Product 78BD5812-2


Description
Brake disc
Axe
Front-Rear
No. of Pieces
2
Barcode
EAN13 Code
8424073147455
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5812-2
Weight (gr.)
6360
R90 Homologation
R90 90R-02C0415/0064
Measures
Ø227x10.8x45.8
Brake Disc Type: solid
Minimum thickness [mm]: 9
Hole Arrangement/Number: 4
Bolt Hole Circle Ø [mm]: 98
Wheel Hub Diameter [mm]: 61.5
Brand OE Reference
AUTOBIANCHI 4 139 010
AUTOBIANCHI 4 208 311
AUTOBIANCHI 4 385 812
AUTOBIANCHI 9 438 581 2
AUTOBIANCHI 9 443 901 0
AUTOBIANCHI RF16500250
AUTOBIANCHI RF16500253
FIAT 1 650 025 3
FSO 655 438 512
FSO 655 439 010
LANCIA 7 173 842 2
LANCIA RF16-500250
LANCIA RF16-500253
SEAT 009 843 771 02
SEAT 009 843 858 12
SEAT 4 38 5812
SEAT RF1 650 0250
SEAT RF1 650 0253
SEAT SE0 221 650 02 A
ZASTAVA 0 420 831 1
ZASTAVA 0 438 581 2
ZASTAVA 4 2083 11
ZASTAVA 4 385 812
ZASTAVA 4 661 870 3
ZASTAVA RF16500250
ZASTAVA RF16500253
Maker Cross reference
ATE 24.0111-0130.1
ATE 411130
BENDIX ANTIGUO 561380B
BOSCH 0 986 478 063
BREMBO 08.3636.10
DELPHI LOCKHEED BG2147
LETEC LBY001S
ROAD HOUSE 6030.00
SANLI SL10161
TRW DF1721
Vehicle Engine Fuel Date CC KW CV Traction
1.4

124 BLC.000

1 08/1969-11/1972 1438 51 70 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9

A112A 5.000

1 10/1969-12/1972 903 32 44 1
0.9

A112A 5.000

1 01/1976-12/1978 903 33 45 1
0.9 E

A112A 5.000

1 01/1973-12/1977 903 34 47 1
0.9 Junior

A112A 5.000

A112B2.000

1 07/1975-12/1985 903 31 42 1
1.0 Abarth

A112A1.000

1 09/1971-12/1975 982 43 58 1
1.0 Abarth

A112A2.000

1 01/1974-12/1984 1050 51 70 1
1.0 E,Elite,LX

A112B1.000

1 11/1977-12/1985 965 35 48 1
Vehicle Engine Fuel Date CC KW CV Traction
1.0 1 03/1986-12/1992 999 32 44 1
1.0

156 A2.000

1 03/1985-10/1995 999 33 45 1
1.0

156A.000

1 03/1985-10/1995 1049 41 56 1
1.0 4WD

156 A3.000

1 12/1986-10/1995 999 37 50 3
1.0 Cat

156A2.246

1 10/1987-10/1995 999 33 45 1
1.0 Turbo

156A1.000

1 03/1985-10/1995 1049 63 85 1
1.1 1 02/1990-09/1992 1108 37 50 1
1.1

156C.000

1 06/1989-10/1995 1108 42 57 1
1.1 4WD

156C.000

1 06/1989-10/1995 1108 42 57 3
1.1 4WD (156AC) 1 02/1990-04/1991 1108 37 50 3
1.1 4WD (156AH) 1 10/1994-08/1995 1108 40 54 3
1.1 i.e. Cat

156C.046

1 09/1990-10/1995 1108 42 57 1
Vehicle Engine Fuel Date CC KW CV Traction
1500 Sport (BS)

124 AC.000

1 01/1966-12/1972 1438 66 90 2
1600 Sport (BS)

125 B.000

1 11/1969-08/1973 1608 82 112 2
1600 Sport (BS1)

125 B.000

1 11/1969-08/1973 1608 74 100 2
1600 Sport (BS1)

125 B.000

1 01/1969-12/1974 1608 81 110 2
1600 Sport (CS)

125 B.000

1 01/1969-12/1974 1608 76 104 2
1800 Rally Abarth (CSA)

132 AC1.000

1 09/1972-07/1975 1756 94 128 2
1800 Sport (CS1) 1 01/1973-07/1975 1739 82 112 2
1800 Sport (CS1)

132 AC1.000

1 01/1972-12/1977 1756 87 118 2
2000

132 C3.031

1 04/1972-11/1985 1995 77 105 2
Vehicle Engine Fuel Date CC KW CV Traction
1200 (124A)

124 A.000

1 09/1967-07/1975 1197 48 65 2
1200 (TA)

124 A.000

1 07/1966-10/1973 1197 44 60 2
1400 Special

124 B2.000

1 12/1968-12/1972 1438 51 70 2
1400 Special (124A)

124 B2.000

1 01/1971-07/1975 1438 55 75 2
1500 Special T

124 AC.000

1 01/1971-07/1975 1438 59 80 2
1600 Special T (124A)

124 A9.000

132 AC.000

1 01/1973-07/1975 1592 70 95 2
Vehicle Engine Fuel Date CC KW CV Traction
1.4

124 B.000

1 09/1967-05/1971 1438 51 69 2
1200

124 A.000

1 04/1967-05/1973 1197 44 60 2
1200

124 A.000

1 05/1973-03/1975 1197 48 65 2
Vehicle Engine Fuel Date CC KW CV Traction
1400 Sport

124 AC.000

1 06/1967-10/1972 1438 66 90 2
1600 (BC 1)

125 B.000

1 11/1971-10/1973 1608 74 100 2
1600 (BC 1)

