Product 78BD7829-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Barcode
-
8424073148612
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD7829-2
- Weight (gr.)
- 14064
- R90 Homologation
-
90R-02C0433/0090
- Measures
- Ø280x24x44
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
22.5 -
Hole Arrangement/Number:
4 -
Bolt Hole Circle Ø [mm]:
100 -
Wheel Hub Diameter [mm]:
61
| Brand | OE Reference |
|---|---|
| RENAULT | 77 00 426 389 |
| RENAULT | 77 01 205 230 |
| RENAULT | 77 01 205 842 |
| RENAULT | 77 01 206 118 |
| RENAULT | 77 01 207 829 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0124-0158.1 |
| ATE | 424158 |
| BENDIX ANTIGUO | 562103B |
| BOSCH | 0 986 478 590 |
| BREMBO | 09.8137.20 |
| BREMBO | 09.8137.21 |
| BREMBO | 09.8137.24 |
| DELPHI LOCKHEED | BG3430 |
| LETEC | LBR708V |
| NECTO | WN1134 |
| ROAD HOUSE | 6583.10 |
| SANLI | SL32812 |
| TRW | DF4110 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 TCe 115 | 1 | 08/2018-12/2021 | 1197 | 85 | 115 | 1 | |
| 1.6 SCe 100 | 1 | 09/2017-12/2021 | 1598 | 75 | 102 | 1 | |
| 1.5 dCi 75 | 2 | 09/2017-12/2021 | 1461 | 55 | 75 | 1 | |
| 1.5 dCi 90 | 2 | 09/2017-12/2021 | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 dCi (KEMW) |
K9K 612 K9K 830 |
2 | 11/2012-12/2021 | 1461 | 63 | 85 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 TCe 110 (RKMD) | 1 | 09/2021- | 999 | 81 | 110 | 1 | |
| 1.6 HYBRID 140 (RKN8) | 13 | 01/2023- | 1598 | 104 | 141 | 1 | |
| 1.0 TCe 100 ECO-G (RKMT) | 18 | 09/2021- | 999 | 74 | 101 | 1 | |
| 1.0 TCe 90 ECO-G (RKMT) | 18 | 09/2021- | 999 | 67 | 91 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 dCi (JSMW) |
K9K 612 K9K 830 |
2 | 11/2012- | 1461 | 63 | 85 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 T |
H5F 403 |
1 | 06/2013- | 1197 | 83 | 113 | 1 |
| 1.2 T |
H5F 403 |
1 | 06/2015- | 1197 | 85 | 116 | 1 |
| 1.2 TCe (J5AU) |
H5F 408 |
1 | 02/2018- | 1197 | 97 | 132 | 1 |
| 1.2 TCe 120 |
H5F 408 H5F 412 |
1 | 01/2016- | 1197 | 87 | 118 | 1 |
| 1.2 TCe 120 |
H5F 403 |
1 | 06/2013- | 1197 | 88 | 120 | 1 |
| 1.3 TCe 130 (J5NJ, J5NE) |
H5H 450 |
1 | 03/2018- | 1332 | 96 | 131 | 1 |
| 1.3 TCe 150 (J5NK, J5JS) |
H5H 450 |
1 | 03/2018- | 1332 | 110 | 150 | 1 |
| 1.6 (J5JA, J5JY, H5JA) |
H4M 750 |
1 | 02/2018- | 1598 | 84 | 114 | 1 |
| 1.5 dCi (J5MW) |
K9K 830 |
2 | 06/2013- | 1461 | 63 | 86 | 1 |
| 1.5 dCi 110 |
K9K 646 K9K 856 |
2 | 01/2015- | 1461 | 81 | 110 | 1 |
| 1.5 dCi 90 (J5N4, J5M5, J5MW, J5M6, J5AL, J5AJ) |
K9K 608 K9K 609 K9K 628 K9K 629 K9K 838 |
