Product 78BD8762-2

Description
Brake disc
Axe
Front-Rear
No. of Pieces
2
Barcode
EAN13 Code
8424073193674
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD8762-2
Weight (gr.)
16844
Measures
Ø290x28x46
Brake Disc Type: Vented
Minimum thickness [mm]: 25
Hole Arrangement/Number: 9
Bolt Hole Circle Ø [mm]: 95
Wheel Hub Diameter [mm]: 64
Reference applications
Brand OE Reference
IVECO 2996121
IVECO 504121612
IVECO 5801341021
Maker Cross reference
BREMBO 09.9760.10
TEXTAR 92155700
IVECO
() Bus 09/2011-02/2014
Vehicle Engine Fuel Date CC KW CV Traction
35S17, 40C17, 45C17, 50C17 2 09/2011-02/2014 2998 125 170 2
50C15 2 09/2011-02/2014 2998 107 146 2
NaturalPower 50C14 8 09/2011-02/2014 2998 100 136 2
DAILY III () Platform/Chassis 03/1998-10/2009
Vehicle Engine Fuel Date CC KW CV Traction
35 C 10 V , 35 S 10 V (AMJA14A1, AMJA64A1, AMJA65A1,...

F1AE0481A

 2 09/2002-04/2006 2287 70 95 2
DAILY IV () Bus 05/2006-12/2016
Vehicle Engine Fuel Date CC KW CV Traction
35S14, 35S14 /P

F1AE0481H

 2 05/2006-08/2011 2287 100 136 2
DAILY IV () Platform/Chassis 05/2006-03/2012
Vehicle Engine Fuel Date CC KW CV Traction
35C10, 35S10

F1AE0481F

 2 05/2006-08/2011 2287 70 95 2
35C11, 35S11, 35S11 D, 35S11 /P

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
35C12, 35S12

F1AE0481G

F1AE0481R

 2 05/2006-08/2011 2287 85 116 2
35C13, 35C13 /P, 35S13 D, 35S13, 35S13 /P

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
35C14, 35C14 /P, 35S14, 35S14 /P, 35S14 D, 35S14 D/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
35C14, 35S14, 35S14 /P

F1AE0481H

 2 05/2006-08/2011 2287 100 136 2
35C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
35C17, 35C17 /P, 35S17, 35S17 /P, 35S17 D

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
35C18, 35S18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
40C10

F1AE0481F

 2 05/2006-08/2011 2287 70 95 2
40C11, 40C11 D

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
40C12

F1AE0481G

 2 05/2006-08/2011 2287 85 116 2
40C13, 40C13 /P

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
40C14, 40C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
40C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
40C17, 40C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
40C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
45C14, 45C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
45C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
45C17, 45C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
45C18, 45C18 /P, 45C18 D, 45C18 D/P

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
50C14, 50C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
50C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
50C17, 50C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
50C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
60C14, 60C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
60C15, 60C15 /P, 60C15 D, 60C15 D/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
60C17, 60C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
65C14, 65C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
65C15, 65C15 /P, 65C15 D, 65C15 D/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
65C17, 65C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
65C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
70C14, 70C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
70C15

F1CE0481F

 2 07/2008-08/2011 2998 107 146 2
70C17, 70C17P

F1CE3481C

 2 09/2009-08/2011 2998 125 170 2
35C14 G, 35C14 G/P, 35S14 G, 35S14 G/P, 35C14 GD,...

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
40C14 G, 40C14 G/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
50C14 G, 50C14 G/P, 50C14 GD, 50C14 GD/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
65C14 G, 65C14 G/P, 65C14 GD, 65C14 GD/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
DAILY IV () Van 05/2006-03/2012
Vehicle Engine Fuel Date CC KW CV Traction
3.0 2 08/2007-03/2012 2998 114 155 2
35C10, 35S10

F1AE0481F

 2 05/2006-08/2011 2287 70 95 2
35C11 V, 35S11 V

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
35C12 V, 35C12 V/P, 35S12 V, 35S12 V/P

F1AE0481G

F1AE0481R

 2 05/2006-08/2011 2287 85 116 2
35C13 V, 35C13 V/P, 35S13 V, 35S13 V/P

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
35C14 V, 35C14 V/P, 35S14 V, 35S14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
35C15 V, 35C15 V/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
35C17 V, 35C17 V/P, 35S17 V, 35S17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
35C18 V, 35C18 V/P, 35S18 V, 35S18 V/P

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
35S14 2 08/2007-03/2012 2998 100 136 2
35S14 C, 35S14 C/P, 35S14 V, 35S14 V/P, 35C14 V,...

