Product 78BD6848-1 - Web Catalogo

Product 78BD6848-1

Description: Brake disc
Axe: Front
No. of Pieces: 1
Barcode: 8424073148162
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD6848-1
Weight (gr.): 10038

Measures: Ø306x28x78
: Brake Disc Type: Vented; Minimum thickness [mm]: 25; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 130; Wheel Hub Diameter [mm]: 90

Reference applications

Brand	OE Reference
NISSAN	40206-00QAD
OPEL	44 03 038
OPEL	45 01 421
RENAULT	77 00 314 064
VAUXHALL	91 110 38
VAUXHALL	91 61 721

Maker	Cross reference
ATE	24.0128-0129.1
BENDIX ANTIGUO	562190B
BOSCH	0 986 479 001
BREMBO	09.9080.10
LETEC	LBR723V
ROAD HOUSE	6643.10
SANLI	SL31976
TRW	DF4249S

NISSAN

INTERSTAR (X70) Bus 04/2002-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
dCi 100	G9U 720 G9U 754	2	11/2003-03/2006	2463	73	99	1
dCi 100	G9U 650	2	04/2006-03/2011	2463	74	101	1
dCi 115	G9U 724 G9U 750 G9U 754	2	04/2002-08/2006	2463	84	115	1
dCi 120	G9U 650	2	09/2006-03/2011	2463	88	120	1
dCi 140	ZD30	2	11/2003-	2953	100	136	1
dCi 150	G9U 632	2	09/2006-03/2011	2463	107	145	1
dCi 80	F9Q 772 F9Q 774	2	04/2002-08/2006	1870	60	82	1
dCI 90	G9T 722	2	07/2002-08/2006	2188	66	90	1

INTERSTAR (X70) Van 04/2002-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
dCi 100	G9U 720 G9U 754	2	11/2003-03/2006	2463	73	99	1
dCi 100	G9U 720 G9U 754	2	04/2006-	2463	74	101	1
dCi 115	G9U 720 G9U 724 G9U 750 G9U 754	2	04/2002-	2463	84	115	1
dCi 120	G9U 650	2	09/2006-	2463	88	120	1
dCi 140	ZD30	2	11/2003-	2953	100	136	1
dCi 150	G9U 632	2	09/2006-	2463	107	145	1
dCi 80	F9Q 772 F9Q 774	2	04/2002-08/2006	1870	60	82	1
dCI 90	G9T 722	2	07/2002-	2188	66	90	1

INTERSTAR (X70) Platform/Chassis 08/2003-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
dCi 100	G9U 720 G9U 754	2	02/2004-	2463	73	99	1
dCi 115	G9U 720 G9U 724 G9U 750 G9U 754	2	08/2003-	2463	84	115	1
dCi 120	G9U 650	2	08/2006-	2463	88	120	1
dCi 140	ZD30	2	11/2003-	2953	100	136	1
dCi 150	G9U 632	2	08/2006-	2463	107	145	1

OPEL

MOVANO (X70) Platform/Chassis 07/1998-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 DTI (ED, HD, UD0, UD4)	G9T 720 G9T 722 G9T 750	2	09/2000-	2188	66	90	1
2.5 CDTI (ED, HD, UD0, UD4)	G9U 650	2	08/2006-	2464	74	101	1
2.5 CDTI (ED, HD, UD0, UD4)	G9U 632 G9U 650	2	08/2006-	2464	88	120	1
2.5 CDTI (ED, HD, UD0, UD4)	G9U 632 G9U 650	2	08/2006-	2464	107	146	1
2.5 DTI (ED, HD, UD0, UD4)	G9U 754	2	10/2003-	2463	73	99	1
2.5 DTI (ED, HD, UD0, UD4)	G9U 720 G9U 724 G9U 750 G9U 754	2	10/2001-	2463	84	115	1
2.8 DTI (ED, HD, UD0, UD4)	S9W 700 S9W 702	2	07/1998-10/2001	2799	84	114	1
3.0 DTI (ED, HD, UD0, UD4)	ZD3 200 ZD3 202	2	10/2003-	2953	100	136	1

MOVANO (X70) Bus 07/1998-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 DTI (JD)	F9Q 770	2	09/2000-10/2001	1870	59	80	1
1.9 DTI (JD)	F9Q 772 F9Q 774	2	10/2001-	1870	60	82	1
2.2 DTI (JD)	G9T 720 G9T 722 G9T 750	2	09/2000-	2188	66	90	1
2.5 CDTI (JD)	G9U 650	2	09/2007-	2464	74	101	1
2.5 CDTI (JD)	G9U 632 G9U 650	2	08/2006-	2464	88	120	1
2.5 CDTI (JD)	G9U 632 G9U 650	2	08/2006-	2464	107	146	1
2.5 DTI (JD)		2	10/2003-08/2006	2463	73	99	1
2.5 DTI (JD)	G9U 720 G9U 724 G9U 750 G9U 754	2	10/2001-	2463	84	115	1
2.8 DTI (JD)	S9W 700 S9W 702	2	07/1998-10/2001	2799	84	114	1
3.0 DTi (JD)	ZD3 200 ZD3 202	2	10/2003-	2953	100	136	1

