Product 78BD6567-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073148025
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6567-2
Weight (gr.)
12950
R90 Homologation
R90 90R-02C0074/0224
Measures
Ø280x26x56.3
Brake Disc Type: Vented
Minimum thickness [mm]: 24
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 68
Reference applications
Brand OE Reference
VOLVO 3 516 567
VOLVO 3 516 567 9
VOLVO 6 848 902
Maker Cross reference
ATE 24.0126-0105.1
BOSCH 0 986 478 298
BREMBO 09.5315.10
BREMBO 09.5315.14
ROAD HOUSE 6304.10
TRW DF1697
VOLVO
740 (744) Saloon 04/1983-12/1992
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 F

 1 09/1990-08/1992 1986 82 111 2
2.0

B 200 G

 1 08/1985-07/1992 1986 89 121 2
2.0

B 204 FTE

 1 09/1990-08/1992 1986 147 200 2
2.0 Turbo

B 200 FT

 1 09/1990-08/1991 1986 114 155 2
2.3

B 230 F

 1 08/1987-07/1992 2316 85 115 2
2.3

B 234 F

 1 08/1988-08/1992 2316 111 151 2
2.3

B 234 F

 1 08/1988-07/1991 2316 114 156 2
2.3 Turbo

B 230 FT

B 230 GT

 1 09/1989-08/1991 2316 125 170 2
2.4 Diesel

D 24

 2 08/1984-07/1992 2383 60 82 2
740 Kombi (745) Estate 08/1984-12/1992
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 F

 1 08/1989-07/1991 1986 82 112 2
2.0

B 200 E

B 200 G

 1 08/1985-07/1992 1986 89 121 2
2.0

B 204 FTE

 1 09/1990-08/1992 1986 147 200 2
2.0 Turbo

B 200 FT

 1 09/1990-08/1991 1986 114 155 2
2.3

B 230 F

 1 08/1987-07/1992 2316 85 115 2
2.3

B 230 F

 1 01/1988-10/1990 2316 87 118 2
2.3

B 234 F

 1 07/1989-08/1992 2316 111 151 2
2.3 Turbo

B 230 FT

B 230 GT

 1 09/1989-08/1991 2316 125 170 2
2.4 Turbo-Diesel

D 24 T

 2 09/1985-07/1992 2383 80 109 2
780 (782) Coupe 04/1986-11/1990
Vehicle Engine Fuel Date CC KW CV Traction
2.4 D

D 24 TIC

 2 04/1986-07/1990 2383 90 122 2
940 (944) Saloon 08/1990-03/1995
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 F

 1 01/1992-07/1994 1986 82 112 2
2.0

B 200 E

B 200 G

 1 09/1990-09/1993 1986 89 121 2
2.0

B 204 FT

 1 09/1990-09/1993 1986 102 139 2
2.0 GL

B 204 E

 1 09/1990-04/1992 1986 103 140 2
2.0 Turbo

B 200 FT

 1 08/1990-12/1994 1986 114 155 2
2.3

B 230 FD

 1 08/1992-07/1994 2316 85 116 2
2.3

B 230 FB

B 230 G

 1 08/1990-12/1994 2316 96 131 2
2.3

B 230 FK

 1 05/1991-03/1995 2316 99 135 2
2.3

B 234 F

B 234 G

 1 08/1990-07/1991 2316 114 156 2
2.3

B 230 FT

 1 09/1990-09/1993 2316 118 160 2
2.3 Turbo

B 230 FT

 1 08/1990-07/1994 2316 121 165 2
2.3 Turbo

B 230 FT+

 1 08/1991-07/1993 2316 140 190 2
2.4 D

D 24

 2 08/1990-12/1994 2383 60 82 2
2.4 TD Intercooler

D 24 TIC

 2 08/1990-12/1994 2383 90 122 2
2.4 Turbo Diesel

D 24 T

 2 08/1990-12/1994 2383 80 109 2
940 Kombi (945) Estate 08/1990-10/1995
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 F