2 | 06/2013- | 1461 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.0 16V (CB0M, CB1G) | 1 | 06/2001-05/2005 | 1998 | 126 | 172 | 1 | |
| 2.0 16V Sport |
F4R 738 |
1 | 01/2004-04/2005 | 1998 | 132 | 179 | 1 |
| 2.0 16V Sport (CB0M) |
F4R 730 F4R 736 |
1 | 02/2000-06/2009 | 1998 | 124 | 169 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 16V |
D4F 764 |
1 | 06/2006-08/2010 | 1149 | 43 | 58 | 1 |
| 1.2 16V |
D4F 786 |
1 | 09/2010-12/2014 | 1149 | 76 | 103 | 1 |
| 1.6 | 1 | 09/2005-12/2010 | 1598 | 79 | 107 | 1 | |
| 1.6 16V GT (BR10, CR10) |
K4M 862 |
1 | 06/2009-12/2014 | 1598 | 94 | 128 | 1 |
| 2.0 16V (BR0C, BR0K, CR0C, CR0K) |
M4R 700 M4R 701 |
1 | 09/2006-12/2014 | 1997 | 102 | 139 | 1 |
| 1.2 Ethanol (CR1U, BR1U) |
D4F 742 |
19 | 07/2008-12/2012 | 1149 | 55 | 75 | 1 |
| 1.5 dCi |
K9K 770 |
2 | 08/2010-12/2014 | 1461 | 55 | 75 | 1 |
| 1.5 dCi |
K9K 766 K9K 770 |
2 | 08/2010-12/2014 | 1461 | 65 | 88 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 (SR0J) |
D4F 740 |
1 | 11/2005-12/2014 | 1149 | 55 | 75 | 1 |
| 1.2 (SR0P) |
D4F 784 |
1 | 11/2007-12/2011 | 1149 | 74 | 101 | 1 |
| 1.2 Hi-Flex (SR1U) |
D4F 742 |
19 | 11/2007-12/2009 | 1149 | 58 | 79 | 1 |
| 1.5 dCi |
K9K 768 |
2 | 10/2005-07/2010 | 1461 | 50 | 68 | 1 |
| 1.5 dCi | 2 | 08/2010-12/2014 | 1461 | 55 | 75 | 1 | |
| 1.5 dCi |
K9K 766 |
2 | 06/2005-07/2010 | 1461 | 63 | 86 | 1 |
| 1.5 dCi |
K9K 764 |
2 | 10/2005-10/2007 | 1461 | 78 | 106 | 1 |
| 1.5 dCi (SR1H) |
K9K 770 |
2 | 08/2010-12/2014 | 1461 | 65 | 88 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.5 dCi (KR0F) |
K9K 766 |
2 | 11/2007-12/2012 | 1461 | 63 | 86 | 1 |
| 1.5 dCi (KR0G) |
K9K 714 K9K 768 |
2 | 11/2007-12/2012 | 1461 | 50 | 68 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.0 TCe 100 (B7MT) |
H4D 450 H4D 452 H4D 460 H4D 472 |
1 | 06/2019- | 999 | 74 | 101 | 1 |
| 1.0 TCe 90 (B7MT) | 1 | 08/2020- | 999 | 67 | 91 | 1 | |
| 1.3 TCe 130 (B7MF) |
H5H 450 H5H 470 |
1 | 06/2019- | 1332 | 96 | 131 | 1 |
| 1.3 TCe 140 (B7N0) | 1 | 09/2020- | 1332 | 103 | 140 | 1 | |
| 1.6 E-TECH 140 (B7MU) |
H4M 630 |
13 | 03/2020- | 1598 | 103 | 140 | 1 |
| 1.6 E-TECH 145 (B7MU) | 13 | 01/2022- | 1598 | 105 | 143 | 1 | |
| 1.0 LPG (B7MT) | 18 | 11/2021- | 999 | 67 | 91 | 1 | |
| 1.0 LPG (B7MT) |
H4D 450 H4D 452 H4D 460 H4D 472 |
18 | 06/2019- | 999 | 74 | 101 | 1 |
| 1.5 Blue dCi 100 (B7AD) | 2 | 11/2021- | 1461 | 74 | 101 | 1 | |
| 1.5 Blue dCi 115 (B7AD) |
K9K 854 K9K 862 K9K 872 |
2 | 06/2019- | 1461 | 85 | 116 | 1 |
| 1.5 Blue dCi 85 (B7AG) |
K9K 854 K9K 872 |
2 | 06/2019- | 1461 | 63 | 86 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V 4x4 (KC0P, KC0S, KC0L) |
