Product 78BD6470-2 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073147905
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6470-2
Weight (gr.): 6580

R90 Homologation: 90R-02C0453/0107
Measures: Ø258x9x53.5
: Brake Disc Type: solid; Minimum thickness [mm]: 7.3; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 112; Wheel Hub Diameter [mm]: 67

Reference applications

Brand	OE Reference
MERCEDES-BENZ	201 423 09 12
MERCEDES-BENZ	201 423 11 12
MERCEDES-BENZ	201 423 12 12

Maker	Cross reference
ATE	24.0109-0118.1
BOSCH	0 986 478 188
BREMBO	08.4738.10
BREMBO	08.4738.14
LETEC	LBM003S
ROAD HOUSE	6194.00
SANLI	SL16721
TRW	DF1583

MERCEDES-BENZ

124 (W124) Saloon 12/1984-08/1993

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
200	M 102.922	1	01/1986-10/1992	1996	77	105	2
200 (124.020)	M 102.922	1	01/1986-05/1990	1996	75	102	2
200 (124.020)	M 102.922	1	12/1985-05/1990	1996	80	109	2
200 E		1	11/1992-05/1993	1997	77	105	2
200 E (124.019)	M 111.940	1	10/1992-06/1993	1998	100	136	2
200 E (124.021)	M 102.963	1	09/1988-08/1993	1996	87	118	2
200 E (124.021)	M 102.963	1	09/1988-12/1989	1996	90	122	2
220 E (124.022)	M 111.960	1	10/1992-06/1993	2199	110	150	2
230 E (124.023)	M 102.982	1	12/1984-03/1992	2298	97	132	2
230 E (124.023)	M 102.982	1	01/1985-06/1993	2298	100	136	2
230 E Cat (124.023)	M 102.982	1	06/1989-06/1993	2298	97	132	2
260 E (124.026)	M 103.940	1	09/1985-08/1992	2597	118	160	2
260 E (124.026)	M 103.940	1	09/1985-12/1989	2597	122	166	2
260 E 4-matic (124.226)	M 103.943	1	09/1986-08/1992	2597	118	160	3
260 E 4-matic (124.226)	M 103.940	1	12/1986-12/1989	2597	122	166	3
280 E (124.028)	M 104.942	1	10/1992-06/1993	2799	145	197	2
300 E	M 103.980	1	01/1985-12/1985	2960	138	188	2
300 E	M 103.983	1	06/1985-08/1992	2960	138	188	2
300 E (124.030)	M 103.983	1	08/1985-08/1992	2960	132	180	2
300 E 4-matic	M 103.983	1	09/1986-02/1992	2960	138	188	3
300 E 4-matic (124.230)	M 103.985	1	09/1986-06/1993	2960	132	180	3
300 E-24 (124.031)	M 104.980	1	09/1988-08/1992	2960	162	220	2
200 D (124.120)	OM 601.912	2	12/1984-08/1989	1997	53	72	2
200 D (124.120)	OM 601.912	2	08/1989-06/1993	1997	55	75	2
250 D (124.125)	OM 602.912	2	04/1985-06/1993	2497	66	90	2
250 D (124.125)	OM 602.912	2	01/1989-06/1993	2497	69	94	2
250 Turbo-D (124.128)	OM 602.962	2	09/1988-06/1993	2497	93	126	2
3.4 300 TD SD		2	06/1991-05/1993	3449	110	150	2
300 D (124.130)	OM 603.912	2	12/1984-08/1989	2996	80	109	2
300 D (124.130)	OM 603.912	2	06/1990-06/1993	2996	81	110	2
300 D (124.130)	OM 603.912	2	08/1989-06/1993	2996	83	113	2
300 D 4-matic (124.330)	OM 603.913	2	09/1986-08/1992	2996	80	109	3
300 D 4-matic (124.330)	OM 603.913	2	08/1989-06/1993	2996	83	113	3
300 Turbo-D (124.133)	OM 603.960 OM 603.963	2	09/1986-09/1988	2996	105	143	2
300 Turbo-D (124.133)	OM 603.960	2	09/1988-06/1993	2996	108	147	2
300 Turbo-D 4-matic (124.333)	OM 603.960 OM 603.963	2	09/1986-09/1988	2996	105	143	3
300 Turbo-D 4-matic (124.333)	OM 603.963	2	01/1988-06/1993	2996	108	147	3

