Product 78BD7476-2 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073148469
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD7476-2
Weight (gr.): 9896

R90 Homologation: 90R-02C0453/0106
Measures: Ø286x10x69.1
: Brake Disc Type: solid; Minimum thickness [mm]: 8; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 110; Wheel Hub Diameter [mm]: 65.5

Reference applications

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5	A151	1	11/2017-	1499	85	116	1
1.5	A151-R1	1	07/2019-	1499	110	150	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 T	B205E	1	09/1997-12/2009	1985	110	150	1
2.0 T	B205L	1	07/2000-12/2009	1985	136	185	1
2.0 Turbo SE	B205E	1	10/1998-07/2000	1985	141	192	1
2.3 T	B235E	1	09/1997-12/2003	2290	125	170	1
2.3 T	B235E	1	01/2001-12/2009	2290	136	185	1
2.3 Turbo	B235E	1	04/2008-12/2009	2290	134	182	1
2.3 Turbo	B235L	1	07/2003-12/2009	2290	162	220	1
2.3 Turbo	B235R	1	10/1999-09/2001	2290	169	230	1
2.3 Turbo	B235R	1	09/2001-12/2009	2290	184	250	1
2.3 Turbo	B235R	1	04/2008-12/2009	2290	188	256	1
2.3 Turbo	B235R	1	11/2005-12/2009	2290	191	260	1
2.3 Turbo	B235R	1	06/2003-08/2005	2290	224	305	1
3.0 V6t	B308E	1	01/1998-08/2005	2962	147	200	1
2.0 t Biopower	B205E	19	01/2005-12/2009	1985	110	150	1
2.0 t Biopower	B205E	19	09/2005-12/2009	1985	132	179	1
2.3 t BioPower	B235E	19	01/2007-12/2009	2290	136	185	1
2.3 t BioPower	B235R	19	11/2006-12/2009	2290	152	207	1
1.9 TiD	Z 19 DTH	2	01/2006-12/2009	1910	110	150	1
2.2 TiD	D223L	2	03/2002-12/2009	2171	88	120	1
3.0 TiD	D308L	2	07/2001-08/2005	2958	130	177	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 T	B205E	1	10/1998-12/2009	1985	110	150	1
2.0 T	B205L	1	07/2000-07/2001	1985	136	185	1
2.0 T	B205E	1	10/1998-07/2000	1985	141	192	1
2.3 T	B235E	1	10/1998-12/2009	2290	125	170	1
2.3 T	B235E	1	01/2001-12/2009	2290	136	185	1
2.3 Turbo	B235L	1	07/2003-12/2009	2290	162	220	1
2.3 Turbo	B235R	1	10/1999-09/2001	2290	169	230	1
2.3 Turbo	B235R	1	09/2001-12/2009	2290	184	250	1
2.3 Turbo	B235R	1	01/2006-12/2009	2290	191	260	1
2.3 Turbo	B235R	1	06/2003-08/2005	2290	224	305	1
3.0 V6t	B308E	1	10/1998-08/2005	2962	147	200	1
2.0 t Biopower	B205E	19	01/2006-12/2009	1985	110	150	1
2.0 t Biopower	B205E	19	09/2005-12/2009	1985	132	179	1
2.3 t BioPower	B235E	19	01/2007-12/2009	2290	136	185	1
2.3 t BioPower	B235R	19	11/2006-12/2009	2290	152	207	1
2.3 t BioPower	B235R	19	11/2006-12/2009	2290	154	210	1
1.9 TiD	Z 19 DTH	2	01/2006-12/2009	1910	110	150	1
1.9 TiD	Z 19 DTR	2	01/2007-12/2009	1910	129	175	1
2.2 TiD	D223L	2	03/2002-12/2009	2171	88	120	1
3.0 TiD	D308L	2	07/2001-08/2005	2958	130	177	1