125 B.000

1 04/1970-10/1973 1608 81 110 2
1600 Sport

132 AC.000

1 08/1972-12/1975 1592 76 104 2
1600 Sport

132 AC.000

1 08/1972-02/1976 1592 80 108 2
1800 Sport 1 01/1973-02/1976 1756 82 112 2
1800 Sport (CC1) 1 01/1973-02/1976 1756 87 118 2
Vehicle Engine Fuel Date CC KW CV Traction
1.3

131 A.000

1 06/1968-03/1974 1297 48 65 2
1.6 (TA)

125 A.000

1 07/1967-03/1974 1608 66 90 2
1.6 (TA)

125 B.000

1 10/1968-10/1973 1608 74 100 2
Vehicle Engine Fuel Date CC KW CV Traction
0.9

100 GL.048

1 06/1971-05/1983 903 29 40 1
0.9 (127A)

100 GL.000

1 09/1971-12/1984 903 33 45 1
1.0

127 A.000

1 04/1977-12/1986 1049 37 50 1
1.0 Sport

127 A1.000

1 07/1978-02/1982 1049 51 70 1
1.3 Sport

127 A3.000

1 12/1981-05/1983 1301 55 75 1
1.3 Diesel

127 A5.000

2 04/1981-12/1986 1301 33 45 1
Vehicle Engine Fuel Date CC KW CV Traction
1.0

127 A.000

1 01/1977-12/1986 1049 37 50 1
1.3 D

127 A5.000

2 06/1981-12/1986 1301 33 45 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1

128 A.048

1 02/1975-09/1981 1116 33 45 1
1.1 (128A)

128 A.000

1 03/1969-12/1984 1116 40 55 1
1.3 (128A)

128 A1.000

1 08/1974-12/1984 1290 44 60 1
1.3 Rally (128A)

128 AR.000

1 07/1971-02/1976 1290 49 67 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1 (AF)

128 A.048

1 02/1975-02/1981 1116 33 45 1
1.1 (AF)

128 A.000

1 10/1969-10/1982 1116 40 55 1
1.3 (AF1)

128 A1.000

1 12/1974-10/1982 1290 44 60 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1 (AC 5)

128 AC5.000

1 03/1972-02/1981 1116 47 64 1
1.1 (AC 5)

128 AC5.000

1 08/1975-02/1981 1116 48 65 1
1.3 (AC)

128 A1.000

128 AC.000

1 03/1972-12/1979 1290 55 75 1
1.3 Berlinetta (AC)

128 AC.000

1 06/1975-12/1979 1290 54 73 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3 Mirafiori

131 A6.000

1 10/1974-09/1981 1297 40 54 2
1.3 Mirafiori (131A)

131 A.000

1 10/1974-12/1982 1297 48 65 2
1.3 Super Mirafiori

131 B.000

1 03/1978-12/1980 1297 57 78 2
1.4 Mirafiori

131 C.000

131 C1.000

1 11/1980-01/1984 1367 51 70 2
1.4 Super Mirafiori

131 C1.000

1 04/1981-12/1983 1367 55 75 2
1.6

131 C2.000

1 11/1976-12/1984 1585 63 85 2
1.6 (131A1)

131 A1.000

1 10/1974-09/1981 1585 55 75 2
1.6 Super

131 C3.000

1 03/1978-01/1984 1585 71 97 2
1.6 Super Mirafiori (A)

131 B1.000

1 03/1979-03/1982 1585 72 98 2
2.0 Abarth Rally

131 B2.000

1 01/1976-07/1980 1995 103 140 2
2.0 Racing

131 B2.000

1 06/1978-12/1981 1995 85 115 2
2.0 Super

131 C4.000

1 01/1981-12/1984 1995 83 113 2
2.0 D

8144.65

2 03/1978-03/1987 1995 44 60 2
2.5 D

8144.61

2 06/1978-02/1984 2445 53 72 2
Vehicle Engine Fuel Date CC KW CV Traction
1.3 Mirafiori (131AF)

131 A6.000

1 03/1975-12/1978 1297 40 54 2
1.3 Mirafiori (AF)

131 A.000

1 03/1975-03/1982 1297 48 65 2
1.4 Mirafiori

131 C.000

131 C1.000

1 11/1981-01/1984 1367 51 70 2
1.6

131 C2.000

1 11/1980-12/1984 1585 63 85 2
1.6 CL (AF1)

131 A1.000

1 03/1975-12/1978 1585 55 75 2
1.6 Super

131 C3.000

1 12/1979-12/1981 1585 72 97 2
2.0 Mirafiori (131AF2)

131 B2.000

1 11/1980-12/1984 1995 84 114 2
2.0 Super

131 C4.000

1 01/1981-12/1984 1995 83 113 2
2.0 D

8144.65

2 07/1978-08/1984 1995 44 60 2
2.5 Super Diesel (AF)

8144.61

2 03/1979-12/1984 2445 53 72 2
Vehicle Engine Fuel Date CC KW CV Traction
1.6

132 C.000

1 05/1977-09/1982 1585 65 88 2
1.6

132 C6.000

1 03/1977-12/1981 1585 66 90 2
1.6

132 C.000

1 01/1976-12/1982 1585 72 98 2
1.6

132 BB OA O

1 04/1972-01/1976 1592 72 98 2
1.7 GLS (A1)

132 B1.000

1 04/1974-12/1975 1756 79 107 2
1.7 GLS (A1)

132 B1.000

1 11/1975-01/1977 1756 82 112 2
1.7 Special (A1)

