Product 78BD5924-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073147486
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD5924-2
Weight (gr.)
13560
R90 Homologation
R90 90R-02C0433/0115
Measures
Ø294x24x45.7
Brake Disc Type: Vented
Minimum thickness [mm]: 22
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 114.3
Wheel Hub Diameter [mm]: 60.02
Reference applications
Brand OE Reference
MITSUBISHI 45 15A 189
MITSUBISHI 46 15A 006
MITSUBISHI 46 15A 113
MITSUBISHI 46 15A 179
MITSUBISHI MR 128 659
MITSUBISHI MR 205 215
MITSUBISHI MR 295 368
MITSUBISHI MR 307 386
PEUGEOT 16 063 757 80
PEUGEOT 16 114 298 80
PEUGEOT 4249.58
PEUGEOT 4249.59
PEUGEOT 4249.F3
Maker Cross reference
ATE 24.0124-0215.1
ATE 424215
BENDIX ANTIGUO 562528BC
BOSCH 0 986 479 372
BREMBO 09.A738.11
BREMBO 09.A738.14
BREMBO 09.A738.1E
BREMBO 09.A738.1X
DELPHI LOCKHEED BG4038
FERODO DDF1642
GIRLING 6061741
HELLA-PAGID 8DD 355 111-561
LETEC LBMT019V
MINTEX MDC1385
SANLI SL32599
TEXTAR 92135203
TRW DF6174
CITROËN
C-CROSSER (VU_, VV_) SUV 02/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0

4B11

 1 11/2010-12/2012 1998 108 147 1
2.0 Alas 4 ruedas

4B11

 1 11/2010-12/2012 1998 108 147 3
2.4 16V

SFZ (4B12 MMC)

 1 08/2008-12/2012 2360 125 170 3
2.2 HDi

4HK (DW12ME5)

4HN (DW12MTED4)

 2 02/2007-12/2012 2179 115 156 3
C-CROSSER (VU_) SUV Van 02/2007-12/2012
Vehicle Engine Fuel Date CC KW CV Traction
2.2 HDi (VU4HNH) 2 06/2007-12/2012 2179 115 156 3
C-CROSSER ENTERPRISE (VU_, VV_) SUV Van 01/2009-
Vehicle Engine Fuel Date CC KW CV Traction
2.4 16V

4B12

 1 01/2009- 2360 125 170 3
2.2 HDi

4HN (DW12MTED4)

 2 01/2009- 2179 115 156 3
MITSUBISHI
LANCER II-III (C6_A, C7_A) Saloon 04/1988-12/1997
Vehicle Engine Fuel Date CC KW CV Traction
EVO IV (CN9A)

4G63 TURBO

 1 08/1996-12/1997 1997 206 280 3
LANCER III / LIBERO (CB_A, CD_A, CE_A) Saloon 07/1991-12/1996
Vehicle Engine Fuel Date CC KW CV Traction
EVO I (CD9A)

4G63 TURBO

 1 10/1992-12/1993 1997 184 250 3
EVO II (CE9A)

4G63 TURBO

 1 01/1994-07/1995 1997 192 261 3
EVO III (CE9A)

4G63 TURBO

 1 08/1995-07/1996 1997 198 269 3
LANCER V EX / GALANT FORTIS / LANCER SERIE R / LANCER FORTIS (CY_A, CZ_A) Saloon 03/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 EVO X 1 06/2009- 1998 296 402 3
LANCER V EX Sportback / GALANT FORTIS Sportback (CX_A) Hatchback 10/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 Ralliart 4WD (CX4A)

4B11-T/C

 1 10/2008- 1998 177 241 3
OUTLANDER / AIRTREK (CU_W) SUV 03/2001-07/2008
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (CU2W)

4G63 (DOHC 16V)

 1 05/2003-10/2006 1997 100 136 1
2.0 4WD (CU2W) 1 05/2003-10/2006 1997 93 126 3
2.0 4WD (CU2W)

4G63 (DOHC 16V)

 1 05/2003-10/2006 1997 100 136 3
2.0 Turbo 4WD (CU2W)

4G63-T (DOHC 16V)

 1 04/2004-10/2006 1997 148 201 3
2.0 Turbo-R 4WD (CU2W)

4G63 TURBO

 1 01/2002-10/2006 1997 177 241 3
2.4 4WD (CU4W)

4G64 (16V)

 1 05/2003-10/2006 2351 102 139 3
2.4 4WD (CU5W)

4G69

 1 11/2003-09/2007 2378 118 160 3
2.4 4WD (CU5W)

4G69

 1 05/2003-09/2007 2378 119 162 3
2.4 HDD Mivec (CU5W)

4G69

 1 03/2001-12/2006 2378 118 160 1
OUTLANDER II (CW_W) SUV 09/2005-12/2012
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (CW4W)

