Product 78BD5603-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073147127
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5603-2
Weight (gr.)
11804
R90 Homologation
R90 90R-02C0433/0090
Measures
Ø280x22x36.5
Brake Disc Type: Vented
Minimum thickness [mm]: 19
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 100
Wheel Hub Diameter [mm]: 65
Reference applications
Brand OE Reference
VW 1J0 615 301 E
VW 1J0 615 301 M
VW 1J0 615 301 P
Maker Cross reference
ATE 24.0122-0150.1
ATE 422150
ATE 522150
BENDIX ANTIGUO 562039B
BOSCH 0 986 478 852
BREMBO 09.7012.10
BREMBO 09.7012.11
BREMBO 09.7012.14
DELPHI LOCKHEED BG3036
FERODO DDF928
LETEC LBA015V
NECTO WN916
ROAD HOUSE 6546.10
SANLI SL37194
TRW DF2804
AUDI
A3 (8L1) Hatchback 09/1996-09/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.6

AVU

BFQ

 1 08/2000-05/2003 1595 75 102 1
1.8

AGN

APG

 1 09/1996-05/2003 1781 92 125 1
1.9 TDI

AGR

ALH

 2 09/1996-07/2001 1896 66 90 1
1.9 TDI

AHF

ASV

 2 08/1997-07/2001 1896 81 110 1
BESTURN (FAW)
B30 () Saloon 11/2015-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 11/2015- 1598 80 109 1
SEAT
LEON (1M1) Hatchback 11/1999-06/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.6

AEH

AKL

 1 11/1999-06/2006 1595 74 100 1
1.6

BFQ

 1 10/2005-06/2006 1595 75 102 1
1.8 20V

AGN

APG

 1 11/1999-06/2006 1781 92 125 1
1.9 SDI

AQM

 2 11/1999-06/2006 1896 50 68 1
1.9 TDI

AGR

ALH

 2 11/1999-06/2006 1896 66 90 1
1.9 TDI

AXR

 2 10/2005-06/2006 1896 74 100 1
1.9 TDI

AHF

ASV

 2 11/1999-06/2006 1896 81 110 1
1.9 TDI

ASZ

 2 05/2003-06/2006 1896 96 130 1
TOLEDO II (1M2) Saloon 10/1998-05/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.8 1 05/2001-04/2004 1781 132 179 1
1.8 1 05/2002-05/2003 1781 154 209 1
1.8 20V

AGN

APG

 1 10/1998-07/2004 1781 92 125 1
1.8 20VT

APP

ARY

AUQ

 1 09/2000-07/2004 1781 132 180 1
1.9 SDI 2 11/1999-06/2004 1896 50 68 2
1.9 TDI

AGR

ALH

 2 03/1999-07/2004 1896 66 90 1
1.9 TDI

AXR

 2 08/2005-05/2006 1896 74 101 1
1.9 TDI

AHF

ASV

 2 10/1998-07/2004 1896 81 110 1
1.9 TDI

ASZ

 2 05/2003-05/2006 1896 96 130 1
SKODA
OCTAVIA (1U2) Hatchback 09/1996-12/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.4

AMD

 1 04/1999-03/2001 1397 44 60 1
1.4 16V

AXP

BCA

 1 09/2000-12/2010 1390 55 75 1
1.6

AEH

AKL

 1 02/1997-12/2007 1595 74 101 1
1.6

AVU

BFQ

 1 11/2000-12/2010 1595 75 102 1
1.6

AEE

 1 09/1996-09/2004 1598 55 75 1
1.8

AGN

 1 09/1996-07/2000 1781 92 125 1
1.8 T

AGU

ARX

ARZ

AUM

 1 08/1997-12/2010 1781 110 150 1
1.8 T 4x4

ARX

 1 05/2001-05/2006 1781 110 150 3
2.0

AEG

APK

AQY

AZH

AZJ

 1 04/1999-05/2007 1984 85 116 1
1.9 SDI

AGP

AQM

 2 06/1997-12/2003 1896 50 68 1
1.9 TDI

AGR

ALH

 2 09/1996-03/2010 1896 66 90 1
1.9 TDI

AXR

 2 10/2005-12/2010 1896 74 100 1
1.9 TDI

AHF

ASV

 2 08/1997-01/2006 1896 81 110 1
1.9 TDI

ASZ

 2 09/2002-09/2004 1896 96 130 1
OCTAVIA Combi (1U5) Estate 07/1998-12/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AXP

