Product 78BD5613-2 - Web Catalogo

Product 78BD5613-2

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073147226
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5613-2
Weight (gr.): 14120

R90 Homologation: 90R-02C0452/0080
Measures: Ø294x24x43
: Brake Disc Type: Vented; Minimum thickness [mm]: 22.1; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 100; Wheel Hub Diameter [mm]: 82

Reference applications

Brand	OE Reference
FORD	1 387 781
FORD	4 041 428
FORD	YC1W-1125-BA

Maker	Cross reference
ATE	24.0124-0168.1
BENDIX ANTIGUO	562140B
BOSCH	0 986 478 303
BREMBO	09.8837.10
BREMBO	09.8837.14
LETEC	LBF036V
ROAD HOUSE	6608.10
SANLI	SL36651
TRW	DF4217

FORD

TRANSIT IV (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) Bus 01/2000-05/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3 16V RWD (F_B_, F_C_, F_A_)	E5FA E5FC	1	08/2000-05/2006	2295	107	146	2
2.4 DI (F_B_, F_C_, F_A_)	D2FA D2FB	2	01/2000-05/2006	2402	66	90	2
2.4 DI RWD (F_B_, F_C_, F_A_)	D4FA	2	01/2000-05/2006	2402	88	120	2
2.4 DI RWD (F_B_, F_C_)	F4FA	2	01/2000-05/2006	2402	55	75	2
2.4 TDCi	H9FA	2	03/2004-05/2006	2402	101	137	2
2.4 TDE	FXFA	2	03/2004-05/2006	2402	85	115	2
2.4 TDE (F_C_, F_B_, F_A_)	DOFA	2	07/2001-05/2006	2402	92	125	2

TRANSIT IV (FA_ _) Van 01/2000-05/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3 16V RWD (FAA_, FAB_, FAC_)	E5FA E5FC	1	04/2001-05/2006	2295	107	146	2
2.3 BiFuel	E5FC	18	03/2001-03/2006	2295	105	143	2
2.4 DI (FAA_, FAB_, FAC_, FAD_)	D2FA D2FB	2	01/2000-05/2006	2402	66	90	2
2.4 DI RWD (FAA_, FAB_, FAC_, FAD_)	F4FA	2	01/2000-05/2006	2402	55	75	2
2.4 DI RWD (FAA_, FAB_, FAC_, FAD_)	D4FA	2	01/2000-05/2006	2402	88	120	2
2.4 TDCi	H9FA	2	03/2004-05/2006	2402	101	137	2
2.4 TDE	FXFA	2	03/2004-05/2006	2402	85	115	2
2.4 TDE	DOFA	2	07/2001-05/2006	2402	92	125	2

TRANSIT IV (FM_ _, FN_ _) Platform/Chassis 01/2000-05/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3		1	03/2001-03/2006	2295	105	143	2
2.3 16V (F_A_, F_B_, F_C_, F_D_)	E5FA E5FC	1	04/2001-05/2006	2295	107	146	2
2.3 BiFuel		18	03/2001-03/2006	2295	105	143	2
2.4 DI (F_A_, F_B_, F_C_, F_D_)	F4FA	2	01/2000-05/2006	2402	55	75	2
2.4 DI (F_A_, F_B_, F_C_, F_D_)	D2FA D2FB D2FE	2	01/2000-05/2006	2402	66	90	2
2.4 DI (F_A_, F_B_, F_C_, F_D_)	D4FA	2	01/2000-05/2006	2402	88	120	2
2.4 TDCi	H9FA	2	03/2004-05/2006	2402	101	137	2
2.4 TDE	FXFA	2	03/2004-05/2006	2402	85	115	2
2.4 TDE	DOFA	2	07/2001-05/2006	2402	92	125	2
