Product 78BD6010-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073147547
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6010-2
Weight (gr.)
12324
Measures
Ø310x22x29.1
Brake Disc Type: Vented
Minimum thickness [mm]: 20
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 139,7
Wheel Hub Diameter [mm]: 108.25
Reference applications
Brand OE Reference
SUZUKI 55211-65D10
SUZUKI 55211-65D11
SUZUKI 55211-65D12
SUZUKI 55211-65D13
Maker Cross reference
ATE 24.0122-0200.1
BENDIX ANTIGUO 562445B
BOSCH 0 986 478 839
DELPHI LOCKHEED BG3821
FERODO DDF1282
TRW DF4156
SUZUKI
GRAND VITARA II (GT) Open Off-Road Vehicle 03/1998-09/2005
Vehicle Engine Fuel Date CC KW CV Traction
1.6 4x4 (SQ416)

G16B

 1 03/1998-07/2003 1590 69 94 3
GRAND VITARA II / GRAND ESCUDO (FT, HT) Closed Off-Road Vehicle 03/1998-08/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.6 4x4 (SQ416)

G16B

 1 09/2003-09/2005 1590 71 97 3
2.0 4x4 (SQ420)

J20A

 1 08/1998-12/2000 1995 97 132 3
2.0 4x4 (SQ420)

J20A

 1 04/1998-08/2005 1995 103 140 3
2.0 4x4 (TA52, TL52, SQ420)

J20A

 1 03/1998-07/2003 1995 94 128 3
2.5 V6 24V 4x4

H 25 A

 1 09/2003-09/2005 2493 118 160 3
2.5 V6 24V 4x4 (SQ625)

H 25 A

 1 04/2001-07/2003 2493 116 158 3
2.5 V6 24V 4x4 (TD62, SQ625)

H 25 A

 1 04/1998-07/2003 2493 106 144 3
2.7 (JA 627)

H 27 A

 1 06/2001-08/2003 2736 127 173 2
2.7 (JA 627)

H 27 A

 1 09/2003-08/2006 2736 135 184 2
2.7 4x4 (JA627, SQ627W2)

H 27 A

 1 09/2001-07/2003 2736 127 173 3
2.7 4x4 (TX92, JA627)

H 27 A

 1 04/2003-07/2003 2736 135 184 3
2.0 HDI 110 16V 4x4 (SQ420D, TD83V)

RHW

 2 07/2001-09/2005 1997 80 109 3
2.0 TD 2 10/1998-03/2003 1998 68 92 2
2.0 TD 4x4 (SQ420D)

RFM

 2 04/2000-09/2005 1998 63 86 3
2.0 TD 4x4 (SQ420D)

RF

 2 03/1998-07/2003 1998 64 87 3
GRAND VITARA III / ESCUDO / GRAND ESCUDO (JT, TE, TD) Closed Off-Road Vehicle 04/2005-
Vehicle Engine Fuel Date CC KW CV Traction
2.7 A las 4 ruedas (JB627, TD94V)

H 27 A

 1 01/2007-12/2008 2737 136 185 3