BCA

 1 08/2000-12/2010 1390 55 75 1
1.6

AEH

AKL

 1 07/1998-12/2007 1595 74 101 1
1.6

AVU

BFQ

 1 09/2000-12/2010 1595 75 102 1
1.6

AEE

 1 07/1998-09/2004 1598 55 75 1
1.8 T

AGU

ARX

ARZ

AUM

 1 07/1998-12/2010 1781 110 150 1
1.8 T 4x4

ARX

 1 05/2001-05/2006 1781 110 150 3
2.0

AEG

APK

AQY

AZH

AZJ

 1 04/1999-05/2007 1984 85 116 1
2.0 4x4

AZH

AZJ

 1 08/2000-09/2004 1984 85 116 3
2.0 4x4

ATF

 1 01/2000-12/2010 1984 88 120 3
1.9 SDI

AGP

AQM

 2 07/1998-12/2003 1896 50 68 1
1.9 TDI

AGR

ALH

 2 07/1998-03/2010 1896 66 90 1
1.9 TDI

AXR

 2 08/2000-12/2010 1896 74 100 1
1.9 TDI

AHF

ASV

 2 07/1998-01/2006 1896 81 110 1
1.9 TDI

ASZ

 2 09/2002-09/2004 1896 96 130 1
1.9 TDI 4x4

AGR

 2 11/1999-02/2006 1896 66 90 3
1.9 TDI 4x4

ATD

 2 09/2000-01/2006 1896 74 100 3
OCTAVIA (1U5) Estate Van 08/2000-03/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.9 D

AQM

 2 08/2000-12/2003 1896 50 68 1
1.9 TDI

ALH

 2 08/2000-03/2010 1896 66 90 1
OCTAVIA II / LAURA (1Z3) Hatchback 02/2004-06/2013
Vehicle Engine Fuel Date CC KW CV Traction
2.0 TDI

BMM

 2 11/2005-05/2010 1968 103 140 1
2.0 TDI 16V

BKD

CFHC

CLCB

 2 02/2004-04/2013 1968 103 140 1
VW
BORA / JETTA IV (1J2) Saloon 10/1998-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AHW

AKQ

APE

AXP

BCA

 1 03/2000-05/2005 1390 55 75 1
1.6

AEH

AKL

APF

 1 10/1998-05/2005 1595 74 101 1
1.6

AVU

BFQ

 1 08/2000-05/2005 1595 75 102 1
1.6 1 06/2002-10/2004 1595 78 107 1
1.6 16V

ATN

AUS

AZD

BCB

 1 05/2000-05/2005 1598 77 105 1
1.6 FSI

BAD

 1 01/2002-05/2005 1598 81 110 1
1.8

AGN

BAF

 1 10/1998-05/2005 1781 92 125 1
1.8 4motion

AGN

 1 02/1999-05/2005 1781 92 125 3
2.0

AEG

APK

AQY

AVH

AZG

AZH

AZJ

BBW

BER

BEV

BHP

CBPA

CFEA

 1 10/1998-12/2013 1984 85 115 1
2.0 4motion

AZH

AZJ

 1 04/2000-05/2005 1984 85 115 3
1.9 SDI

AGP

AQM

 2 10/1998-05/2005 1896 50 68 1
1.9 TDI

AGR

ALH

 2 10/1998-05/2005 1896 66 90 1
1.9 TDI

ATD

AXR

BEW

 2 09/2000-05/2005 1896 74 101 1
1.9 TDI

AHF

ASV

 2 10/1998-06/2001 1896 81 110 1
1.9 TDI

AJM

AUY

 2 12/1998-01/2002 1896 85 115 1
1.9 TDI 4motion

AGR

 2 11/1998-04/2002 1896 66 90 3
1.9 TDI 4motion

ATD

 2 09/2000-05/2005 1896 74 101 3
1.9 TDI 4motion

AJM

AUY

 2 02/1999-06/2001 1896 85 115 3
1.9 TDI 4motion

ASZ

 2 11/2000-05/2005 1896 96 130 3
BORA Variant / JETTA IV (1J6) Estate 05/1999-05/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AHW