4B11

 1 11/2006-11/2012 1998 108 147 1
2.0 4WD

4B11

 1 11/2006-11/2012 1998 108 147 3
2.4 (CW5W)

4B12

 1 11/2006-11/2012 2360 125 170 1
2.4 4WD (CW5W)

4B12

 1 09/2007-11/2012 2360 125 170 3
3.0 1 10/2009-11/2012 2998 177 241 1
3.0 4WD (CW6W)

6B31

 1 11/2006-11/2012 2998 162 220 3
3.0 4WD (CW6W)

6B31

 1 09/2010-12/2012 2998 169 230 3
3.0 AWD

6B31

 1 11/2006-12/2010 2998 164 223 3
3.0 AWD 1 09/2009-11/2012 2998 172 234 3
2.4 Flex 4WD

4B12

 19 09/2007-11/2012 2360 125 170 3
2.0 DI-D (CW8W)

BSY

 2 02/2007-11/2012 1968 103 140 3
2.2 DI-D

4N14

 2 11/2006-11/2012 2268 130 177 1
2.2 DI-D 4WD

4HK

4HN

 2 08/2007-11/2012 2179 115 156 3
2.2 DI-D 4WD

4N14

 2 09/2010-11/2012 2268 103 140 3
2.2 DI-D 4WD

4N14

 2 11/2006-11/2012 2268 130 177 3
OUTLANDER II (CW_W) SUV Van 11/2006-12/2012
Vehicle Engine Fuel Date CC KW CV Traction
Di-D 4WD (CW1W) 2 09/2010-12/2012 2268 130 177 3
Di-D 4WD (CW8W) 2 12/2006-06/2010 1968 103 140 3
OUTLANDER II (CW_W) Van 12/2006-11/2012
Vehicle Engine Fuel Date CC KW CV Traction
2.0 DI-D 2 12/2006-11/2012 1968 103 140 2
2.2 DI-D 2 09/2010-11/2012 2268 130 177 2
OUTLANDER III / PHEV III (GG_W, GF_W, ZJ, ZL, ZK) SUV 11/2010-
Vehicle Engine Fuel Date CC KW CV Traction
2.0

4B11

 1 10/2012- 1998 105 143 1
2.0 1 10/2012- 1998 106 144 1
2.0 (GF2W)

4B11

 1 10/2012- 1998 107 146 1
2.0 (GF7W)

4J11

 1 08/2012- 1998 110 150 1
2.0 (GF7W)

4J11

 1 04/2013- 1998 112 152 1
2.0 (GF7W) 1 03/2013-12/2018 1998 118 160 1
2.0 4WD (GF7W, GF2W)

4B11

 1 10/2012- 1998 107 146 3
2.0 4WD (GF7W)

4J11

 1 08/2012- 1998 110 150 3
2.0 Hybrid 4WD (GG2W)

4B11

S61

Y61

 13 12/2012- 1998 89 121 3
2.0 Hybrid 4WD (GG2W)

4B11

S61

Y61

 13 12/2012- 1998 139 189 3
2.0 Hybrid 4WD (GG2W)

4B11

S61

Y61

 13 01/2014- 1998 147 200 3
2.4 Hybrid 4WD (GG3W)

4B12

 13 09/2018- 2360 153 208 3
Plug-in Hybrid (GG2W) 13 09/2017-12/2021 1998 147 200 3
2.0 BiFuel 18 10/2012- 1998 107 146 1
2.0 Bifuel 4WD 18 10/2012- 1998 107 146 3
2.2 DI-D (GF6W)

4N14

 2 08/2012- 2268 110 150 1
2.2 DI-D 4WD

4N14

 2 06/2015-12/2018 2268 121 165 3
2.2 DI-D 4WD (GF6W)

4N14

 2 08/2012- 2268 110 150 3
2.2 DiD 4WD

4N14

 2 05/2015- 2268 132 179 3
OUTLANDER III / PHEV III (GF_W, GG_W) SUV Van 11/2010-
Vehicle Engine Fuel Date CC KW CV Traction
Hybrid 4WD (GG3W) 13 09/2018- 2360 153 208 3
Di-D 4WD (GF6W) 2 04/2013- 2268 110 150 3
PEUGEOT
4007 (VU_, VV_) SUV 02/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0

4B11

 1 11/2010-03/2013 1998 108 147 1
2.0 4x4

4B11

 1 11/2010-03/2013 1998 108 147 3
2.4 16V

SFY (4B12-MMC)

SFZ (4B12-MMC)

 1 02/2007-03/2013 2360 125 170 3
2.2 HDi

4HK (DW12ME5)

4HN (DW12MTED4)

 2 02/2007-03/2013 2179 115 156 3
4007 (VU_, VV_) SUV Van 02/2007-03/2013
Vehicle Engine Fuel Date CC KW CV Traction
HDi 155 (VU4HNH, VV4HK8) 2 02/2007-03/2013 2179 115 156 3
