Product 78BD8702-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073148926
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD8702-2
Weight (gr.): 7090

Measures: Ø210x16x37
: Brake Disc Type: solid; Minimum thickness [mm]: 14.5; Hole Arrangement/Number: 4; Bolt Hole Circle Ø [mm]: 97; Wheel Hub Diameter [mm]: 70

Reference applications

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
0.7		1	01/1996-03/1998	659	30	41	2
1.0	CB41	1	12/1992-05/1998	993	33	45	2
1.0 i	CB42	1	07/1994-05/1998	993	35	48	2
1.3 i 16V	HC-E	1	05/1998-10/2005	1295	48	65	2
1.2 D	LDW12	2	05/1995-03/1998	1221	26	35	2
1.4 D	LDW14	2	03/1998-12/2000	1371	28	38	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0	CB41	1	12/1992-09/1994	993	34	46	2
1.0	CB42	1	10/1994-05/1998	993	35	48	2
1.2 D		2	01/1996-03/1998	1221	27	37	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0 i	CB42	1	07/1994-05/1998	993	35	48	2
1.3	HC-E	1	08/1998-	1295	48	65	2
1.3 4WD	HC-E	1	10/2001-	1295	48	65	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.3	HC-E	1	06/1998-	1295	48	65	2
1.3 4WD	HC-E	1	10/2001-06/2004	1295	48	65	3
1.4 D	LDW14	2	04/1998-12/1999	1371	28	38	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.3 (S221G)	HC-E	1	06/1998-10/2005	1295	48	65	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 TD 4WD (K34T)	4D56-T	2	11/1992-08/1996	2477	64	87	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 DI-D 4WD (KB4T)	4D56-HP	2	11/2005-12/2015	2477	100	136	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0	CB41	1	02/1993-05/1998	993	33	45	2
1.0	CB42	1	07/1994-07/2002	993	35	48	2
1.3		1	01/2016-	1299	61	83	2
1.3	DA471QLR	1	01/2011-	1308	52	71	2
1.3	DA471QLR	1	01/2011-	1308	53	72	2
1.3 16V	HC-EL	1	06/1998-12/2010	1296	48	65	2
1.3 16V 4x4	HC-EL	1	06/1998-12/2010	1296	48	65	3
1.3 4x4		1	01/2011-	1308	52	71	3
1.3 i 16V		1	05/1998-	1295	48	65	2
1.3 i 16V 4x4		1	05/1998-	1295	48	65	3
1.3 CNG		16	07/2016-	1299	54	73	2
1.3 LPG	HC-EL	18	06/1998-12/2011	1296	48	64	2
1.3 LPG		18	01/2016-	1299	61	83	2
1.3 LPG	DA471QLR	18	01/2011-	1308	52	71	2
1.3 LPG	DA471QLR	18	01/2011-	1308	53	72	2
1.2 D	P120	2	01/2011-	1201	47	64	2
1.2 D	LDW1204	2	05/1995-	1221	26	35	2
1.4 D	LDW1404	2	04/1998-	1371	28	38	2
ELECTRO		11	06/1998-		11	15	2
Elektro		11	01/2011-		18	24	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0	CB41	1	02/1993-06/1994	993	33	45	2
1.0	CB42	1	07/1994-	993	35	48	2
1.3		1	11/2015-	1299	59	80	2
1.3		1	11/2015-	1299	61	83	2
1.3	DA471QLR	1	01/2011-	1308	52	71	2
1.3	DA471QLR	1	01/2011-	1308	53	72	2
1.3 16V	HC-EL	1	06/1998-12/2010	1296	48	65	2
1.3 16V 4x4	HC-EL	1	06/1998-12/2010	1296	48	65	3
1.3 4x4		1	01/2011-	1308	52	71	3
1.3 i 16V		1	05/1998-	1295	48	65	2
1.3 i 16V 4x4		1	05/1998-	1295	48	65	3
1.3 CNG		16	07/2016-	1299	54	73	2
1.3 CNG	DA471QLR	16	01/2011-	1308	52	71	2
1.3 LPG	HC-EL	18	06/1998-12/2011	1296	48	64	2
1.3 LPG		18	01/2016-	1299	59	80	2
1.3 LPG		18	01/2016-	1299	61	83	2
1.3 LPG		18	01/2011-	1308	51	69	2
1.3 LPG	DA471QLR	18	01/2011-	1308	52	71	2
1.3 LPG	DA471QLR	18	01/2011-	1308	53	72	2
1.2 D	P120	2	01/2011-	1201	47	64	2
1.2 D	LDW1204	2	05/1995-	1221	26	35	2
1.4 D	LDW1404	2	04/1998-	1371	28	38	2
Electric		11	06/1998-		11	15	2
Elektro		11	01/2011-		18	24	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.0	CB41	1	01/1995-06/2004	993	33	45	2
1.0	CB42	1	01/1995-07/2002	993	35	48	2
1.3		1	08/2004-	1295	47	64	2
1.3		1	11/2015-	1299	61	83	2
1.3	DA471QLR	1	01/2011-	1308	52	71	2
1.3	DA471QLR	1	01/2011-	1308	53	72	2
1.3 CNG		16	07/2016-	1299	54	73	2
1.3 LPG		18	11/2015-	1299	61	83	2
1.3 LPG	DA471QLR	18	01/2011-	1308	52	71	2
1.3 LPG	DA471QLR	18	01/2011-	1308	53	72	2
1.2 D	P120	2	01/2011-	1201	47	64	2
1.4 D		2	04/1998-12/2003	1371	28	38	2
Elektro		11	01/1995-		11	15	2
Elektro		11	01/2011-		18	24	2
