Product 78BD7019-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073148216
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD7019-2
Weight (gr.): 14300

R90 Homologation: 90R-02C0452/0127
Measures: Ø294x28x46.5
: Brake Disc Type: Vented; Minimum thickness [mm]: 26.4; Hole Arrangement/Number: 6; Bolt Hole Circle Ø [mm]: 139.7; Wheel Hub Diameter [mm]: 94

Reference applications

Brand	OE Reference
MITSUBISHI	46 15A 147
MITSUBISHI	MN 102 276

Maker	Cross reference
BENDIX ANTIGUO	562695BC
BENDIX-ROULUNDS	522085
BOSCH	0 986 479 704
BREMBO	09.A868.10
BREMBO	09.A868.1X
DELPHI LOCKHEED	BG4257
FERODO	DDF1818
LETEC	LBMT026V
MINTEX	MDC1960
ROAD HOUSE	61118.10
SANLI	SL34477
TEXTAR	92180203
TEXTAR	92180205
TRW	DF4920
TRW	DF6735

FIAT

FULLBACK (502_, 503_) Pickup 01/2016-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 (KT0T)	4G64	1	04/2016-	2351	97	132	2
2.4 4x4 (KT0T)	4G64	1	04/2016-	2351	97	132	3
2.4 D (KT0T)	4N15	2	04/2016-	2442	113	154	2
2.4 D 4x4 (KT0T)	4N15	2	04/2016-	2442	110	150	3
2.4 D 4x4 (KT0T)	4N15	2	04/2016-	2442	113	154	3
2.4 D 4x4 (KT0T)	4N15	2	04/2016-	2442	133	181	3
2.5 D 4WD (KT0T)	4D56	2	04/2016-	2477	81	110	3
2.5 D 4x4 (KT0T)	4D56	2	04/2016-	2477	100	136	3

MITSUBISHI

L200 III / COLT-RODEO / STRADA / TRITON (K7_T, K6_T, K5_T) Pickup 01/1996-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 DI-D 4x4 (K74T)		2	01/2004-12/2007	2477	89	121	3

L200 IV / TRITON (KA_T, KB_T) Pickup 01/2004-12/2018

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 (KA5T)		1	11/2005-12/2015	2351	94	128	2
2.4 (KA5T)	4G64 (16V)	1	05/2007-12/2015	2351	97	132	2
2.4 4WD (KB5T)	4G64 (16V)	1	09/2009-12/2012	2351	94	128	3
2.4 4WD (KB5T)	4G64 (16V)	1	08/2011-12/2015	2351	97	132	3
3.5 (KA9T)		1	07/2006-12/2011	3497	135	184	2
3.5 4WD (KB9T)	6G74 (SOHC 24V)	1	11/2005-12/2015	3497	132	180	3
3.5 4WD (KB9T)		1	07/2006-12/2010	3497	135	184	3
3.5 4WD (KB9T)		1	08/2011-12/2015	3497	137	186	3
3.5 4WD (KB9T)	6G74 (SOHC 24V)	1	05/2007-12/2015	3497	147	200	3
3.5 Flexfuel		1	12/2012-	3497	182	247	1
2.4 CNG (KA5T)		16	04/2010-12/2015	2351	94	128	2
2.4 Flex (KA5T)	4G64 (16V)	19	11/2013-04/2018	2351	104	142	2
3.5 Flex 4WD (KB9T)	6G74 (SOHC 24V)	19	09/2009-12/2015	3497	147	200	3
3.5 Flexfuel 4WD (KB9T)	6G74 (SOHC 24V)	19	08/2009-12/2017	3497	151	205	3
2.5 D		2	08/2011-12/2015	2477	55	75	2
2.5 D (KA4T)	4D56-TD	2	08/2011-12/2015	2477	66	90	2
2.5 D 4WD		2	08/2011-12/2015	2477	55	75	3
2.5 DI-D		2	04/2010-	2477	104	141	2
2.5 DI-D (KA4T)	4D56 (16V) 4D56-HP	2	04/2010-12/2015	2477	94	128	2
2.5 DI-D (KA4T)	4D56-HP	2	11/2005-12/2015	2477	100	136	2
2.5 DI-D (KA4T)		2	04/2010-12/2015	2477	103	140	2
2.5 DI-D (KA4T)	4D56-HP	2	08/2007-12/2015	2477	123	167	2
2.5 DI-D (KA4T)		2	01/2010-12/2015	2477	131	178	2
2.5 DI-D 16V 4WD	4D56 (16V)	2	04/2007-12/2015	2477	98	133	3
2.5 DI-D 4WD (KB4T)	4D56 (16V)	2	04/2010-12/2015	2477	94	128	3
2.5 DI-D 4WD (KB4T)	4D56-HP	2	11/2005-12/2015	2477	100	136	3
2.5 DI-D 4WD (KB4T)		2	04/2010-12/2015	2477	103	140	3
2.5 DI-D 4WD (KB4T)	4D56-HP	2	10/2007-12/2015	2477	123	167	3
2.5 DI-D 4WD (KB4T)	4D56-HP	2	04/2010-12/2015	2477	131	178	3
2.5 TDiC		2	11/2005-	2477	98	133	2
2.8 D 4WD (KB7T)		2	05/2005-12/2015	2835	71	97	3
3.2 DI-D 4WD (KB8T)		2	07/2006-12/2009	3200	118	160	3
3.2 DI-D 4WD (KB8T)		2	01/2007-12/2015	3200	121	165	3
3.2 DI-D 4WD (KB8T)	4M41	2	01/2012-12/2016	3200	125	170	3
3.2 DI-D 4WD (KB8T)	4M41	2	11/2013-12/2018	3200	132	180	3

