2.0

CBPA

 1 01/2005-12/2014 1984 85 116 1
2.0 Total Flex

CFEA

 19 02/2009-07/2010 1984 85 116 1
2.0 Total Flex 19 02/2009-08/2010 1984 88 120 1
GOLF IV (1J1) Hatchback 08/1997-04/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.0 1 08/1997-05/2002 998 51 69 1
1.0 Turbo 1 08/1997-05/2002 998 82 111 1
1.4 16V

AHW

AKQ

APE

AXP

BCA

 1 10/1997-05/2004 1390 55 75 1
1.6 1 12/1998-05/2002 1595 68 92 1
1.6

AEH

AKL

APF

 1 08/1997-05/2004 1595 74 100 1
1.6

AVU

BFQ

 1 08/2000-06/2005 1595 75 102 1
1.6 1 08/2003-06/2005 1595 78 107 1
1.6

BAH

 1 02/2001-03/2007 1598 74 101 1
1.6 16V

ATN

AUS

AZD

BCB

 1 02/2000-06/2005 1598 77 105 1
1.6 FSI

BAD

 1 01/2002-06/2005 1598 81 110 1
1.8 1 10/1997-09/1999 1781 66 90 1
1.8 1 04/1998-05/2002 1781 77 105 1
1.8

AGN

 1 08/1997-06/2005 1781 92 125 1
2.0

AEG

APK

AQY

AVH

AZG

AZJ

BER

BEV

 1 07/1998-05/2004 1984 85 115 1
2.8 VR6 1 01/1999-12/2002 2792 130 177 1
2.8 VR6 1 03/2002-06/2005 2792 147 200 1
1.0 13 08/1998-05/2002 998 43 58 1
2.0 BiFuel

BEH

 16 05/2002-05/2003 1984 85 116 1
1.6 TotalFlex 19 02/2001-04/2008 1598 76 103 1
1.9 SDI

AGP

AQM

 2 08/1997-06/2005 1896 50 68 1
1.9 TD 2 10/1997-09/1999 1896 55 75 1
1.9 TDI

AGR

ALH

 2 10/1997-05/2004 1896 66 90 1
1.9 TDI

ATD

AXR

BEW

 2 09/2000-06/2005 1896 74 101 1
1.9 TDI

AHF

ASV

 2 08/1997-05/2004 1896 81 110 1
1.9 TDI

AJM

AUY

 2 12/1998-06/2001 1896 85 115 1
1.9 TDI

ASZ

 2 11/2000-06/2005 1896 96 130 1
1.9 TDI

ARL

 2 05/2000-06/2005 1896 110 150 1
GOLF IV Furgoneta (1J1) Hatchback Van 10/1997-05/2004
Vehicle Engine Fuel Date CC KW CV Traction
1.9 SDI

AQM

 2 11/1998-05/2004 1896 50 68 1
1.9 TDI

AGR

 2 05/2000-09/2002 1896 66 90 1
1.9 TDI

AHF

 2 10/1997-05/2004 1896 81 110 1
1.9 TDI

ASZ

 2 04/2001-05/2004 1896 96 130 1
GOLF IV VAN Variant / JETTA IV (1J5) Estate Van 05/1999-06/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.4

AXP

BCA

 1 05/2000-06/2006 1390 55 75 1
1.6

AUS

AZD

BCB

 1 05/2000-06/2006 1598 77 105 1
1.9 SDI

AQM

 2 05/1999-05/2006 1896 50 68 1
1.9 TDI

AGR

ALH

 2 05/1999-05/2006 1896 66 90 1
1.9 TDI

ATD

AXR

 2 02/2000-06/2006 1896 74 101 1
1.9 TDI

AHF

ASV

 2 05/1999-05/2006 1896 81 110 1
1.9 TDI 2 04/2001-05/2006 1896 96 131 1
GOLF IV Variant / JETTA IV (1J5) Estate 05/1999-06/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AHW

