Product 78BD7823-1 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 1
Barcode: 8424073148605
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD7823-1
Weight (gr.): 5284

R90 Homologation: 90R-02C0559/0109
Measures: Ø240x8x80.5
: Brake Disc Type: solid; Minimum thickness [mm]: 7; Hole Arrangement/Number: 4; Bolt Hole Circle Ø [mm]: 100; Wheel Hub Diameter [mm]: 55

Reference applications

Brand	OE Reference
RENAULT	77 01 207 823

Maker	Cross reference
ATE	24.0108-0114.2
BOSCH	0 986 479 007
BREMBO	08.A141.10
BREMBO	08.A141.17
BREMBO	08.A238.47
LETEC	LBR739S
ROAD HOUSE	6750.00
SANLI	SL27397
TRW	DF4274BS
VALEO	675403

NISSAN

NOTE (E11, NE11) MPV 01/2005-08/2013

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5	HR15DE	1	03/2006-12/2010	1498	80	109	1
1.4 LPG	CR14DE	18	01/2006-08/2013	1386	65	88	1
1.5 dCi	K9K 276	2	09/2010-06/2012	1461	66	90	1

RENAULT

CLIO II / EURO CLIO (BR0/1, CR0/1) Hatchback 01/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V	D4F 764	1	06/2006-08/2010	1149	43	58	1
1.2 16V	D4F 786	1	09/2010-12/2014	1149	76	103	1
1.2 16V (BR02, BR0J, BR11, CR02, CR0J, CR11)	D4F 706 D4F 740 D4F 764	1	06/2005-12/2014	1149	55	75	1
1.2 16V (BR0R, BR1D, BR1L, CR0R)	D4F 740	1	06/2005-12/2014	1149	48	65	1
1.4 16V	K4J 780	1	06/2005-12/2012	1390	72	98	1
1.6		1	09/2005-12/2010	1598	79	107	1
1.6 16V (BR05, BR0B, BR0Y, BR15, BR1J, BR1M, BR1Y, CR0B,...	K4M 800 K4M 801	1	06/2005-12/2014	1598	82	112	1
1.6 16V GT (BR10, CR10)	K4M 862	1	06/2009-12/2014	1598	94	128	1
1.2 16V Hi-Flex (BR1U, CR1U)	D4F 740	18	07/2008-12/2014	1149	55	75	1
1.2 Ethanol (CR1U, BR1U)	D4F 742	19	07/2008-12/2012	1149	55	75	1
1.5 dCi	K9K 770	2	08/2010-12/2014	1461	55	75	1
1.5 dCi	K9K 766 K9K 770	2	08/2010-12/2014	1461	65	88	1
1.5 dCi (BR0H, CR0H, CR1S, BR1S)	K9K 764 K9K 774	2	06/2005-12/2014	1461	78	106	1
1.5 dCi (BR17, CR17)	K9K 766	2	06/2005-12/2012	1461	63	86	1
1.5 dCi (BR1C, CR1C)	K9K 772	2	06/2005-12/2012	1461	76	103	1
1.5 dCi (C/BR0G, C/BR1G)	K9K 714 K9K 768	2	06/2005-12/2012	1461	50	68	1

CLIO III (SB_, SR_) Hatchback Van 06/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (SR0J)	D4F 740	1	11/2005-12/2014	1149	55	75	1
1.2 (SR0P)	D4F 784	1	11/2007-12/2011	1149	74	101	1
1.2 Hi-Flex (SR1U)	D4F 742	19	11/2007-12/2009	1149	58	79	1
1.5 dCi	K9K 768	2	10/2005-07/2010	1461	50	68	1
1.5 dCi		2	08/2010-12/2014	1461	55	75	1
1.5 dCi	K9K 766	2	06/2005-07/2010	1461	63	86	1
1.5 dCi	K9K 764	2	10/2005-10/2007	1461	78	106	1
1.5 dCi (SR1H)	K9K 770	2	08/2010-12/2014	1461	65	88	1

CLIO III Grandtour (KR0/1_) Estate 11/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V	D4F 786	1	03/2010-12/2012	1149	76	103	1
1.4 16V	K4J 780	1	11/2007-12/2012	1390	72	98	1
1.6 16V		1	11/2007-12/2012	1598	80	109	1
1.2 16V Hi-Flex (KR1U)	D4F 742	19	11/2007-12/2012	1149	58	79	1
1.5 dCi	K9K 752	2	11/2007-12/2012	1461	48	65	1
1.5 dCi	K9K 770	2	08/2010-12/2012	1461	55	75	1
1.5 dCi	K9K 770 K9K 772	2	08/2010-12/2012	1461	65	88	1