F1AE0481H

 2 05/2006-08/2011 2287 100 136 2
35S15

F1CE0481L

 2 06/2006-08/2011 2998 107 145 2
40C10 V

F1AE0481F

 2 05/2006-08/2011 2287 70 95 2
40C11 V

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
40C12 V, 40C14 V/P

F1AE0481G

 2 05/2006-08/2011 2287 85 116 2
40C13 V, 40C13 V/P

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
40C14 V, 40C14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
40C15 V, 40C15 V/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
40C17 V, 40C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
40C18 V, 40C18 V/P

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
45C15 V

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
45C17 V, 45C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
45C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
50C14 V, 50C14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
50C15 V, 50C15 V/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
50C17 V, 50C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
50C18 V, 50C18 V/P

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
55C17

F1CE3481C

 2 08/2007-03/2012 2998 125 170 2
60C17 V, 60C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
65C14 V, 65C14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
65C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
65C17 V, 65C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
65C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
70C14 V, 70C14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
70C17V, 70C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
35C14 GV, 35C14 GV/P, 35S14 GV, 35S14 GV/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
40C14 GV, 40C14 GV/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
50C14 GV, 50C14 GV/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
DAILY IV () Dump Truck 05/2006-08/2011
Vehicle Engine Fuel Date CC KW CV Traction
35C10 K

F1AE0481F

 2 05/2006-08/2011 2287 70 95 2
35C11 K, 35C11 DK, 35S11 K, 35S11 DK

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
35C12

F1AE0481G

 2 05/2006-08/2011 2287 85 116 2
35C13 K, 35C13 DK, 35S13 K, 35S13 DK

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
35C14 K, 35C14 DK, 35S14 K, 35S14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
35C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
35C17 K, 35C17 DK, 35S17 K, 35S17 DK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
35C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
35S14 K, 35S14 DK

F1AE0481H

 2 07/2007-08/2011 2287 100 136 2
40C14 K, 40C14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
40C17 K, 40C17 DK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
50C14 K, 50C14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
50C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
50C17 K, 50C17 DK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
50C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
60C14 K, 60C14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
60C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
60C17 K, 60C17 DK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
65C14 K, 65C14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
65C17 K, 65C17 DK, 65C17KK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
70C14 K, 70C14 DK, 70C14 KK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
70C17 K, 70C17 DK, 70C17 KK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
DAILY V () Platform/Chassis 09/2011-02/2014
Vehicle Engine Fuel Date CC KW CV Traction
26L11, 29L11, 29S11, 35C11D, 35S11, 40C11

F1AE3481A

 2 09/2011-02/2014 2287 78 106 2
29L15, 35S15, 35C15, 40C15, 50C15

F1AE3481C

 2 09/2011-02/2014 2287 107 146 2
29S13, 29L13, 29L13D, 35S13, 35C13D, 40C13

F1AE3481B

 2 09/2011-02/2014 2287 93 126 2
35C15, 35S15, 40C15, 45C15, 50C15, 60C15, 65C15, 70C15

F1CE3481B

F1CE3481J

 2 09/2011-02/2014 2998 107 146 2
35C17, 35S17, 40C17, 45C17, 50C17, 60C17, 65C17, 70C17

F1CE3481C

F1CE3481K

 2 09/2011-02/2014 2998 125 170 2
35C21, 35S21, 40C21, 45C21, 50C21, 60C21, 65C21, 70C21

F1CE3481D

 2 09/2011-02/2014 2998 150 205 2
50C80E Electric 11 09/2011-02/2014 80 109 2
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14

F1CE0441A

 8 09/2011-02/2014 2998 100 136 2
DAILY V () Van 09/2011-02/2014
Vehicle Engine Fuel Date CC KW CV Traction
29L15 V, 35S15 V, 35C15L V, 40C15L V, 50C15L V

