Product 78BD5632-2

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073147356
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5632-2
Weight (gr.): 15220

Measures: Ø280x28x54.6
: Brake Disc Type: Vented; Minimum thickness [mm]: 25; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 111; Wheel Hub Diameter [mm]: 93

Reference applications

Brand	OE Reference
FORD	1371394
FORD	1503290
FORD	1547061

Maker	Cross reference
ATE	24.0128-0156.1
ATE	428156
BENDIX ANTIGUO	562541BC
BOSCH	0 986 479 392
BREMBO	09.A529.10
DELPHI LOCKHEED	BG4007
FERODO	DDF1554
GIRLING	6023895
HELLA-PAGID	8DD 355 113-251
LETEC	LBF052V
MINTEX	MDC1759
NECTO	WN1483
ROAD HOUSE	61021.10
SANLI	SL33859
TEXTAR	92151800
TRW	DF2389S
VALEO	197249

FORD

TRANSIT V (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) Bus 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi	P8FA P8FB	2	04/2006-08/2014	2198	63	85	1
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1

TRANSIT V (FA_ _) Van 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi	P8FA P8FB	2	04/2006-08/2014	2198	63	85	1
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1

TRANSIT V (FM_ _, FN_ _, FF_ _) Platform/Chassis 04/2006-12/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi	P8FA P8FB	2	04/2006-08/2014	2198	63	85	1
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-09/2011	2198	103	140	1

TRANSIT TOURNEO III () Bus 07/2006-08/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi	QVFA	2	07/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	QWFA	2	07/2006-08/2014	2198	96	131	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1
