Product 78BD7916-1 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 1
Barcode: 8424073291110
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD7916-1
Weight (gr.): 22400

Measures: Ø302x32x61
: Brake Disc Type: Vented; Minimum thickness [mm]: 30; Hole Arrangement/Number: 6; Bolt Hole Circle Ø [mm]: 140; Wheel Hub Diameter [mm]: 98

Reference applications

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5		1	12/2011-10/2018	2488	122	166	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 Flex		1	03/2014-	2488	127	173	1
2.5 i	GBVAF GBVAK GBVAL	1	11/2011-	2488	122	166	2
2.5 i 4x4	GBVAF GBVAK GBVAL	1	11/2011-	2488	122	166	3
2.5 i CNG	GBVAF,GBVAK,GBVAL	16	07/2019-	2488	122	166	2
2.0 EcoBlue		2	06/2021-	1996	125	170	2
2.0 EcoBlue 4x4		2	09/2018-	1995	132	179	3
2.0 EcoBlue 4x4		2	03/2019-	1996	96	131	3
2.0 EcoBlue 4x4		2	03/2019-	1996	125	170	3
2.0 EcoBlue 4x4		2	09/2018-	1996	157	213	3
2.0 EcoBlue Tracción trasera		2	09/2018-	1996	132	180	2
2.2 TDCi	GBVAJPF	2	04/2011-	2198	88	120	2
2.2 TDCi	GBVAJQW	2	04/2011-	2198	92	125	2
2.2 TDCi		2	05/2015-	2198	96	131	2
2.2 TDCi	GBVAJQJ	2	11/2011-	2198	110	150	2
2.2 TDCi		2	05/2015-	2198	118	160	2
2.2 TDCi 4x4	GBVAJQW	2	04/2011-	2198	92	125	3
2.2 TDCi 4x4		2	05/2015-	2198	96	131	3
2.2 TDCi 4x4	GBVAJQJ	2	04/2011-	2198	110	150	3
2.2 TDCi 4x4	GBVAJQJ	2	05/2015-	2198	118	160	3
3.2 TDCi		2	11/2011-	3198	147	200	2
3.2 TDCi 4x4	ENSA SA2R SA2S SA2W SAFA	2	04/2011-	3198	147	200	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 D	GBVAJQW	2	01/2015-	2197	92	125	2
2.2 TDCi	GBVAJPF	2	04/2011-	2198	88	120	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.2 TDCi 4x4		2	04/2014-	2198	88	120	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 i		1	11/2011-	2488	122	166	1
2.0 TDCi Bi-Turbo 4x4 (PXIII)	YN2S	2	07/2018-05/2022	1996	157	213	3
2.2 TDCi		2	01/2014-05/2022	2198	88	120	2
2.2 TDCi	GBVAKQW	2	01/2014-	2198	92	125	2
2.2 TDdi		2	06/2015-	2198	118	160	2
2.2 TDdi (PX)	P4-AT	2	11/2011-06/2015	2198	110	150	2
2.2 TDdi 4x4	P4-AT	2	11/2011-06/2015	2198	110	150	3
2.2 TDdi 4x4		2	06/2015-	2198	118	160	3
3.2 TDdi (PX, PXII, PXIII)	P5-AT	2	11/2011-05/2022	3198	147	200	2
3.2 TDdi 4x4 (PX, PXII, PXIII)	P5-AT	2	11/2011-05/2022	3198	147	200	3

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.5 i	1	11/2011-	2488	122	166	1
2.2 TDdi	2	11/2011-	2198	110	150	2
2.2 TDdi	2	11/2011-	2198	110	150	2
2.2 TDdi	2	06/2015-	2198	118	160	2
2.2 TDdi	2	06/2015-	2198	118	160	2
3.2 TDdi	2	11/2011-	3198	147	200	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 MZI		1	11/2011-	2488	122	166	2
2.5 MZI 4WD		1	11/2011-	2488	120	163	3
2.5 MZI 4WD		1	11/2011-	2488	122	166	3
2.5 CNG	L5-Y3	16	11/2011-	2488	122	166	2
2.2 MZ-CD		2	11/2011-	2198	88	120	2
2.2 MZ-CD		2	04/2015-	2198	92	125	2
2.2 MZ-CD		2	11/2011-06/2020	2198	110	150	2
2.2 MZ-CD	P4-AT	2	11/2011-	2198	115	156	2
2.2 MZ-CD 4WD	P4-AT	2	11/2011-	2198	88	120	3
2.2 MZ-CD 4WD	P4-AT	2	12/2012-	2198	92	125	3
2.2 MZ-CD 4WD	P4-AT	2	11/2011-11/2020	2198	110	150	3
3.2 MZ-CD	P5-AT	2	11/2011-	3198	145	197	2
3.2 MZ-CD (UP0YF1, UR0YF1)		2	11/2011-	3198	147	200	2
3.2 MZ-CD 4WD (UP0YF1, UR0YF1)	P5-AT	2	11/2011-	3198	147	200	3
3.2 MZ-DC 4WD	P5-AT	2	07/2015-	3198	163	222	3

Vehicle	Fuel	Date	CC	KW	CV	Traction
2.2 MZ-CD	2	11/2011-	2198	110	150	2
3.2 MZ-CD (UP0YF1, UR0YF1)	2	11/2011-	3198	147	200	2
3.2 MZ-CD 4WD (UP0YF1, UR0YF1)	2	11/2011-	3198	147	200	3