MEGANE (BA0/1_) Hatchback 08/1995-12/2004

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (BA0D, BA1H, BA0W, BA10)	K4J 714 K4J 750	1	03/1999-08/2003	1390	70	95	1
1.8 16V (BA06, BA12, BA1A, BA1M, BA1R)	F4P 720 F4P 722	1	01/2001-08/2003	1783	85	115	1
2.0 16V (BA0H)	F7R 710 F7R 714	1	07/1996-08/2003	1998	108	147	1
2.0 i	F3R 750 F3R 751	1	03/1999-08/2003	1998	80	109	1
1.9 dTi (BA1U)	F9Q 744	2	02/2001-08/2003	1870	59	80	1

MEGANE Classic (LA0/1_) Saloon 09/1996-08/2008

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (LA0D, LA1H, lA0W, LA10)	K4J 714 K4J 750	1	03/1999-08/2003	1390	70	95	1
1.6 16V (LA00, LA04, LA0B, LA11, LA16, LA19, LA1J, LA1K,...	K4M 700 K4M 701 K4M 706 K4M 708 K4M 709	1	03/1999-07/2003	1598	79	107	1
1.9 dTi (LA08, LA0N, LA0K)	F9Q 730 F9Q 731 F9Q 734 F9Q 736	2	03/1997-02/2001	1870	72	98	1
1.9 dTi (LA1U)	F9Q 744	2	02/2001-08/2003	1870	59	80	1

MEGANE Grandtour (KA0/1_) Estate 03/1999-08/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (KA0D, KA1H, KA0W, KA10)	K4J 714 K4J 750	1	03/1999-08/2003	1390	70	95	1
1.4 e (KA0V)	E7J 626	1	03/1999-08/2003	1390	55	75	1
1.6 16V (KA0B, KA04, KA11)	K4M 700 K4M 701 K4M 708 K4M 709	1	03/1999-08/2003	1598	79	107	1
1.6 e (KA0F)	K7M 702 K7M 703	1	03/1999-08/2003	1598	66	90	1
1.9 dCi (KA05, KA1F)	F9Q 732 F9Q 733 F9Q 738	2	02/2001-08/2003	1870	75	102	1
1.9 dTi (KA1U)	F9Q 744	2	02/2001-08/2003	1870	59	80	1

MEGANE Kombi van (KA_) Estate Van 02/2000-07/2003

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (KA0D)	K4J 714 K4J 750	1	04/2001-07/2003	1390	70	95	1

MEGANE II (BM0/1_, CM0/1_) Hatchback 07/2001-10/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	K4J 732	1	10/2003-02/2008	1390	60	82	1
1.4 16V (BM0B, CM0B)	K4J 730 K4J 740	1	11/2002-02/2008	1390	72	98	1
1.6	K4M 788	1	06/2005-02/2008	1598	77	105	1
1.6		1	05/2006-01/2011	1598	79	107	1
1.6 16V	K4M 760 K4M 812 K4M 813	1	01/2006-06/2008	1598	82	112	1
1.6 16V (BM0C, CM0C)	K4M 760	1	11/2002-02/2008	1598	83	113	1
2.0 16V (BM0U, CM0U)	F4R 770	1	11/2002-02/2008	1998	99	135	1
2.0 16V Turbo	F4R 776	1	05/2004-02/2008	1998	120	163	1
1.6 BiFuel	K4M 788	18	06/2005-02/2008	1598	77	105	1
1.6 Flex-Fuel	K4M 788	19	01/2007-02/2008	1598	77	105	1
1.5 dCi (BM02, BM13, BM2A, CM02, CM13)	K9K 728 K9K 729	2	10/2003-02/2008	1461	74	101	1
1.5 dCi (BM0F, BM0T, BM2B, CM0F, CM0T)	K9K 722	2	09/2002-02/2008	1461	60	82	1
1.5 dCi (BM16, CM16)	K9K 734	2	01/2007-03/2009	1461	76	103	1
1.5 dCi (BM1E, CM1E)	K9K 732	2	05/2005-06/2008	1461	78	106	1
1.5 dCi (BM1F, CM1F)	K9K 724	2	05/2005-02/2008	1461	63	86	1
1.9 dCi	F9Q 808	2	11/2002-12/2005	1870	66	90	1
1.9 dCi	F9Q 808	2	03/2004-08/2006	1870	68	92	1
1.9 dCi	F9Q 804 F9Q 818	2	05/2005-02/2008	1870	81	110	1
1.9 dCi	F9Q 804 F9Q 816 F9Q 818	2	11/2002-02/2008	1870	85	115	1
1.9 dCi	F9Q 803 F9Q 804 F9Q 816 F9Q 818	2	05/2005-12/2009	1870	96	131	1
1.9 dCi (BM0G, CM0G)	F9Q 800	2	11/2002-02/2008	1870	88	120	1

