Product 78BD6539-1

Description: Brake disc
Axe: Front
No. of Pieces: 1
Barcode: 8424073147998
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6539-1
Weight (gr.): 11540

R90 Homologation: 90R-02C0339/1729
Measures: Ø308x33x55.3
: Brake Disc Type: Vented; Minimum thickness [mm]: 30; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 111; Wheel Hub Diameter [mm]: 93

Reference applications

Brand	OE Reference
FORD	1 763 884
FORD	1 842 633
FORD	BK21-1125-AB
FORD	BK21-1125-AC
FORD	CK41-1125-AD

Maker	Cross reference
BENDIX-ROULUNDS	521717
BOSCH	0 986 479 D40
BOSCH	0 986 479 F46
GIRLING	6067525
MINTEX	MDC2719
ROAD HOUSE	61565.10
SANLI	SL37935
TEXTAR	92273003
TEXTAR	98200 2730 0 1

FORD

TOURNEO CUSTOM V362 (F3) Bus 09/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	12/2015-12/2023	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	12/2015-12/2023	1995	96	130	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	12/2015-12/2023	1995	125	170	1
2.0 EcoBlue	BCFA BCFB	2	05/2019-12/2023	1995	136	185	1
2.2 TDCi	DRF4 DRFF DRFG	2	09/2012-12/2015	2198	74	100	1
2.2 TDCi	CYF4 CYFF	2	09/2012-12/2015	2198	92	125	1
2.2 TDCi	CVFF	2	09/2012-12/2015	2198	114	155	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-12/2023	1995	96	130	1
2.0 EcoBlue mHEV	BCFC BCFD	14	05/2019-12/2023	1995	136	185	1

TRANSIT V (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) Bus 04/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi RWD	CVRC	2	10/2011-08/2014	2198	114	155	2

TRANSIT VI V363 (FAD, FBD) Bus 08/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	03/2016-	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	03/2016-	1995	96	130	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	03/2016-06/2024	1995	125	170	1
2.0 EcoBlue RWD	YMHA	2	05/2019-	1995	96	130	2
2.2 TDCi	DRF5 DRFF DRFG	2	08/2013-12/2018	2198	74	100	1
2.2 TDCi	CY14 CYF5 CYFG USF6	2	08/2013-12/2018	2198	92	125	1
2.2 TDCi	CVF5	2	12/2014-12/2018	2198	114	155	1
2.2 TDCi 4x4	CY24 CYR5	2	08/2013-12/2018	2198	92	125	3
2.2 TDCi A las 4 ruedas		2	08/2015-12/2018	2198	114	155	3
2.2 TDCi RWD	DRR5	2	08/2013-12/2018	2198	74	100	2
2.2 TDCi RWD	CYR5 USR6	2	08/2013-12/2018	2198	92	125	2
2.2 TDCi RWD	UHR5	2	08/2013-	2198	99	135	2
2.2 TDCi RWD	CV24 CVR5 UYR6	2	08/2013-12/2018	2198	114	155	2

TRANSIT VI V363 (FCD, FDD) Van 08/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	03/2016-	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	03/2016-	1995	96	130	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	03/2016-06/2024	1995	125	170	1
2.0 EcoBlue RWD	BJRA YLR6 YLRA	2	03/2016-	1995	77	105	2
2.0 EcoBlue RWD	BKRA YMHA YMR6	2	03/2016-	1995	96	130	2
2.0 EcoBlue RWD	BLHA BLRA YNR6	2	03/2016-06/2024	1995	125	170	2
2.2 TDCi	CY14 CYF5 CYFG USF6	2	08/2013-12/2018	2198	92	125	1
2.2 TDCi	CVF5	2	08/2013-12/2018	2198	114	155	1
2.2 TDCi 4x4	CY24 CYR5	2	08/2013-12/2018	2198	92	125	3
2.2 TDCi 4x4	CV24 CVR5	2	08/2015-12/2018	2198	114	155	3
2.2 TDCi RWD	DRR5	2	08/2013-12/2018	2198	74	100	2
2.2 TDCi RWD	CYR5 USR6	2	08/2013-12/2018	2198	92	125	2
2.2 TDCi RWD	CV24 CVR5 UYR6	2	08/2013-12/2018	2198	114	155	2

