Product 78BD5644-1 - Web Catalogo

Product 78BD5644-1

Description: Brake disc
Axe: Rear
No. of Pieces: 1
Barcode: 8424073288806
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5644-1
Weight (gr.): 8520

R90 Homologation: 90R-02C0415/0092
Measures: Ø288x16x68.8
: Brake Disc Type: solid; Minimum thickness [mm]: 13; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 160; Wheel Hub Diameter [mm]: 96

Reference applications

Brand	OE Reference
FORD	1 764 283
FORD	1 867 715
FORD	2 013 002
FORD	2021562
FORD	BK21-2A097-BA
FORD	BK21-2A097-FA

Maker	Cross reference
ATE	24.0116-0235.1
BOSCH	0 986 479 H68
BREMBO	08.D505.20
DELPHI LOCKHEED	BG4784C
FERODO	DDF2472
GIRLING	6065105
HELLA-PAGID	8DD 355 120-181
LETEC	LBF064S*
MINTEX	MDC2552
TEXTAR	93260703
TRW	DF6510S

FORD

TOURNEO CUSTOM V362 (F3) Bus 09/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 EcoBoost PHEV	M1FA	13	04/2020-12/2023	996	92	125	1
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	12/2015-12/2023	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	12/2015-12/2023	1995	96	130	1
2.0 EcoBlue		2	01/2022-12/2023	1995	110	150	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	12/2015-12/2023	1995	125	170	1
2.0 EcoBlue	BCFA BCFB	2	05/2019-12/2023	1995	136	185	1
2.2 TDCi	DRF4 DRFF DRFG	2	09/2012-12/2015	2198	74	100	1
2.2 TDCi	CYF4 CYFF	2	09/2012-12/2015	2198	92	125	1
2.2 TDCi	CVFF	2	09/2012-12/2015	2198	114	155	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-12/2023	1995	96	130	1
2.0 EcoBlue mHEV		14	01/2022-12/2023	1995	110	150	1
2.0 EcoBlue mHEV	BCFC BCFD	14	05/2019-12/2023	1995	136	185	1

TRANSIT VI V363 (FCD, FDD) Van 08/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	03/2016-	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	03/2016-	1995	96	130	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	03/2016-06/2024	1995	125	170	1
2.0 EcoBlue	BCFB	2	05/2019-	1995	136	185	1
2.0 EcoBlue RWD	BCRA	2	05/2019-	1995	136	185	2
2.2 TDCi	DRF5 DRFF DRFG	2	08/2013-12/2018	2198	74	100	1
2.2 TDCi	CY14 CYF5 CYFG USF6	2	08/2013-12/2018	2198	92	125	1
2.2 TDCi	CVF5	2	08/2013-12/2018	2198	114	155	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-	1995	96	130	1
2.0 EcoBlue mHEV	BLFC BLFD	14	05/2019-06/2024	1995	125	170	1
2.0 EcoBlue mHEV RWD	BKRB	14	05/2019-	1995	96	130	2
2.0 EcoBlue mHEV RWD	BLRB	14	05/2019-06/2024	1995	125	170	2

TRANSIT VI V363 (FED, FFD) Platform/Chassis 08/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	03/2016-	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	03/2016-	1995	96	130	1
2.0 EcoBlue		2	01/2021-	1995	118	160	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	03/2016-06/2024	1995	125	170	1
2.0 EcoBlue	BCFB	2	05/2019-	1995	136	185	1
2.0 EcoBlue RWD	BCRA	2	05/2019-	1995	136	185	2
2.2 TDCi	DRF5 DRFF DRFG	2	08/2013-12/2018	2198	74	100	1
2.2 TDCi	CY14 CYF5 CYFG USF6	2	08/2013-12/2018	2198	92	125	1
2.2 TDCi	CVF5	2	08/2013-12/2018	2198	114	155	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-	1995	96	130	1
2.0 EcoBlue mHEV	BLFC BLFD	14	05/2019-06/2024	1995	125	170	1
2.0 EcoBlue mHEV RWD	BKRB	14	05/2019-	1995	96	130	2
2.0 EcoBlue mHEV RWD	BLRB	14	05/2019-06/2024	1995	125	170	2

TRANSIT VI V363 (FAD, FBD) Bus 08/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.7 RWD	C37PDED	1	09/2015-12/2019	3726	205	279	2
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	03/2016-	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	03/2016-	1995	96	130	1
2.0 EcoBlue		2	10/2021-	1995	110	150	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	03/2016-06/2024	1995	125	170	1
2.0 EcoBlue RWD	BLHA	2	05/2019-06/2024	1995	125	170	2
2.2 TDCi	DRF5 DRFF DRFG	2	08/2013-12/2018	2198	74	100	1
2.2 TDCi	CY14 CYF5 CYFG USF6	2	08/2013-12/2018	2198	92	125	1
2.2 TDCi	CVF5	2	12/2014-12/2018	2198	114	155	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-	1995	96	130	1
2.0 EcoBlue mHEV		14	10/2021-	1995	110	150	1
2.0 EcoBlue mHEV	BLFC BLFD	14	05/2019-06/2024	1995	125	170	1

TRANSIT CUSTOM V362 (F3) Bus 04/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 EcoBoost PHEV	M1FA	13	04/2020-12/2023	996	92	125	1
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	12/2015-12/2023	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	12/2015-12/2023	1995	96	130	1
2.0 EcoBlue		2	01/2022-12/2023	1995	110	150	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	12/2015-12/2023	1995	125	170	1
2.0 EcoBlue	BCFA BCFB	2	05/2019-12/2023	1995	136	185	1
2.2 TDCi	DRF4 DRFF DRFG	2	09/2012-12/2015	2198	74	100	1
2.2 TDCi	CYF4 CYFF	2	09/2012-12/2015	2198	92	125	1
2.2 TDCi	CVFF	2	09/2012-12/2015	2198	114	155	1
2.0 EcoBlue mHEV	BJFC BJFD	14	05/2019-12/2023	1995	77	105	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-12/2023	1995	96	130	1
2.0 EcoBlue mHEV		14	01/2022-12/2023	1995	110	150	1
2.0 EcoBlue mHEV	BLFC BLFD	14	05/2019-12/2023	1995	125	170	1
2.0 EcoBlue mHEV	BCFC BCFD	14	05/2019-12/2023	1995	136	185	1

TRANSIT CUSTOM V362 (FY, FZ) Van 09/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	12/2015-12/2023	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	12/2015-12/2023	1995	96	130	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	12/2015-12/2023	1995	125	170	1
2.0 EcoBlue	BCFA BCFB	2	05/2019-12/2023	1995	136	185	1
2.2 TDCi	DRF4 DRFF DRFG	2	09/2012-12/2015	2198	74	100	1
2.2 TDCi	CYF4 CYFF	2	09/2012-12/2023	2198	92	125	1
2.2 TDCi	CVFF	2	09/2012-12/2015	2198	114	155	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-12/2023	1995	96	130	1
2.0 EcoBlue mHEV	BLFC BLFD	14	05/2019-12/2023	1995	125	170	1
2.0 EcoBlue mHEV	BCFC BCFD	14	05/2019-12/2023	1995	136	185	1

FORD AUSTRALIA

TOURNEO () Bus 05/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi		2	05/2014-	2198	114	155	2

TRANSIT (VO) Platform/Chassis 09/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi		2	09/2014-	2198	114	155	2

TRANSIT CUSTOM (VN) Van 09/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi		2	09/2013-	2198	92	125	2