K4M 750 K4M 752 K4M 753 |
1 | 10/2001- | 1598 | 70 | 95 | 3 |
| 1.9 dCi 4x4 |
F9Q 790 |
2 | 10/2003- | 1870 | 62 | 84 | 3 |
| 1.9 dCi 4x4 (KC0V) |
F9Q 782 F9Q 790 |
2 | 10/2001- | 1870 | 59 | 80 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V 4x4 (FC0L, FC0P, FC0S) |
K4M 750 K4M 752 K4M 753 |
1 | 10/2001- | 1598 | 70 | 95 | 3 |
| 1.9 dCi 4x4 (FC0V) |
F9Q 782 F9Q 790 |
2 | 10/2001- | 1870 | 59 | 80 | 3 |
| 1.9 dCi 4x4 (FC0V) |
F9Q 790 |
2 | 07/2003- | 1870 | 62 | 84 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V (B568, B561) |
K4M 720 K4M 724 |
1 | 11/1997-03/2001 | 1598 | 79 | 107 | 1 |
| 1.8 16V (B563, B564) |
F4P 760 F4P 770 |
1 | 04/1998-03/2001 | 1783 | 88 | 120 | 1 |
| 2.0 | 1 | 11/1993-03/2001 | 1994 | 70 | 95 | 1 | |
| 2.0 |
F3R 611 |
1 | 03/1999-03/2001 | 1998 | 80 | 109 | 1 |
| 2.0 |
F3R 722 F3R 768 |
1 | 06/1995-02/2001 | 1998 | 84 | 114 | 1 |
| 2.0 (B56C/H/N) |
F3R 722 F3R 723 |
1 | 11/1993-03/2001 | 1998 | 83 | 113 | 1 |
| 2.9 24V (B56V) | 1 | 03/1997-03/2001 | 2946 | 140 | 190 | 1 | |
| 3.0 24V (B56V) |
L7X 700 L7X 701 |
1 | 03/1997-03/2001 | 2946 | 140 | 190 | 1 |
| 1.9 dCi (B56W) |
F9Q 718 |
2 | 09/1999-03/2001 | 1870 | 79 | 107 | 1 |
| 1.9 dTi (B56J) |
F9Q 710 F9Q 716 F9Q 717 |
2 | 10/1997-03/2001 | 1870 | 72 | 98 | 1 |
| 2.2 dT (B569) |
G8T 760 |
2 | 03/1996-03/2001 | 2188 | 83 | 113 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V (K568) |
K4M 720 K4M 724 |
1 | 11/1997-03/2001 | 1598 | 79 | 107 | 1 |
| 1.8 (K56S/T/0) |
F3P 670 F3P 678 |
1 | 09/1995-03/2001 | 1794 | 66 | 90 | 1 |
| 1.8 (K56Z) |
F3P 678 F3P 720 F3P 724 |
1 | 09/1995-03/2001 | 1794 | 69 | 94 | 1 |
| 1.8 16V (K563, K564) |
F4P 760 |
1 | 04/1998-03/2001 | 1783 | 88 | 120 | 1 |
| 2.0 |
F3R 728 F3R 768 |
1 | 10/1998-01/2001 | 1998 | 84 | 114 | 1 |
| 2.0 (K56C/H) |
F3R 722 F3R 723 |
1 | 09/1995-03/2001 | 1998 | 83 | 113 | 1 |
| 3.0 24V (K56V) |
L7X 700 L7X 701 |
1 | 03/1997-03/2001 | 2946 | 140 | 190 | 1 |
| 1.9 dCi (K56W) |
F9Q 718 |
2 | 09/1999-03/2001 | 1870 | 79 | 107 | 1 |
| 1.9 dTi (K56J) |
F9Q 710 F9Q 716 F9Q 717 |
2 | 10/1997-03/2001 | 1870 | 72 | 98 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V | 1 | 11/2001-12/2004 | 1598 | 81 | 110 | 1 | |
| 1.6 16V (BA04, BA0B, BA11, BA1J, BA16, BA19, BA1K, BA1V,... |
K4M 700 K4M 701 K4M 706 K4M 708 K4M 709 |
1 | 03/1999-08/2002 | 1598 | 79 | 107 | 1 |
| 1.8 16V (BA06, BA12, BA1A, BA1M, BA1R) |
F4P 720 F4P 722 |
1 | 01/2001-08/2003 | 1783 | 85 | 115 | 1 |
| 2.0 16V (BA0H) |
F7R 710 F7R 714 |
1 | 07/1996-08/2003 | 1998 | 108 | 147 | 1 |
| 2.0 i |
F3R 750 F3R 751 |
