Product 78BD7305-2 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073193629
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD7305-2
Weight (gr.): 14712

Measures: Ø302x22x50.9
: Brake Disc Type: Vented; Minimum thickness [mm]: 20; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 108; Wheel Hub Diameter [mm]: 63.6

Reference applications

Maker	Cross reference
BREMBO	09.B026.10
TEXTAR	92196403

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 T	B 4204 T6	1	12/2009-12/2012	1999	149	203	1
2.0 T5 Flexfuel		1	09/2014-	1969	162	220	1
3.2	B 6324 S4	1	09/2011-12/2014	3192	171	233	1
3.2		1	09/2009-12/2010	3192	175	238	1
3.2	B 6324 S5	1	09/2011-12/2014	3192	179	243	1
3.2 AWD	B 6324 S	1	07/2009-12/2010	3192	175	238	3
3.2 AWD	B 6324 S5	1	03/2010-12/2015	3192	179	243	3
T5	B 4204 T11 B 4204 T41	1	10/2013-02/2017	1969	180	245	1
T5	B 4204 T7	1	09/2010-02/2017	1999	177	241	1
T5 AWD	B 4204 T11 B 4204 T41	1	10/2015-02/2017	1969	180	245	3
T5 AWD	B 5254 T12	1	04/2014-02/2017	2497	183	249	3
T5 AWD	B 5254 T12	1	04/2014-02/2017	2497	187	254	3
T6	B 4204 T9	1	10/2013-02/2017	1969	225	306	1
T6 AWD	B 4204 T9	1	10/2013-12/2017	1969	225	306	3
T6 AWD	B 6304 T2	1	05/2008-12/2010	2953	210	286	3
T6 AWD	B 6304 T4	1	03/2010-02/2017	2953	224	304	3
T6 AWD	B 6304 T3 B 6304 T4	1	04/2014-12/2015	2953	242	329	3
2.4 D	D 5244 T14	2	04/2009-12/2010	2400	129	175	1
2.4 D / D3 / D4 AWD	D 5244 T16 D 5244 T17 D 5244 T5	2	05/2008-02/2017	2400	120	163	3
D3	D 4204 T4	2	03/2015-04/2017	1969	110	150	1
D3	D 5204 T7	2	04/2012-12/2015	1984	100	136	1
D3 / D4	D 5204 T2 D 5204 T3	2	03/2010-12/2014	1984	120	163	1
D4	D 4204 T5	2	10/2013-12/2015	1969	133	181	1
D4	D 4204 T14	2	03/2015-02/2017	1969	140	190	1
D4 AWD	D 5244 T12	2	10/2013-12/2015	2400	133	181	3
D4 AWD	D 5244 T21	2	03/2015-02/2017	2400	140	190	3
D5	D 5244 T11 D 5244 T15	2	06/2011-02/2017	2400	158	215	1
D5 AWD	D 5244 T4	2	05/2008-12/2009	2400	136	185	3
D5 AWD	D 5244 T10	2	07/2009-06/2011	2400	151	205	3
D5 AWD	D 5244 T11 D 5244 T15	2	04/2011-12/2015	2400	158	215	3
D5 AWD	D 5244 T20 D 5244 T22	2	03/2015-02/2017	2400	162	220	3
D5 AWD	D 5244 T23	2	04/2014-12/2015	2400	169	230	3

Vehicle	Fuel	Date	CC	KW	CV	Traction
D3	2	09/2013-12/2015	1984	100	136	1
D4	2	09/2013-02/2017	1984	120	163	1
D4 AWD	2	09/2013-02/2017	2400	120	163	3
D5 AWD	2	09/2013-02/2017	2400	158	215	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
D5 AWD	D 5244 T11 D 5244 T15	2	04/2011-12/2015	2400	158	215	3

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.0 T5	1	11/2014-	1969	180	245	1
2.0 T5	1	11/2014-	1984	157	214	1
2.5 T6	1	11/2014-	2497	187	254	1