TRANSIT VI V363 (FED, FFD) Platform/Chassis 08/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	03/2016-	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	03/2016-	1995	96	130	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	03/2016-06/2024	1995	125	170	1
2.0 EcoBlue RWD	BJRA YLR6 YLRA	2	03/2016-	1995	77	105	2
2.0 EcoBlue RWD	BKRA YMHA YMR6	2	03/2016-	1995	96	130	2
2.0 EcoBlue RWD	BLHA BLRA YNR6	2	03/2016-06/2024	1995	125	170	2
2.2 TDCi	DRF5 DRFF DRFG	2	08/2013-12/2018	2198	74	100	1
2.2 TDCi	CY14 CYF5 CYFG USF6	2	08/2013-12/2018	2198	92	125	1
2.2 TDCi	CVF5	2	08/2013-12/2018	2198	114	155	1
2.2 TDCi 4x4	CY24 CYR5	2	08/2013-12/2018	2198	92	125	3
2.2 TDCi 4x4	CV24 CVR5	2	08/2013-12/2018	2198	114	155	3
2.2 TDCi RWD	DRR5	2	08/2013-12/2018	2198	74	100	2
2.2 TDCi RWD	CYR5 USR6	2	08/2013-12/2018	2198	92	125	2
2.2 TDCi RWD	UHR5	2	08/2013-12/2018	2198	99	135	2
2.2 TDCi RWD	CV24 CVR5 UYR6	2	08/2013-	2198	114	155	2

TRANSIT CUSTOM V362 (F3) Bus 04/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	12/2015-12/2023	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	12/2015-12/2023	1995	96	130	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	12/2015-12/2023	1995	125	170	1
2.0 EcoBlue	BCFA BCFB	2	05/2019-12/2023	1995	136	185	1
2.2 TDCi	DRF4 DRFF DRFG	2	09/2012-12/2015	2198	74	100	1
2.2 TDCi	CYF4 CYFF	2	09/2012-12/2015	2198	92	125	1
2.2 TDCi	CVFF	2	09/2012-12/2015	2198	114	155	1
2.0 EcoBlue mHEV	BJFC BJFD	14	05/2019-12/2023	1995	77	105	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-12/2023	1995	96	130	1
2.0 EcoBlue mHEV	BLFC BLFD	14	05/2019-12/2023	1995	125	170	1
2.0 EcoBlue mHEV	BCFC BCFD	14	05/2019-12/2023	1995	136	185	1

TRANSIT CUSTOM V362 (FY, FZ) Van 09/2012-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 EcoBoost PHEV	M1FA	13	04/2020-12/2023	996	92	125	1
2.0 EcoBlue	BJFA BJFB YLF6 YLFA YLFB YLFS	2	12/2015-12/2023	1995	77	105	1
2.0 EcoBlue	BKFA BKFB YMF6 YMFA YMFB YMFS	2	12/2015-12/2023	1995	96	130	1
2.0 EcoBlue	BLFA BLFB YNF6 YNFA YNFB YNFS	2	12/2015-12/2023	1995	125	170	1
2.0 EcoBlue	BCFA BCFB	2	05/2019-12/2023	1995	136	185	1
2.2 TDCi	DRF4 DRFF DRFG	2	09/2012-12/2015	2198	74	100	1
2.2 TDCi	CYF4 CYFF	2	09/2012-12/2023	2198	92	125	1
2.2 TDCi	CVFF	2	09/2012-12/2015	2198	114	155	1
2.0 EcoBlue mHEV	BKFC BKFD	14	05/2019-12/2023	1995	96	130	1
2.0 EcoBlue mHEV	BLFC BLFD	14	05/2019-12/2023	1995	125	170	1
2.0 EcoBlue mHEV	BCFC BCFD	14	05/2019-12/2023	1995	136	185	1

FORD AUSTRALIA

TOURNEO () Bus 05/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi		2	05/2014-	2198	114	155	2

TRANSIT (VO) Van 09/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi		2	09/2014-	2198	114	155	2

TRANSIT (VO) Platform/Chassis 09/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi		2	09/2014-	2198	114	155	2

TRANSIT CUSTOM (VN) Van 09/2013-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi		2	09/2013-	2198	92	125	2