1 | 03/1999-08/2003 | 1998 | 80 | 109 | 1 |
| 1.6 LPG |
K4M 704 K4M 712 |
18 | 10/2000-08/2002 | 1598 | 80 | 109 | 1 |
| 1.9 dCi |
F9Q 732 F9Q 738 |
2 | 03/1999-08/2003 | 1870 | 77 | 105 | 1 |
| 1.9 dCi (BA05, BA1F) |
F9Q 732 F9Q 733 |
2 | 02/2001-08/2003 | 1870 | 75 | 102 | 1 |
| 1.9 DT |
F8Q 784 |
2 | 08/1998-10/1999 | 1870 | 76 | 104 | 1 |
| 1.9 dTI |
F9Q 730 |
2 | 02/2000-09/2000 | 1870 | 60 | 82 | 1 |
| 1.9 dTi (BA08, BA0N) |
F9Q 730 F9Q 731 F9Q 734 F9Q 736 |
2 | 03/1997-02/2001 | 1870 | 72 | 98 | 1 |
| 1.9 dTi (BA1U) |
F9Q 744 |
2 | 02/2001-08/2003 | 1870 | 59 | 80 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.9 dCi |
F9Q 738 |
2 | 10/2000-07/2003 | 1870 | 59 | 80 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 16V (DA0D, DA1H, DA0W, DA10) |
K4J 700 K4J 714 K4J 750 |
1 | 03/1999-07/2003 | 1390 | 70 | 95 | 1 |
| 1.6 16V (DA0B, DA04, DA11) |
K4M 700 K4M 701 K4M 708 K4M 709 |
1 | 03/1999-07/2003 | 1598 | 79 | 107 | 1 |
| 2.0 16V |
F4R 746 |
1 | 01/2002-08/2003 | 1998 | 102 | 139 | 1 |
| 2.0 16V (DA0H) |
F7R 710 F7R 714 |
1 | 03/1996-11/1999 | 1998 | 108 | 147 | 1 |
| 2.0 16V IDE (DA03, DA0P, DA14) |
F5R 740 |
1 | 11/1999-08/2003 | 1998 | 103 | 140 | 1 |
| 2.0 i |
F3R 791 F3R 796 |
1 | 03/1999-08/2003 | 1998 | 80 | 109 | 1 |
| 1.9 dCi |
F9Q 732 F9Q 733 |
2 | 03/1999-09/2000 | 1870 | 77 | 105 | 1 |
| 1.9 dCi (DA05, DA1F) |
F9Q 732 F9Q 733 |
2 | 02/2001-08/2003 | 1870 | 75 | 102 | 1 |
| 1.9 dTi (DA0N) |
F9Q 731 F9Q 734 F9Q 736 |
2 | 03/1997-02/2001 | 1870 | 72 | 98 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 16V | 1 | 09/1999-12/2001 | 1598 | 81 | 110 | 1 | |
| 1.6 16V (LA00, LA04, LA0B, LA11, LA16, LA19, LA1J, LA1K,... |
K4M 700 K4M 701 K4M 706 K4M 708 K4M 709 |
1 | 03/1999-07/2003 | 1598 | 79 | 107 | 1 |
| 1.8 16V (LA06, LA12, LA1A, LA1M, LA1R) |
F4P 720 F4P 722 |
1 | 01/2001-08/2003 | 1783 | 85 | 115 | 1 |
| 2.0 i (LA0G) |
F3R 750 F3R 751 F3R 752 F3R 791 F3R 796 F3R 797 F3R 798 |
1 | 03/1999-08/2003 | 1998 | 80 | 109 | 1 |
| 2.0 RT |
F4R 747 F5R 740 |
1 | 03/2001-08/2003 | 1998 | 103 | 140 | 1 |
| 1.9 dCi (LA05, LA1F) |
F9Q 732 F9Q 733 F9Q 738 |
2 | 02/2001-08/2003 | 1870 | 75 | 102 | 1 |
| 1.9 dCi (LA05) |
F9Q 732 F9Q 733 |
2 | 03/1999-07/2003 | 1870 | 77 | 105 | 1 |
| 1.9 DT |
F8Q 784 |
2 | 08/1998-10/1999 | 1870 | 76 | 104 | 1 |
| 1.9 dTi (LA1U) |
F9Q 744 |
2 | 02/2001-08/2003 | 1870 | 59 | 80 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 16V (EA0D, EA1H, EA0W, EA10) |
K4J 714 K4J 750 |
1 | 03/1999-08/2003 | 1390 | 70 | 95 | 1 |
| 1.6 16V (EA04, EA0B, EA11, EA1J) |
K4M 700 K4M 701 K4M 708 K4M 709 |