L200 IV / TRITON (KA_T, KB_T) Platform/Chassis 03/2006-12/2015

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	01/2009-12/2015	2351	94	128	1
2.4 CNG		1	12/2009-12/2015	2351	94	128	1
2.5 DI-D (KA4T)	4D56 (16V)	2	08/2007-12/2015	2477	94	128	2
2.5 DI-D (KA4T)		2	01/2008-12/2015	2477	100	136	2
2.5 DI-D 4WD (KB4T)	4D56-HP	2	09/2009-12/2015	2477	131	178	3

L200 V / TRITON (KJ_, KK_, KL_) Pickup 02/2014-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 (KK4T)		1	11/2014-	2351	94	128	2
2.4 (KK4T)		1	11/2014-	2351	96	131	2
2.4 2WD	4G64 (16V)	1	11/2014-08/2020	2351	94	128	2
2.4 4WD	4G64 (16V)	1	11/2014-	2351	97	132	3
2.2 DI-D	4N14	2	07/2019-	2268	110	150	2
2.2 DI-D 4WD	4N14	2	07/2019-	2268	110	150	3
2.4 DI-D		2	07/2019-	2442	100	136	2
2.4 DI-D		2	08/2015-	2442	112	152	2
2.4 DI-D (KJ0T)	4N15	2	09/2015-	2442	113	154	2
2.4 DI-D (KK1T)	4N15	2	01/2015-	2442	133	181	2
2.4 DI-D 4WD		2	07/2019-	2442	100	136	3
2.4 DI-D 4WD		2	09/2015-	2442	112	152	3
2.4 DI-D 4WD (KJ0T)	4N15	2	09/2015-	2442	113	154	3
2.4 DI-D 4WD (KL1T, KL2T)	4N15	2	09/2015-	2442	140	190	3
2.4 DI-D 4WD (KL1T)	4N15	2	11/2014-	2442	133	181	3
2.5 DI-D	4D56 (16V)	2	01/2016-	2477	81	110	2
2.5 DI-D	4D56 (16V)	2	01/2015-	2477	100	136	2
2.5 DI-D (KJ3T)	4D56 (16V)	2	11/2014-	2477	94	128	2
2.5 DI-D (KK3T)	4D56 (16V)	2	11/2014-	2477	131	178	2
2.5 DI-D 4WD	4D56 (16V)	2	11/2014-	2477	81	110	3
2.5 DI-D 4WD	4D56 (16V)	2	11/2014-	2477	100	136	3
2.5 DI-D 4WD		2	11/2014-	2477	131	178	3
3.2 DI-D 4WD	4M41	2	05/2015-	3200	132	180	3

L200 V / TRITON / STRADA (MQ) Platform/Chassis 01/2015-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 D (KK1T)		2	01/2015-	2442	133	181	2
2.4 D 4WD (KL1T)		2	01/2015-	2442	133	181	3

PAJERO SPORT / G-WAGON / MONTERO SPORT / CHALLENGER (K7_, K9_) Closed Off-Road Vehicle 07/1996-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.2 TDi		2	11/1998-	3200	121	165	2

PAJERO SPORT II / PAJERO DAKAR / CHALLENGER / MONTERO SPORT / NATIVA (KH_, KG_) Closed Off-Road Vehicle 01/2008-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.0 4WD	6B31	1	09/2008-	2998	162	220	3
3.0 Mivec (KG6W)	6B31	1	01/2012-12/2015	2998	161	219	2
3.5	6G74 (SOHC 24V)	1	01/2010-	3497	137	186	3
3.5 V6 24V	6G74 (SOHC 24V)	1	09/2008-	3497	153	208	3
3.5 Flex 4WD		19	06/2011-12/2018	3497	151	205	3
2.5 DI-D (KH4W)	4D56-HP	2	07/2008-12/2015	2477	131	178	2
2.5 DI-D 4WD (KH4W)	4D56-HP	2	07/2008-	2477	131	178	3
3.2 DI-D 4WD	4M41	2	07/2008-	3200	118	160	3
3.2 DI-D 4WD	4M41	2	07/2008-	3200	121	165	3

RAM

1200 (E_) Pickup 03/2017-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4 4x4 (E80)		1	03/2017-	2351	97	132	3
2.5 D 4x4 (E85)		2	03/2017-	2477	100	136	3
