Product 78BD6198-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073147813
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6198-2
Weight (gr.)
14644
R90 Homologation
R90 90R-02C0433/0090
Measures
Ø280x24x44
Brake Disc Type: Vented
Minimum thickness [mm]: 21.8
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 61
Reference applications
Brand OE Reference
RENAULT 77 00 80 231
RENAULT 77 00 830 283
RENAULT 77 01 204 305
RENAULT 77 01 205 231
RENAULT 77 01 205 843
RENAULT 77 01 206 198
Maker Cross reference
ATE 24.0124-0171.1
BENDIX ANTIGUO 562104B
BOSCH 0 986 478 734
BREMBO 09.8137.10
BREMBO 09.8137.14
DELPHI LOCKHEED BG2697
LETEC LBR753V
ROAD HOUSE 6301.10
SANLI SL32112
TRW DF4109
RENAULT
ESPACE III (JE0_) MPV 11/1996-10/2002
Vehicle Engine Fuel Date CC KW CV Traction
2.0

F4R 700

F4R 701

 1 09/2001-10/2002 1998 102 139 1
2.0 (JE0A)

F3R 728

F3R 729

F3R 742

F3R 768

F3R 769

 1 11/1996-10/2000 1998 84 114 1
3.0 (JE0D)

Z7X 775

 1 11/1996-10/1998 2963 123 167 1
1.9 dTi (JE0M)

F9Q 722

 2 02/1999-10/2002 1870 72 98 1
2.2 12V TD (JE0E, JE0H, JE0P)

G8T 714

G8T 716

G8T 760

 2 11/1996-10/2000 2188 83 113 1
2.2 D

G8T 716

 2 11/1997-01/2000 2188 84 114 1
2.2 dCi (JE0S)

G9T 710

 2 07/2000-10/2002 2188 85 115 1
KANGOO II / GRAND KANGOO (KW0/1_) MPV 02/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.5 dCi 95 (KW16)

K9K 872

 2 03/2019- 1461 70 95 1
KANGOO II EXPRESS (FW0/1_) Box Body/MPV 02/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 1 09/2008- 1598 81 110 1
LAGUNA I (B56_, 556_) Hatchback 11/1993-08/2002
Vehicle Engine Fuel Date CC KW CV Traction
1.8

F3P 674

 1 06/1995-02/2001 1794 69 94 1
1.8

F3P 676

 1 06/1995-06/1998 1794 70 95 1
1.8 (B56A/B)

F3P 720

F3P 724

 1 11/1993-03/2001 1794 66 90 1
1.8 (B56S/T/0)

F3P 670

F3P 678

 1 08/1995-03/2001 1794 66 90 1
1.8 (B56Z)

F3P 720

F3P 724

 1 08/1995-03/2001 1794 69 94 1
1.8 16V (B563, B564)

F4P 760

F4P 770

 1 04/1998-03/2001 1783 88 120 1
2.0

N7Q 700

N7Q 704

 1 06/1995-02/2001 1948 103 140 1
2.0 (556A)

F4R 780

 1 09/1999-02/2001 1998 102 139 1
2.0 16V (556A/B)

F4R 780

 1 09/1999-03/2001 1998 103 140 1
2.0 16V (B56D, B56M)

N7Q 700

N7Q 704

 1 06/1995-03/2001 1948 102 139 1
3.0 (B56E, B565, B56R)

Z7X 760

Z7X 765

 1 11/1993-03/2001 2963 123 167 1
3.0 24V (B56V)

L7X 700

L7X 701

 1 03/1997-03/2001 2946 140 190 1
2.2 dT (B569)

G8T 760

 2 03/1996-03/2001 2188 83 113 1
LAGUNA I Grandtour (K56_) Estate 09/1995-08/2002
Vehicle Engine Fuel Date CC KW CV Traction
3.0 (K56R, K565)

Z7X 765

 1 02/1996-03/2001 2963 123 167 1
3.0 24V (K56V)

L7X 700

L7X 701

 1 03/1997-03/2001 2946 140 190 1
2.2 D (K56F/2, S56F)

G8T 706

G8T 752

G8T 790

G8T 794

 2 09/1995-03/2001 2188 61 83 1
2.2 dT (K569)

G8T 760

 2 03/1996-03/2001 2188 83 113 1
SAFRANE (B54_) Hatchback 04/1992-10/1997
Vehicle Engine Fuel Date CC KW CV Traction
3.0

Z7X 721

 1 03/1993-10/1996 2963 125 170 1
3.0

Z7X 723

 1 02/1993-06/1996 2975 125 170 1
3.0 Biturbo 4x4 (B545)

Z7X 726

 1 02/1993-07/1996 2963 193 262 3
3.0 V6 (B54B, B544)

Z7X 721

Z7X 722

Z7X 723

Z7X 753

 1 12/1992-07/1996 2975 123 167 1
3.0 V6 4x4 (B54B, B544)

Z7X 721

Z7X 722

Z7X 723

 1 12/1992-07/1996 2975 123 167 3
2.5 dT (B548)

S8U 762

S8U 763

 2 12/1992-07/1996 2499 83 113 1
SAFRANE II (B54_) Hatchback 07/1996-12/2000
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V (B54L)

N7Q 710

N7Q 711

 1 07/1996-12/2000 1948 100 136 1
2.5 20V (B54F)

N7U 700

N7U 701

 1 07/1996-12/2000 2435 121 165 1
2.9 24V (B54N)

L7X 713

 1 03/1999-12/2000 2946 140 190 1
3.0 V6 (B54M)

Z7X 755

 1 07/1996-12/2000 2963 123 167 1
2.2 dT (B54G)

G8T 740

 2 07/1996-12/2000 2188 83 113 1
SCÉNIC (JA0/1_, FA0_) MPV 08/1999-07/2010
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V RX4

F4R 744

F4R 746

 1 06/2000-08/2003 1998 102 139 3
1.9 dCi RX4

F9Q 732

F9Q 748

F9Q 796

 2 12/2002-08/2003 1870 74 101 3
1.9 dCi RX4

F9Q 740

 2 11/2000-08/2003 1870 75 102 3