1 | 03/1999-07/2003 | 1598 | 79 | 107 | 1 |
| 2.0 16V |
F4R 746 F4R 770 |
1 | 01/2002-08/2003 | 1998 | 102 | 139 | 1 |
| 2.0 16V (EA0H) |
F7R 710 F7R 714 |
1 | 10/1996-11/1999 | 1998 | 108 | 147 | 1 |
| 2.0 16V IDE (EA03, EA0P, EA14) |
F5R 740 |
1 | 11/1999-08/2003 | 1998 | 103 | 140 | 1 |
| 2.0 i (EA0G) |
F3R 791 F3R 796 |
1 | 03/1999-08/2003 | 1998 | 80 | 109 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 i (JA0E) |
E7J 764 |
1 | 01/1997-09/1999 | 1390 | 55 | 75 | 1 |
| 1.6 16V (JA0B, JA04, JA11, JA00) |
K4M 700 K4M 701 K4M 704 K4M 708 |
1 | 04/1998-10/1999 | 1598 | 79 | 107 | 1 |
| 1.6 e (JA0F) |
K7M 702 K7M 703 |
1 | 10/1996-10/1999 | 1598 | 66 | 90 | 1 |
| 1.6 i (JA0L) |
K7M 720 |
1 | 01/1997-09/1999 | 1598 | 55 | 75 | 1 |
| 2.0 i (JA02, JA0G) |
F3R 791 F3R 796 |
1 | 01/1999-09/1999 | 1998 | 80 | 109 | 1 |
| 2.0 i (JA0G) |
F3R 750 F3R 751 |
1 | 01/1997-09/1999 | 1998 | 84 | 114 | 1 |
| 2.0 RXE 4x4 |
F3R 750 |
1 | 05/1997-10/1999 | 1998 | 84 | 114 | 3 |
| 1.9 D (JA0J) |
F8Q 790 |
2 | 03/1997-09/1999 | 1870 | 47 | 64 | 1 |
| 1.9 dT (JA0K, JA0Y) |
F8Q 784 F8Q 786 |
2 | 01/1997-09/1999 | 1870 | 66 | 90 | 1 |
| 1.9 dTi (JA0N) |
F9Q 730 F9Q 734 |
2 | 04/1997-09/1999 | 1870 | 72 | 98 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.9 DT (JA0K) | 2 | 01/1997-09/1999 | 1870 | 66 | 90 | 1 | |
| 1.9 dTi (JA0N) | 2 | 04/1997-09/1999 | 1870 | 72 | 98 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 BiFuel | 1 | 04/2001-07/2003 | 1598 | 79 | 107 | 1 | |
| 1.8 16V (KA0S, KA12, KA1A, KA1M, KA1R) |
F4P 720 F4P 722 |
1 | 01/2001-08/2003 | 1783 | 85 | 115 | 1 |
| 1.6 BiFuel |
K4M 704 |
18 | 03/1999-09/2000 | 1598 | 80 | 109 | 1 |
| 1.9 dCi |
F9Q 732 |
2 | 03/1999-09/2000 | 1870 | 77 | 105 | 1 |
| 1.9 dCi (KA05, KA1F) |
F9Q 732 F9Q 733 F9Q 738 |
2 | 02/2001-08/2003 | 1870 | 75 | 102 | 1 |
| 1.9 dTi (KA0N) |
F9Q 731 F9Q 736 |
2 | 03/1999-02/2001 | 1870 | 72 | 98 | 1 |
| 1.9 dTi (KA1U) |
F9Q 744 |
2 | 02/2001-08/2003 | 1870 | 59 | 80 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 (KA0B, KA04) |
K4M 700 K4M 701 K4M 708 K4M 709 |
1 | 04/2001-07/2003 | 1598 | 79 | 107 | 1 |
| 1.8 (KA1M) |
F4P 722 |
1 | 04/2001-07/2003 | 1783 | 85 | 116 | 1 |
| 1.6 BiFuel (KA04) |
K4M 704 |
18 | 04/2001-07/2003 | 1598 | 80 | 109 | 1 |
| 1.6 BiFuel (KA0B) |
K4M 712 |
18 | 04/2001-07/2003 | 1598 | 79 | 107 | 1 |
| 1.9 dCi (KA05) |
F9Q 732 F9Q 733 |
2 | 04/2001-07/2003 | 1870 | 75 | 102 | 1 |
| 1.9 dCi (KA05) |
F9Q 732 F9Q 733 |
2 | 04/2001-07/2003 | 1870 | 77 | 105 | 1 |
| 1.9 dTi (KA1U) |
F9Q 744 |