AKQ

APE

AXP

BCA

 1 05/1999-06/2006 1390 55 75 1
1.6

AEH

AKL

APF

 1 05/1999-04/2002 1595 74 101 1
1.6

AVU

BFQ

 1 08/2000-06/2006 1595 75 102 1
1.6 16V

ATN

AUS

AZD

BCB

 1 02/2000-06/2006 1598 77 105 1
1.6 FSI

BAD

 1 01/2002-06/2006 1598 81 110 1
1.6 FSI 1 10/2003-07/2004 1598 85 116 1
1.8 T

AGU

ARZ

AUM

 1 05/2000-06/2006 1781 110 150 1
2.0

APK

AQY

AZJ

 1 05/1999-06/2006 1984 85 115 1
2.0 4motion

ATF

 1 12/1999-06/2006 1984 88 120 3
2.3 V5

AGZ

 1 05/1999-06/2006 2324 110 150 1
2.3 V5

AQN

 1 10/2000-06/2006 2324 125 170 1
2.0 Bi-Fuel

BEH

 16 02/2002-06/2006 1984 85 116 1
1.9 SDI

AGP

AQM

 2 05/1999-06/2006 1896 50 68 1
1.9 TDI

AGR

ALH

 2 05/1999-05/2006 1896 66 90 1
1.9 TDI

ATD

AXR

 2 09/2000-06/2006 1896 74 101 1
1.9 TDI

AHF

ASV

 2 05/1999-06/2001 1896 81 110 1
1.9 TDI

AJM

AUY

 2 08/1999-06/2001 1896 85 115 1
1.9 TDI

ASZ

 2 11/2000-06/2006 1896 96 130 1
GOLF V (9B3) Hatchback 03/2006-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

BAH

CCRA

CFZA

 1 03/2007-12/2010 1598 74 101 1
2.0

BER

BEV

BHP

CBPA

 1 01/2007-12/2010 1984 85 116 1
1.6 TotalFlex

BAH

BPA

 19 03/2007-03/2014 1598 74 101 1
1.6 TotalFlex 19 05/2008-06/2014 1598 77 104 1
JETTA V / BORA / VENTO (1K2) Saloon 09/2004-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 05/2005-10/2010 1984 85 116 1
NEW BEETLE / BETTLE / NOVO FUSCA (9C1, 1C1) Hatchback 01/1998-07/2012
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BCA

 1 11/2001-09/2010 1390 55 75 1
1.6

AWH

 1 10/1999-09/2000 1595 74 100 1
1.6

AYD

BFS

 1 06/2000-09/2010 1595 75 102 1
1.8 T

AGU

APH

AVC

AWU

AWV

BKF

 1 10/1999-09/2010 1781 110 150 1
2.0

AEG

APK

AQY

AVH

AZG

AZJ

BER

BEV

 1 01/1998-09/2010 1984 85 115 1
2.3 V5

AQN

 1 10/2000-09/2010 2324 125 170 1
2.5

BPR

BPS

 1 07/2005-09/2010 2480 110 150 1
1.9 TDI

ALH

 2 01/1998-06/2004 1896 66 90 1
1.9 TDI

ATD

AXR

BEW

 2 02/2001-09/2010 1896 74 101 1
1.9 TDI

BSW

 2 07/2005-09/2010 1896 77 105 1
NEW BEETLE / BETTLE (1Y7) Convertible 09/2002-07/2012
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BCA

 1 01/2003-09/2010 1390 55 75 1
1.6

BFS

 1 01/2003-09/2010 1595 75 102 1
1.8 T

AWU

AWV

BKF

 1 01/2003-09/2010 1781 110 150 1
2.0

AZJ

BDC

BEV

BGD

 1 09/2002-10/2010 1984 85 115 1
2.5

BPR

BPS

 1 07/2005-09/2010 2480 110 150 1
1.9 TDI

AXR

BEW

 2 06/2003-07/2005 1896 74 100 1
1.9 TDI

BSW

 2 07/2005-09/2010 1896 77 105 1
POLO III CLASSIC / DERBY / FLIGHT (6V2) Saloon 01/1995-11/2009
Vehicle Engine Fuel Date CC KW CV Traction
1.6

BAH

CCRA

 1 11/2002-07/2006 1598 74 101 1
POLO III PLAYA / IBIZA () Hatchback 01/1995-11/2009
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 01/1995-11/2009 1598 74 101 1
POLO IV (9N_, 9A_) Hatchback 10/2001-10/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.2

AWY

BMD

 1 01/2002-05/2007 1198 40 54 1
1.2

BBM

 1 05/2007-11/2009 1198 44 60 1
1.2 12V

AZQ

BME

 1 10/2001-07/2007 1198 47 64 1
1.2 12V

BZG

 1 05/2007-11/2009 1198 51 69 1
1.4

BLM

 1 08/2002-11/2009 1390 61 83 1
1.4 16V

AUA

BBY

BKY

 1 10/2001-05/2008 1390 55 75 1
1.4 16V

BUD

 1 05/2006-11/2009 1390 59 80 1
1.4 16V

AUB

BBZ

 1 10/2001-05/2008 1390 74 101 1
1.4 FSI

AXU

 1 02/2002-07/2006 1390 63 86 1
1.6 1 08/2002-05/2005 1598 74 101 1
1.6 16V

BTS

 1 05/2006-11/2009 1598 77 105 1
1.8 GTI

BJX

 1 09/2005-11/2009 1781 110 150 1
1.8 GTi Cup Edition

BBU

 1 05/2006-11/2009 1781 132 180 1
1.4 BiFuel

BUD

 18 05/2006-11/2009 1390 60 82 1
1.6 Flex 19 06/2008-04/2009 1599 74 101 1
1.4 TDI