MEGANE II (KM0/1_) Estate 08/2003-08/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	K4J 730 K4J 740	1	08/2003-07/2009	1390	72	98	1
1.6	K4M 760 K4M 761	1	08/2003-07/2009	1598	83	113	1
1.6 16V	K4M 768	1	05/2005-07/2009	1598	75	102	1
1.6 16V	K4M 762	1	05/2005-07/2009	1598	77	105	1
1.6 16V	K4M 762	1	05/2006-10/2011	1598	81	110	1
1.6 16V	K4M 760 K4M 761 K4M 812 K4M 813	1	01/2006-08/2009	1598	82	112	1
2.0	F4R 770 F4R 771	1	08/2003-07/2009	1998	99	135	1
2.0 (KM0S, KM2N, KM23)	F4R 770 F4R 771	1	12/2006-01/2011	1998	102	138	1
1.6 Flex		19	12/2006-08/2012	1598	81	110	1
1.5 dCi (KM02, KM13)	K9K 728 K9K 729	2	02/2004-03/2006	1461	74	101	1
1.5 dCi (KM0F, KM0T, KM2B)	K9K 722	2	08/2003-05/2006	1461	60	82	1
1.5 dCi (KM16, KM1E)	K9K 732	2	05/2005-06/2008	1461	78	106	1
1.5 dCi (KM16)	K9K 734	2	01/2007-07/2009	1461	76	103	1
1.5 dCi (KM1F)	K9K 724	2	05/2005-07/2009	1461	63	86	1
1.9 dCi	F9Q 808	2	03/2004-02/2007	1870	68	92	1
1.9 dCi	F9Q 804 F9Q 818	2	05/2005-07/2009	1870	81	110	1
1.9 dCi	F9Q 803 F9Q 804	2	05/2005-07/2009	1870	96	131	1
1.9 dCi (KMRG, KM1G, KM0G, KM2C)	F9Q 800	2	08/2003-07/2009	1870	88	120	1

MEGANE II (LM0/1_) Saloon 08/2003-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	K4J 732	1	09/2003-	1390	60	82	1
1.4	K4J 730 K4J 740	1	09/2003-	1390	72	98	1
1.6		1	09/2003-	1598	75	102	1
1.6	K4M 762	1	05/2005-	1598	77	105	1
1.6		1	09/2007-12/2010	1598	80	109	1
1.6	K4M 760 K4M 761	1	09/2003-11/2008	1598	81	110	1
1.6	K4M 760 K4M 761	1	09/2003-	1598	83	113	1
1.6 16V (LM1R, LM0C)	K4M 760 K4M 761 K4M 812 K4M 813	1	01/2006-	1598	82	112	1
2.0	F4R 770 F4R 771	1	09/2003-	1998	99	135	1
2.0	F4R 770	1	04/2006-11/2010	1998	101	138	1
1.6 Hi-Flex (LM2E, LM2M, LM24)	K4M 766	19	03/2006-	1598	85	116	1
1.5 dCi (LM02, LM13, LM2A)	K9K 728 K9K 729	2	02/2004-12/2010	1461	74	101	1
1.5 dCi (LM0F, LM0T, LM2B)	K9K 722	2	08/2003-12/2010	1461	60	82	1
1.5 dCi (LM16)	K9K 734	2	10/2003-12/2010	1461	76	103	1
1.5 dCi (LM1E)	K9K 732	2	05/2005-12/2010	1461	78	106	1
1.5 dCi (LM1F)	K9K 724	2	05/2005-12/2010	1461	63	86	1
1.9 dCi	F9Q 808	2	09/2003-12/2005	1870	66	90	1
1.9 dCi	F9Q 808	2	03/2004-	1870	68	92	1
1.9 dCi	F9Q 803 F9Q 804	2	05/2005-	1870	96	131	1
1.9 dCi (LM0G, LM1G, LM2C)	F9Q 800	2	09/2003-	1870	88	120	1
1.9 dCi (LM14, LM1D)	F9Q 803 F9Q 804 F9Q 816 F9Q 818	2	05/2005-	1870	81	110	1

