Product 78BD5614-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073147233
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5614-2
Weight (gr.)
12284
R90 Homologation
R90 90R-02C0538/0103
Measures
Ø280x22x50
Brake Disc Type: Vented
Minimum thickness [mm]: 19
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 112
Wheel Hub Diameter [mm]: 65
Reference applications
Brand OE Reference
AUDI 1K0 615 301 AK
SEAT 1K0 615 301 AS
VW 1K0 615 301 AC
VW 1K0 615 301 S
VW 5C0 615 301
Maker Cross reference
ATE 24.0122-0210.1
ATE 422210
BENDIX ANTIGUO 562237B
BOSCH 0 986 479 098
BREMBO 09.9167.10
DELPHI LOCKHEED BG3832
FERODO DDF1223
LETEC LBA028V
NECTO WN1241
ROAD HOUSE 6647.10
SANLI SL32442
TRW DF4294
VALEO 672862
AUDI
A3 II (8P1) Hatchback 05/2003-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TFSI

CAXC

CMSA

 1 09/2007-08/2012 1390 92 125 1
1.6

BGU

BSE

BSF

 1 05/2003-08/2012 1595 75 102 1
1.6 FSI

BAG

BLF

BLP

 1 08/2003-09/2007 1598 85 115 1
1.9 TDI

BKC

BLS

BXE

 2 05/2003-05/2010 1896 77 105 1
A3 II Sportback (8PA) Hatchback 09/2004-12/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TFSI

CAXC

CMSA

 1 09/2007-03/2013 1390 92 125 1
1.6

BGU

BSE

BSF

 1 09/2004-03/2013 1595 75 102 1
1.6 FSI

BLF

BLP

 1 09/2004-09/2007 1598 85 115 1
A3 II (8P7) Convertible 04/2008-05/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.6

BSE

 1 09/2008-05/2010 1595 75 102 1
1.8 TFSI

BZB

CDAA

 1 04/2008-05/2013 1798 118 160 1
2.0 TFSI

CAWB

CCZA

 1 04/2008-05/2013 1984 147 200 1
1.9 TDI

BLS

 2 04/2008-10/2009 1896 77 105 1
2.0 TDI

CBAB

CFFB

 2 04/2008-05/2013 1968 103 140 1
SEAT
ALTEA (5P1) MPV 03/2004-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

BXW

CGGB

 1 05/2006-05/2011 1390 63 86 1
1.4 TSI

CAXC

 1 11/2007-07/2015 1390 92 125 1
1.6

BGU

BSE

BSF

CCSA

 1 03/2004-03/2010 1595 75 102 1
1.8 TFSI

BYT

BZB

CDAA

 1 01/2007-07/2015 1798 118 160 1
2.0 FSI

BLR

BLY

BVY

BVZ

 1 05/2004-03/2009 1984 110 150 1
1.6 MultiFuel

CMXA

 19 11/2010-05/2011 1595 75 102 1
1.9 TDI

BJB

BKC

BLS

BXE

 2 04/2004-12/2010 1896 77 105 1
2.0 TDI

AZV

 2 03/2004-05/2009 1968 100 136 1
2.0 TDI

BMM

 2 11/2005-11/2010 1968 103 140 1
2.0 TDI

BMN

CEGA

 2 03/2006-05/2010 1968 125 170 1
2.0 TDI 16V

BKD

CFHC

 2 03/2004-07/2015 1968 103 140 1
ALTEA XL (5P5, 5P8) MPV 10/2006-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

BXW

CGGB

 1 10/2006-06/2013 1390 63 86 1
1.4 TSI

CAXC

 1 11/2007-07/2015 1390 92 125 1
1.6

BGU

BSE

BSF

CCSA

 1 10/2006-11/2010 1595 75 102 1
1.8 TFSI

BYT

BZB

CDAA

 1 01/2007-07/2015 1798 118 160 1
2.0 FSI

BVY

BVZ

 1 10/2006-03/2009 1984 110 150 1
2.0 TFSI 1 05/2009-07/2015 1984 155 211 1
2.0 TFSI 4x4

BWA

 1 06/2007-05/2009 1984 147 200 3
1.9 TDI

BKC

BLS

BXE

 2 10/2006-12/2010 1896 77 105 1
2.0 TDI

AZV

 2 11/2006-03/2009 1968 100 136 1
2.0 TDI

BMM

 2 10/2006-11/2010 1968 103 140 1
2.0 TDI 16V

BKD

CFHC

 2 10/2006-07/2015 1968 103 140 1
2.0 TDI 4x4

BMM

 2 06/2007-11/2010 1968 103 140 3
LEON II (1P1) Hatchback 05/2005-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