 1 01/1992-07/1994 1986 82 112 2
2.0 GL

B 204 E

 1 09/1990-04/1992 1986 103 140 2
2.0 Turbo

B 200 FT

 1 01/1991-07/1995 1986 114 155 2
2.3

B 230 FD

 1 08/1992-07/1994 2316 85 116 2
2.3

B 230 FB

 1 08/1990-12/1994 2316 96 131 2
2.3

B 234 F

 1 08/1990-07/1991 2316 114 155 2
2.3

B 230 FB

 1 09/1990-09/1993 2316 118 160 2
2.3 Turbo

B 230 FT

 1 08/1990-07/1994 2316 121 165 2
2.3 Turbo

B 230 FT+

 1 08/1991-07/1993 2316 140 190 2
2.4 D

D 24

 2 08/1990-07/1995 2383 60 82 2
2.4 TD 2 05/1991-03/1995 2383 95 130 2
2.4 TD Intercooler

D 24 TIC

 2 08/1990-08/1994 2383 90 122 2
2.4 Turbo Diesel

D 24 T

 2 08/1990-07/1994 2383 80 109 2
940 (945) Estate 09/1990-10/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 G

 1 11/1994-12/1995 1986 89 121 2
2.0

B 204 FT

 1 10/1994-05/1997 1986 102 139 2
2.0 GLT

B 200 GT

 1 10/1994-05/1997 1986 139 189 2
2.0 Turbo

B 200 FT

 1 04/1996-10/1998 1986 114 155 2
2.3

B 230 FD

 1 08/1994-07/1995 2316 85 116 2
2.3

B 230 FB

 1 08/1994-10/1998 2316 96 131 2
2.3 1 10/1994-05/1997 2316 113 154 1
2.3 ti

B 230 FK

 1 01/1995-10/1998 2316 99 135 2
2.3 Turbo

B 230 FT

 1 08/1994-10/1998 2316 121 165 2
2.3 Turbo

B 230 FT

 1 08/1995-10/1998 2316 126 171 2
940 (944) Saloon 08/1994-12/1998
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 G

 1 11/1994-12/1995 1986 89 121 2
2.0

B 204 FT

 1 10/1994-05/1997 1986 102 139 2
2.0 GLT

B 200 GT

 1 10/1994-05/1997 1986 139 189 2
2.0 Turbo

B 200 FT

 1 04/1996-10/1998 1986 114 155 2
2.3

B 230 FD

 1 08/1994-07/1995 2316 85 116 2
2.3

B 230 FB

 1 08/1994-10/1998 2316 96 131 2
2.3 1 10/1994-05/1997 2316 113 154 1
2.3 ti

B 230 FK

 1 01/1995-10/1998 2316 99 135 2
2.3 Turbo

B 230 FT

 1 08/1994-10/1998 2316 121 165 2
2.3 Turbo

B 230 FT

 1 01/1995-12/1998 2316 126 171 2
960 (964) Saloon 08/1990-07/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 200 F

 1 09/1990-09/1993 1986 82 111 2
2.0

B 204 E

 1 09/1990-08/1993 1986 103 140 2
2.0

B 204 FT

 1 08/1990-09/1993 1986 140 190 2
2.8 GL

B 280 F

 1 09/1990-05/1992 2849 108 147 2
2.8 GL 1 09/1990-05/1992 2849 115 156 1
2.9

B 6304 F

B 6304 FS

B 6304 GS

 1 08/1990-07/1994 2922 150 204 2
2.4 TD Interc.

D 24 TIC

 2 09/1991-07/1994 2383 85 115 2
960 Kombi (965) Estate 08/1990-07/1994
Vehicle Engine Fuel Date CC KW CV Traction
2.0

B 204 E

 1 09/1990-08/1993 1986 103 140 2
2.0

B 204 FT

 1 08/1990-09/1993 1986 140 190 2
2.3 Turbo

B 230 FT

 1 09/1990-08/1993 2316 121 165 2
2.8

B 280 F

 1 09/1990-05/1992 2849 108 147 2
2.8 1 09/1990-05/1992 2849 115 156 1
2.9

B 6304 F

B 6304 S

 1 08/1990-07/1994 2922 150 204 2
2.4 TD Interc.

D 24 TIC

 2 09/1991-07/1994 2383 85 115 2
2.4 TDi

D 24 TIC

 2 09/1990-08/1993 2383 90 122 2