132 B1.000

1 04/1972-01/1974 1756 77 105 2
2.0

132 C2.000

1 01/1976-06/1981 1995 83 113 2
Vehicle Engine Fuel Date CC KW CV Traction
1.0

127 A.000

1 10/1976-12/1995 1049 37 50 1
1.3

127 A2.011

1 07/1980-08/1984 1297 45 61 1
1.3 Rallye

127 A2.011

1 07/1980-07/1983 1297 53 72 1
1.4 1 10/1980-10/1996 1372 46 63 1
1.3 D

127 A5.000

2 07/1982-06/1984 1301 33 45 1
1.3 D

127 A5.000

2 10/1980-10/1995 1301 36 49 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3

127 A2.011

1 07/1980-07/1983 1297 41 56 1
1.3

127 A2.011

1 01/1982-12/1986 1297 45 61 1
1.3 D

127 A5.000

2 07/1982-07/1983 1301 33 45 1
1.3 D

127 A5.000

2 07/1984-12/1986 1301 36 49 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9 Sport

100 GL.040

1 02/1968-10/1972 903 38 52 2
Vehicle Engine Fuel Date CC KW CV Traction
0.8

100 G.000

1 07/1964-10/1972 843 25 34 2
0.8 Special (GB)

100 GB.000

1 03/1968-10/1972 843 35 48 2
Vehicle Engine Fuel Date CC KW CV Traction
0.8

126 G.100

1 10/1965-10/1968 843 36 49 2
Vehicle Engine Fuel Date CC KW CV Traction
0.9

100 GF 000

1 01/1978-01/1986 903 26 35 2
Vehicle Engine Fuel Date CC KW CV Traction
0.9

100 GF 000

1 01/1978-01/1986 903 26 35 2
Vehicle Engine Fuel Date CC KW CV Traction
1600

132 D.000

1 04/1981-12/1985 1585 72 98 2
1600 i.e

132 D.000

1 04/1981-12/1985 1585 66 90 2
2000

132 C2.000

132 D1.000

1 06/1978-12/1985 1995 83 113 2
2000 i.e.

132 C3.000

1 06/1981-07/1986 1995 90 122 2
2000 Volumex

132 C3.000

1 06/1984-07/1985 1995 99 135 2
2500 Diesel

8144.61

2 06/1981-11/1985 2445 53 72 2
2500 Turbodiesel

8144.61.500.81

2 07/1983-08/1985 2445 66 90 2
Vehicle Engine Fuel Date CC KW CV Traction
2.0

6132 AZ 2.000

1 06/1974-10/1989 1995 59 80 3
2.4 D

8144.61.200

2 06/1974-10/1989 2445 53 72 3
Vehicle Engine Fuel Date CC KW CV Traction
1050

127 A.000

1 01/1980-12/1987 1049 37 50 1
900

100 GL.000

1 10/1977-10/1986 903 33 45 1
Vehicle Engine Fuel Date CC KW CV Traction
1.0

127 A.000

127A.046

1 06/1982-10/1987 1049 37 50 1
Vehicle Engine Fuel Date CC KW CV Traction
1.0

127 A.000

1 01/1980-12/1987 1049 37 50 1
1.0

156 A.000

1 12/1986-04/1988 1049 41 56 1
1.3 D

127 A5.000

2 03/1982-01/1988 1301 33 45 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3 D 2 01/1982-01/1988 1301 33 45 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9 Fire S A las 4 ruedas

146 A.048

1 10/1980-04/1986 903 33 45 3
1000

156 A2.100

1 01/1986-04/1992 999 32 44 1
1000

156 A3.000

1 01/1985-12/1992 999 37 50 1
1000 4x4

156 A2.100

156 A3.100

1 01/1986-07/1989 999 32 44 3
1000 4x4

141 C2.000

156 A2.246

1 05/1986-12/1994 999 33 45 3
1000 4x4

156 A3.000

1 01/1986-12/1992 999 37 50 3
1000 i.e. Cat

141 C2.000

156 A2.246

1 10/1987-08/1998 999 33 45 1
1100

156 C.046

1 05/1991-12/1999 1108 37 50 1
1100

176 B2.000

187 A1.000

1 02/1995-09/2003 1108 40 54 1
1100 4x4

176 B2.000

1 02/1995-07/2004 1108 40 54 3
1100 Trekking 4x4

156 C.046

1 10/1991-07/2004 1108 37 50 3
650

141 A.000

1 01/1982-07/2004 652 22 30 1
650 1 01/1982-07/2004 652 22 30 1
750

156 A4.000

1 01/1986-10/2003 770 25 34 1
750 1 01/1986-01/1995 770 25 34 1
750 Cat 1 01/1995-10/2003 770 25 34 1
800

100 GL6.000

1 02/1981-12/1985 843 25 34 1
900

1170 A1.046

1 04/1992-12/1996 899 29 40 1
900

100 GL3.000

146 A.000

1 10/1980-06/1994 903 33 45 1
950

A 112 B1.054

1 09/1982-08/1983 965 35 48 1
950 4x4

A 112 B1.054

1 09/1983-12/1986 965 35 48 3
1300 D

156 A5.000

2 04/1986-12/1992 1302 27 37 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1

156 C.046

1 05/1991-03/1995 1108 37 50 3
1.1

187 A1.000

1 09/2000-02/2004 1108 40 54 1
1.1 4x4

187 A1.000

1 09/2000-02/2004 1108 40 54 3
1000

156 A2.100

156 A3.100

1 01/1986-02/1992 999 32 44 1
1000 i.e

156 A2.246

1 08/1992-02/2004 999 33 45 1
750

141 B.000

1 01/1986-07/1992 764 25 34 1
D

156 A5.000

2 05/1986-04/1991 1302 27 37 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6

149 A.000

1 10/1984-06/1989 1585 60 82 1
1.6

138 AR.000

1 09/1983-08/1986 1585 77 105 1
100 1.6 (RF)