AXP

BCA

 1 09/2001-05/2005 1390 55 75 1
1.6

AEH

AKL

APF

 1 05/1999-05/2005 1595 74 100 1
1.6

AVU

BFQ

 1 08/2000-05/2005 1595 75 102 1
1.6 16V

ATN

AUS

AZD

BCB

 1 02/2000-05/2005 1598 77 105 1
1.6 FSI

BAD

 1 01/2002-05/2005 1598 81 110 1
1.8 4motion

AGN

 1 05/1999-05/2005 1781 92 125 3
2.0

APK

AQY

AVH

AZG

AZH

AZJ

BEV

 1 05/1999-05/2005 1984 85 115 1
2.0 4motion

AZH

AZJ

 1 04/2000-05/2005 1984 85 115 3
2.0 4motion

ATF

 1 12/1999-05/2003 1984 88 120 3
1.9 TDI

AGR

ALH

 2 07/2004-05/2005 1896 66 90 1
1.9 TDI

ATD

AXR

BEW

 2 09/2000-05/2005 1896 74 101 1
1.9 TDI

AHF

ASV

 2 05/1999-06/2001 1896 81 110 1
1.9 TDI

AJM

AUY

 2 05/1999-06/2001 1896 85 115 1
1.9 TDI

ASZ

 2 11/2000-05/2005 1896 96 130 1
1.9 TDI 4motion

ATD

 2 09/2000-05/2005 1896 74 101 3
1.9 TDI 4motion

AJM

AUY

 2 05/1999-06/2001 1896 85 115 3
1.9 TDI 4motion

ASZ

 2 11/2000-05/2005 1896 96 130 3
BORA / JETTA IV (9M2) Saloon 01/2005-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.8 Turbo 1 01/2005-12/2014 1781 132 179 1
2.0

CBPA

 1 01/2005-12/2014 1984 85 116 1
2.0 Total Flex

CFEA

 19 02/2009-07/2010 1984 85 116 1
2.0 Total Flex 19 02/2009-08/2010 1984 88 120 1
FOX III (5Z5) Hatchback 08/2014-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 10/2015- 1598 75 102 1
1.6 1 09/2014-09/2017 1598 81 110 1
GOLF IV (1J1) Hatchback 08/1997-04/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.0 1 08/1997-05/2002 998 51 69 1
1.0 Turbo 1 08/1997-05/2002 998 82 111 1
1.4 16V

AHW

AKQ

APE

AXP

BCA

 1 10/1997-05/2004 1390 55 75 1
1.6 1 12/1998-05/2002 1595 68 92 1
1.6

AEH

AKL

APF

 1 08/1997-05/2004 1595 74 100 1
1.6

AVU

BFQ

 1 08/2000-06/2005 1595 75 102 1
1.6 1 08/2003-06/2005 1595 78 107 1
1.6

BAH

 1 02/2001-03/2007 1598 74 101 1
1.6 16V

ATN

AUS

AZD

BCB

 1 02/2000-06/2005 1598 77 105 1
1.8 1 10/1997-09/1999 1781 66 90 1
1.8 1 04/1998-05/2002 1781 77 105 1
1.8

AGN

 1 08/1997-06/2005 1781 92 125 1
1.8 4motion

AGN

 1 05/1998-06/2005 1781 92 125 3
1.8 T

AGU

AQA

ARZ

AUM

AWD

AWW

 1 08/1997-06/2005 1781 110 150 1
2.0

AEG

APK

AQY

AVH

AZG

AZJ

BER

BEV

 1 07/1998-05/2004 1984 85 115 1
2.0 4motion

AZH

AZJ

 1 10/2000-06/2005 1984 85 115 3
1.0 13 08/1998-05/2002 998 43 58 1
2.0 BiFuel

BEH

 16 05/2002-05/2003 1984 85 116 1
1.6 TotalFlex 19 02/2001-04/2008 1598 76 103 1
1.9 SDI