124 T-Model (S124) Estate 09/1985-12/1993

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
200 TE (124.079)	M 111.940	1	05/1986-06/1993	1998	100	136	2
220 TE (124.082)	M 111.960	1	10/1992-05/1993	2199	110	150	2
260 TE FGST.	M 103.940	1	09/1989-08/1992	2597	118	160	2
260 TE FGST.	M 103.940	1	09/1985-12/1989	2597	122	166	2
280 TE (124.088)	M 104.942	1	10/1992-06/1993	2799	145	197	2
300 TE 4-matic (124.290)	M 103.985	1	09/1986-06/1993	2960	132	180	3
300 TE 4-matic (124.290)	M 103.983	1	09/1986-12/1989	2960	138	188	3
250 T D (124.185)	OM 602.912	2	09/1985-06/1993	2497	66	90	2
250 T D (124.185)	OM 602.912	2	01/1989-06/1993	2497	69	94	2
300 TD T		2	06/1992-05/1993	2996	100	136	2

124 (C124) Coupe 03/1987-07/1993

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
200 CE (124.041)	M 102.963	1	03/1990-12/1992	1996	87	118	2
200 CE (124.041)	M 102.963	1	03/1990-12/1992	1996	90	122	2
220 CE (124.042)	M 111.960	1	10/1992-05/1993	2199	110	150	2
230 CE (124.043)	M 102.982	1	03/1987-12/1992	2298	97	132	2
230 CE (124.043)	M 102.982	1	03/1987-12/1992	2298	100	136	2
230 CE Cat (124.043)	M 102.982	1	06/1989-12/1992	2298	97	132	2
300 CE	M 103.983	1	03/1987-12/1989	2960	138	188	2
300 CE (124.050)	M 103.983	1	03/1987-05/1993	2960	132	180	2

190 (W201) Saloon 10/1982-08/1993

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 (201.022)	M 102.921	1	10/1982-10/1984	1996	66	90	2
2.0 (201.023)	M 102.924	1	01/1986-05/1990	1996	75	102	2
2.0 (201.023)	M 102.924	1	08/1983-05/1990	1996	77	105	2
2.3	M 102.985	1	09/1987-09/1988	2299	97	132	2
2.3 E	M 102.985	1	10/1982-09/1988	2299	100	136	2
2.6	M 103.942	1	10/1982-09/1988	2599	118	160	2
E 1.8 (201.018)	M 102.910	1	04/1990-08/1993	1797	80	109	2
E 2.0	M 102.962	1	01/1985-08/1993	1996	87	118	2
E 2.0	M 102.961	1	10/1982-06/1993	1996	93	126	2
E 2.0 (201.024)	M 102.961 M 102.962	1	02/1985-12/1986	1996	83	113	2
E 2.0 (201.024)	M 102.962	1	02/1985-12/1986	1996	85	116	2
E 2.0 (201.024)	M 102.961 M 102.962	1	10/1982-06/1993	1996	90	122	2
E 2.3	M 102.985	1	09/1986-08/1991	2298	97	132	2
E 2.3 (201.028)	M 102.985	1	10/1986-08/1993	2298	100	136	2
E 2.3-16	M 102.983	1	09/1985-12/1987	2298	125	170	2
E 2.3-16	M 102.983	1	09/1985-08/1988	2298	130	177	2
E 2.3-16 (201.034)	M 102.983	1	04/1984-01/1987	2298	136	185	2
E 2.5-16 (201.035)	M 102.990	1	09/1988-08/1993	2498	150	204	2
E 2.5-16 Evolution (201.036)	M 102.991	1	03/1989-08/1993	2498	143	194	2
E 2.5-16 Evolution II	M 102.992	1	05/1990-08/1993	2498	173	235	2
E 2.6	M 103.942	1	09/1986-12/1989	2597	122	166	2
E 2.6 (201.029)	M 103.942	1	09/1986-08/1993	2597	118	160	2
D 2.0 (201.122)	OM 601.911	2	08/1983-08/1989	1997	53	72	2
D 2.0 (201.122)	OM 601.911	2	08/1989-08/1993	1997	55	75	2
D 2.5 (201.126)	OM 602.911	2	04/1985-08/1993	2497	66	90	2
D 2.5 (201.126)	OM 602.911	2	08/1989-08/1993	2497	69	94	2
Turbo-D 2.5 (201.128)	OM 602.961	2	02/1988-08/1993	2497	90	122	2
Turbo-D 2.5 (201.128)	OM 602.961	2	02/1988-08/1993	2497	93	126	2

