Product 78BD5642-2 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073147400
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5642-2
Weight (gr.): 10840

Measures: Ø300x12x48.4
: Brake Disc Type: solid; Minimum thickness [mm]: 10; Hole Arrangement/Number: 9; Bolt Hole Circle Ø [mm]: 112; Wheel Hub Diameter [mm]: 65

Reference applications

Brand	OE Reference
VW	3Q0 615 601

Maker	Cross reference
ATE	24.0112-0210.1
ATE	24.0312-0210.1
ATE	412210
BENDIX-ROULUNDS	522197
BOSCH	0 986 479 A84
BREMBO	08.C501.1E
BREMBO	08.C501.1X
BREMBO	08.C501.75
GIRLING	6065044
HELLA-PAGID	8DD 355 119-481
LETEC	LBA088S
MINTEX	MDC2527
ROAD HOUSE	61587.00
TEXTAR	92255403
TEXTAR	98200 2554 0 1
TRW	DF6504

AUDI

A3 III (8V1, 8VK) Hatchback 04/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 TFSI	CJZA	1	02/2013-05/2015	1197	77	105	1
1.2 TFSI	CYVB	1	05/2014-08/2016	1197	81	110	1
1.4 TFSI	CMBA CXSA	1	04/2012-05/2014	1395	90	122	1
1.4 TFSI	CXSB CZCA	1	05/2014-08/2016	1395	92	125	1
1.4 TFSI	CPTA	1	03/2013-08/2016	1395	103	140	1
1.4 TSI	CZEA	1	05/2014-12/2017	1395	110	150	1
1.5 TFSI	DADA	1	05/2017-12/2017	1498	110	150	1
1.8 TFSI	CJSA	1	04/2012-08/2016	1798	132	180	1
1.8 TFSI quattro	CJSB	1	08/2012-08/2016	1798	132	180	3
S3 quattro	CJXB	1	02/2013-07/2014	1984	206	280	3
S3 quattro	CJXF	1	05/2014-08/2016	1984	210	286	3
S3 quattro	CJXC	1	11/2012-08/2016	1984	221	300	3
1.6 TDI	CLHA	2	10/2012-05/2015	1598	77	105	1
1.6 TDI	CRKB CXXB DBKA	2	09/2013-12/2017	1598	81	110	1
1.6 TDI	DDYA	2	02/2017-10/2020	1598	85	115	1
2.0 TDI	CRFA	2	01/2013-08/2016	1968	81	110	1
2.0 TDI	CRBD CRLC	2	05/2013-08/2016	1968	100	136	1
2.0 TDI	CRFC	2	09/2012-10/2020	1968	105	143	1
2.0 TDI	CRBC CRLB CRUA DBGA DCYA DEJA	2	04/2012-12/2017	1968	110	150	1
2.0 TDI	CUNA	2	05/2013-12/2017	1968	135	184	1
2.0 TDI quattro	CRBC CRLB DCYA	2	10/2012-12/2017	1968	110	150	3
2.0 TDI quattro	CUNA DGCA	2	12/2012-12/2017	1968	135	184	3

A3 III Sportback (8VA, 8VF) Hatchback 09/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 TFSI	CJZA	1	05/2013-05/2015	1197	77	105	1
1.2 TFSI	CYVB	1	05/2014-08/2016	1197	81	110	1
1.4 TFSI	CMBA CXSA	1	09/2012-10/2020	1395	90	122	1
1.4 TFSI	CXSB CZCA	1	05/2014-08/2016	1395	92	125	1
1.4 TFSI	CPTA	1	03/2013-11/2014	1395	103	140	1
1.4 TSI	CZEA	1	05/2014-10/2020	1395	110	150	1
1.5 TFSI	DADA	1	05/2017-10/2018	1498	110	150	1
1.8 TFSI	CJSA CJSB	1	09/2012-08/2016	1798	132	180	1
1.8 TFSI quattro	CJSB	1	05/2013-08/2016	1798	132	180	3
2.0 45 TFSI		1	02/2015-08/2016	1984	162	220	1
30 TFSI	DKRF	1	07/2018-10/2020	999	85	116	1
35 TFSI	DADA DPCA	1	10/2018-10/2020	1498	110	150	1
40 TFSI	DKZA	1	07/2018-10/2020	1984	140	190	1
40 TFSI quattro	DKZA	1	07/2018-10/2020	1984	140	190	3
S3 quattro	CJXB	1	05/2013-08/2016	1984	206	280	3
S3 quattro	CJXF	1	05/2014-08/2016	1984	210	286	3
S3 quattro	CJXC DNUE	1	11/2012-10/2020	1984	221	300	3
1.4 TFSI e-tron	CUKB CXUA	13	05/2014-10/2020	1395	110	150	1
1.4 TFSI e-tron	CXUA	13	05/2014-10/2020	1395	150	204	1
40 e-tron		13	07/2018-10/2020	1395	150	204	1
1.4 TFSI g-tron	CPWA	16	11/2013-10/2020	1395	81	110	1
1.6 TDI	CLHA	2	10/2012-12/2016	1598	77	105	1
1.6 TDI	CRKB CXXB DBKA	2	09/2013-10/2020	1598	81	110	1
1.6 TDI	DDYA	2	02/2017-10/2020	1598	85	115	1
1.6 TDI quattro	CXXB	2	05/2015-08/2016	1598	81	110	3
2.0 TDI	CRFA DEJB	2	05/2013-10/2020	1968	81	110	1
2.0 TDI	CRBD CRLC	2	05/2013-08/2016	1968	100	136	1
2.0 TDI	CRFC	2	03/2013-10/2020	1968	105	143	1
2.0 TDI	CRBC CRLB CRUA DBGA DCYA DEJA DFGA	2	09/2012-10/2020	1968	110	150	1
2.0 TDI	CUNA	2	05/2013-07/2018	1968	135	184	1
2.0 TDI quattro	CRBC CRLB DCYA	2	02/2013-10/2020	1968	110	150	3
2.0 TDI quattro	CUNA DGCA	2	05/2013-07/2018	1968	135	184	3
30 TDI	DGTE	2	07/2018-10/2020	1598	85	115	1
35 TDI	DFGA	2	07/2018-10/2020	1968	110	150	1
40 TDI quattro	DJGA	2	07/2018-10/2020	1968	135	184	3