2 | 04/2001-07/2003 | 1870 | 59 | 80 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 |
K4M 788 |
1 | 06/2005-02/2008 | 1598 | 77 | 105 | 1 |
| 1.6 | 1 | 05/2006-01/2011 | 1598 | 79 | 107 | 1 | |
| 1.6 16V |
K4M 760 K4M 812 K4M 813 |
1 | 01/2006-06/2008 | 1598 | 82 | 112 | 1 |
| 1.6 16V (BM0C, CM0C) |
K4M 760 |
1 | 11/2002-02/2008 | 1598 | 83 | 113 | 1 |
| 2.0 16V (BM0U, CM0U) |
F4R 770 |
1 | 11/2002-02/2008 | 1998 | 99 | 135 | 1 |
| 2.0 16V Turbo |
F4R 776 |
1 | 05/2004-02/2008 | 1998 | 120 | 163 | 1 |
| 1.6 BiFuel |
K4M 788 |
18 | 06/2005-02/2008 | 1598 | 77 | 105 | 1 |
| 1.6 Flex-Fuel |
K4M 788 |
19 | 01/2007-02/2008 | 1598 | 77 | 105 | 1 |
| 1.9 dCi |
F9Q 808 |
2 | 11/2002-12/2005 | 1870 | 66 | 90 | 1 |
| 1.9 dCi |
F9Q 808 |
2 | 03/2004-08/2006 | 1870 | 68 | 92 | 1 |
| 1.9 dCi |
F9Q 804 F9Q 818 |
2 | 05/2005-02/2008 | 1870 | 81 | 110 | 1 |
| 1.9 dCi |
F9Q 804 F9Q 816 F9Q 818 |
2 | 11/2002-02/2008 | 1870 | 85 | 115 | 1 |
| 1.9 dCi |
F9Q 803 F9Q 804 F9Q 816 F9Q 818 |
2 | 05/2005-12/2009 | 1870 | 96 | 131 | 1 |
| 1.9 dCi (BM0G, CM0G) |
F9Q 800 |
2 | 11/2002-02/2008 | 1870 | 88 | 120 | 1 |
| 2.0 dCi (BM1K, CM1K) |
M9R 700 M9R 722 |
2 | 09/2005-02/2008 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 |
K4M 760 K4M 761 |
1 | 08/2003-07/2009 | 1598 | 83 | 113 | 1 |
| 1.6 16V |
K4M 768 |
1 | 05/2005-07/2009 | 1598 | 75 | 102 | 1 |
| 1.6 16V |
K4M 762 |
1 | 05/2005-07/2009 | 1598 | 77 | 105 | 1 |
| 1.6 16V |
K4M 762 |
1 | 05/2006-10/2011 | 1598 | 81 | 110 | 1 |
| 1.6 16V |
K4M 760 K4M 761 K4M 812 K4M 813 |
1 | 01/2006-08/2009 | 1598 | 82 | 112 | 1 |
| 2.0 |
F4R 770 F4R 771 |
1 | 08/2003-07/2009 | 1998 | 99 | 135 | 1 |
| 2.0 (KM0S, KM2N, KM23) |
F4R 770 F4R 771 |
1 | 12/2006-01/2011 | 1998 | 102 | 138 | 1 |
| 1.6 LPG 16V |
K4M 760 |
18 | 01/2006-08/2009 | 1598 | 82 | 112 | 1 |
| 1.6 16V Hi-Flex |
K4M 856 |
19 | 02/2008-07/2009 | 1598 | 77 | 105 | 1 |
| 1.6 Flex | 19 | 12/2006-08/2012 | 1598 | 81 | 110 | 1 | |
| 1.6 Flex (KM2E, KM2M, KM24, KM26) | 19 | 11/2006-08/2012 | 1598 | 85 | 115 | 1 | |
| 1.9 dCi |
F9Q 808 |
2 | 04/2004-12/2005 | 1870 | 66 | 90 | 1 |
| 1.9 dCi |
F9Q 808 |
2 | 03/2004-02/2007 | 1870 | 68 | 92 | 1 |
| 1.9 dCi |
F9Q 804 F9Q 818 |
2 | 05/2005-07/2009 | 1870 | 81 | 110 | 1 |
| 1.9 dCi |
F9Q 818 |
2 | 05/2005-07/2009 | 1870 | 85 | 115 | 1 |
| 1.9 dCi |
F9Q 803 F9Q 804 |
2 | 05/2005-07/2009 | 1870 | 96 | 131 | 1 |
| 1.9 dCi (KMRG, KM1G, KM0G, KM2C) |
F9Q 800 |
2 | 08/2003-07/2009 | 1870 | 88 | 120 | 1 |
| 2.0 dCi |
M9R 700 M9R 722 |
2 | 09/2005-07/2009 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 | 1 | 09/2003- | 1598 | 75 | 102 | 1 | |