BXW

CGGB

 1 06/2006-12/2012 1390 63 86 1
1.4 TSI

CAXC

 1 11/2007-12/2012 1390 92 125 1
1.6

BSE

BSF

CCSA

 1 07/2005-12/2012 1595 75 102 1
1.9 TDI

BXF

 2 06/2007-12/2010 1896 66 90 1
2.0 TDI

AZV

 2 07/2005-05/2010 1968 100 136 1
TOLEDO III (5P2) MPV 04/2004-05/2009
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TSI

CAXC

 1 11/2007-05/2009 1390 92 125 1
1.6

BGU

BSE

BSF

CCSA

 1 10/2004-05/2009 1595 75 102 1
2.0 TDI

AZV

 2 09/2004-05/2009 1968 100 136 1
SKODA
OCTAVIA II / LAURA (1Z3) Hatchback 02/2004-06/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BCA

 1 05/2004-05/2006 1390 55 75 1
1.4

BUD

CGGA

 1 06/2004-04/2013 1390 59 80 1
1.6

BGU

BSE

BSF

CCSA

CMXA

 1 06/2004-06/2013 1595 75 102 1
1.6 FSI

BLF

 1 02/2004-10/2008 1598 85 115 1
1.8 T 1 09/2005-12/2008 1781 110 150 1
1.8 TSI

CDAB

 1 03/2009-06/2013 1798 112 152 1
1.8 TSI

BZB

CDAA

 1 06/2007-04/2013 1798 118 160 1
1.9 TDI

BJB

BKC

BLS

BXE

 2 06/2004-12/2010 1896 77 105 1
2.0 TDI

AZV

 2 02/2004-05/2010 1968 100 136 1
OCTAVIA II Combi (1Z5) Estate 02/2004-06/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BCA

 1 05/2004-05/2006 1390 55 75 1
1.4

BUD

CGGA

 1 05/2006-06/2013 1390 59 80 1
1.6

BGU

BSE

BSF

CCSA

CMXA

 1 09/2004-06/2013 1595 75 102 1
1.6 FSI

BLF

 1 02/2004-10/2008 1598 85 115 1
1.8 TSI

CDAB

 1 03/2009-06/2013 1798 112 152 1
1.8 TSI

BZB

CDAA

 1 06/2007-04/2013 1798 118 160 1
1.8 TSI 4x4

CDAB

 1 03/2009-02/2013 1798 112 152 3
1.9 TDI

BJB

BKC

BLS

BXE

 2 09/2004-12/2010 1896 77 105 1
1.9 TDI 4x4

BKC

BLS

BXE

 2 11/2004-12/2010 1896 77 105 3
2.0 TDI

CFHF

CLCA

 2 03/2010-06/2013 1968 81 110 1
2.0 TDI

BMM

 2 11/2005-05/2010 1968 103 140 1
2.0 TDI 16V

AZV

 2 02/2004-05/2010 1968 100 136 1
2.0 TDI 4x4

CFHF

 2 05/2011-02/2013 1968 81 110 3
2.0 TDI 4x4

BMM

 2 07/2006-05/2010 1968 103 140 3
SKODA (SVW)
OCTAVIA (913) Hatchback 06/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 06/2007-12/2017 1598 77 105 1
1.6 1 01/2010-12/2015 1598 77 105 1
1.8 TSI 1 06/2007-03/2014 1798 118 160 1
VW
CADDY III (2KB, 2KJ, 2CB, 2CJ) MPV 03/2004-03/2016
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BCA

 1 03/2004-05/2006 1390 55 75 1
1.4

BUD

 1 05/2006-08/2010 1390 59 80 1
1.6 1 01/2005-12/2009 1595 65 88 1
1.6 1 03/2005-05/2015 1595 74 101 1
1.6