A3 III (8VS, 8VM) Saloon 05/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 TFSI	CJZA	1	10/2013-05/2015	1197	77	105	1
1.2 TFSI	CYVB	1	05/2014-08/2016	1197	81	110	1
1.4 TFSI	CXSA	1	09/2013-10/2020	1395	90	122	1
1.4 TFSI	CXSB CZCA	1	09/2013-08/2016	1395	92	125	1
1.4 TFSI	CPTA	1	05/2013-08/2016	1395	103	140	1
1.4 TSI	CZEA	1	05/2014-10/2020	1395	110	150	1
1.5 TFSI	DADA	1	05/2017-10/2018	1498	110	150	1
1.8 TFSI	CNSB	1	11/2013-10/2020	1798	125	170	1
1.8 TFSI	CJSA CJSB	1	05/2013-08/2016	1798	132	180	1
1.8 TFSI quattro	CJSB	1	11/2013-08/2016	1798	132	180	3
2.0 TFSI	CHHB CNTC	1	11/2015-10/2020	1984	162	220	1
30 TFSI	DKRF	1	07/2018-10/2020	999	85	115	1
35 TFSI	DADA DPCA	1	10/2018-10/2020	1498	110	150	1
40 TFSI	DKZA	1	07/2018-10/2020	1984	140	190	1
40 TFSI quattro	DKZA	1	07/2018-10/2020	1984	140	190	3
S3 quattro	CJXB	1	10/2013-05/2014	1984	206	280	3
S3 quattro	CJXF	1	05/2014-08/2016	1984	210	286	3
S3 quattro	CJXC DNUE	1	10/2013-10/2020	1984	221	300	3
1.6 TDI	CLHA	2	09/2013-05/2015	1598	77	105	1
1.6 TDI	CRKB CXXB DBKA	2	05/2014-10/2020	1598	81	110	1
1.6 TDI	DDYA	2	03/2017-10/2020	1598	85	115	1
1.6 TDI quattro	CXXB	2	05/2015-08/2016	1598	81	110	3
2.0 TDI	CRFA DEJB	2	05/2013-10/2020	1968	81	110	1
2.0 TDI	CRBD CRLC	2	09/2013-08/2016	1968	100	136	1
2.0 TDI	CRFC	2	10/2013-10/2020	1968	105	143	1
2.0 TDI	CRBC CRLB CRUA DBGA DCYA DEJA DFGA	2	05/2013-10/2020	1968	110	150	1
2.0 TDI	CUNA	2	05/2014-07/2018	1968	135	184	1
2.0 TDI quattro	CRBC CRLB DCYA	2	10/2013-10/2020	1968	110	150	3
2.0 TDI quattro	CUNA DGCA	2	05/2014-07/2018	1968	135	184	3
30 TDI	DGTE	2	07/2018-10/2020	1598	85	115	1
35 TDI	DFGA	2	07/2018-10/2020	1968	110	150	1
40 TDI quattro	DJGA	2	07/2018-07/2019	1968	135	184	3

A3 III (8V7, 8VE) Convertible 10/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
40 TFSI	DKZA	1	11/2018-10/2020	1984	140	190	1
40 TFSI quattro	DKZA	1	11/2018-10/2020	1984	140	190	3

Q3 (8UB, 8UG) SUV 06/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TFSI	CZDB	1	07/2016-10/2018	1395	92	125	1
1.4 TSI	CHPB CZDA CZEA	1	10/2013-10/2018	1395	110	150	1
2.0 TFSI	CULB	1	05/2015-10/2018	1984	132	180	1
2.0 TFSI quattro	CCZC	1	06/2011-04/2015	1984	125	170	3
2.0 TFSI quattro	CULB	1	11/2014-10/2018	1984	132	180	3
2.0 TFSI quattro	CCTA	1	09/2014-10/2018	1984	147	200	3
2.0 TFSI quattro	CPSA	1	06/2011-04/2015	1984	155	211	3
2.0 TFSI quattro	CULC	1	11/2014-10/2018	1984	162	220	3
1.4 TFSi Flex	CWLA CZDA	19	02/2016-10/2018	1395	110	150	1
2.0 TDI	CUVD DFTC	2	03/2015-10/2018	1968	88	120	1
2.0 TDI	CFFA CUVB DFTB	2	09/2011-10/2018	1968	100	136	1
2.0 TDI	CFFB CLJA	2	09/2011-10/2018	1968	103	140	1
2.0 TDI	CUVC DBBA DFTA	2	11/2014-10/2018	1968	110	150	1
2.0 TDI	CFGC	2	06/2011-04/2015	1968	130	177	1
2.0 TDI	CUWA DFUA	2	05/2015-10/2018	1968	135	184	1
2.0 TDI quattro	CFFB	2	01/2012-10/2018	1968	103	140	3
2.0 TDI quattro	CUVC DFTA	2	11/2014-10/2018	1968	110	150	3
2.0 TDI quattro	CFGD	2	06/2011-04/2015	1968	120	163	3
2.0 TDI quattro	CFGC CLLB	2	06/2011-10/2018	1968	130	177	3
2.0 TDI quattro	CUWA CYLA DFUA	2	11/2014-10/2018	1968	135	184	3