| 1.6 |
K4M 762 |
1 | 05/2005- | 1598 | 77 | 105 | 1 |
| 1.6 | 1 | 09/2007-12/2010 | 1598 | 80 | 109 | 1 | |
| 1.6 |
K4M 760 K4M 761 |
1 | 09/2003-11/2008 | 1598 | 81 | 110 | 1 |
| 1.6 |
K4M 760 K4M 761 |
1 | 09/2003- | 1598 | 83 | 113 | 1 |
| 1.6 16V (LM1R, LM0C) |
K4M 760 K4M 761 K4M 812 K4M 813 |
1 | 01/2006- | 1598 | 82 | 112 | 1 |
| 2.0 |
F4R 770 F4R 771 |
1 | 09/2003- | 1998 | 99 | 135 | 1 |
| 2.0 |
F4R 770 |
1 | 04/2006-11/2010 | 1998 | 101 | 138 | 1 |
| 1.6 Hi-Flex (LM2E, LM2M, LM24) |
K4M 766 |
19 | 03/2006- | 1598 | 85 | 116 | 1 |
| 1.9 dCi |
F9Q 808 |
2 | 09/2003-12/2005 | 1870 | 66 | 90 | 1 |
| 1.9 dCi |
F9Q 808 |
2 | 03/2004- | 1870 | 68 | 92 | 1 |
| 1.9 dCi |
F9Q 803 F9Q 804 |
2 | 05/2005- | 1870 | 96 | 131 | 1 |
| 1.9 dCi (LM0G, LM1G, LM2C) |
F9Q 800 |
2 | 09/2003- | 1870 | 88 | 120 | 1 |
| 1.9 dCi (LM14, LM1D) |
F9Q 803 F9Q 804 F9Q 816 F9Q 818 |
2 | 05/2005- | 1870 | 81 | 110 | 1 |
| 2.0 dCi |
M9R 700 M9R 722 |
2 | 09/2005- | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 (KM0C) |
K4M 780 |
1 | 10/2003-01/2008 | 1598 | 82 | 111 | 1 |
| 1.5 dCi (KM02) |
K9K 728 |
2 | 08/2003-07/2009 | 1461 | 74 | 101 | 1 |
| 1.5 dCi (KM0F) |
K9K 722 |
2 | 08/2003-07/2009 | 1461 | 60 | 82 | 1 |
| 1.5 dCi (KM1E) |
K9K 732 |
2 | 08/2003-07/2009 | 1461 | 78 | 106 | 1 |
| 1.5 dCi (KM1F) |
K9K 724 |
2 | 05/2005-07/2009 | 1461 | 63 | 86 | 1 |
| 1.9 dCi (KM14) |
F9Q E 804 |
2 | 02/2006-10/2006 | 1870 | 96 | 131 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 |
K4M 788 |
1 | 06/2005-03/2009 | 1598 | 77 | 105 | 1 |
| 1.6 |
K4M 760 K4M 761 |
1 | 09/2003-03/2009 | 1598 | 83 | 113 | 1 |
| 1.6 16V |
K4M 760 K4M 761 K4M 812 K4M 813 |
1 | 01/2006-06/2008 | 1598 | 82 | 112 | 1 |
| 2.0 |
F4R 770 F4R 771 |
1 | 09/2003-12/2009 | 1998 | 99 | 135 | 1 |
| 2.0 (EM0S) |
F4R 770 F4R 771 |
1 | 09/2003-02/2007 | 1998 | 102 | 139 | 1 |
| 2.0 16V Turbo |
F4R 776 |
1 | 05/2004-03/2009 | 1998 | 120 | 163 | 1 |
| 1.9 dCi |
F9Q 804 F9Q 816 F9Q 818 |
2 | 05/2005-03/2009 | 1870 | 81 | 110 | 1 |
| 1.9 dCi |
F9Q 804 F9Q 816 F9Q 818 |
2 | 09/2003-03/2009 | 1870 | 85 | 115 | 1 |
| 1.9 dCi |
F9Q 800 |
2 | 09/2003-03/2009 | 1870 | 88 | 120 | 1 |
| 1.9 dCi |
F9Q 803 F9Q 804 |
2 | 05/2005-02/2007 | 1870 | 96 | 131 | 1 |
| 2.0 dCi |
M9R 700 M9R 722 |
2 | 09/2005-03/2009 | 1995 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 16V (JA0D, JA1H, Ja0W, JA10) |
K4J 714 K4J 750 |
1 | 09/1999-08/2003 | 1390 | 70 | 95 | 1 |
| 1.6 |
K4M 708 K4M 709 |
1 | 03/2001-08/2003 | 1598 | 75 | 102 | 1 |
| 1.6 (JA00, JA16, JA15, JA19, JA1V, JA2B, JA2C, JA0B,... |
K4M 700 K4M 706 K4M 707 K4M 776 |
