Product 78BD5633-2

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073147363
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5633-2
Weight (gr.): 17020

R90 Homologation: 90R-02C0100/0841
Measures: Ø280x16x68.8
: Brake Disc Type: solid; Minimum thickness [mm]: 13; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 160; Wheel Hub Diameter [mm]: 96

Reference applications

Brand	OE Reference
FORD	1387152
FORD	1451161
FORD	6C112A097AB

Maker	Cross reference
ATE	24.0116-0116.2
ATE	416116
BENDIX ANTIGUO	562638BC
BOSCH	0 986 479 389
BREMBO	08.A730.10
BREMBO	08.A730.20
DELPHI LOCKHEED	BG4008
FERODO	DDF1573
GIRLING	6048215
HELLA-PAGID	8DD 355 113-811
LETEC	LBF056S
MINTEX	MDC1808
ROAD HOUSE	61107.00
SANLI	SL11180
TEXTAR	92159100
TRW	DF4821S

FORD

TRANSIT V (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) Bus 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi	P8FA P8FB	2	04/2006-08/2014	2198	63	85	1
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1
2.4 TDCi	PHFA PHFC	2	04/2006-08/2014	2402	74	100	2
2.4 TDCi	JXFA JXFC	2	04/2006-08/2014	2402	85	115	2
2.4 TDCi	H9FD	2	04/2006-08/2014	2402	103	140	2
2.4 TDCi 4x4	H9FB	2	11/2006-08/2014	2402	103	140	3
3.2 TDCi	SAFA SAFB	2	02/2008-08/2014	3199	147	200	2

TRANSIT V (FA_ _) Van 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3 16V RWD	GZFA GZFB GZFC	1	04/2006-08/2014	2261	107	145	2
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1
2.4 TDCi 4x4	H9FB	2	11/2006-08/2014	2402	103	140	3
2.4 TDCi RWD	PHFA PHFC	2	04/2006-08/2014	2402	74	100	2
2.4 TDCi RWD	JXFA JXFC	2	04/2006-08/2014	2402	85	115	2
2.4 TDCi RWD	H9FB H9FD	2	04/2006-08/2014	2402	103	140	2
3.2 TDCi RWD	SAFA SAFB	2	09/2007-08/2014	3199	147	200	2

TRANSIT V (FM_ _, FN_ _, FF_ _) Platform/Chassis 04/2006-12/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.3 16V RWD	GZFA GZFB GZFC	1	04/2006-08/2014	2261	107	145	2
2.2 TDCi	P8FA P8FB	2	04/2006-08/2014	2198	63	85	1
2.2 TDCi	DRFA DRFB DRFC DRFD DRFE	2	10/2011-08/2014	2198	74	100	1
2.2 TDCi	QVFA	2	04/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QWFA	2	04/2006-08/2014	2198	96	130	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1
2.4 TDCi 4x4	H9FB	2	11/2006-08/2014	2402	103	140	3
2.4 TDCi RWD	PHFA PHFC	2	04/2006-08/2014	2402	74	100	2
2.4 TDCi RWD	JXFA JXFC	2	04/2006-08/2014	2402	85	115	2
2.4 TDCi RWD	H9FD	2	04/2006-08/2014	2402	103	140	2
3.2 TDCi RWD	SAFA SAFB	2	09/2007-08/2014	3199	147	200	2

TRANSIT TOURNEO III () Bus 07/2006-08/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2	CYFA CYFB CYFC CYFD	2	10/2011-08/2014	2198	92	125	1
2.2 TDCi	QVFA	2	07/2006-08/2014	2198	81	110	1
2.2 TDCi	SRFA SRFB SRFC SRFD SRFE	2	10/2008-08/2014	2198	85	115	1
2.2 TDCi	QWFA	2	07/2006-08/2014	2198	96	131	1
2.2 TDCi	PGFA PGFB UHFA UHFB UHFC	2	10/2007-08/2014	2198	103	140	1