Q3 II (F3B) SUV 07/2018-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
35 TFSI	CZDA	1	11/2018-	1395	110	150	1
35 TFSI	DADA DPCA	1	08/2018-	1498	110	150	1
40 TFSI quattro		1	02/2021-	1984	132	180	3
40 TFSI quattro	DKTC	1	07/2018-	1984	140	190	3
45 TFSI quattro		1	01/2021-	1984	180	245	3
35 TFSI Mild Hybrid	DFYA	13	11/2019-	1498	110	150	1
45 TFSIe		13	11/2020-	1395	180	245	1
35 TDI	DFGA	2	09/2018-	1968	110	150	1
35 TDI quattro	DFGA	2	09/2018-	1968	110	150	3
40 TDI quattro	DFHA	2	10/2018-	1968	140	190	3
40 TDI quattro		2	11/2020-	1968	147	200	3

Q3 II Sportback (F3N) SUV 06/2019-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
35 TFSI	CZDA	1	10/2019-	1395	110	150	1
35 TFSI	DPCA	1	09/2019-	1498	110	150	1
40 TFSI quattro		1	06/2019-	1984	132	179	3
40 TFSI quattro	DKTC	1	11/2019-	1984	140	190	3
45 TFSI quattro	DKTA	1	06/2019-	1984	169	230	3
45 TFSI quattro		1	01/2021-	1984	180	245	3
35 TFSI Mild Hybrid	DFYA	13	11/2019-	1498	110	150	1
45 TFSIe		13	11/2020-	1395	180	245	1
35 TDI	DFGA	2	11/2019-	1968	110	150	1
35 TDI quattro	DFGA	2	09/2019-	1968	110	150	3
40 TDI quattro	DFHA	2	07/2019-	1968	140	190	3
40 TDI quattro	DTUA	2	09/2020-	1968	147	200	3

TT III (FV3, FVP) Coupe 07/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 TFSI	CJSA CJSB	1	07/2015-08/2018	1798	132	180	1
2.0 TFSI	CHHC	1	07/2014-	1984	169	230	1
2.0 TFSI quattro	CNTC	1	04/2015-	1984	162	220	3
2.0 TFSI quattro	CHHC	1	07/2014-	1984	169	230	3
2.0 TTS quattro	CJXF	1	02/2015-	1984	210	286	3
2.0 TTS quattro	CJXG	1	11/2014-	1984	228	310	3
40 TFSI	DKZB	1	07/2018-	1984	145	197	1
45 TFSI	DKTB	1	07/2018-	1984	180	245	1
45 TFSI quattro	DKTB	1	07/2018-	1984	180	245	3
TTS quattro		1	01/2021-	1984	235	320	3
2.0 TDI	CUNA	2	07/2014-	1968	135	184	1
2.0 TDI quattro	CUNA	2	01/2017-	1968	135	184	3

TT III (FV9, FVR) Convertible 11/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 TFSI	CJSA CJSB	1	07/2015-08/2018	1798	132	180	1
2.0 TFSI	CHHC	1	11/2014-	1984	169	230	1
2.0 TFSI quattro	CNTC	1	04/2015-	1984	162	220	3
2.0 TFSI quattro	CHHC	1	11/2014-	1984	169	230	3
2.0 TTS quattro	CJXF	1	02/2015-	1984	210	286	3
2.0 TTS quattro	CJXG	1	11/2014-	1984	228	310	3
40 TFSI	DKZB	1	07/2018-	1984	145	197	1
45 TFSI	DKTB	1	07/2018-	1984	180	245	1
45 TFSI quattro	DKTB	1	07/2018-	1984	180	245	3
2.0 TDI	CUNA	2	11/2014-	1968	135	184	1
2.0 TDI quattro	CUNA	2	01/2017-	1968	135	184	3

FORD

(SK) MPV 02/2022-

Vehicle	Fuel	Date	CC	KW	CV	Traction
1.5 EcoBoost	1	02/2022-08/2024	1498	84	114	1
2.0 EcoBlue	2	02/2022-	1968	55	75	1
2.0 EcoBlue	2	02/2022-	1968	75	102	1
2.0 EcoBlue	2	02/2022-	1968	90	122	1
2.0 EcoBlue 4WD	2	02/2022-	1968	90	122	3

TRANSIT CONNECT (SKN) Box Body/MPV 05/2022-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
EcoBlue 4WD		2	05/2024-	1968	90	122	3

SEAT

ALHAMBRA II (710, 711) MPV 06/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZDA DJKA	1	05/2015-12/2022	1395	110	150	1
2.0 TSI	DEDA	1	05/2015-12/2022	1984	162	220	1
2.0 TDI	CUVC DFLA DLTA	2	05/2015-12/2022	1968	110	150	1
2.0 TDI	CUWA DFMA	2	05/2015-08/2018	1968	135	184	1
2.0 TDI 4Drive	CUVC DFLA	2	05/2015-12/2022	1968	110	150	3
2.0 TDI 4Drive	DLUB	2	11/2018-12/2022	1968	130	177	3
2.0 TDI 4Drive	DFMA	2	05/2016-08/2018	1968	135	184	3

ALHAMBRA II (711) Box Body/MPV 06/2010-

Vehicle	Fuel	Date	CC	KW	CV	Traction
TSi	1	05/2015-12/2022	1395	110	150	1
TDI	2	05/2015-12/2022	1968	110	150	1
TDI	2	05/2015-08/2018	1968	135	184	1
TDI 4Drive	2	05/2015-12/2022	1968	110	150	3

