Product 78BD6041-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073147622
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6041-2
- Weight (gr.)
- 12064
- R90 Homologation
-
90R-02C0452/0118
- Measures
- Ø279x22x47
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
20 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
114.3 -
Wheel Hub Diameter [mm]:
62
| Brand | OE Reference |
|---|---|
| FIAT | 71742850 |
| FIAT | 71750162 |
| FIAT | 71768306 |
| SUZUKI | 55311-79J01 |
| SUZUKI | 55311-79J02 |
| SUZUKI | 55311-80J02 |
| SUZUKI | 5531179J01000 |
| SUZUKI | 5531179J02000 |
| SUZUKI | 5531179J03 |
| SUZUKI | 5531179J03000 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0122-0252.1 |
| ATE | 422252 |
| BENDIX ANTIGUO | 562534BC |
| BENDIX BRAKING-TMD | BDS1940 |
| BOSCH | 0 986 479 403 |
| BREMBO | 09.A296.11 |
| DELPHI LOCKHEED | BG4093 |
| FERODO | DDF1620 |
| GIRLING | 6047411 |
| HELLA-PAGID | 8DD 355 113-631 |
| LETEC | LBS515V |
| MINTEX | MDC1822 |
| ROAD HOUSE | 61018.10 |
| SANLI | SL33843 |
| TEXTAR | 92156600 |
| TEXTAR | 92156603 |
| TEXTAR | 92222103 |
| TRW | DF4741 |
| VALEO | 197135 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V |
M16A |
1 | 06/2006-10/2014 | 1586 | 79 | 107 | 1 |
| 1.6 16V |
M16A |
1 | 06/2006-10/2014 | 1586 | 88 | 120 | 1 |
| 1.6 16V 4x4 |
M16A |
1 | 06/2006-10/2014 | 1586 | 79 | 107 | 3 |
| 1.6 16V 4x4 |
M16A |
1 | 06/2006-10/2014 | 1586 | 88 | 120 | 3 |
| 1.9 D Multijet |
D19AA |
2 | 06/2006-10/2011 | 1910 | 88 | 120 | 1 |
| 1.9 D Multijet 4x4 |
D19AA |
2 | 06/2006-10/2011 | 1910 | 88 | 120 | 3 |
| 2.0 D Multijet |
D20AA |
2 | 06/2006-10/2014 | 1956 | 99 | 135 | 1 |
| 2.0 D Multijet 4x4 |
D20AA |
2 | 06/2006-10/2014 | 1956 | 99 | 135 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 (RW 415) |
M15A |
1 | 06/2006-07/2010 | 1490 | 73 | 99 | 1 |
| 1.5 VVT (RW415, YA11S) |
M15A |
1 | 07/2010- | 1490 | 82 | 112 | 1 |
| 1.5 VVT 4x4 (RW 415) |
M15A |
1 | 07/2010- | 1490 | 82 | 112 | 3 |
| 1.5 VVTi (YA11S) |
M15A |
1 | 07/2007-12/2015 | 1490 | 81 | 110 | 1 |
| 1.6 VVT | 1 | 12/2012-12/2015 | 1586 | 81 | 110 | 1 | |
| 1.6 VVT |
M16A |
1 | 11/2010-12/2015 | 1586 | 82 | 112 | 1 |
| 1.6 VVT (RW416, YA21S) |
M16A |
1 | 06/2006- | 1586 | 79 | 107 | 1 |
| 1.6 VVT (RW416, YA21S) |
M16A |
1 | 07/2009- | 1586 | 88 | 120 | 1 |
| 1.6 VVT 4x4 | 1 | 01/2012-12/2015 | 1586 | 81 | 110 | 3 | |
| 1.6 VVT 4x4 (RW416) |
M16A |
1 | 06/2006- | 1586 | 79 | 107 | 3 |
| 1.6 VVT 4x4 (RW416) |
M16A |
1 | 07/2009- | 1586 | 82 | 112 | 3 |