AGP

AQM

 2 08/1997-06/2005 1896 50 68 1
1.9 TD 2 10/1997-09/1999 1896 55 75 1
1.9 TDI

AGR

ALH

 2 10/1997-05/2004 1896 66 90 1
1.9 TDI

ATD

AXR

BEW

 2 09/2000-06/2005 1896 74 101 1
1.9 TDI

AHF

ASV

 2 08/1997-05/2004 1896 81 110 1
1.9 TDI

AJM

AUY

 2 12/1998-06/2001 1896 85 115 1
1.9 TDI

ASZ

 2 11/2000-06/2005 1896 96 130 1
1.9 TDI 4motion

AGR

 2 07/1998-04/2002 1896 66 90 3
1.9 TDI 4motion

ATD

 2 09/2000-06/2005 1896 74 101 3
1.9 TDI 4motion

AJM

AUY

 2 09/1999-06/2001 1896 85 115 3
1.9 TDI 4motion

ASZ

 2 11/2000-06/2005 1896 96 130 3
GOLF IV Furgoneta (1J1) Hatchback Van 10/1997-05/2004
Vehicle Engine Fuel Date CC KW CV Traction
1.9 TDI

AGR

 2 05/2000-09/2002 1896 66 90 1
1.9 TDI

AHF

 2 10/1997-05/2004 1896 81 110 1
1.9 TDI 4motion

AUY

 2 01/2000-04/2001 1896 85 116 3
GOLF IV VAN Variant / JETTA IV (1J5) Estate Van 05/1999-06/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.4

AXP

BCA

 1 05/2000-06/2006 1390 55 75 1
1.6

AUS

AZD

BCB

 1 05/2000-06/2006 1598 77 105 1
1.9 SDI

AQM

 2 05/1999-05/2006 1896 50 68 1
1.9 TDI

AGR

ALH

 2 05/1999-05/2006 1896 66 90 1
1.9 TDI

ATD

AXR

 2 02/2000-06/2006 1896 74 101 1
1.9 TDI

AHF

ASV

 2 05/1999-05/2006 1896 81 110 1
1.9 TDI

AJM

 2 05/1999-04/2002 1896 85 116 1
1.9 TDI 2 04/2001-05/2006 1896 96 131 1
GOLF IV Variant / JETTA IV (1J5) Estate 05/1999-06/2006
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

AHW

AKQ

APE

AXP

BCA

 1 05/1999-06/2006 1390 55 75 1
1.6

AEH

AKL

APF

 1 05/1999-04/2002 1595 74 101 1
1.6

AVU

BFQ

 1 08/2000-06/2006 1595 75 102 1
1.6 16V

ATN

AUS

AZD

BCB

 1 02/2000-06/2006 1598 77 105 1
1.6 FSI

BAD

 1 01/2002-06/2006 1598 81 110 1
1.6 FSI 1 10/2003-07/2004 1598 85 116 1
1.8 4motion

AGN

 1 05/1999-06/2006 1781 92 125 3
1.8 T

AGU

ARZ

AUM

 1 05/2000-06/2006 1781 110 150 1
2.0

APK

AQY

AZJ

 1 05/1999-06/2006 1984 85 115 1
2.0 4motion

AZH

AZJ

 1 10/2000-06/2006 1984 85 115 3
2.0 4motion

ATF

 1 12/1999-06/2006 1984 88 120 3
2.0 Bi-Fuel

BEH

 16 02/2002-06/2006 1984 85 116 1
1.9 SDI

AGP

AQM

 2 05/1999-06/2006 1896 50 68 1
1.9 TDI

AGR

ALH

 2 05/1999-05/2006 1896 66 90 1
1.9 TDI

ATD

AXR

 2 09/2000-06/2006 1896 74 101 1
1.9 TDI

AHF

ASV

 2 05/1999-06/2001 1896 81 110 1
1.9 TDI

AJM

AUY

 2 08/1999-06/2001 1896 85 115 1
1.9 TDI

ASZ

 2 11/2000-06/2006 1896 96 130 1
1.9 TDI

ARL

 2 06/2001-06/2006 1896 110 150 1
1.9 TDI 4motion

AGR

 2 05/1999-04/2002 1896 66 90 3
1.9 TDI 4motion

ATD

 2 09/2000-06/2006 1896 74 101 3
1.9 TDI 4motion

AJM

 2 12/1999-04/2001 1896 85 115 3
1.9 TDI 4motion

ASZ

 2 11/2000-06/2006 1896 96 130 3
GOLF V (9B3) Hatchback 03/2006-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

