Product 78BD5630-2 - Web Catalogo

Product 78BD5630-2

Description: Brake disc
Axe: Front-Rear
No. of Pieces: 2
Barcode: 8424073147332
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5630-2
Weight (gr.): 18152

R90 Homologation: 90R-02C0538/0082
Measures: Ø300x28x54.5
: Brake Disc Type: Vented; Minimum thickness [mm]: 24; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 111.5; Wheel Hub Diameter [mm]: 93

Reference applications

Brand	OE Reference
FORD	1 371 393
FORD	1 503 287
FORD	6C11-1125-AA
FORD	6C11-1125-AB

Maker	Cross reference
BREMBO	09.A531.10
FERODO	DDF1555
LETEC	LBF051V
SANLI	SL37026
TRW	DF2390S
TRW	DF4817S

FORD

TRANSIT V (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) Bus 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1
2.2 TDCi RWD	DRRA DRRB DRRC	2	10/2011-08/2014	2198	74	100	2
2.2 TDCi RWD	CYRA	2	09/2011-12/2014	2198	92	125	2
2.2 TDCi RWD	USRA USRB	2	09/2011-08/2014	2198	100	135	2
2.4 TDCi	PHFA PHFC	2	04/2006-08/2014	2402	74	100	2
2.4 TDCi	JXFA JXFC	2	04/2006-08/2014	2402	85	115	2
2.4 TDCi	H9FD	2	04/2006-08/2014	2402	103	140	2
2.4 TDCi 4x4	H9FB	2	11/2006-08/2014	2402	103	140	3
3.2 TDCi	SAFA SAFB	2	02/2008-08/2014	3199	147	200	2

TRANSIT V (FA_ _) Van 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3 16V RWD	GZFA GZFB GZFC	1	04/2006-08/2014	2261	107	145	2
2.3 16V CNG RWD	GZFC	16	04/2006-08/2014	2261	100	136	2
2.3 16V LPG RWD	GZFC	18	04/2006-08/2014	2261	107	145	2
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1
2.2 TDCi 4x4	CYRB CYRC	2	10/2011-08/2014	2198	92	125	3
2.2 TDCi RWD	DRRA DRRB DRRC	2	10/2011-08/2014	2198	74	100	2
2.2 TDCi RWD	CYRA	2	09/2011-12/2014	2198	92	125	2
2.2 TDCi RWD	USRA USRB	2	10/2011-08/2014	2198	100	136	2
2.2 TDCi RWD	CVRA CVRB CVRC	2	10/2011-08/2014	2198	114	155	2
2.4 TDCi 4x4	H9FB	2	11/2006-08/2014	2402	103	140	3
2.4 TDCi RWD	PHFA PHFC	2	04/2006-08/2014	2402	74	100	2
2.4 TDCi RWD	JXFA JXFC	2	04/2006-08/2014	2402	85	115	2
2.4 TDCi RWD	H9FB H9FD	2	04/2006-08/2014	2402	103	140	2
3.2 TDCi RWD	SAFA SAFB	2	09/2007-08/2014	3199	147	200	2

TRANSIT V (FM_ _, FN_ _, FF_ _) Platform/Chassis 04/2006-12/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3 16V RWD	GZFA GZFB GZFC	1	04/2006-08/2014	2261	107	145	2
2.3 16V CNG RWD	GZFC	16	04/2006-08/2014	2261	100	136	2
2.3 16V LPG RWD	GZFC	18	04/2006-08/2014	2261	107	145	2
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-09/2011	2198	103	140	1
2.2 TDCi 4x4	CYRB CYRC	2	10/2011-08/2014	2198	92	125	3
2.2 TDCi RWD	DRRA DRRB DRRC	2	10/2011-08/2014	2198	74	100	2
2.2 TDCi RWD	CYRA	2	10/2011-08/2014	2198	92	125	2
2.2 TDCi RWD	CVRA CVRB CVRC	2	10/2011-08/2014	2198	114	155	2
2.4 TDCi 4x4	H9FB	2	11/2006-08/2014	2402	103	140	3
2.4 TDCi RWD	PHFA PHFC	2	04/2006-08/2014	2402	74	100	2
2.4 TDCi RWD	JXFA JXFC	2	04/2006-08/2014	2402	85	115	2
2.4 TDCi RWD	H9FD	2	04/2006-08/2014	2402	103	140	2
3.2 TDCi RWD	SAFA SAFB	2	09/2007-08/2014	3199	147	200	2

TRANSIT TOURNEO III () Bus 07/2006-08/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