TARRACO (KN2) SUV 09/2018-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 TSI ACT	DADA DPCA	1	09/2018-	1498	110	150	1
2.0 TFSI 4Drive		1	01/2021-	1984	180	245	3
2.0 TSI 4Drive	DKZA	1	11/2018-	1984	140	190	3
1.4 e-HYBRID		13	02/2021-	1395	180	245	1
2.0 TDI	DFGA	2	09/2018-	1968	110	150	1
2.0 TDI 4Drive	DFGA	2	09/2018-	1968	110	150	3
2.0 TDI 4Drive	DFHA	2	09/2018-	1968	140	190	3
2.0 TDI 4Drive	DTUA	2	07/2020-	1968	147	200	3

SKODA

(NZ5) Estate 11/2023-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 TSI mHEV		13	11/2023-	1498	110	150	1
2.0 TDI		2	11/2023-	1968	110	150	1

KODIAQ (NS6, NS7, NV7) SUV 10/2016-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZCA	1	10/2016-	1395	92	125	1
1.4 TSI	CZDA CZEA	1	10/2016-	1395	110	150	1
1.4 TSI 4x4	CZDA CZEA	1	10/2016-	1395	110	150	3
1.5 TSI	DADA DPCA	1	07/2018-	1498	110	150	1
1.5 TSI 4x4	DADA DPCA	1	07/2018-	1498	110	150	3
2.0 TSI 4x4	CZPA	1	10/2016-	1984	132	180	3
2.0 TSI 4x4	DKZA	1	02/2019-	1984	140	190	3
2.0 TDI		2	07/2018-	1968	85	116	1
2.0 TDI	DBGA DBGC DFGA DTSB	2	10/2016-	1968	110	150	1
2.0 TDI 4x4	DBGA DBGC DFGA DTSB	2	10/2016-	1968	110	150	3
2.0 TDI 4x4	CRGB	2	04/2017-	1968	130	177	3
2.0 TDI 4x4	DFHA	2	10/2016-	1968	140	190	3
2.0 TDI 4x4	DTUA	2	06/2020-	1968	147	200	3

SUPERB III (3V3) Hatchback 03/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZCA	1	03/2015-	1395	92	125	1
1.4 TSI	CZDA CZEA	1	03/2015-	1395	110	150	1
1.4 TSI 4x4	CZEA	1	03/2015-	1395	110	150	3
1.5 TSI	DADA DPCA	1	02/2017-	1498	110	150	1
1.8 TSI	CJSA CJSC	1	03/2015-	1798	132	180	1
2.0 TSI	CZPB DKZA DNNA	1	07/2019-	1984	140	190	1
2.0 TSI	CHHB	1	03/2015-	1984	162	220	1
2.0 TSI 4x4	DNUA	1	03/2015-	1984	200	272	3
2.0 TSI 4x4	CJXA DNFE	1	03/2015-	1984	206	280	3
1.4 TSI iV		13	08/2019-	1395	160	218	1
1.6 TDI	DCXA DCZA	2	03/2015-	1598	88	120	1
2.0 TDI		2	07/2020-	1968	90	122	1
2.0 TDI	CRLB DFEA DFGA DSRA DSRB	2	03/2015-	1968	110	150	1
2.0 TDI		2	03/2015-	1968	130	177	1
2.0 TDI	DDAA DFCA DFHA	2	03/2015-	1968	140	190	1
2.0 TDI	DTUA	2	09/2020-	1968	147	200	1
2.0 TDI 4x4	CRLB DFEA DFGA	2	03/2015-	1968	110	150	3
2.0 TDI 4x4	DDAA DFCA DFHA	2	03/2015-	1968	140	190	3
2.0 TDI 4x4	DTUA	2	09/2020-	1968	147	200	3

SUPERB III (3V5) Estate 03/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZCA	1	03/2015-	1395	92	125	1
1.4 TSI	CZDA CZEA	1	03/2015-	1395	110	150	1
1.4 TSI 4x4	CZEA	1	03/2015-	1395	110	150	3
1.5 TSI	DADA DPCA	1	02/2017-	1498	110	150	1
1.8 TSI	CJSA CJSC	1	03/2015-	1798	132	180	1
2.0 TSI	CZPB DKZA DNNA	1	07/2019-	1984	140	190	1
2.0 TSI	CHHB	1	03/2015-	1984	162	220	1
2.0 TSI 4x4	DNUA	1	03/2015-	1984	200	272	3
2.0 TSI 4x4	CJXA DNFE	1	03/2015-	1984	206	280	3
1.4 TSI iV		13	08/2019-	1395	160	218	1
1.6 TDI	DCXA DCZA	2	03/2015-	1598	88	120	1
2.0 TDI		2	07/2020-	1968	90	122	1
2.0 TDI	CRLB DFEA DFGA DSRA DSRB	2	03/2015-	1968	110	150	1
2.0 TDI		2	03/2015-	1968	130	177	1
2.0 TDI	DDAA DFCA DFHA	2	03/2015-	1968	140	190	1
2.0 TDI	DTUA	2	09/2020-	1968	147	200	1
2.0 TDI 4x4	CRLB DFEA DFGA	2	03/2015-	1968	110	150	3
2.0 TDI 4x4	DDAA DFCA DFHA	2	03/2015-	1968	140	190	3
2.0 TDI 4x4	DTUA	2	09/2020-	1968	147	200	3

VW

ARTEON (3H7, 3H8) Hatchback 03/2017-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 TSI	DADA DPCA	1	11/2017-	1498	110	150	1
2.0 TSI	CZPB DKZA	1	05/2017-	1984	140	190	1
2.0 TSI 4motion	DLRB DNUA	1	04/2018-	1984	200	272	3
2.0 TSI 4motion	DJHC	1	04/2017-	1984	206	280	3
2.0 TSI R		1	11/2020-	1984	235	320	3
1.4 eHybrid		13	11/2020-	1395	160	218	1
2.0 TDI	DBGA DFGA DSRA DSRB DTSA DTSB	2	03/2017-	1968	110	150	1
2.0 TDI	DFHA	2	05/2017-06/2020	1968	140	190	1
2.0 TDI		2	09/2020-	1968	147	200	1
2.0 TDI 4motion	DFHA	2	05/2017-06/2020	1968	140	190	3
2.0 TDI 4motion		2	09/2020-	1968	147	200	3
2.0 TDI 4motion	CUAA	2	03/2017-07/2020	1968	176	240	3

