Product 78BD6478-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073147974
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6478-2
- Weight (gr.)
- 20160
- R90 Homologation
-
90R-02C0593/1548
- Measures
- Ø330x28x46.5
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
26 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
112 -
Wheel Hub Diameter [mm]:
67
| Brand | OE Reference |
|---|---|
| MERCEDES-BENZ | 203 421 13 12 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0128-0177.1 |
| ATE | 428177 |
| BENDIX ANTIGUO | 562354B |
| BOSCH | 0 986 479 135 |
| BREMBO | 09.A448.20 |
| BREMBO | 09.A448.21 |
| DELPHI LOCKHEED | BG3985 |
| FERODO | DDF1582 |
| GIRLING | 6061535 |
| HELLA-PAGID | 8DD 355 109-411 |
| LETEC | LBM037V |
| MINTEX | MDC2301 |
| ROAD HOUSE | 61138.10 |
| ROAD HOUSE | 61138.11 |
| SANLI | SL36894X |
| TEXTAR | 92119803 |
| TRW | DF6153S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| C 250 D (202.125) |
OM 605.910 |
2 | 05/1993-05/2000 | 2497 | 83 | 113 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| C 180 Kompressor (203.046) |
M 271.946 |
1 | 05/2002-02/2007 | 1796 | 105 | 143 | 2 |
| C 200 CGI Kompressor (203.743) |
M 271.942 |
1 | 07/2003-02/2007 | 1796 | 125 | 170 | 2 |
| C 200 Kompressor (203.045) |
M 271.940 |
1 | 05/2002-02/2007 | 1796 | 120 | 163 | 2 |
| C 230 (203.052) |
M 272.920 |
1 | 01/2005-02/2007 | 2496 | 150 | 204 | 2 |
| C 230 Kompressor (203.040) |
M 271.948 |
1 | 02/2004-02/2007 | 1796 | 141 | 192 | 2 |
| C 240 (203.061) |
M 112.912 |
1 | 05/2000-02/2007 | 2597 | 125 | 170 | 2 |
| C 280 (203.054) |
M 272.940 |
1 | 01/2005-02/2007 | 2996 | 170 | 231 | 2 |
| C 280 4-matic (203.092) |
M 272.941 |
1 | 01/2005-02/2007 | 2996 | 170 | 231 | 3 |
| C 320 (203.064) |
M 112.946 |
1 | 05/2000-02/2007 | 3199 | 160 | 218 | 2 |
| C 200 CDI (203.004) |
OM 611.962 |
2 | 02/2001-06/2003 | 2148 | 75 | 102 | 2 |
| C 200 CDI (203.004) |
OM 611.962 |
2 | 09/2000-06/2003 | 2148 | 85 | 116 | 2 |
| C 200 CDI (203.007) |
OM 646.962 OM 646.963 |
2 | 04/2003-02/2007 | 2148 | 90 | 122 | 2 |
| C 220 CDI (203.006, 203.008) |
OM 611.962 OM 646.963 |
2 | 05/2000-02/2007 | 2148 | 105 | 143 | 2 |
| C 220 CDI (203.006) |
OM 611.962 |
2 | 05/2000-02/2007 | 2148 | 100 | 136 | 2 |
| C 220 CDI (203.008) |
OM 646.963 |
2 | 04/2003-02/2007 | 2148 | 110 | 150 | 2 |
| C 270 CDI (203.016) |
OM 612.962 |
2 | 12/2000-02/2007 | 2685 | 120 | 163 | 2 |
| C 270 CDI (203.016) |
OM 612.962 |
2 | 12/2000-02/2007 | 2685 | 125 | 170 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| C 180 Kompressor (203.246) |
M 271.946 |
1 | 05/2002-08/2007 | 1796 | 105 | 143 | 2 |
| C 200 CGI Kompressor (203.743) |
M 271.942 |
1 | 07/2003-08/2007 | 1796 | 125 | 170 | 2 |
| C 200 Kompressor (203.245) |
M 271.940 |
1 | 05/2002-08/2007 | 1796 | 120 | 163 | 2 |