1 | 09/1999-09/2003 | 1598 | 79 | 107 | 1 |
| 1.6 (JA00) | 1 | 06/2001-09/2003 | 1598 | 81 | 110 | 1 | |
| 1.6 16V | 1 | 09/1999-08/2003 | 1598 | 85 | 116 | 1 | |
| 1.8 16V (JA12, JA1R, JA1M, JA1A) |
F4P 720 F4P 722 |
1 | 01/2001-08/2003 | 1783 | 85 | 115 | 1 |
| 1.8 4x4 |
F4P 722 |
1 | 07/2000-04/2001 | 1783 | 85 | 116 | 3 |
| 2.0 16V (JA1B, JA1D, JA0C) |
F4R 740 F4R 741 F4R 746 |
1 | 07/2000-08/2003 | 1998 | 102 | 139 | 1 |
| 2.0 16V (JA1D, JA17) |
F4R 740 F4R 741 F4R 744 F4R 747 |
1 | 09/1999-08/2003 | 1998 | 103 | 140 | 1 |
| 1.6 BiFuel | 18 | 03/2001-08/2003 | 1598 | 75 | 102 | 1 | |
| 1.6 BiFuel (JA04) |
K4M 704 K4M 712 |
18 | 09/1999-04/2001 | 1598 | 79 | 107 | 1 |
| 1.9 D (JA0J, FA0J) |
F8Q 788 F8Q 790 |
2 | 09/1999-03/2001 | 1870 | 47 | 64 | 1 |
| 1.9 dCi (JA05, JA1F) |
F9Q 732 F9Q 733 |
2 | 09/1999-08/2003 | 1870 | 75 | 102 | 1 |
| 1.9 dCi RX4 |
F9Q 732 F9Q 748 F9Q 796 |
2 | 12/2002-08/2003 | 1870 | 74 | 101 | 3 |
| 1.9 dCi RX4 |
F9Q 740 |
2 | 11/2000-08/2003 | 1870 | 75 | 102 | 3 |
| 1.9 dTi (JA0N) |
F9Q 731 F9Q 734 F9Q 736 |
2 | 09/1999-08/2003 | 1870 | 72 | 98 | 1 |
| 1.9 dTi (JA1U) |
F9Q 744 |
2 | 02/2001-08/2003 | 1870 | 59 | 80 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.9 (FA0J) | 2 | 09/1999-02/2001 | 1870 | 47 | 64 | 1 | |
| 1.9 dTi (JA0N) | 2 | 09/1999-04/2001 | 1870 | 72 | 98 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 (JM0B, JM0H, JM1A) |
K4J 730 K4J 740 K4J 770 |
1 | 06/2003-11/2008 | 1390 | 72 | 98 | 1 |
| 1.6 |
K4M 788 |
1 | 06/2006-11/2008 | 1598 | 77 | 105 | 1 |
| 1.6 (JM0C, JM0J, JM1B) |
K4M 761 K4M 782 |
1 | 06/2003-10/2006 | 1598 | 83 | 113 | 1 |
| 1.6 16V (JM1R) |
K4M 706 K4M 766 K4M 812 K4M 813 |
1 | 10/2005-11/2008 | 1598 | 82 | 112 | 1 |
| 1.6 Hi-Flex |
K4M 766 |
19 | 03/2005-07/2010 | 1598 | 81 | 110 | 1 |
| 1.5 dCi (JM02, JM13) |
K9K 728 K9K 729 |
2 | 11/2003-08/2005 | 1461 | 74 | 101 | 1 |
| 1.5 dCi (JM0F) |
K9K 722 |
2 | 06/2003-05/2006 | 1461 | 60 | 82 | 1 |
| 1.5 dCi (JM16) |
K9K 728 K9K 734 |
2 | 01/2007-11/2008 | 1461 | 76 | 103 | 1 |
| 1.5 dCi (JM1E, JM16) |
K9K 732 K9K 734 |
2 | 05/2005-11/2008 | 1461 | 78 | 106 | 1 |
| 1.5 dCi (JM1F) |
K9K 724 |
2 | 05/2005-11/2008 | 1461 | 63 | 86 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 RS (CN0N, CN0R, CN0S) |
K4M 854 |
1 | 05/2008-09/2014 | 1598 | 98 | 133 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.2 (E4MF) |
D4F 782 |
1 | 07/2010- | 1149 | 74 | 101 | 1 |
| 1.2 TCe 100 (E4MF) |
D4F 780 |
1 | 02/2011- | 1149 | 75 | 102 | 1 |
| 1.6 (E4MB, E4MC) |
K4M 854 |
1 | 07/2010- | 1598 | 98 | 133 | 1 |
