Product 78BD8067-1

Description
Brake disc
Axe
Rear
No. of Pieces
1
Barcode
EAN13 Code
8424073148773
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD8067-1
Weight (gr.)
6670
R90 Homologation
R90 90R-02C0656/0123
Measures
Ø300x22x72.5
Brake Disc Type: Vented
Minimum thickness [mm]: 20.4
Hole Arrangement/Number: 6
Bolt Hole Circle Ø [mm]: 139.7
Wheel Hub Diameter [mm]: 94
Reference applications
Brand OE Reference
MITSUBISHI MR 418 067
Maker Cross reference
BREMBO 09.A450.10
LETEC LBMT020V
SANLI SL31953
MITSUBISHI
PAJERO III / MONTERO / SHOGUN (V7_W, V6_W) Closed Off-Road Vehicle 01/1999-09/2007
Vehicle Engine Fuel Date CC KW CV Traction
2.4 1 10/2001-01/2007 2351 82 112 3
3.0 V6 24V 1 04/2000-12/2006 2972 133 181 3
3.5 (V75W) 1 04/2000-04/2004 3497 140 190 3
3.5 i (V75W) 1 09/2003-10/2006 3497 162 220 3
3.8 (V67W)

6G75

 1 03/2003-01/2007 3828 184 250 3
3.8 (V77W) 1 09/2003-10/2006 3828 150 204 3
3.8 4WD

6G75

 1 09/2002-12/2006 3828 160 218 3
2.5 TDi 4WD 2 07/2001-09/2007 2477 98 133 3
2.8 TD 4WD (V76W) 2 05/2000-07/2002 2835 92 125 3
3.2 DI-D 2 04/2000-01/2007 3200 129 175 3
3.2 DI-D (V68W)

4M41

 2 04/2000-12/2006 3200 118 160 3
PAJERO III / MONTERO / SHOGUN (V6_W, V7_W) Open Off-Road Vehicle 02/2000-12/2006
Vehicle Engine Fuel Date CC KW CV Traction
2.4 1 10/2001-12/2006 2351 82 112 3
3.0 (V73W)

6G72 (SOHC 24V)

 1 10/2001-12/2006 2972 125 170 3
3.5 GDi 4WD (V75W) 1 10/2001-12/2006 3497 125 170 3
3.5 V6 GDI (V65W, V75W)

6G74 (GDI)

 1 04/2000-12/2006 3497 149 203 3
3.8 i 4WD (V60/V70) 1 09/2003-10/2006 3828 149 203 3
2.5 TDi (V64W, V74W)

4D56-T

 2 04/2000-12/2006 2477 73 99 3
2.5 TDi (V64W, V74W)

4D56-T

 2 09/2001-12/2006 2477 85 115 3
3.2 DI-D (V68W, V78W)

4M41

 2 10/2001-12/2006 3200 118 160 3
3.2 DI-D (V68W, V78W)

4M41

 2 04/2000-12/2006 3200 121 165 3
PAJERO II / MONTERO / SHOGUN (V3_W) Closed Off-Road Vehicle 04/2000-09/2007
Vehicle Engine Fuel Date CC KW CV Traction
3.2 DiD 4WD

4M41

 2 05/2005-09/2007 3200 118 160 3
3.2 DiD 4WD

4M41

 2 04/2000-09/2007 3200 121 165 3
PAJERO II CLASSIC / MONTERO CLASSIC / SHOGUN CLASSIC (V2_W, V6_W, V7_W) Closed Off-Road Vehicle 07/2001-
Vehicle Engine Fuel Date CC KW CV Traction
3.0 (V72W, V83W, V93W) 1 09/2006- 2972 131 178 3
3.0 ZR (V72W) 1 08/2003- 2972 132 179 3
3.8 A las 4 ruedas (V67W) 1 09/2006- 3828 184 250 3
3.8 A las 4 ruedas (V77W)

6G75

 1 06/2002- 3828 160 218 3
2.5 TD (V24W)

4D56-T

 2 07/2001- 2477 85 115 3
3.2 DI-D 2 05/2005- 3200 118 160 2
3.2 DI-D (V68W, V78W)

4M41

 2 09/2006- 3200 125 170 3
PAJERO IV FULL / MONTERO / SHOGUN (V8_W, V9_W) SUV 10/2006-
Vehicle Engine Fuel Date CC KW CV Traction
3.0 4WD

6G72 (SOHC 24V)

 1 08/2014- 2972 128 174 3
3.0 4WD

6G72 (SOHC 24V)

 1 09/2009- 2972 130 177 3
3.0 4WD 1 01/2007- 2972 135 184 3
3.0 4WD (V83W, V93W)

6G72 (SOHC 24V)

 1 02/2007- 2972 131 178 3
3.5 V6 4WD 1 09/2009- 3497 139 189 3
3.8 4WD 1 01/2007-12/2007 3828 174 237 3
3.8 4WD

6G75

 1 01/2009-12/2013 3828 179 243 3
3.8 i 4WD (V97W, V87W)

6G75

 1 01/2009- 3828 175 238 3
3.8 Mivec 4WD

6G75

 1 06/2012- 3828 172 234 3
3.8 V6

6G75

 1 02/2010- 3828 180 245 3
3.2 4WD (V98W)

4M41

 2 10/2016- 3200 141 192 3
3.2 DI-D

4M41

 2 02/2007- 3200 123 167 3
3.2 DI-D 4WD

4M41

 2 11/2008- 3200 121 165 3
3.2 DI-D 4WD (V98W, V88W)

4M41

 2 02/2007- 3200 140 190 3
3.2 DI-D 4WD (V98W, V88W)

4M41

 2 01/2009- 3200 147 200 3
3.2 DI-D 4WD (V98W) 2 01/2012- 3200 149 203 3
PAJERO IV / MONTERO / SHOGUN (V9_, V8_, V8_V) Closed Off-Road Van 11/2006-
Vehicle Engine Fuel Date CC KW CV Traction
3.2 DI-D 4WD (V88W, V98W)

4M41

 2 02/2007- 3200 140 190 3
3.2 TD 4WD (V88V, V98V)

4M41

 2 01/2010- 3200 147 200 3
PAJERO SPORT / G-WAGON / MONTERO SPORT / CHALLENGER (K7_, K9_) Closed Off-Road Vehicle 07/1996-
Vehicle Engine Fuel Date CC KW CV Traction
2.5 TD 4WD (K94W)

4D56-T

 2 11/1997-10/1998 2477 83 112 3
PAJERO SPORT II / PAJERO DAKAR / CHALLENGER / MONTERO SPORT / NATIVA (KH_, KG_) Closed Off-Road Vehicle 01/2008-
Vehicle Engine Fuel Date CC KW CV Traction
3.2 DI-D 4WD 2 11/2013-12/2018 3200 132 180 3
MITSUBISHI (GAC)
PAJERO () SUV 01/2004-12/2014
Vehicle Engine Fuel Date CC KW CV Traction
3.0 A las 4 ruedas (CFA2031) 1 12/2004-12/2006 2972 133 181 3
3.8 A las 4 ruedas (CFA5037) 1 12/2004-12/2005 3828 150 204 3