MOVANO (X70) Van 01/1999-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 DTI (FD)	F9Q 770	2	09/2000-10/2001	1870	59	80	1
1.9 DTI (FD)	F9Q 772 F9Q 774	2	10/2001-	1870	60	82	1
2.2 DTI (FD)	G9T 720 G9T 722 G9T 750	2	09/2000-	2188	66	90	1
2.5 CDTI (FD)	G9U 650	2	10/2003-	2464	74	101	1
2.5 CDTI (FD)	G9U 632 G9U 650	2	10/2003-	2464	88	120	1
2.5 CDTI (FD)	G9U 632 G9U 650	2	10/2003-	2464	107	146	1
2.5 DTI (FD)	G9U 754	2	10/2003-	2463	73	99	1
2.5 DTI (FD)	G9U 720 G9U 724 G9U 754	2	10/2001-	2463	84	115	1
2.8 DTI (FD)	S9W 700 S9W 702	2	01/1999-10/2001	2799	84	114	1
3.0 DTI (FD)	ZD3 200 ZD3 202	2	10/2003-	2953	100	136	1

MOVANO (X70) Dump Truck 01/1999-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 DTI (ED, HD, UD0, UD4)	G9T 720 G9T 722 G9T 750	2	09/2000-	2188	66	90	1
2.5 CDTI (ED, HD, UD0, UD4)	G9U 650	2	08/2006-	2464	74	101	1
2.5 CDTI (ED, HD, UD0, UD4)	G9U 632 G9U 650	2	08/2006-	2464	88	120	1
2.5 CDTI (ED, HD, UD0, UD4)	G9U 632 G9U 650	2	08/2006-	2464	107	146	1
2.5 DTI (ED, HD, UD0, UD4)	G9U 754	2	10/2003-	2463	73	99	1
2.8 DTI (ED, HD, UD0, UD4)	S9W 700 S9W 702	2	01/1999-10/2001	2799	84	114	1

RENAULT

MASTER II (FD) Van 12/1997-12/2013

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 dCi 80	F9Q 772 F9Q 774	2	11/2001-10/2006	1870	60	82	1
1.9 dTI	F9Q 770	2	12/1997-03/2002	1870	59	80	1
2.2 dCI 90	G9T 720 G9T 722 G9T 750	2	12/1997-10/2006	2188	66	90	1
2.5 D	S8U 770 S8U 772	2	07/1998-01/2001	2499	59	80	1
2.5 dCi	G9U 650	2	08/2006-01/2010	2463	74	101	1
2.5 dCi	G9U 650	2	08/2006-01/2010	2463	88	120	1
2.5 dCi	G9U 632	2	08/2006-01/2010	2463	107	146	1
2.5 dCi 100 (FD0U, FD0V)	G9U 754	2	10/2003-03/2010	2463	73	99	1
2.5 dCi 120	G9U 720 G9U 724 G9U 750 G9U 754	2	10/2001-09/2007	2463	84	115	1
2.8 D		2	01/2002-09/2004	2799	63	86	1
2.8 dTI	S9W 702	2	07/1998-10/2001	2799	84	114	1
3.0 dCi 140 (HD0S, FD0S, HD1S)	ZD3 202	2	10/2003-10/2006	2953	100	136	1

MASTER II (ED/HD/UD) Platform/Chassis 12/1997-03/2013

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 dCI 90	G9T 720 G9T 722 G9T 750	2	12/1997-09/2006	2188	66	90	1
2.5 D	S8U 770 S8U 772	2	07/1998-01/2001	2499	59	80	1
2.5 dCi	G9U 650	2	08/2006-01/2010	2463	74	101	1
2.5 dCi	G9U 650	2	08/2006-01/2011	2463	88	120	1
2.5 dCi	G9U 632	2	08/2006-01/2010	2463	107	146	1
2.5 dCi 100 (ED4V, ED8V)	G9U 754	2	10/2002-05/2010	2463	73	99	1
2.5 dCi 120	G9U 720 G9U 724 G9U 750 G9U 754	2	10/2001-05/2010	2463	84	115	1
2.8 dTI	S9W 702	2	07/1998-10/2001	2799	84	114	1
3.0 dCi 140 (ED0S, UD0S)	ZD3 200 ZD3 202	2	10/2003-01/2010	2953	100	136	1