149 A4.000

149 C3.000

1 09/1984-12/1990 1585 74 101 1
70 1.3

138 B2.000

1 01/1984-07/1989 1301 50 68 1
75 1.5

138 B3.048

138 C2.048

138 C3.048

149 C1.000

1 09/1984-07/1989 1498 55 75 1
75 1.5 i.e. Cat 1 12/1986-07/1989 1498 55 75 1
85 1.5

138 B3.000

1 01/1984-04/1989 1498 60 82 1
85 1.5

138 B3.000

1 06/1983-08/1986 1498 63 86 1
90 i.e. 1.6

149 C2.000

1 01/1987-07/1989 1595 66 90 1
60 Diesel 1.7

149 B3.000

2 01/1984-12/1989 1698 44 60 1
65 Diesel 1.9

149 A1.000

2 04/1984-07/1989 1929 48 65 1
80 Turbo Diesel 1.9

831 D1.000

2 05/1986-07/1989 1929 59 80 1
Vehicle Engine Fuel Date CC KW CV Traction
100 1.6 1 09/1983-08/1986 1585 77 105 1
100 Super 1.6

149 C3.000

1 10/1983-07/1989 1585 70 95 1
100 Super 1.6

149 A2.000

149 A4.000

1 10/1983-12/1990 1585 74 101 1
70 1.3

149 A3.000

149 A7.000

1 09/1983-07/1989 1301 48 65 1
70 1.3

138 B2.000

1 09/1983-07/1986 1301 50 68 1
75 1.5

138 B3.048

138 C2.048

138 C3.048

149 C1.000

1 12/1983-07/1989 1498 55 75 1
75 i.e. 1.5 1 07/1985-07/1989 1498 55 75 1
85 1.5

149 A5.000

1 05/1985-12/1987 1498 58 79 1
85 1.5

138 B3.000

1 02/1984-08/1986 1498 63 86 1
85 1.6

149 A.000

1 10/1983-06/1990 1585 60 82 1
85 Super 1.5

138 B3.000

1 09/1983-04/1985 1498 60 82 1
90 i.e. 1.6

149 C2.000

1 01/1987-07/1989 1595 66 90 1
60 Diesel 1.7

149 B3.000

2 05/1985-03/1989 1698 44 60 1
60 Diesel 1.7

138 B6.000

2 09/1983-12/1986 1714 43 58 1
65 Diesel 1.9

149 A1.000

2 04/1984-07/1989 1929 48 65 1
80 Turbo Diesel 1.9

831 D1.000

2 05/1986-07/1989 1929 59 80 1
Vehicle Engine Fuel Date CC KW CV Traction
1.0

127 A6.000

1 09/1978-09/1982 1049 44 60 1
1.1

138 B.000

138 B1.000

138 C1.000

1 10/1982-12/1987 1116 40 55 1
1.1

146 A4.048

1 04/1985-12/1987 1116 43 58 1
1.1

138 B.000

146 A4.000

1 08/1980-08/1988 1116 44 60 1
1.1 (138A)

138 C1.000

1 05/1985-09/1987 1116 42 57 1
1.3

138 A1.000

149 A3.000

149 A7.000

1 01/1978-08/1985 1301 48 65 1
1.3 1 11/1983-08/1985 1301 48 65 1
1.3

138 B2.000

1 01/1983-04/1985 1301 50 68 1
1.3

138 A3.000

1 01/1981-09/1982 1301 55 75 1
1.5 1 10/1985-05/1987 1498 55 75 1
1.5

138 A2.000

138 C2.048

138 C3.048

149 C1.000

1 01/1978-12/1988 1498 55 75 1
1.5

149 A5.000

1 08/1985-05/1987 1498 58 79 1
1.5

138 B3.000

1 01/1983-12/1987 1498 60 82 1
1.5

138 A4.000

1 01/1981-05/1987 1498 63 85 1
1.6

138 AR.000

1 12/1985-12/1987 1585 66 90 1
1.6

149 A4.000

1 01/1983-12/1987 1585 74 100 1
1.6

138 AR.000

1 05/1981-12/1987 1585 77 105 1
1.6 1 09/1985-12/1987 1595 66 90 1
1.7 Diesel

138 C.000

149 B3.000

2 05/1985-12/1987 1698 44 60 1
1.7 Diesel

138 A5.000

2 10/1979-09/1982 1714 40 55 1
1.7 Diesel 2 10/1979-10/1985 1714 43 58 2
1.9 TD

831 D1.000

2 12/1985-12/1987 1929 59 80 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3

138 A1.000

1 10/1979-09/1983 1301 48 65 1
100 1.6

138 AR.048

1 10/1985-12/1987 1585 74 100 1
100 1.6

138 AR.000

1 10/1985-12/1987 1585 77 105 1
50 1.3

138 B2.000

1 10/1985-12/1987 1302 50 68 1
85 1.5

138 B3.000

1 03/1983-12/1986 1498 60 82 1
85 1.5

138 A4.000

1 01/1980-07/1989 1498 63 86 1
Vehicle Engine Fuel Date CC KW CV Traction
105 1.6 1 01/1983-12/1987 1585 77 105 1
75 1.5 1 09/1985-12/1988 1498 55 75 1
75 1.5 1 09/1985-12/1988 1498 55 75 1
60 Diesel 1.7 2 10/1982-10/1985 1714 43 58 2
Vehicle Engine Fuel Date CC KW CV Traction
1.2

188 A4.000

1 04/2003- 1242 44 60 1
1.2

178 B5.000

1 06/1999-12/2006 1242 54 73 1
1.2 Trekking

178 B7.045

1 11/2005- 1242 60 82 1
1.6 Trekking

178 D2.011

1 11/2005- 1581 76 103 1
1.3 D Multijet

223 A9.000

2 05/2006- 1248 62 85 1
1.3 D Multijet (278AYR1A)