| C 230 (203.252) |
M 272.920 |
1 | 01/2005-08/2007 | 2496 | 150 | 204 | 2 |
| C 230 Kompressor (203.240) |
M 271.948 |
1 | 02/2004-08/2007 | 1796 | 141 | 192 | 2 |
| C 240 (203.261) |
M 112.912 |
1 | 03/2001-08/2007 | 2597 | 125 | 170 | 2 |
| C 280 (203.254) |
M 272.940 |
1 | 01/2005-08/2007 | 2996 | 170 | 231 | 2 |
| C 280 4-matic (203.292) |
M 272.941 |
1 | 01/2005-08/2007 | 2996 | 170 | 231 | 3 |
| C 320 (203.264) |
M 112.946 |
1 | 03/2001-08/2007 | 3199 | 160 | 218 | 2 |
| C 200 CDI (203.204) |
OM 611.962 OM 646.962 |
2 | 03/2001-08/2007 | 2148 | 75 | 102 | 2 |
| C 200 CDI (203.204) |
OM 611.962 |
2 | 03/2001-08/2007 | 2148 | 85 | 116 | 2 |
| C 200 CDI (203.207) |
OM 646.962 OM 646.963 |
2 | 04/2003-08/2007 | 2148 | 90 | 122 | 2 |
| C 220 CDI (203.206, 203.208) |
OM 611.962 |
2 | 03/2001-08/2007 | 2148 | 105 | 143 | 2 |
| C 220 CDI (203.208) |
OM 646.963 |
2 | 08/2006-08/2007 | 2148 | 100 | 136 | 2 |
| C 220 CDI (203.208) |
OM 646.963 |
2 | 02/2004-08/2007 | 2148 | 110 | 150 | 2 |
| C 270 CDI (203.216) |
OM 612.962 |
2 | 03/2001-08/2007 | 2685 | 120 | 163 | 2 |
| C 270 CDI (203.216) |
OM 612.962 |
2 | 03/2001-08/2007 | 2685 | 125 | 170 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| CLK 200 CGI (209.343) |
M 271.942 |
1 | 07/2003-05/2009 | 1796 | 125 | 170 | 2 |
| CLK 200 Kompressor (209.442) |
M 271.940 |
1 | 09/2002-05/2009 | 1796 | 120 | 163 | 2 |
| CLK 200 Kompressor (209.442) |
M 271.955 |
1 | 10/2006-05/2009 | 1796 | 135 | 184 | 2 |
| CLK 280 (209.354) |
M 272.940 |
1 | 01/2005-05/2009 | 2996 | 170 | 231 | 2 |
| CLK 220 CDI (209.308) |
OM 646.966 |
2 | 01/2005-05/2009 | 2148 | 100 | 136 | 2 |
| CLK 220 CDI (209.308) |
OM 646.966 |
2 | 01/2005-05/2009 | 2148 | 110 | 150 | 2 |
| CLK 270 CDI (209.316) |
OM 612.962 OM 612.967 |
2 | 10/2002-05/2009 | 2685 | 125 | 170 | 2 |
| CLK 320 CDI (209.320) |
OM 642.910 |
2 | 01/2005-05/2009 | 2987 | 165 | 224 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| CLK 200 CGI (209.343) |
M 271.942 |
1 | 07/2003-03/2010 | 1796 | 125 | 170 | 2 |
| CLK 200 Kompressor (209.442) |
M 271.940 |
1 | 02/2003-03/2010 | 1796 | 120 | 163 | 2 |
| CLK 200 Kompressor (209.442) |
M 271.955 |
1 | 10/2006-03/2010 | 1796 | 135 | 184 | 2 |
| CLK 280 (209.454) |
M 272.940 |
1 | 01/2005-03/2010 | 2996 | 170 | 231 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 200 Kompressor (171.445) |
M 271.944 |
1 | 03/2004-02/2011 | 1796 | 120 | 163 | 2 |
| 200 Kompressor (171.445) |
M 271.954 |
1 | 01/2008-02/2011 | 1796 | 135 | 184 | 2 |
| 280 (171.454) |
M 272.942 |
1 | 01/2005-02/2011 | 2996 | 170 | 231 | 2 |
| 300 (171.454) |
M 272.942 |
1 | 04/2009-02/2011 | 2996 | 170 | 231 | 2 |
| 350 (171.456) |
M 272.963 |
1 | 06/2004-02/2011 | 3498 | 200 | 272 | 2 |
| 350 (171.458) |
M 272.969 |
1 | 01/2008-02/2011 | 3498 | 224 | 305 | 2 |