ARTEON SHOOTING BRAKE (3H9) Estate 06/2020-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 TSI	DADA DPCA	1	08/2020-	1498	110	150	1
2.0 TSI		1	09/2020-	1984	140	190	1
2.0 TSI 4motion	DLRB	1	06/2020-	1984	200	272	3
2.0 TSI 4motion		1	06/2020-	1984	206	280	3
2.0 TSI R		1	11/2020-	1984	235	320	3
1.4 eHybrid		13	11/2020-	1395	160	218	1
2.0 TDI	DSRA DSRB DTSB	2	09/2020-	1968	110	150	1
2.0 TDI	DFHA	2	09/2020-	1968	140	190	1
2.0 TDI		2	09/2020-	1968	147	200	1
2.0 TDI 4motion	DFHA	2	09/2020-	1968	140	190	3
2.0 TDI 4motion	DTUA	2	09/2020-	1968	147	200	3

CADDY IV (SBB, SBJ) MPV 09/2020-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 TSi EVO		1	01/2021-11/2024	1498	84	114	1
1.6 SRE		1	02/2021-	1598	81	110	1
1.5 TGI CNG		16	06/2022-04/2024	1498	96	131	1
2.0 TDi BMT		2	09/2020-	1968	55	75	1
2.0 TDi BMT	DTRE	2	09/2020-	1968	75	102	1
2.0 TDi BMT	DTRC	2	09/2020-	1968	90	122	1
2.0 TDI BMT 4motion		2	03/2021-	1968	90	122	3

CADDY IV (SBA, SBH) Box Body/MPV 09/2020-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 TSi EVO		1	01/2021-11/2024	1498	84	114	1
1.6 SRE		1	02/2021-	1598	81	110	1
1.5 TGI CNG		16	06/2022-04/2024	1498	96	131	1
2.0 TDi BMT	DTRF	2	09/2020-	1968	55	75	1
2.0 TDi BMT	DTRE	2	09/2020-	1968	75	102	1
2.0 TDi BMT	DTRC	2	09/2020-	1968	90	122	1
2.0 TDI BMT 4motion		2	03/2021-	1968	90	122	3

CADDY CALIFORNIA V (SBB, SBJ) MPV 09/2020-

Vehicle	Fuel	Date	CC	KW	CV	Traction
1.5 TSi EVO	1	01/2021-11/2024	1498	84	114	1
1.6 SRE	1	02/2021-	1598	81	110	1
2.0 TDi BMT	2	09/2020-	1968	55	75	1
2.0 TDi BMT	2	09/2020-	1968	75	102	1
2.0 TDi BMT	2	09/2020-	1968	90	122	1
2.0 TDI BMT 4motion	2	03/2021-	1968	90	122	3

GOLF VII / JETTA VII (5G1, BQ1, BE1, BE2) Hatchback 08/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 TSI	CHZC	1	11/2016-08/2020	999	81	110	1
1.0 TSI	CHZD DKRF	1	05/2015-08/2020	999	85	115	1
1.2 TSI	CJZB CYVA	1	08/2012-03/2017	1197	63	86	1
1.2 TSI	CJZA	1	11/2012-03/2017	1197	77	105	1
1.2 TSI	CYVB	1	04/2014-03/2017	1197	81	110	1
1.4 TSI	CMBA CXSA	1	11/2012-03/2017	1395	90	122	1
1.4 TSI	CZCA	1	05/2014-08/2020	1395	92	125	1
1.4 TSI	CHPA CPTA	1	08/2012-07/2017	1395	103	140	1
1.4 TSI	CHPB CZDA CZEA DGXA	1	05/2014-03/2021	1395	110	150	1
1.5 TSI	DACA	1	05/2017-08/2020	1495	96	130	1
1.5 TSI	DADA DPCA	1	04/2017-08/2020	1498	110	150	1
1.6	CWVA	1	05/2014-07/2017	1598	81	110	1
1.8 TSI		1	07/2013-07/2017	1798	125	170	1
2.0 GTI	CNTA CXCA	1	11/2013-07/2017	1984	155	210	1
2.0 GTI	CHHB CNTC CXCB CXDA	1	04/2013-08/2020	1984	162	220	1
2.0 GTI	CHHA CXDB	1	04/2013-08/2020	1984	169	230	1
2.0 GTI	DKTB DLBA	1	03/2017-08/2020	1984	180	245	1
2.0 GTI Clubsport	CJXE	1	02/2016-03/2017	1984	195	265	1
2.0 R 4motion	CJXB	1	11/2013-03/2017	1984	206	280	3
2.0 R 4motion	CJXC DNUE	1	11/2013-08/2020	1984	221	300	3
1.4 GTE Hybrid	CUKB	13	05/2014-08/2020	1395	150	204	1
1.4 TGI CNG	CPWA CZBA	16	06/2013-07/2018	1395	81	110	1
1.5 TGI	DHFA	16	11/2018-08/2020	1498	96	130	1
1.4 TSI MultiFuel	CPVA	19	11/2012-03/2017	1395	90	122	1
1.4 TSI MultiFuel	CPVB	19	12/2013-07/2018	1395	92	125	1
1.6 TDI	CLHB CRKA CXXA DDYB	2	04/2013-07/2018	1598	66	90	1
1.6 TDI	CLHA	2	08/2012-03/2017	1598	77	105	1
1.6 TDI	CRKB CXXB DBKA	2	01/2013-03/2017	1598	81	110	1
1.6 TDI	DDYA DGTE	2	11/2016-08/2020	1598	85	115	1
1.6 TDI 4motion	CLHA	2	11/2012-03/2017	1598	77	105	3
1.6 TDI 4motion	CRKB CXXB	2	01/2013-03/2017	1598	81	110	3
2.0 GTD		2	11/2016-	1968	130	177	1
2.0 GTD	CUNA DGCA DJGA	2	04/2013-08/2020	1968	135	184	1
2.0 TDI	CRLD CRVA CYKB DCYB DEJB DFGB	2	11/2012-08/2020	1968	81	110	1
2.0 TDI	CRBB CRVC	2	08/2012-08/2020	1968	105	143	1
2.0 TDI	CRBC CRLB CRMB CRUA DCYA DEJA DFGA	2	08/2012-08/2020	1968	110	150	1
2.0 TDI 4motion	CKFC CRBC CRLB CRMB DCYA	2	11/2012-08/2020	1968	110	150	3