199 B1.000

2 10/2010- 1248 70 95 1
1.7 TD

176 A3.000

2 06/1999-12/2006 1698 51 69 1
1.9 D

223 A6.000

2 12/2000- 1910 46 63 1
1.9 JTD

188 A2.000

2 04/2003- 1910 59 80 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 Flex 1 09/2009- 1598 86 117 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9 1 02/1984-08/1989 903 30 41 1
1.0 1 08/1990-06/2001 994 35 48 1
1.0 (146E)

156 A2.000

1 06/1989-02/1992 999 31 42 1
1.0 iE

156 A2.246

1 05/1998-08/2000 999 34 46 1
1.1

160 A3.000

1 04/1986-06/2006 1108 41 56 1
1.1

146 A4.048

160 A3.000

1 10/1988-06/2006 1108 43 58 1
1.3 Turbo i.e.

146 A2.146

1 01/1987-12/1987 1301 73 99 1
1.3 Turbo i.e.

146 A2.246

1 09/1989-03/1991 1301 74 101 1
1.3 Turbo i.e.

146 A2.000

1 04/1985-08/1989 1301 77 105 1
1.4 1 07/1991-07/1996 1372 51 69 1
1.4 Turbo

146 A8.000

1 10/1988-08/2000 1372 77 105 1
1.4 Turbo i.e.

146 A8.046

1 09/1989-09/1993 1372 82 112 1
1.4 Turbo i.e.

146 A8.000

1 12/1989-12/1996 1372 87 118 1
1.5 75 iE 1 01/1994-10/1995 1498 56 76 1
1.6

159 A3.046

1 12/1989-04/1993 1581 65 88 1
1.6 R

159 A3.048

1 05/1993-12/1995 1581 66 90 1
45 0.9

146 A.000

146 A1.000

1 03/1983-09/1992 903 33 45 1
45 0.9

146 A.000

1 02/1984-12/1988 903 34 46 1
45 1.0 1 06/1986-12/1993 999 37 50 1
45 1.0 (146A.ED)

156 A2.048

156 A2.100

1 06/1986-12/1993 999 32 44 1
45 i.e. 1.0 (146E, 146A)

156 A2.000

156 A2.246

1 10/1984-10/1995 999 33 45 1
50 1.1

156 C.046

1 01/1990-12/1993 1108 37 50 1
50 1.1

146 A4.044

1 01/1986-12/1989 1116 37 50 1
50 i.e. 1.1

146 C3.000

1 06/1992-12/1993 1116 36 49 1
55 1.0 1 11/1993-08/2000 996 41 56 1
55 1.1

138 B.000

1 01/1983-08/1989 1116 40 54 1
60 1.1 (146A.EG)

146 A4.048

1 05/1985-08/1989 1116 43 58 1
70 1.3

149 A7.000

1 05/1985-08/1989 1302 48 65 1
70 1.3

138 B2.000

1 01/1983-04/1985 1302 50 68 1
70 i.e. 1.4

160 A1.046

1 09/1989-07/1996 1372 51 70 1
70 i.e. 1.4

146 C1.000

1 09/1989-12/1993 1372 53 72 1
70 S 1.4

160 A1.046

160 A1.048

1 10/1988-06/2006 1372 52 71 1
75 i.e. 1.5

138 C2.048

149 C1.000

1 10/1985-12/1993 1498 55 75 1
1.3 Super Diesel

127 A5.000

146 B1.000

2 06/1983-03/1992 1302 33 45 1
1.7 D

146 B2.000

2 11/1994-08/2000 1697 43 58 1
1.9 D 2 01/1989-12/1991 1929 58 79 1
70 TD 1.4

146 B.000

146 B3.000

2 10/1986-10/1990 1367 52 71 1
Vehicle Engine Fuel Date CC KW CV Traction
45 0.9

146 A.000

146 A1.000

1 02/1988-07/1996 903 33 45 1
1.7 D

146 B2.000

149 B4.046

2 02/1988-02/1992 1697 43 58 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3

128 AS.000

1 10/1975-06/1978 1290 54 73 2
1.3

128 AS.000

1 05/1973-12/1979 1290 55 75 2
1.5

138 BS.031

1 06/1985-12/1989 1499 56 76 2
1.5 (128AS1_)

138 A4.000

138 AS.000

1 11/1978-12/1989 1498 63 85 2
Vehicle Engine Fuel Date CC KW CV Traction
1.3 1 01/1967-12/1982 1298 40 54 2
1.6 1 01/1967-12/1982 1599 48 65 2
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 01/1967-12/1982 1599 48 65 2
Vehicle Engine Fuel Date CC KW CV Traction
1.3 1300

116 C 076

1 10/1967-08/1992 1295 47 64 2
1.5 1500

115 C 076

1 10/1967-08/1992 1481 55 75 2
Vehicle Engine Fuel Date CC KW CV Traction
1.3

116 C 076

1 10/1967-08/1992 1295 47 64 2
1.5

115 C 076

1 10/1967-08/1992 1481 55 75 2
Vehicle Engine Fuel Date CC KW CV Traction
1.5

115 C 076

1 06/1975-12/1989 1481 60 82 2
Vehicle Engine Fuel Date CC KW CV Traction
0.6 1 09/1972-07/1977 594 17 23 2
0.6

126 A1.048

1 07/1977-12/1991 652 22 30 2
650

126 A1.048

1 07/1981-09/2000 652 18 24 2
Vehicle Engine Fuel Date CC KW CV Traction
0.9

100 GL.000

1 10/1969-10/1976 903 33 45 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6

