Product 78BD5612-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073147219
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5612-2
Weight (gr.)
12384
R90 Homologation
R90 90R-02C0452/0086
Measures
Ø276x24.5x43.2
Brake Disc Type: Vented
Minimum thickness [mm]: 22.1
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 100
Wheel Hub Diameter [mm]: 61
Reference applications
Brand OE Reference
FORD 1C1W-1125-AA
FORD 4 041 427
FORD 4 395 257
Maker Cross reference
ATE 24.0124-0167.1
BOSCH 0 986 478 299
BREMBO 09.8960.10
LETEC LBF038V
ROAD HOUSE 6609.10
SANLI SL37247
TRW DF4216
FORD
TRANSIT IV (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) Bus 01/2000-05/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 09/2000-03/2006 1998 84 114 1
2.3 1 08/2000-03/2006 2295 107 145 2
2.0 DI (F_E_, F_F_, F_G_)

D3FA

 2 08/2000-05/2006 1998 55 75 1
2.0 DI (F_E_, F_F_, F_G_)

F3FA

 2 08/2000-05/2006 1998 63 86 1
2.0 DI (F_E_, F_F_, F_G_)

ABFA

 2 08/2000-05/2006 1998 74 100 1
2.0 TDCi (F_F_, F_E_, F_G_)

FIFA

 2 08/2002-05/2006 1998 92 125 1
2.4 TD 2 08/2000-08/2003 2402 55 75 2
2.4 TDdi 2 10/2001-03/2006 2402 66 90 1
2.4 TDdi 2 08/2000-08/2003 2402 88 120 2
TRANSIT IV (FA_ _) Van 01/2000-05/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.0 1 09/2000-03/2006 1998 84 114 1
2.3

E5FC

 1 03/2001-03/2006 2295 105 143 2
2.3 1 03/2001-03/2006 2295 107 145 2
2.0 DI (FAE_, FAF_, FAG_)

D3FA

 2 08/2000-05/2006 1998 55 75 1
2.0 DI (FAE_, FAF_, FAG_)

F3FA

 2 08/2000-05/2006 1998 63 86 1
2.0 DI (FAE_, FAF_, FAG_)

ABFA

 2 08/2000-05/2006 1998 74 100 1
2.0 TDCi

FIFA

 2 08/2002-05/2006 1998 92 125 1
2.4 TD

F4FA

 2 08/2000-08/2003 2402 55 75 1
2.4 TDdi 2 08/2000-08/2003 2402 88 120 2
2.4 TDE

DOFA

 2 07/2001-05/2006 2402 92 125 2
TRANSIT IV (FM_ _, FN_ _) Platform/Chassis 01/2000-05/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.0 DI (F_E_, F_F_)

D3FA

 2 08/2000-05/2006 1998 55 75 1
2.0 DI (F_E_, F_F_)

F3FA

 2 08/2000-05/2006 1998 63 86 1
2.0 DI (F_E_, F_F_)

ABFA

 2 08/2000-05/2006 1998 74 100 1
2.0 TDCi (F_E_, F_F_)

FIFA

 2 08/2002-05/2006 1998 92 125 1
2.4 TDdi 2 08/2000-08/2003 2402 88 120 2
TRANSIT TOURNEO II (FC_ _) Bus 06/2000-03/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.0

D3FA

 2 06/2000-08/2003 1998 55 75 1
2.0

ABFA

 2 06/2000-03/2005 1998 74 101 1
2.0

FIFA

 2 03/2002-03/2006 1998 92 125 1