BGU

BSE

BSF

 1 04/2004-05/2015 1595 75 102 1
1.9 D 2 10/2005-06/2009 1896 48 65 1
CADDY III (2KA, 2KH, 2CA, 2CH) Box Body/MPV 03/2004-03/2016
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BCA

 1 03/2004-05/2006 1390 55 75 1
1.4

BUD

 1 05/2006-08/2010 1390 59 80 1
1.6

BGU

BSE

BSF

 1 04/2004-05/2015 1595 75 102 1
GOLF V / RABBIT V (1K1) Hatchback Van 07/2003-
Vehicle Engine Fuel Date CC KW CV Traction
TDI 2 11/2003-02/2006 1896 77 105 1
GOLF V / RABBIT V (1K1) Hatchback 10/2003-07/2010
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

BCA

 1 10/2003-05/2006 1390 55 75 1
1.4 16V

BUD

 1 05/2006-11/2008 1390 59 80 1
1.4 FSI

BKG

BLN

 1 10/2003-07/2006 1390 66 90 1
1.4 TSI

CAXA

 1 05/2007-11/2008 1390 90 122 1
1.4 TSI

BMY

 1 05/2006-11/2008 1390 103 140 1
1.4 TSI

BLG

 1 11/2005-11/2008 1390 125 170 1
1.6 1 08/2005- 1595 67 91 1
1.6

BGU

BSE

BSF

CCSA

 1 01/2004-11/2008 1595 75 102 1
1.6 FSI

BAG

BLF

BLP

 1 10/2003-07/2008 1598 85 115 1
2.0 GTI

BYD

 1 09/2006-12/2008 1984 169 230 1
1.6 FSI 13 02/2006- 1598 74 101 1
1.9 SDI 2 12/2005- 1896 47 64 2
1.9 TDI

BRU

BXF

BXJ

 2 05/2004-11/2008 1896 66 90 1
1.9 TDI

BKC

BLS

BXE

 2 10/2003-11/2008 1896 77 105 1
1.9 TDI 4motion

BKC

BLS

BXE

 2 08/2004-11/2008 1896 77 105 3
2.0 SDI

BDK

 2 01/2004-11/2008 1968 55 75 1
2.0 TDI

AZV

 2 10/2003-11/2008 1968 100 136 1
2.0 TDI

BMM

 2 12/2004-11/2008 1968 103 140 1
2.0 TDI 16V

BKD

 2 10/2003-11/2008 1968 103 140 1
2.0 TDI 16V 4motion

BKD

 2 08/2004-11/2008 1968 103 140 3
2.0 TDI 4motion

BMM

 2 01/2007-11/2008 1968 103 140 3
GOLF PLUS V (5M1, 521) Hatchback 12/2004-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V

BCA

 1 01/2005-11/2006 1390 55 75 1
1.4 16V

BUD

CGGA

 1 05/2006-12/2013 1390 59 80 1
1.4 FSI

BLN

 1 07/2005-11/2006 1390 66 90 1
1.4 TSI

BMY

 1 05/2006-06/2008 1390 103 140 1
1.4 TSI

BLG

 1 05/2006-06/2008 1390 125 170 1
1.6 1 08/2005- 1595 67 91 1
1.6

BSE

BSF

CCSA

CMXA

 1 05/2005-12/2013 1595 75 102 1
1.6 FSI

BLF

 1 12/2004-05/2008 1598 85 115 1
1.6 MultiFuel

CCSA

CMXA

 19 11/2007-12/2013 1595 75 102 1
1.9 SDI 2 12/2005- 1896 47 64 2
1.9 TDI

BRU

BXF

BXJ

 2 05/2005-12/2008 1896 66 90 1
1.9 TDI

BKC

BLS

BXE

 2 01/2005-01/2009 1896 77 105 1
2.0 TDI

BEE

 2 05/2005-05/2007 1968 96 131 1
2.0 TDI

AZV

CBDA

CFHB

 2 05/2005-12/2013 1968 100 136 1
2.0 TDI

BMM

 2 12/2005-05/2011 1968 103 140 1
2.0 TDI 16V

BKD

CBDB

CFHC

 2 01/2005-12/2013 1968 103 140 1
GOLF V Variant / BORA V / JETTA V / VENTO V (1K5) Estate 01/2007-07/2009
Vehicle Engine Fuel Date CC KW CV Traction
1.4