132 AB.0A.0

1 01/1974-09/1978 1592 72 98 2
1.8

132 A1.000

1 07/1975-09/1978 1756 79 107 2
Vehicle Engine Fuel Date CC KW CV Traction
1.5

115 C 076

1 06/1981-12/1991 1481 60 82 2
Vehicle Engine Fuel Date CC KW CV Traction
1.5

115 C 076

1 06/1981-12/1991 1481 60 82 2
Vehicle Engine Fuel Date CC KW CV Traction
1.3

116 C 076

1 01/1978-12/1980 1295 48 65 2
1.5

AA

1 10/1977-08/1988 1481 55 75 2
1.5

115 C.074

1 01/1978-08/1988 1481 60 82 2
1.5 Turbo

115 C 082

1 01/1978-12/1991 1481 70 95 2
1.6

CB

1 08/1986-08/1988 1598 64 87 2
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1 07/1983-07/1988 1481 59 80 2
1.6 1 08/1988-10/1995 1598 64 87 2
1.9 D 2 04/1985-10/1995 1905 51 69 2
Vehicle Engine Fuel Date CC KW CV Traction
1.5

AA

1 08/1988-08/1992 1481 55 75 2
1.5 i

115 C.074

1 08/1988-08/1992 1481 55 75 2
1.6

CB

1 08/1988-08/1992 1598 64 87 2
1.9 D

XUD 9A

2 08/1988-08/1992 1905 51 69 2
Vehicle Engine Fuel Date CC KW CV Traction
1.4 i 16V 1 09/1992-03/2002 1398 76 103 2
1.6 GLI 1 03/1996-03/2002 1598 59 80 1
1.6 i

147CK46

1 09/1992-03/2002 1598 57 78 2
Vehicle Engine Fuel Date CC KW CV Traction
1.4 i 16V

ROVER K16 DOHC

1 09/1992-03/2002 1398 76 103 2
1.5

AA

1 05/1994-12/1997 1481 55 75 2
1.6 i

147CK46

1 09/1992-03/2002 1598 57 78 2
1.8 1 02/2003-01/2005 1796 81 110 1
1.9 D

XUD 9A

2 09/1992-03/2002 1905 51 69 2
Vehicle Engine Fuel Date CC KW CV Traction
1.4 i 16V

14K4F

ROVER K16 DOHC

1 04/1994-09/1998 1396 76 103 2
1.6 i

147CK46

1 04/1994-09/1998 1598 57 78 2
1.9 D

XUD 9A

2 04/1994-09/1998 1905 51 69 2
Vehicle Engine Fuel Date CC KW CV Traction
45

100 GL 064

1 01/1990-12/1992 903 33 45 1
55

146 A6.000

1 01/1990-12/1992 1116 40 55 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9 Junior (A112B/2)

A112 A.000

A112 A5.000

A112 B2.000

1 03/1981-06/1986 903 29 40 1
1.0 Abarth (A112B2/5)

A112 A2.000

1 03/1978-02/1984 1050 51 69 1
1.0 LX (A112)

A112 B1.000

1 03/1984-12/1986 965 35 48 1
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (137AS)

828 B1.000

1 06/1981-10/1983 1995 90 122 2
Vehicle Engine Fuel Date CC KW CV Traction
1.1 (831AB.015)

831 B8.000

1 01/1986-12/1990 1116 47 64 1
1.3 (831.AB)

831 A2.000

1 09/1983-08/1992 1301 58 79 1
1.3 (831AB.011)

831 A2.000

831 B.000

1 09/1979-08/1992 1301 55 75 1
1.5 (831AB.025)

831 A1.000

831 B1.000

1 09/1979-12/1992 1498 63 86 1
1.6 GT (831AB.06)

831 A4.000

1 11/1982-04/1986 1585 77 105 1
1.6 GT i.e. (831AB.010)

149 C2.000

1 05/1987-08/1992 1585 66 90 1
1.6 GT i.e. (831AB.016)

831 B7.000

1 08/1986-08/1988 1585 80 109 1
1.6 HF Turbo 1 08/1986-05/1993 1585 122 166 1
1.6 HF Turbo (831AB.0)

831 A7.000

1 10/1983-12/1986 1585 96 131 1
1.6 HF Turbo (831AB.020S)

831 B7.046

1 04/1987-03/1989 1585 97 132 1
1.6 HF Turbo (831AB.020S)

831 B3.000

1 08/1986-08/1988 1585 103 140 1
2.0 16V HF Integrale (831AB.026)

831 D5.000

1 03/1989-09/1991 1995 144 196 3
2.0 HF Integrale (831AB.024S, 831AB.028)

831 B5.000

1 11/1986-08/1988 1995 122 166 3
2.0 HF Integrale (831AB.024S, 831AB.028)

831 C5.046

1 12/1986-12/1992 1995 130 177 3
2.0 HF Integrale (831AB.024S, 831AB.028)

831 C5.000

1 10/1987-12/1991 1995 133 181 3
1.9 Turbo DS (831AB.021)

831 D1.000

2 10/1986-12/1989 1929 59 80 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3 (831AB)

831 A2.000

1 01/1983-12/1989 1301 58 79 1
1.5 (831AB)

138 C2.048

831 B1.048

1 09/1985-02/1992 1498 55 75 1
1.5 (831AB)

831 B1.000

1 05/1986-07/1989 1498 59 80 1
1.5 (831AB)

831 A1.000

1 01/1983-04/1986 1498 63 86 1
1.6 (831AB)

831 B6.000

1 08/1987-08/1988 1585 71 97 1
1.6 (831AB)

831 B6.000

1 08/1986-02/1992 1585 73 99 1
1.6 (831AB)

831 A4.000

1 01/1983-04/1986 1585 77 105 1
1.6 i.e. (831AB)