BAH

CCRA

CFZA

 1 03/2007-12/2010 1598 74 101 1
2.0

BER

BEV

BHP

CBPA

 1 01/2007-12/2010 1984 85 116 1
1.6 TotalFlex

BAH

BPA

 19 03/2007-03/2014 1598 74 101 1
1.6 TotalFlex 19 05/2008-06/2014 1598 77 104 1
GOLF V Variant / BORA V / JETTA V / VENTO V (1K5) Estate 01/2007-07/2009
Vehicle Engine Fuel Date CC KW CV Traction
1.6

BSE

BSF

CCSA

 1 06/2007-07/2009 1595 75 102 1
1.9 TDI

BLS

BXE

 2 06/2007-07/2009 1896 77 105 1
1.9 TDI 4motion

BLS

 2 01/2008-07/2009 1896 77 105 3
JETTA V / BORA / VENTO (1K2) Saloon 09/2004-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.6

BGU

BSE

BSF

CCSA

 1 09/2004-10/2010 1595 75 102 1
1.6 FSI

BLF

 1 09/2005-10/2010 1598 85 115 1
1.9 TDI

BKC

BLS

BXE

 2 08/2005-10/2010 1896 77 105 1
LUPO (6X1, 6E1) Hatchback 09/1998-07/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TDI

AMF

 2 01/1999-07/2005 1422 55 75 1
NEW BEETLE / BETTLE / NOVO FUSCA (9C1, 1C1) Hatchback 01/1998-07/2012
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BCA

 1 11/2001-09/2010 1390 55 75 1
1.6

AWH

 1 10/1999-09/2000 1595 74 100 1
1.6

AYD

BFS

 1 06/2000-09/2010 1595 75 102 1
1.8 T

AGU

APH

AVC

AWU

AWV

BKF

 1 10/1999-09/2010 1781 110 150 1
2.0

AEG

APK

AQY

AVH

AZG

AZJ

BER

BEV

 1 01/1998-09/2010 1984 85 115 1
1.9 TDI

ALH

 2 01/1998-06/2004 1896 66 90 1
1.9 TDI

ATD

AXR

BEW

 2 02/2001-09/2010 1896 74 101 1
1.9 TDI

BSW

 2 07/2005-09/2010 1896 77 105 1
NEW BEETLE / BETTLE (1Y7) Convertible 09/2002-07/2012
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BCA

 1 01/2003-09/2010 1390 55 75 1
1.6

BFS

 1 01/2003-09/2010 1595 75 102 1
1.8 T

AWU

AWV

BKF

 1 01/2003-09/2010 1781 110 150 1
2.0

AZJ

BDC

BEV

BGD

 1 09/2002-10/2010 1984 85 115 1
1.9 TDI

AXR

BEW

 2 06/2003-07/2005 1896 74 100 1
1.9 TDI

BSW

 2 07/2005-09/2010 1896 77 105 1
VW (SVW)
LAVIDA (181) Saloon 04/2008-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TSI 1 03/2010-12/2013 1390 96 131 1
1.6 1 04/2008-08/2012 1598 77 105 1
2.0 1 04/2008-08/2012 1984 88 120 1
LAVIDA II (182, 184, 186) Saloon 08/2012-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 TSI

CYAA

 1 07/2015- 1197 81 110 1
1.4 TSI 1 09/2012-12/2013 1390 96 131 1
1.5

DLFA

 1 07/2019- 1498 82 112 1
1.6 1 08/2012-12/2014 1598 77 105 1
1.6 1 03/2013-02/2019 1598 81 110 1
280TSi 1 05/2016- 1395 110 150 1
CNG 16 02/2015-09/2019 1598 70 95 1
LAVIDA III (0C1, 0E1, 0C2) Saloon 05/2018-
Vehicle Engine Fuel Date CC KW CV Traction
230 TSI 1 05/2018- 1395 95 130 1
ZHONGHUA (BRILLIANCE)
H530 () Saloon 08/2011-
Vehicle Engine Fuel Date CC KW CV Traction
1.6

4A92A

4A92S

 1 08/2011- 1590 87 118 1
Return