MASTER II (JD) Bus 12/1997-01/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 dCi 80	F9Q 772 F9Q 774	2	11/2001-10/2006	1870	60	82	1
1.9 dTI	F9Q 770	2	12/1997-03/2002	1870	59	80	1
2.2 dCI 90	G9T 720 G9T 722 G9T 750	2	12/1997-09/2006	2188	66	90	1
2.5 D	S8U 770 S8U 772	2	07/1998-01/2001	2499	59	80	1
2.5 dCi	G9U 650	2	09/2006-01/2010	2463	74	101	1
2.5 dCi	G9U 650	2	06/2006-01/2010	2463	88	120	1
2.5 dCi	G9U 632	2	08/2006-01/2010	2463	107	146	1
2.5 dCi 100 (JDCV)	G9U 754	2	10/2003-01/2010	2463	73	99	1
2.5 dCi 120	G9U 720 G9U 750 G9U 754	2	10/2001-12/2006	2463	84	115	1
2.8 dTI	S9W 702	2	07/1998-10/2001	2799	84	114	1
3.0 dCi 140 (JD0T)	ZD3 200 ZD3 202	2	10/2003-09/2006	2953	100	136	1

VAUXHALL

MOVANO Mk I (A) (X70) Van 10/1998-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 DTI (FD)		2	09/2000-10/2001	1870	59	80	1
1.9 DTI (FD)	F9Q 770	2	09/2000-10/2001	1870	59	80	1
1.9 DTI (FD)	F9Q 774	2	10/2001-05/2010	1870	60	82	1
2.2 DTI (FD)	G9T 720 G9T 722 G9T 750	2	09/2000-05/2010	2188	66	90	1
2.5 (FD)	G9U 754	2	11/2003-12/2006	2464	73	99	1
2.5 CDTI (FD)	G9U 650	2	10/2006-12/2010	2463	74	101	1
2.5 CDTI (FD)	G9U 632 G9U 650	2	08/2006-05/2010	2464	88	120	1
2.5 CDTI (FD)	G9U 632	2	08/2006-05/2010	2464	107	146	1
2.5 D (FD)	S8U 770	2	10/1998-09/2000	2499	59	80	1
2.5 DTI (FD)	G9U 720 G9U 724 G9U 750 G9U 754	2	10/2001-05/2010	2463	84	115	1
2.8 TDI (FD)	S9W 702	2	10/1998-10/2001	2799	84	114	1
3.0 DTI (FD)	ZD3 202	2	10/2003-05/2010	2953	100	136	1

MOVANO Mk I (A) (X70) Bus 10/1998-05/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.9 DTI (JD)		2	09/2000-10/2001	1870	59	80	1
1.9 DTI (JD)	F9Q 770	2	09/2000-10/2001	1870	59	80	1
1.9 DTI (JD)	F9Q 774	2	10/2001-05/2010	1870	60	82	1
2.2 DTI (JD)	G9T 720 G9T 722 G9T 750	2	09/2000-05/2010	2188	66	90	1
2.5 CDTI (JD)	G9U 650	2	10/2001-08/2009	2463	74	101	1
2.5 CDTI (JD)	G9U 632 G9U 650	2	02/2003-08/2009	2464	88	120	1
2.5 CDTI (JD)	G9U 632	2	08/2006-05/2010	2464	107	146	1
2.5 DTI (JD)	G9U 720 G9U 724 G9U 750 G9U 754	2	10/2001-08/2009	2463	84	115	1
2.8 DTI (JD)	S9W 702	2	10/1998-10/2001	2799	84	114	1
3.0 DTi (JD)	ZD3 200	2	10/2003-05/2010	2953	100	136	1

MOVANO Mk I (A) (X70) Platform/Chassis 10/1998-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 DTI (UD0)	G9T 720 G9T 722 G9T 750	2	09/2000-05/2010	2188	66	90	1
2.5 CDTI (ED, UD0)	G9U 632 G9U 650	2	08/2006-05/2010	2463	88	120	1
2.5 CDTI (ED, UD0)	G9U 632 G9U 650	2	08/2006-05/2010	2463	107	146	1
2.5 CDTI (UD0, ED)	G9U 650	2	10/2006-12/2010	2463	74	101	1
2.5 CDTI (UD0, ED)	G9U 754	2	11/2003-12/2006	2464	73	99	1
2.5 D (UD0)	S8U 770 S8U 772	2	10/1998-08/2002	2499	59	80	1
2.5 DTI (ED, UD0)	G9U 720 G9U 724 G9U 750 G9U 754	2	01/2001-12/2006	2463	84	115	1
2.8 DTI (UD0, ED, HD)	S9W 702	2	10/1998-10/2001	2799	84	114	1
3.0 DTi (ED)	ZD3 200 ZD3 202	2	10/2003-05/2010	2953	100	136	1
