Product 78BD6744-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073193605
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6744-2
Weight (gr.): 12800

Measures: Ø260x26x36.5
: Brake Disc Type: Vented; Minimum thickness [mm]: 24; Hole Arrangement/Number: 6; Bolt Hole Circle Ø [mm]: 103; Wheel Hub Diameter [mm]: 81

Reference applications

Maker	Cross reference
BREMBO	09.6744.10
TEXTAR	92074700

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.2 TD	QD32	2	10/1997-08/2006	3153	76	103	2

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.5 TD	2	05/1992-10/1995	2494	61	83	2
2.7 TD	2	10/1993-10/1995	2664	91	124	2
3.2 D	2	10/1993-10/1997	3246	70	95	2
3.2 TD	2	05/1992-10/1994	3166	106	144	2

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.4	1	05/1992-10/1995	2389	88	120	1
2.7	1	05/1992-10/1995	2689	108	147	2
3.0	1	05/1992-10/1995	2960	92	125	1
3.0	1	10/1994-10/1997	2960	118	160	1
2.5 TD	2	05/1992-10/1995	2494	61	83	2
2.7 TD	2	10/1993-10/1995	2664	91	124	2
3.2 D	2	10/1993-10/1997	3246	70	95	2
3.2 TD	2	05/1992-10/1994	3166	106	144	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4	KA24DE	1	09/1997-09/2004	2389	110	150	2
3.0	VG30E	1	05/2000-	2960	120	163	2
3.3		1	09/2000-12/2004	3275	157	214	2
2.5 D		2	01/2008-	2488	98	133	2
2.5 TD	TD25	2	02/1998-10/2001	2494	59	80	2
2.5 TD		2	02/1998-10/2001	2494	62	84	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	09/2013-	2389	105	143	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 dCi	YD25DDTI	2	04/2008-	2488	98	133	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 dCi		2	09/2013-	2488	98	133	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4	Z24	1	01/1992-12/1996	2389	79	107	2
2.4 4WD	Z24	1	01/1988-12/1996	2389	79	107	3
2.4 i 12V	KA24E	1	04/1992-02/1998	2389	91	124	2
2.4 i 12V 4WD	KA24E	1	04/1992-02/1998	2389	93	126	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0		1	01/1997-08/2001	1998	92	125	2
2.4		1	01/1997-04/2005	2389	76	103	2
2.4	Z24 Z24S	1	01/1997-12/2002	2389	79	107	2
2.4		1	02/1998-10/2001	2389	87	118	2
2.4		1	03/1997-04/2005	2389	93	126	2
2.4		1	11/2001-04/2005	2389	98	133	2
2.4	KA24DE	1	01/2003-	2389	110	150	2
2.4 4WD		1	01/1997-12/2002	2389	79	107	3
2.4 i	KA24E	1	02/1998-04/2005	2389	88	120	2
2.4 i 4WD	KA24E	1	02/1998-04/2005	2389	88	120	3
2.5 D	TD25	2	02/1998-04/2005	2494	61	83	2
2.5 D 4WD	TD25	2	02/1998-04/2005	2494	61	83	3
2.5 DI	YD25DDTI	2	03/2002-12/2010	2488	98	133	2
2.5 TD		2	05/1998-10/2001	2494	76	103	2
2.5 TD 4WD	TD25TI	2	05/1998-04/2005	2494	76	103	3
2.7 D	TD27	2	02/1998-04/2005	2664	66	90	2
2.7 TD	TD27T	2	01/1997-10/2001	2664	73	99	2
2.7 TD 4WD	TD27T	2	01/1997-10/2001	2664	73	99	3
3.2 D 4WD	QD32	2	12/1998-04/2005	3153	76	103	3
3.2 TD		2	01/1997-10/2001	3153	76	103	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	Z20S	1	06/1986-09/1994	1952	65	88	2
2.0	Z20S	1	01/1992-09/1993	1952	66	90	2
2.4		1	10/1993-05/1997	2389	72	98	1
2.4 i	Z24I	1	05/1989-09/1993	2389	74	101	2
3.0		1	02/1992-04/1997	2960	95	129	1
2.5 D	TD25	2	05/1989-10/1996	2494	59	80	2
2.7 D	TD27	2	03/1987-09/1993	2664	62	84	2
2.7 TD		2	10/1994-04/1997	2664	58	79	2
3.2 TD		2	02/1992-04/1997	3246	81	110	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	Z20	1	05/1987-05/1997	1952	64	87	2
2.0	Z20S	1	06/1986-09/1994	1952	65	88	2
2.0	Z20S	1	02/1987-07/1994	1952	66	90	2
2.4	Z24I	1	10/1993-05/1997	2389	72	98	2
2.4		1	02/1992-04/1997	2389	74	101	1
3.0		1	02/1992-04/1997	2960	95	129	1
2.0 D		2	02/1992-09/1994	1952	49	67	2
2.3 D	TD23	2	01/1988-05/1997	2289	51	69	2
2.5 D	TD25	2	12/1988-05/1997	2494	59	80	2
2.7 D		2	03/1987-09/1993	2664	62	84	2
2.7 TD		2	10/1994-04/1997	2664	58	79	2
3.2 D		2	02/1992-04/1997	3246	70	95	2
3.2 TD		2	02/1992-04/1997	3246	81	110	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8		1	10/1995-08/2000	1789	66	90	1
2.0		1	10/2000-09/2002	1998	88	120	2
2.4		1	05/2001-11/2010	2389	103	140	2
3.0		1	10/1995-08/2000	2960	120	163	1
2.7 TD	TD27TI	2	10/1995-08/2000	2664	92	125	2
3.0 Di	ZD30DD	2	10/2000-11/2010	2953	77	105	2
3.0 Di		2	05/2002-11/2010	2953	89	121	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8		1	10/1995-08/2000	1789	66	90	2
2.7 TD	TD27ETI	2	10/1995-08/2000	2664	92	125	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	04/1999-10/2005	2389	110	150	1
