Product 78BD7036-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073193612
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD7036-2
- Weight (gr.)
- 10204
- Measures
- Ø256x24x45.6
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
21.5 -
Hole Arrangement/Number:
4 -
Bolt Hole Circle Ø [mm]:
114.3 -
Wheel Hub Diameter [mm]:
69
| Brand | OE Reference |
|---|---|
| MITSUBISHI | 4605A068 |
| MITSUBISHI | M4605A068 |
| SMART | 4544200001 |
| Maker | Cross reference |
|---|---|
| BREMBO | 09.9991.10 |
| TEXTAR | 92134803 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.1 (Z31A, Z32A) |
3A91 |
1 | 10/2004-06/2012 | 1124 | 55 | 75 | 1 |
| 1.3 (Z21A) |
4A90 |
1 | 10/2004-06/2012 | 1332 | 68 | 92 | 1 |
| 1.3 (Z21A) |
4A90 |
1 | 06/2004-06/2012 | 1332 | 70 | 95 | 1 |
| 1.3 4WD (Z22A) | 1 | 10/2004-06/2012 | 1332 | 67 | 91 | 3 | |
| 1.5 (Z23) | 1 | 07/2006-06/2012 | 1499 | 77 | 105 | 1 | |
| 1.5 (Z23A) |
4A91 |
1 | 06/2004-06/2012 | 1499 | 80 | 109 | 1 |
| 1.5 (Z27) | 1 | 09/2004-02/2006 | 1468 | 72 | 98 | 1 | |
| 1.5 4WD (Z24A) | 1 | 07/2006-06/2012 | 1499 | 77 | 105 | 3 | |
| 1.1 LPG |
3A91 |
18 | 10/2004-06/2012 | 1124 | 55 | 75 | 1 |
| 1.3 LPG (Z33A) |
4A90 |
18 | 06/2004-06/2012 | 1332 | 70 | 95 | 1 |
| 1.3 Flexfuel (Z35A) | 19 | 10/2008-06/2012 | 1332 | 70 | 95 | 1 | |
| 1.5 DI-D (Z38A) |
OM 639.939 |
2 | 08/2004-06/2012 | 1493 | 50 | 68 | 1 |
| 1.5 DI-D (Z39A) |
OM 639.939 |
2 | 08/2004-06/2012 | 1493 | 70 | 95 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 DiD | 2 | 08/2004-06/2012 | 1493 | 70 | 95 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 (Z36A) |
4A91 |
1 | 05/2006-07/2009 | 1499 | 80 | 109 | 1 |
| 1.5 Turbo (Z37A) |
4G15T |
1 | 05/2006-07/2009 | 1468 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.1 (454.030) |
M 134.910 |
1 | 01/2004-06/2006 | 1124 | 55 | 75 | 1 |
| 1.1 (454.033) |
M 134.911 |
1 | 02/2005-06/2006 | 1124 | 47 | 64 | 1 |
| 1.3 (454.031) |
M 135.930 |
1 | 01/2004-06/2006 | 1332 | 70 | 95 | 1 |
| 1.5 (454.032) |
M 135.950 |
1 | 01/2004-06/2006 | 1499 | 80 | 109 | 1 |
| 1.5 (454.032) |
M 135.950 |
1 | 01/2004-06/2006 | 1499 | 90 | 122 | 1 |
| 1.5 BRABUS (454.034) |
M 122.950 |
1 | 05/2005-06/2006 | 1468 | 130 | 177 | 1 |
| 1.5 CDI (454.000) |
OM 639.939 |
2 | 09/2004-06/2006 | 1493 | 50 | 68 | 1 |
| 1.5 CDI (454.001) |
OM 639.939 |
2 | 09/2004-06/2006 | 1493 | 70 | 95 | 1 |