BNM

BWB

 2 04/2005-11/2009 1422 51 70 1
1.4 TDI

AMF

BAY

 2 10/2001-06/2005 1422 55 75 1
1.4 TDI

BMS

BNV

 2 04/2005-11/2009 1422 59 80 1
1.9 TDI

ATD

AXR

BMT

 2 10/2001-11/2009 1896 74 101 1
1.9 TDI

ASZ

BLT

 2 11/2003-11/2009 1896 96 130 1
POLO IV (9N2) Saloon 09/2002-12/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.9 TDI

ATD

 2 07/2003-12/2010 1896 74 101 1
POLO IV / DERBY (9A4, 9A2, 9N2, 9A6) Saloon 09/2002-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

ARA

 1 02/2003-10/2003 999 58 79 1
1.4

BBY

BKY

 1 11/2002-04/2012 1390 55 75 1
1.4

BLM

 1 12/2003-08/2010 1390 61 83 1
1.4

BBZ

 1 11/2003-06/2005 1390 74 101 1
1.6

BAH

CCRA

CFZA

 1 09/2002- 1598 74 101 1
1.6 Flex

BPA

 19 12/2004-10/2014 1598 76 103 1
1.6 Flex

CCRA

 19 05/2008-10/2014 1598 77 104 1
1.6 TotalFlex

BPA

CCRA

 19 10/2004-06/2006 1598 74 101 1
2.0 Flex

CFEA

 19 10/2008-12/2014 1984 88 120 1
1.4 TDI

BAY

 2 07/2003-06/2005 1422 55 75 1
1.9 TDI

ATD

 2 09/2002- 1896 74 101 1
POLO V (6R1, 6C1) Hatchback 03/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYA

 1 01/2014-10/2017 999 44 60 1
1.0

CHYB

 1 01/2014-10/2017 999 55 75 1
1.0 TSI

CHZB

 1 11/2014-10/2017 999 70 95 1
1.0 TSI

CHZC

 1 11/2014-10/2017 999 81 110 1
1.2

CGPB

 1 06/2009-05/2014 1198 44 60 1
1.2

CGPA

 1 06/2009-05/2014 1198 51 70 1
1.2 1 08/2011-02/2018 1198 55 75 1
1.2 TSI 1 06/2009- 1197 63 86 1
1.2 TSI

CBZC

 1 05/2011-05/2014 1197 66 90 1
1.2 TSI

CBZB

 1 11/2009-05/2022 1197 77 105 1
1.2 TSI

CJZD

 1 01/2014-10/2017 1197 81 110 1
1.2 TSI 16V

CJZC

 1 02/2014-10/2017 1197 66 90 1
1.4 (6R1)

CDDA

CGGB

CLPA

 1 03/2009-05/2014 1390 63 85 1
1.4 GTi

CAVE

CTHE

 1 05/2010-05/2014 1390 132 180 1
1.4 TSI

CPTA

 1 10/2012-05/2014 1395 103 140 1
1.4 TSI

CZEA

 1 05/2014-10/2017 1395 110 150 1
1.6 1 05/2010- 1598 63 86 1
1.6

CWVB

 1 07/2014-10/2017 1598 66 90 1
1.6

CFNA

CLSA

 1 01/2010-05/2022 1598 77 105 1
1.6

CWVA

 1 07/2014-10/2017 1598 81 110 1
1.8 GTI 1 11/2014- 1798 136 185 1
1.8 GTI

DAJA

DAJB

 1 11/2014-10/2017 1798 141 192 1
1.8 GTI 230

DAJA

 1 04/2016-10/2017 1798 169 230 1
1.4 BiFuel

CMAA

 18 03/2010-01/2011 1390 60 82 1
1.6 BiFuel

CNKA

 18 01/2011-05/2014 1598 60 82 1
1.2 TDI

CFWA

 2 10/2009-05/2014 1199 55 75 1
1.4 TDI

CUSA

CYZB

 2 03/2014-10/2017 1422 55 75 1
1.4 TDI

CUSB

 2 02/2014-10/2017 1422 66 90 1
1.4 TDI

CUTA

CYZA

 2 05/2014-10/2017 1422 77 105 1
1.5 TDI 2 07/2014- 1498 66 90 2
1.6 TDI

CAYA

 2 06/2009-05/2014 1598 55 75 1
1.6 TDI

CAYB

 2 06/2009-05/2014 1598 66 90 1
1.6 TDI

CAYC

CLNA

 2 06/2009-08/2015 1598 77 105 1
POLO V (6R) Hatchback Van 03/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYA

 1 01/2014-10/2017 999 44 60 1
1.0

CHYB

 1 01/2014-10/2017 999 55 75 1
1.0 TSI

CHZB

 1 11/2014-10/2017 999 70 95 1
1.0 TSI 1 11/2014-10/2017 999 81 110 1
1.2 TSI

CJZC

 1 02/2014-10/2017 1197 66 90 1
1.2 TSI

CBZC

 1 05/2011-05/2014 1197 66 90 1
1.2 TSI

CJZD

 1 01/2014-10/2017 1197 81 110 1
1.2 TSi BlueMotion

CBZB

 1 11/2009-05/2014 1197 77 105 1
1.4

CGGB

 1 03/2009-05/2014 1390 63 86 1
1.4 GTi

CAVE

 1 05/2010-05/2014 1390 132 179 1
1.4 TSI

CZEA

 1 05/2014-10/2017 1395 110 150 1
1.2 TDi BlueMotion

CFWA

 2 10/2009-05/2014 1199 55 75 1
1.4 TDI

CUSA

CYZB

 2 03/2014-10/2017 1422 55 75 1
1.4 TDI

CUSB

 2 02/2014-10/2017 1422 66 90 1
1.4 TDI 2 03/2014-10/2017 1422 77 105 1
1.6 TDI

CAYA

 2 06/2009-05/2014 1598 55 75 1
1.6 TDI

CAYC

 2 06/2009-05/2014 1598 77 105 1
1.6 TDi BlueMotion

CAYB

 2 06/2009-05/2014 1598 66 90 1
POLO V / VENTO (602, 604, 612, 614) Saloon 05/2009-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TSI

CZCA

 1 05/2016-03/2020 1395 92 125 1
1.6

CWVB

 1 05/2015-03/2020 1598 66 90 1
POLO V VIVO (6S1, 6S3) Hatchback 02/2010-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 1 02/2010-09/2017 1390 55 75 1
POLO VI (AW1, BZ1, AE1) Hatchback 06/2017-
Vehicle Engine Fuel Date CC KW CV Traction
1.0

CHYC

DFNB

 1 08/2017-02/2020 999 48 65 1
1.0

CHYB

 1 06/2017-08/2021 999 55 75 1
1.0 MPi

DFNA

DSGB

 1 09/2018- 999 59 80 1
1.0 TSI

CHZL

DKLA

 1 06/2017- 999 70 95 1
1.0 TSI

DLAA

 1 07/2020- 999 81 110 1
1.0 TSI

CHZJ

DKJA

DKRF

 1 09/2017- 999 85 116 1
1.6 MSi 1 09/2017- 1598 81 110 1
1.0 TGI

DBYA

 16 09/2017- 999 66 90 1
1.6 TDI

DGTC

 2 11/2017-07/2019 1598 59 80 1
1.6 TDI

DGTD

 2 11/2017-02/2021 1598 70 95 1
TAIGO (CS1) SUV 09/2021-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI 1 09/2021- 999 70 95 1
1.0 TSI 1 09/2021- 999 81 110 1
1.5 TSI 1 09/2021- 1498 110 150 1
T-CROSS (C11, D31) SUV 12/2018-
Vehicle Engine Fuel Date CC KW CV Traction
1.0 TSI

CHZL

DKLA

DLAC

 1 12/2018- 999 70 95 1
1.0 TSI

DLAA

 1 06/2020- 999 81 110 1
1.0 TSI

DKJA

DKRF

 1 12/2018- 999 85 116 1
1.5 TSI

DADA

DPCA

 1 01/2020- 1498 110 150 1
1.6 TDI

DGTD

 2 12/2018- 1598 70 95 1
VW (SVW)
LAVIDA (181) Saloon 04/2008-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TSI 1 03/2010-12/2013 1390 96 131 1
1.6 1 04/2008-08/2012 1598 77 105 1
2.0 1 04/2008-08/2012 1984 88 120 1
LAVIDA II (182, 184, 186) Saloon 08/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 TSI

CYAA

 1 07/2015- 1197 81 110 1
1.4 TSI 1 09/2012-12/2013 1390 96 131 1
1.4 TSI 1 10/2013- 1395 96 131 1
1.5

DLFA

 1 07/2019- 1498 82 112 1
1.6 1 08/2012-12/2014 1598 77 105 1
1.6 1 03/2013-02/2019 1598 81 110 1
280TSi 1 05/2016- 1395 110 150 1
CNG 16 02/2015-09/2019 1598 70 95 1
ZHONGHUA (BRILLIANCE)
H330 () Saloon 04/2013-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1 04/2013- 1498 77 105 1
H530 () Saloon 08/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

4A92A

4A92S

 1 08/2011- 1590 87 118 1
JUNJIE FSV () Saloon 03/2006-
Vehicle Engine Fuel Date CC KW CV Traction
1.5

4A91S

 1 08/2010-12/2015 1499 77 105 1
Return