E-Class (W124) Saloon 02/1993-06/1996

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
E 200 (124.019)	M 111.940	1	06/1993-06/1995	1998	100	136	2
E 220 (124.022)	M 111.960	1	06/1993-06/1995	2199	110	150	2
E 280 (124.028)	M 104.942	1	06/1993-06/1995	2799	145	197	2
E 280 (124.029)	M 104.942	1	06/1993-06/1995	2799	142	193	2
E 300 4-matic (124.230)	M 103.985	1	06/1993-06/1995	2960	132	180	3
E 200 D (124.120)	OM 601.912	2	06/1993-06/1995	1997	55	75	2
E 250 D (124.126, 124.129)	OM 605.911	2	07/1993-06/1995	2497	83	113	2
E 250 Turbo-D (124.128)	OM 602.962	2	06/1993-06/1995	2497	93	126	2
E 300 D (124.131)	OM 606.910	2	07/1993-06/1995	2996	100	136	2
E 300 Turbo-D (124.133)	OM 603.960	2	06/1993-06/1995	2996	108	147	2
E 300 Turbo-D 4-matic (124.333)	OM 603.963	2	06/1993-06/1995	2996	108	147	3

E-Class (A124) Convertible 05/1993-03/1998

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
E 200 (124.060)	M 111.940	1	06/1993-03/1998	1998	100	136	2
E 220 (124.062)	M 111.960	1	06/1993-03/1998	2199	110	150	2

E-Class (C124) Coupe 06/1993-06/1997

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
E 200 (124.040)	M 111.940	1	06/1993-06/1997	1998	100	136	2
E 220 (124.042)	M 111.960	1	06/1993-06/1997	2199	110	150	2

E-Class T-Model (S124) Estate 06/1993-06/1996

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
E 200 T (124.079)	M 111.940	1	06/1993-06/1996	1998	100	136	2
E 220 T (124.082)	M 111.960	1	06/1993-06/1996	2199	110	150	2
E 280 T (124.088)	M 104.942	1	06/1993-06/1996	2799	142	193	2
E 280 T (124.088)	M 104.942	1	06/1993-06/1996	2799	145	197	2
E 300 T 4-matic (124.290)	M 103.985	1	06/1993-06/1996	2960	132	180	3
E 250 TD (124.186)	OM 605.911	2	06/1993-06/1996	2497	83	113	2
E 250 Turbo D	OM 602.962	2	06/1993-06/1996	2497	93	126	2
E 300 T Turbo-D (124.193)	OM 603.960	2	06/1993-06/1996	2996	108	147	2
E 300 T Turbo-D 4-matic (124.393)	OM 603.963	2	06/1993-06/1996	2996	108	147	3
E 300 TD (124.191)	OM 606.910	2	06/1993-06/1996	2996	100	136	2