BUD

 1 06/2007-07/2009 1390 59 80 1
1.4 TSI

CAXA

 1 06/2007-07/2009 1390 90 122 1
1.4 TSI

BMY

 1 06/2007-07/2009 1390 103 140 1
2.0 TFSI

BWA

CAWB

CBFA

CCTA

 1 06/2007-07/2009 1984 147 200 1
1.6 MultiFuel

CCSA

 19 11/2007-07/2009 1595 75 102 1
GOLF VI / JETTA VI (5K1) Hatchback 10/2008-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.4

CGGA

 1 10/2008-11/2012 1390 59 80 1
1.6

BSE

BSF

CCSA

CMXA

 1 10/2008-11/2012 1595 75 102 1
1.6 BiFuel

CHGA

 18 03/2009-11/2012 1595 75 102 1
1.6 TDI

CAYC

 2 02/2009-11/2012 1598 77 105 1
2.0 TDI

CBDC

CLCA

 2 10/2008-11/2012 1968 81 110 1
Blue E-Motion

EAA

 11 12/2010-11/2013 65 88 1
GOLF VI / JETTA VI (521) Hatchback Van 01/2009-08/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.6 TDI

CAYC

 2 02/2009-08/2014 1598 77 105 1
GOLF VI VAN Variant / JETTA VI (AJ5) Estate Van 07/2009-05/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.6 TDi BlueMotion

CAYC

 2 07/2009-05/2014 1598 77 105 1
GOLF VI Variant / JETTA VI (AJ5) Estate 07/2009-07/2014
Vehicle Engine Fuel Date CC KW CV Traction
1.6 BiFuel

BSF

 18 07/2009-12/2010 1595 75 102 1
1.6 MultiFuel

CMXA

 19 07/2010-07/2013 1595 75 102 1
1.6 TDI 4motion

CAYC

 2 07/2009-07/2013 1598 77 105 3
2.0 TDI

CLCA

 2 01/2010-07/2013 1968 81 110 1
JETTA V / BORA / VENTO (1K2) Saloon 09/2004-12/2013
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TSI

CAXA

 1 05/2007-10/2010 1390 90 122 1
1.4 TSI

BMY

 1 07/2006-10/2010 1390 103 140 1
1.4 TSI

CAVD

 1 07/2008-10/2010 1390 118 160 1
2.0 TFSI 1 07/2008-10/2010 1984 125 170 1
2.5

BGP

BGQ

BTK

 1 01/2006-10/2010 2480 110 150 1
2.5

CBTA

CBUA

CCCA

 1 07/2008-10/2010 2480 125 170 1
2.8 VR6 1 10/2009-10/2010 2792 128 174 1
1.6 TDI

CAYB

 2 12/2009-10/2010 1598 66 90 1
1.6 TDI

CAYC

 2 06/2009-10/2010 1598 77 105 1
1.9 TDI 2 08/2005-10/2010 1896 74 101 1
JETTA VI / VENTO (162, 163, AV3, AV2) Saloon 01/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.2 TSI 16V

CYVD

 1 08/2014-12/2017 1197 77 105 1
1.6

CWVA

 1 09/2015-04/2018 1598 81 110 1
1.6 MPi

CWVB

 1 09/2015-04/2018 1598 66 90 1
2.0 Flex 19 10/2010-12/2016 1984 88 120 1
JETTA VII (BU3, BU4) Saloon 12/2017-
Vehicle Engine Fuel Date CC KW CV Traction
1.4 TSI

CWLA

CZDA

DGXA

DJXA

 1 12/2017- 1395 110 150 1
2.0 GLi 1 12/2018- 1984 170 231 1
350 TSI 1 12/2018- 1984 169 230 1
VW (FAW)
CADDY (9HB) Van 04/2004-12/2007
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 03/2005- 1595 75 102 1
Return