831 B7.000

1 05/1986-12/1989 1585 80 109 1
1.6 i.e. Super (831AB)

149 C2.000

1 05/1987-12/1989 1585 66 90 1
2.0 i.e. A las 4 ruedas (831AB)

831 B4.000

1 04/1986-12/1989 1995 85 115 3
1.9 Diesel (831AB)

831 D.000

2 01/1983-02/1992 1911 48 65 1
Vehicle Engine Fuel Date CC KW CV Traction
1.0 (156C)

156 A.000

1 03/1985-07/1989 1049 41 56 1
1.0 Fire (156AA, 156AD)

156 A2.000

1 03/1985-02/1990 999 37 50 1
1.0 Fire (156AA)

156 A2.000

1 03/1985-06/1989 999 33 45 1
1.0 Fire (156B, 156AD)

156 A2.100

1 06/1985-06/1991 999 32 44 1
1.0 Fire Catalytic-Conv (156AE)

156 A2.246

1 10/1987-02/1992 999 33 45 1
1.1 i.e. Fire (156AG)

156 C.046

1 07/1989-09/1995 1108 37 50 1
1.1 i.e. Fire A las 4 ruedas (156AG)

156 C.046

1 09/1992-12/1995 1108 37 50 3
Vehicle Engine Fuel Date CC KW CV Traction
2000

132 C3.031

1 11/1984-11/1985 1995 76 103 2
2000

132 C3.031

1 03/1982-09/1985 1995 77 105 2
2000 Volumex

232R14

1 06/1983-11/1985 1995 99 135 2
Vehicle Engine Fuel Date CC KW CV Traction
1.3

831 A2.000

1 01/1980-12/1986 1301 55 75 1
1.5

831 A1.000

1 01/1980-12/1986 1498 63 86 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6

FC16

1 09/1976-10/1980 1585 70 95 2
1.6

FA16

1 09/1975-08/1976 1608 72 98 2
1.8

FA18

1 09/1975-10/1980 1756 87 118 2
1430

FA14

1 01/1970-12/1976 1438 55 75 2
1430 Especial

124 A9.000

1 01/1970-12/1976 1592 70 95 2
2.0

FA19

1 04/1979-10/1980 1995 85 116 2
D1200

124 A.000

1 01/1968-12/1976 1197 44 60 2
LS1200

FA12

1 01/1968-10/1980 1197 48 65 2
Vehicle Engine Fuel Date CC KW CV Traction
D1200

124 A.000

1 01/1970-12/1974 1197 44 60 2
LS1200

124 A.000

1 01/1970-12/1976 1197 48 65 2
Vehicle Engine Fuel Date CC KW CV Traction
0.9

A112 A5.000

1 04/1972-12/1982 903 33 45 1
1.0

110F00

1 04/1972-12/1982 1010 38 52 1
Vehicle Engine Fuel Date CC KW CV Traction
1.2

124 A.000

1 01/1976-12/1980 1197 49 67 1
1.4

124 B2.000

1 01/1976-12/1980 1438 57 78 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6

132 BB OA O

1 03/1982-01/1985 1592 71 97 2
2.0

131 C4.000

1 06/1978-12/1985 1994 85 116 2
2.4 Diesel

8144.61

2 06/1978-12/1986 2445 53 72 2
Vehicle Engine Fuel Date CC KW CV Traction
0.8

DG

1 05/1974-11/1979 837 25 34 2
Vehicle Engine Fuel Date CC KW CV Traction
0.9

09 NCA

100 GL 7000

1 03/1984-12/1986 903 29 40 1
0.9

HB 90

1 01/1982-06/1986 903 31 43 1
0.9

100 GL 3000

1 01/1982-06/1986 903 33 45 1
1.4 Crono

127 B.7000

1 01/1982-06/1986 1438 55 75 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9

09 NCA

146 A 000

1 08/1990-05/1993 903 29 40 1
0.9

146 A 000

1 08/1986-05/1993 903 32 44 1
1.2

021 A 1000

1 11/1984-12/1993 1193 44 60 1
1.2

021 A 1000

1 11/1984-12/1993 1193 46 63 1
1.2 i

021 C.1000

1 01/1989-05/1993 1193 52 71 1
1.5

021 A 2000

1 11/1984-05/1993 1461 63 85 1
1.5 1 10/1986-05/1993 1461 64 87 1
1.5 i

021 D.2000

1 10/1986-05/1993 1461 65 89 1
1.5 i

021 B.2000

1 10/1986-05/1993 1461 74 100 1
1.5 i Cat

021 C.2000

1 10/1986-05/1993 1461 66 90 1
1.7

021 A.3000

1 01/1991-05/1993 1675 72 98 1
1.7 1 01/1991-05/1993 1675 76 103 1
1.7 D

022 A.5000

2 06/1984-05/1993 1714 40 54 1
1.7 D

022 A.5000

2 08/1990-05/1993 1714 42 57 1
Vehicle Engine Fuel Date CC KW CV Traction
1.2

021 A 1000

1 05/1985-12/1993 1193 44 60 1
1.2

021 A 1000

1 11/1984-12/1993 1193 47 64 1
1.2 i

021 C.1000

1 12/1989-12/1993 1193 52 71 1
1.5

021 A 2000

1 05/1985-12/1993 1461 63 85 1
1.5 i

021 B.2000

1 01/1987-12/1993 1461 74 100 1
1.5 i Cat

021 A 2000

021 C.2000

021 D.2000

1 10/1986-12/1993 1461 66 90 1
1.7 D

022 A.5000

2 05/1985-12/1993 1714 40 54 1
1.7 D

022 A.5000

2 05/1990-12/1993 1714 42 57 1
Vehicle Engine Fuel Date CC KW CV Traction
0.8

08 NCA

1 08/1986-12/1993 843 25 34 1
0.9

08 NCB

1 07/1997-10/1998 899 32 44 1
0.9

09 NCA

100 GL 7000

1 01/1987-12/1993 903 29 40 1
0.9 Cat

08 NCB

1 11/1996-10/1998 899 30 41 1
0.9 Cat

09 NCB

100 GL 7000

1 01/1990-11/1996 903 29 40 1
Vehicle Engine Fuel Date CC KW CV Traction
0.8

08 NCA

1 01/1987-12/1993 843 25 34 1
0.9 1 05/1995-05/1999 899 30 41 1
0.9

09 NCA

1 01/1987-12/1993 903 29 40 1
0.9 Cat

09 NCB

1 01/1987-12/1993 903 29 40 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9