GOLF VII / JETTA VII (5G1) Hatchback Van 08/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 TSi BlueMotion	CJZB	1	08/2012-03/2017	1197	63	86	1
1.2 TSi BlueMotion	CJZA	1	11/2012-03/2017	1197	77	105	1
1.4 TSi BlueMotion	CXSA	1	05/2013-03/2017	1395	90	122	1
1.4 TSi BlueMotion	CHPA	1	08/2012-03/2017	1395	103	140	1
2.0 GTI	CHHB	1	04/2013-03/2017	1984	162	220	1
2.0 GTI	CHHA	1	04/2015-03/2017	1984	169	230	1
1.6 TDi BlueMotion	CRKA	2	04/2013-03/2017	1598	66	90	1
1.6 TDi BlueMotion	CLHA	2	08/2012-03/2017	1598	77	105	1
1.6 TDi BlueMotion	CRKB CXXB	2	11/2013-03/2017	1598	81	110	1
2.0 GTD	CUNA	2	04/2013-03/2017	1968	135	184	1
2.0 TDI BlueMotion		2	05/2013-05/2014	1968	110	150	1
2.0 TDi BlueMotion 4motion	CRBC	2	05/2013-05/2014	1968	110	150	3

GOLF VII VAN Variant / JETTA VII (BA5) Estate Van 04/2013-03/2017

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 TSi BlueMotion	CJZB CYVA	1	05/2013-03/2017	1197	63	86	1
1.2 TSi BlueMotion	CJZA	1	04/2013-03/2017	1197	77	105	1
1.4 TSi BlueMotion	CXSA	1	05/2013-03/2017	1395	90	122	1
1.4 TSi BlueMotion	CHPA	1	05/2013-03/2017	1395	103	140	1
1.6 TDi BlueMotion	CLHB CRKA CXXA	2	05/2013-03/2017	1598	66	90	1
1.6 TDi BlueMotion	CLHA	2	05/2013-03/2017	1598	77	105	1
1.6 TDi BlueMotion	CRKB	2	05/2013-03/2017	1598	81	110	1
1.6 TDi BlueMotion 4motion	CLHA	2	05/2013-03/2017	1598	77	105	3
2.0 TDI BlueMotion	CRBC CRLB	2	04/2013-03/2017	1968	110	150	1
2.0 TDi BlueMotion 4motion	CRBC CRLB	2	04/2013-03/2017	1968	110	150	3

GOLF VII Variant / JETTA VII (BA5, BV5) Estate 04/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 TSI	CHZK DKLB	1	01/2017-07/2019	999	63	86	1
1.0 TSI	CHZC	1	11/2016-08/2020	999	81	110	1
1.0 TSI	CHZD DKRF	1	05/2015-08/2020	999	85	115	1
1.2 TSI	CJZB CYVA	1	05/2013-03/2017	1197	63	86	1
1.2 TSI	CJZA	1	04/2013-08/2020	1197	77	105	1
1.2 TSI	CYVB	1	04/2014-03/2017	1197	81	110	1
1.4 TSI	CXSA	1	05/2013-03/2017	1395	90	122	1
1.4 TSI	CZCA CZDD	1	05/2014-08/2020	1395	92	125	1
1.4 TSI	CHPA	1	05/2013-08/2020	1395	103	140	1
1.4 TSI	CHPB CZDA DGXA	1	05/2014-03/2021	1395	110	150	1
1.5 TSI	DACA DPBA	1	07/2017-08/2020	1495	96	130	1
1.5 TSI	DADA DPCA	1	04/2017-08/2020	1498	110	150	1
1.6	CWVA	1	05/2014-07/2017	1598	81	110	1
2.0 R 4motion	CJXB	1	03/2015-03/2017	1984	206	280	3
2.0 R 4motion	CJXC DNUE	1	03/2015-08/2020	1984	221	300	3
1.4 TGI CNG	CPWA	16	09/2013-07/2018	1395	81	110	1
1.5 TGI	DHFA	16	12/2018-08/2020	1498	96	131	1
1.4 TSI MultiFuel	CPVA	19	04/2013-03/2017	1395	90	122	1
1.4 TSI MultiFuel	CPVB	19	05/2014-03/2017	1395	92	125	1
1.6 TDI	CLHB CRKA CXXA DDYB	2	05/2013-07/2018	1598	66	90	1
1.6 TDI	CLHA	2	05/2013-03/2017	1598	77	105	1
1.6 TDI	CRKB CXXB DBKA	2	05/2013-03/2017	1598	81	110	1
1.6 TDI	DDYA DGTE	2	11/2016-08/2020	1598	85	115	1
1.6 TDI 4motion	CLHA	2	05/2013-03/2017	1598	77	105	3
1.6 TDI 4motion	CRKB CXXB	2	05/2013-03/2017	1598	81	110	3
2.0 GTD		2	11/2016-	1968	130	177	1
2.0 GTD	CUNA DGCA DJGA	2	01/2015-07/2019	1968	135	184	1
2.0 TDI	CRLD CRVA CYKB DCYB DEJB DFGB	2	05/2013-08/2020	1968	81	110	1
2.0 TDI	CRBC CRLB CRUA DCYA DEJA DFGA	2	04/2013-08/2020	1968	110	150	1
2.0 TDI 4motion	CRBC CRLB DCYA	2	04/2013-08/2020	1968	110	150	3