MEGANE II Hatchback Van (KM0/2_) Hatchback Van 08/2003-07/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.5 dCi	K9K 722	2	08/2003-02/2008	1461	60	82	1
1.5 dCi	K9K 724	2	04/2005-02/2008	1461	63	86	1
1.5 dCi	K9K 728	2	08/2003-02/2008	1461	74	101	1
1.5 dCi	K9K 734	2	01/2007-03/2009	1461	76	103	1
1.5 dCi	K9K 732	2	05/2005-02/2008	1461	78	106	1

MEGANE II (EM0/1_) Convertible 09/2003-03/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6	K4M 788	1	06/2005-03/2009	1598	77	105	1
1.6	K4M 760 K4M 761	1	09/2003-03/2009	1598	83	113	1
1.6 16V	K4M 760 K4M 761 K4M 812 K4M 813	1	01/2006-06/2008	1598	82	112	1
2.0	F4R 770 F4R 771	1	09/2003-12/2009	1998	99	135	1
2.0 (EM0S)	F4R 770 F4R 771	1	09/2003-02/2007	1998	102	139	1
2.0 16V Turbo	F4R 776	1	05/2004-03/2009	1998	120	163	1
1.5 dCi (EM16)	K9K 734	2	01/2007-06/2009	1461	76	103	1
1.5 dCi (EM1E)	K9K 732	2	03/2006-01/2009	1461	78	106	1
1.9 dCi	F9Q 804 F9Q 816 F9Q 818	2	05/2005-03/2009	1870	81	110	1
1.9 dCi	F9Q 804 F9Q 816 F9Q 818	2	09/2003-03/2009	1870	85	115	1
1.9 dCi	F9Q 800	2	09/2003-03/2009	1870	88	120	1
1.9 dCi	F9Q 803 F9Q 804	2	05/2005-02/2007	1870	96	131	1

MODUS / GRAND MODUS (F/JP0_) Hatchback 09/2004-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2	D4F 786	1	04/2011-	1149	76	103	1
1.2 (FP0C, FP0K, FP0P)	D4F 740	1	05/2005-	1149	48	65	1
1.2 (JP0C, JP0K, FP0C, FP0K, FP0P, JP0P, JP0T)	D4F 740	1	12/2004-	1149	55	75	1
1.2 16V (JP0W)	D4F 784	1	05/2007-	1149	74	101	1
1.4 (JP01, JP0J)	K4J 770 K4J 780	1	12/2004-	1390	72	98	1
1.6 (JP03, JP0B, JP0U, JP0Y, JP1G)	K4M 790 K4M 791 K4M 800 K4M 801	1	12/2004-	1598	82	112	1
1.6 (JP0L, JP0V)	K4M 794	1	12/2004-	1598	65	88	1
1.2 GPL (JP0R)	D4F 744	18	05/2008-12/2012	1149	55	75	1
1.2 16V Hi-Flex	D4F 740	19	10/2008-	1149	55	75	1
1.5 dCi (FP0D, JP0D)	K9K 750	2	09/2004-	1461	60	82	1
1.5 dCi (FP0F, JP0F)	K9K 760 K9K 766	2	12/2004-	1461	63	86	1
1.5 dCi (FP0G, JP0G)	K9K 768	2	12/2004-	1461	50	68	1
1.5 dCi (JP02)	K9K 772	2	05/2007-	1461	76	103	1
1.5 dCi (JP0G, JP0H)	K9K 764	2	05/2005-	1461	78	106	1
1.5 dCi 75	K9K 770	2	10/2010-	1461	55	75	1
1.5 dCi 90	K9K 750 K9K 770	2	10/2010-	1461	65	88	1

THALIA II / SYMBOL (LU_) Saloon 09/2008-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V (LU2V)	D4F 728	1	09/2008-06/2014	1149	55	75	1
1.6		1	01/2009-05/2012	1598	66	90	1
1.6 16V	K4M 743	1	09/2008-	1598	77	105	1
1.6 16V (LU1A, LU1B, LU1D, LU2M)	K4M 744 K4M 745	1	01/2009-	1598	79	107	1
1.5 dCi	K9K 740	2	09/2008-	1461	47	64	1
1.5 dCi	K9K 700	2	01/2009-	1461	48	65	1
1.5 dCi	K9K 718	2	09/2008-	1461	62	85	1
1.5 dCi	K9K 834	2	01/2009-	1461	66	90	1

WIND (E4M_) Convertible 07/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (E4MF)	D4F 782	1	07/2010-	1149	74	101	1
1.2 TCe 100 (E4MF)	D4F 780	1	02/2011-	1149	75	102	1
1.6 (E4MB, E4MC)	K4M 854	1	07/2010-	1598	98	133	1