100 GL 3000

1 10/1980-12/1986 903 31 42 1
Vehicle Engine Fuel Date CC KW CV Traction
1.2

12AC

1 07/1978-09/1983 1197 47 64 1
1.4

15G

1 07/1978-09/1983 1438 57 78 1
1.7 D

022 A.5000

2 10/1979-09/1983 1714 41 56 1
Vehicle Engine Fuel Date CC KW CV Traction
1.2

021 A 1000

1 10/1984-12/1986 1193 44 60 1
1.2

124 B6.000

1 08/1983-05/1985 1197 47 64 1
1.4

124 B7.000

1 06/1982-11/1988 1438 54 73 1
1.5

021 A 2000

1 09/1984-12/1986 1461 63 85 1
1.6

022 A 000

138 AR6.000

1 08/1983-09/1985 1592 68 92 1
1.7 Diesel

022 A.5000

2 06/1982-12/1986 1714 40 54 1
1.7 Diesel

022 A.5000

2 06/1982-12/1986 1714 41 56 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9

09 NCA

1 01/1987-12/1995 903 29 40 1
0.9 Cat

09 NCB

1 01/1990-12/1995 903 29 40 1
1.3 D

MN

2 03/1990-02/1992 1272 33 45 1
1.4 D

1 W

2 10/1990-02/1992 1398 35 48 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9

09 NCA

1 02/1987-12/1996 903 29 40 1
0.9 Cat

09 NCB

1 02/1992-12/1994 903 29 40 1
1.3 D

MN

2 03/1990-12/1994 1272 33 45 1
1.4 D

1 W

2 10/1990-12/1995 1398 35 48 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6

159 A3.048

1 01/1976-12/2001 1581 59 80 2
1.6 i.e 1 01/1999-12/2002 1581 61 83 2
1.6 IE 1 01/1997-07/2002 1581 66 90 2
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 01/1991-09/1996 1581 55 75 2
1.6

131 A1.000

1 10/1985-09/1996 1585 55 75 2
1.6 IE 1 01/1997-07/2002 1581 66 90 2
Vehicle Engine Fuel Date CC KW CV Traction
1.4 Mirafiori 1 01/1980-12/2003 1367 51 69 2
1.6

131 A1.000

1 10/1985-09/1996 1585 55 75 2
1.6 IE 1 01/1997-07/2002 1581 63 86 2
1.6 S

159 A3.048

1 01/1980-12/2003 1581 59 80 2
Vehicle Engine Fuel Date CC KW CV Traction
1.3 1 10/1985-10/1994 1297 48 65 2
Vehicle Engine Fuel Date CC KW CV Traction
0.9

164A0

1 03/1983-12/1991 903 34 46 1
1.1

11A

128A4

1 03/1983-12/1991 1116 41 56 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9 1 04/1988-12/1989 903 33 45 1
1.1 1 03/1989-07/1991 1116 41 56 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1

128A4

1 04/1983-04/1991 1116 41 56 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3

16A6046

1 04/1983-07/1988 1301 49 67 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1

128A4

1 04/1983-12/1984 1116 41 56 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3 1 09/1983-12/1984 1301 47 64 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1

128A4

1 04/1983-04/1991 1116 41 56 1
Vehicle Engine Fuel Date CC KW CV Traction
1.3

146A6

1 07/1988-06/1990 1298 49 67 1
1.3 1 09/1983-07/1988 1301 47 64 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1

138 B.0000

1 08/1989-11/2008 1116 44 60 1
1.3 (103 A)

13 E.3.064

1 03/1991-11/2008 1302 50 68 1
1.4

160 A1.000

1 10/1991-06/1995 1372 51 69 1
1.4 Cat

160 A1.000

1 10/1988-11/2008 1372 52 71 1
1.6

149 A.000

1 08/1989-06/1995 1585 62 84 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4

14FE

1 10/1989-10/1993 1372 52 71 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9

164A0

1 05/1991-12/1993 903 33 45 1
1.1

11A

128A4

1 06/1985-07/1993 1116 41 56 1
1.3

16A6046

1 05/1991-07/1993 1301 49 67 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1

128 A.000

1 12/1975-01/1980 1116 37 50 1
1.1

128 A.000

1 06/1973-01/1990 1116 40 55 1
1.1

128 A.064

1 05/1975-12/1993 1116 41 56 1
1.1 Super

128 AC5.000

1 07/1979-09/1981 1116 47 64 1
1.3

128 AR.000

1 10/1981-12/1993 1290 48 65 1
Vehicle Engine Fuel Date CC KW CV Traction
0.9

9A

1 04/1980-06/1992 903 33 45 1
55

128 A.000

1 04/1980-06/1995 1116 40 54 1
60 EFI (145 A)

100 GL. 0.64

11 E 1.064

1 08/1991-06/1995 1116 44 60 1
65 EFI (145 A)

13 E 1.064

1 07/1981-06/1995 1302 48 65 1
Return