GOLF VII ALLTRACK Variant (BA5, BV5) Estate 12/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 TSI 4motion	CJSB	1	12/2014-08/2020	1798	132	180	3
1.6 TDI 4motion	CRKB CXXB	2	12/2014-03/2017	1598	81	110	3
2.0 TDI 4motion	CRBC CRLB DCYA	2	12/2014-08/2020	1968	110	150	3
2.0 TDI 4motion	CUNA DGCA DJGA	2	12/2014-08/2020	1968	135	184	3

JETTA VII (BU3, BU4) Saloon 12/2017-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 TSI		1	10/2021-	1498	118	160	1

PASSAT B8 (3G2, CB2) Saloon 08/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZCA	1	11/2014-	1395	92	125	1
1.4 TSI	CZDA CZEA	1	11/2014-	1395	110	150	1
1.4 TSI 4motion	CZEA	1	02/2015-	1395	110	150	3
1.5 TSI	DADA DPCA	1	08/2018-	1498	110	150	1
1.8 TSI	CJSA CJSC	1	02/2015-	1798	132	180	1
2.0 TSI	CZPB DKZA DRFA	1	11/2018-	1984	140	190	1
2.0 TSI	CHHB CXDA	1	02/2015-	1984	162	220	1
2.0 TSI 4motion	DNUA	1	09/2018-	1984	200	272	3
2.0 TSI 4motion	CJXA	1	05/2015-	1984	206	280	3
1.4 GTE Hybrid	CUKC DGEB	13	06/2015-	1395	160	218	1
1.6 TDI	DCXA DCZA	2	08/2014-	1598	88	120	1
2.0 TDI	CRLD DBGB DFGB	2	01/2016-05/2017	1968	81	110	1
2.0 TDI	DTRA	2	07/2020-	1968	90	122	1
2.0 TDI	CRLB DBGA DFGA DSRA DSRB	2	11/2014-	1968	110	150	1
2.0 TDI	CUPA	2	07/2015-	1968	135	184	1
2.0 TDI	DDAA DFCA DFHA	2	11/2014-	1968	140	190	1
2.0 TDI		2	09/2020-	1968	147	200	1
2.0 TDI 4motion	CRLB DFEA DFGA	2	08/2014-	1968	110	150	3
2.0 TDI 4motion	DTUA	2	08/2020-	1968	147	200	3
2.0 TDI 4motion	CUAA	2	08/2014-	1968	176	240	3

PASSAT B8 Variant (3G5, CB5) Estate 08/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZCA	1	11/2014-	1395	92	125	1
1.4 TSI	CZDA CZEA	1	11/2014-	1395	110	150	1
1.4 TSI 4motion	CZEA	1	02/2015-	1395	110	150	3
1.5 TSI	DADA DPCA	1	08/2018-	1498	110	150	1
1.8 TSI	CJSA CJSC	1	02/2015-	1798	132	180	1
2.0 TSI	CZPB DKZA DRFA	1	11/2018-	1984	140	190	1
2.0 TSI	CHHB CXDA	1	08/2014-	1984	162	220	1
2.0 TSI 4motion	DNUA	1	09/2018-	1984	200	272	3
2.0 TSI 4motion	CJXA	1	05/2015-	1984	206	280	3
1.4 GTE Hybrid	CUKC DGEB	13	06/2015-	1395	160	218	1
1.6 TDI	DCXA DCZA	2	08/2014-	1598	88	120	1
2.0 TDI		2	01/2016-07/2018	1968	81	110	1
2.0 TDI	DTRA	2	07/2020-	1968	90	122	1
2.0 TDI	CRLB DBGA DFGA DSRA DSRB	2	11/2014-	1968	110	150	1
2.0 TDI	CUPA	2	07/2015-	1968	135	184	1
2.0 TDI	DDAA DFCA DFHA	2	11/2014-	1968	140	190	1
2.0 TDI		2	09/2020-	1968	147	200	1
2.0 TDI 4motion	CRLB DFEA DFGA	2	08/2014-	1968	110	150	3
2.0 TDI 4motion	DDAA DFCA DFHA	2	11/2014-	1968	140	190	3
2.0 TDI 4motion	DTUA	2	08/2020-	1968	147	200	3
2.0 TDI 4motion	CUAA	2	08/2014-	1968	176	240	3

PASSAT B8 ALLTRACK Variant (3G5, CB5) Estate 05/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI 4motion	CZEA	1	05/2015-	1395	110	150	3
2.0 TSI 4motion	CHHB	1	07/2015-	1984	162	220	3
2.0 TSI 4motion	DNUA	1	08/2018-	1984	200	272	3
2.0 TSI 4motion	CJXA	1	11/2018-	1984	206	280	3
2.0 TDI 4motion	CRLB DFEA	2	05/2015-11/2017	1968	110	150	3
2.0 TDI 4motion	CUPA	2	07/2015-	1968	135	184	3
2.0 TDI 4motion	DDAA DFCA DFHA	2	05/2015-	1968	140	190	3
2.0 TDI 4motion		2	08/2020-	1968	147	200	3
2.0 TDI 4motion	CUAA	2	05/2015-	1968	176	240	3

