Product 78BD7114-2
- Description
- Brake disc
- Axe
- Rear
- No. of Pieces
- 2
- Barcode
-
8424073148285
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD7114-2
- Weight (gr.)
- 15740
- R90 Homologation
-
90R-02C0438/1589
- Measures
- Ø332x18x74.5
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
16 -
Hole Arrangement/Number:
6 -
Bolt Hole Circle Ø [mm]:
139,7 -
Wheel Hub Diameter [mm]:
94
| Brand | OE Reference |
|---|---|
| MITSUBISHI | 46 15A 037 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0118-0146.1 |
| DELPHI LOCKHEED | BG4263 |
| ROAD HOUSE | 61099.10 |
| TRW | DF4944S |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.8 A las 4 ruedas (V67W) | 1 | 09/2006- | 3828 | 184 | 250 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.0 4WD |
6G72 (SOHC 24V) |
1 | 08/2014- | 2972 | 128 | 174 | 3 |
| 3.0 4WD | 1 | 01/2007- | 2972 | 135 | 184 | 3 | |
| 3.0 4WD (V83W, V93W) |
6G72 (SOHC 24V) |
1 | 02/2007- | 2972 | 131 | 178 | 3 |
| 3.2 DI-D | 1 | 01/2009- | 3200 | 153 | 208 | 1 | |
| 3.5 V6 4WD | 1 | 09/2009- | 3497 | 139 | 189 | 3 | |
| 3.8 i 4WD (V97W, V87W) |
6G75 |
1 | 01/2009- | 3828 | 175 | 238 | 3 |
| 3.8 V6 (V87W, V97W) |
6G75 |
1 | 02/2007- | 3828 | 184 | 250 | 3 |
| 3.8 V6 (V87W) |
6G75 |
1 | 10/2006- | 3828 | 182 | 248 | 3 |
| 3.2 4WD (V98W) |
4M41 |
2 | 10/2016- | 3200 | 141 | 192 | 3 |
| 3.2 DI-D |
4M41 |
2 | 02/2007- | 3200 | 123 | 167 | 3 |
| 3.2 DI-D (V88W, V98W) |
4M41 |
2 | 02/2007- | 3200 | 118 | 160 | 3 |
| 3.2 DI-D (V88W, V98W) |
4M41 |
2 | 02/2007- | 3200 | 125 | 170 | 3 |
| 3.2 DI-D 4WD |
4M41 |
2 | 11/2008- | 3200 | 121 | 165 | 3 |
| 3.2 DI-D 4WD (V98W, V88W) |
4M41 |
2 | 02/2007- | 3200 | 140 | 190 | 3 |
| 3.2 DI-D 4WD (V98W, V88W) |
4M41 |
2 | 01/2009- | 3200 | 147 | 200 | 3 |
| 3.2 DI-D 4WD (V98W) | 2 | 01/2012- | 3200 | 149 | 203 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.2 DI-D |
4M41 |
2 | 11/2006- | 3200 | 118 | 160 | 3 |
| 3.2 DI-D 4WD (V88W, V98W) |
4M41 |
2 | 02/2007- | 3200 | 140 | 190 | 3 |
| 3.2 TD 4WD (V88V, V98V) |
4M41 |
2 | 01/2010- | 3200 | 147 | 200 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.2 DI-D 4WD | 2 | 11/2013-12/2018 | 3200 | 132 | 180 | 3 |