| 1.6 VVT 4x4 (RW416) |
M16A |
1 | 07/2009- | 1586 | 88 | 120 | 3 |
| 2.0 (RW415, RW416, RW420, YA41S) |
J20A |
1 | 06/2006- | 1995 | 107 | 146 | 1 |
| 2.0 (RW415, RW416, RW420, YA41S) | 1 | 01/2010- | 1995 | 112 | 152 | 1 | |
| 2.0 16V 4x4 (RW415, RW416, RW420) |
J20B |
1 | 01/2010- | 1995 | 112 | 152 | 3 |
| 2.0 4x4 (RW415, RW416, RW420, YB41S) |
J20A |
1 | 06/2006- | 1995 | 107 | 146 | 3 |
| 1.6 LPG |
M16A |
18 | 06/2006-12/2012 | 1586 | 79 | 107 | 1 |
| 1.6 DDIS (RW416D) |
9HX |
2 | 04/2007- | 1560 | 66 | 90 | 1 |
| 1.9 DDiS (RW419D) |
D19AA |
2 | 06/2006- | 1910 | 88 | 120 | 1 |
| 1.9 DDiS 4x4 (RW419D) |
D19AA |
2 | 06/2006- | 1910 | 88 | 120 | 3 |
| 2.0 DDiS (RW420D) |
D20AA |
2 | 07/2009- | 1956 | 99 | 135 | 1 |
| 2.0 DDiS 4x4 (RW420D) |
D20AA |
2 | 07/2009- | 1956 | 99 | 135 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 (RW416) |
M16A |
1 | 10/2007- | 1586 | 79 | 107 | 1 |
| 1.6 (RW416) |
M16A |
1 | 10/2007- | 1586 | 88 | 120 | 1 |
| 1.6 AWD (RW 416) |
M16A |
1 | 10/2007-12/2011 | 1586 | 79 | 107 | 3 |
| 1.6 AWD (RW 416) | 1 | 10/2007- | 1586 | 88 | 120 | 3 | |
| 2.0 | 1 | 09/2011- | 1995 | 112 | 152 | 1 | |
| 2.0 (RW415, RW416, RW420, YA41S) |
J20A |
1 | 10/2007-01/2010 | 1995 | 107 | 146 | 1 |
| 2.0 (RW415, RW416, RW420, YA41S) | 1 | 01/2010- | 1995 | 112 | 152 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 (AKK 310) |
K10C |
1 | 08/2016-06/2022 | 998 | 82 | 111 | 1 |
| 1.0 AllGrip (AKK 310) |
K10C |
1 | 08/2016-06/2022 | 998 | 82 | 111 | 3 |
| 1.4 Turbo 4Style |
K14C |
1 | 01/2017-12/2019 | 1373 | 107 | 146 | 1 |
| 1.6 (AKK416, YA22S) |
M16A |
1 | 12/2013-06/2022 | 1586 | 86 | 117 | 1 |
| 1.6 (AKK416) |
M16A |
1 | 12/2013-06/2022 | 1586 | 85 | 116 | 1 |
| 1.6 (AKK416) |
M16A |
1 | 01/2014-06/2022 | 1586 | 87 | 118 | 1 |
| 1.6 (AKK416) |
M16A |
1 | 08/2013-06/2022 | 1586 | 88 | 120 | 1 |
| 1.6 AllGrip (AKK416, YB22S) |
M16A |
1 | 12/2013-06/2022 | 1586 | 86 | 117 | 3 |
| 1.6 AllGrip (AKK416) |
M16A |
1 | 12/2013-06/2022 | 1586 | 85 | 116 | 3 |
| 1.6 AllGrip (AKK416) |
M16A |
1 | 08/2013-06/2022 | 1586 | 88 | 120 | 3 |
| 1.6 VVT | 1 | 08/2016-06/2022 | 1586 | 93 | 126 | 1 | |
| 1.4 Hybrid (Mild Hybrid) AllGrip (APK414) |
K14D |
13 | 08/2019-06/2022 | 1373 | 95 | 129 | 3 |
| 1.4 Hybrid (Mild Hybrid) AllGrip (APK414) |
K14D |
13 | 08/2019-06/2022 | 1373 | 95 | 129 | 1 |
| 1.6 DDiS (AKK 416D) |
D16AA |
2 | 08/2013-06/2022 | 1598 | 88 | 120 | 1 |
| 1.6 DDiS AllGrip (AKK 416D) |
D16AA |
2 | 08/2013-06/2022 | 1598 | 88 | 120 | 3 |