SHARAN II (7N1, 7N2) MPV 05/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZDA DJKA	1	05/2015-11/2022	1395	110	150	1
2.0 TSI	DEDA	1	05/2015-12/2020	1984	162	220	1
2.0 TDI	CUVC DFLA DLTA	2	05/2015-10/2020	1968	110	150	1
2.0 TDI	CUWA DFMA	2	05/2015-07/2018	1968	135	184	1
2.0 TDI 4motion	CUVC DFLA DLTA	2	05/2015-07/2019	1968	110	150	3
2.0 TDI 4motion	DLUB	2	07/2018-10/2020	1968	130	177	3
2.0 TDI 4motion	DFMA	2	05/2016-07/2018	1968	135	184	3

TIGUAN II (AD1) SUV Van 07/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
TDI BlueMotion		2	01/2016-07/2020	1968	140	190	3

TIGUAN II (AD1, AX1) SUV 01/2016-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZCA	1	01/2016-03/2022	1395	92	125	1
1.4 TSI	CZDA CZEA DJVA	1	05/2016-	1395	110	150	1
1.4 TSI 4motion	CZDA CZEA	1	05/2016-07/2018	1395	110	150	3
1.5 TSI	DPBE	1	07/2018-	1498	96	131	1
1.5 TSI	DADA DPCA	1	11/2018-	1498	110	150	1
2.0 TSI 4motion	CZPA	1	01/2016-	1984	132	180	3
2.0 TSI 4motion	DKZA DRFA	1	09/2018-	1984	140	190	3
2.0 TSI 4motion	CHHB	1	06/2016-	1984	162	220	3
2.0 TSI 4motion	DKTA	1	09/2018-07/2020	1984	169	230	3
2.0 TSI 4motion		1	01/2021-	1984	180	245	3
1.4 eHybrid		13	11/2020-	1395	180	245	1
1.6 TDI	DGDB	2	05/2016-06/2020	1598	85	115	1
2.0 TDI	CYKC	2	08/2016-07/2020	1968	81	110	1
2.0 TDI	DFGC	2	05/2016-07/2019	1968	85	115	1
2.0 TDI		2	06/2020-	1968	90	122	1
2.0 TDI	DFGA DTSA DTSB	2	01/2016-	1968	110	150	1
2.0 TDI 4motion		2	06/2016-07/2020	1968	105	143	3
2.0 TDI 4motion	DBGC DFGA DTSA DTSB	2	01/2016-07/2020	1968	110	150	3
2.0 TDI 4motion	CRGB	2	08/2016-07/2020	1968	130	177	3
2.0 TDI 4motion	DFHA	2	04/2016-07/2020	1968	140	190	3
2.0 TDI 4motion	DTUA	2	06/2020-	1968	147	200	3
2.0 TDI 4motion	CUAA	2	05/2016-07/2020	1968	176	240	3

TIGUAN ALLSPACE (BW2, BJ2) SUV 03/2017-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 TSI	CZDA CZEA	1	06/2017-	1395	110	150	1
1.4 TSI		1	07/2017-	1395	110	150	1
1.5 TSI	DADA DPCA	1	09/2018-	1498	110	150	1
2.0 TSI	DGUA	1	04/2017-	1984	137	186	1
2.0 TSI 4motion	DGVA	1	03/2017-	1984	132	180	3
2.0 TSI 4motion		1	03/2020-	1984	136	185	3
2.0 TSI 4motion	DGUA	1	04/2017-	1984	137	186	3
2.0 TSI 4motion	DNLA	1	09/2018-	1984	140	190	3
2.0 TSI 4motion	CXDA DNJA	1	07/2017-	1984	162	220	3
2.0 TSI 4motion		1	09/2020-	1984	180	245	3
1.4 TSI E100 Flex	CWLA	19	07/2017-	1395	110	150	1
2.0 TDI	DFGA	2	06/2017-	1968	110	150	1
2.0 TDI 4motion	DBGC DFGA	2	06/2017-	1968	110	150	3
2.0 TDI 4motion	DFHA	2	06/2017-07/2021	1968	140	190	3
2.0 TDI 4motion		2	06/2020-	1968	147	200	3
2.0 TDI 4motion	CUAA	2	06/2017-09/2020	1968	176	240	3

TOURAN III (5T1) MPV 05/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 TSI	DKRB	1	12/2018-	999	85	116	1
1.2 TSI	CYVB	1	05/2015-	1197	81	110	1
1.4 TSI	CZDA	1	05/2015-	1395	110	150	1
1.5 TSI	DADA DPCA	1	11/2018-	1498	110	150	1
1.8 TSI	CJSA	1	11/2015-	1798	132	180	1
1.6 TDI	CRKB	2	05/2015-05/2016	1598	81	110	1
2.0 TDI	CRVA CYKB DFEB DFGB	2	11/2015-07/2019	1968	81	110	1
2.0 TDI	DFGC	2	02/2019-	1968	85	116	1
2.0 TDI		2	11/2020-	1968	90	122	1
2.0 TDI	DFEA DFGA	2	05/2015-	1968	110	150	1
2.0 TDI	DFHA	2	11/2015-07/2019	1968	140	190	1

TOURAN III (5T1) Box Body/MPV 05/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 TDI		2	11/2020-	1968	90	122	1
2.0 TDI		2	11/2020-	1968	110	150	1

VW (SVW)

TOURAN III (9R3) MPV 06/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6		1	06/2014-	1598	81	110	1

TOURAN L (0R1) MPV 03/2016-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6	CSRA	1	10/2017-	1598	81	110	1
280TSi	CSSA, DJSA	1	03/2016-	1395	110	150	1
330 Ti	CUFA	1	03/2016-	1798	132	180	1

Return