F1AE3481C

 2 09/2011-02/2014 2287 107 146 2
29S11, 29L11, 35C11, 35S11, 40C11

F1AE3481A

 2 09/2011-02/2014 2287 78 106 2
29S13, 29L13, 35C13, 35S13, 40C13, 40S13

F1AE3481B

 2 09/2011-02/2014 2287 93 126 2
35C15 V, 40C15 V, 45C15 V, 50C15 V, 60C15 V,65C15 V

F1CE3481B

F1CE3481J

 2 09/2011-02/2014 2998 107 146 2
35C17, 35S17, 40C17, 45C17, 50C17, 60C17, 65C17, 70C17

F1CE3481C

F1CE3481K

 2 09/2011-02/2014 2998 125 170 2
35C21 V, 35S21 V, 40C21 V, 45C21 V, 50C21 V

F1CE3481D

 2 09/2011-02/2014 2998 150 204 2
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14

F1CE0441A

 8 09/2011-02/2014 2998 100 136 2
DAILY V () Dump Truck 09/2011-02/2014
Vehicle Engine Fuel Date CC KW CV Traction
35C11K, 35S11DKP

F1AE3481A

 2 09/2011-02/2014 2287 78 106 2
35C13K, 35C13DKP

F1AE3481B

 2 09/2011-02/2014 2287 93 126 2
35C15K, 35S15DKP, 50C15K, 60C15K, 65C15DK, 70C15K

F1CE3481B

 2 09/2011-02/2014 2998 107 146 2
35C17K, 35S17DKP, 50C17K, 65C17DK 70C17K

F1CE3481C

F1CE3481K

 2 09/2011-02/2014 2998 125 170 2
DAILY VI (40C_, 65C_, 70C_, 35C_, 35S_, 50C_, 33S_) Platform/Chassis 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
33S11, 35S11, 35C11

F1AFL411A

 2 03/2014-07/2021 2287 78 106 2
33S13, 35S13, 35C13

F1AFL411B

 2 03/2014- 2287 93 126 2
33S14, 35S14, 35C14

F1AGL411J

 2 04/2016- 2287 100 136 2
33S15, 35S15, 35C15

F1AFL411C

 2 03/2014- 2287 107 146 2
35S14, 35S15, 35C15, 40S14, 40C15, 50C15, 60C5, 65C15,...

F1CE3481J

F1CFL411E

F1CFL411J

 2 03/2014- 2998 107 146 2
35S17, 35C17, 40C17, 45S17,45C17, 50C17, 60C17, 65C17,...

F1CFL411F

F1CFL411H

 2 03/2014- 2998 125 170 2
35S18, 35C18, 40C18, 45C18, 50C18, 60C18, 65C18, 70C18

F1CFL411W

F1CGL411B

 2 04/2016- 2998 132 179 2
35S18, 35C18, 55C18, 55S18, 70C18, 70S18 2 06/2022- 2998 129 175 3
35S18, 55S18, 55C18, 70S18, 70C18 4x4

F1CFL411W

F1CGL411B

 2 04/2016- 2998 132 180 3
35S21, 35C21, 40C21, 45C21, 50C21, 60C21, 65C21, 70C21

F1CFL411G

F1CGL411C

 2 03/2014- 2998 150 205 2
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14

F1CFA401A

 8 03/2014- 2998 100 136 2
DAILY VI () Van 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
33S15, 35S15, 35C15

F1AFL411C

 2 03/2014- 2287 107 146 2
35C21, 35S21, 40C21, 42S21, 50C21, 60C21, 65C21, 70C21 2 07/2021- 2998 152 207 2
35C21, 35S21, 40C21, 50C21, 60C21, 65C21, 70C21 2 04/2019- 2998 155 211 2
35S15, 35C15, 40C15, 45C15, 50C15, 65C15, 70C15

F1CE3481J

F1CFL411E

F1CFL411J

 2 03/2014-04/2016 2998 107 146 2
35S17, 35C17, 40C17, 50C17, 55C17, 60C17, 65C17, 70C17

F1CFL411F

F1CFL411H

 2 03/2014-04/2016 2998 125 170 2
35S18, 35C18, 40C18, 50C18, 60C18, 65C18, 70C18 2 04/2016- 2998 132 180 2
35S21, 35C21, 40C21, 50C21, 65C21, 70C21

F1CFL411G

F1CGL411C

 2 03/2014- 2998 150 205 2
55C18, 55S18, 70S18, 70C18 2 01/2018- 2998 132 179 3
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14

F1CFA401A

F1CFA401B

 8 03/2014- 2998 100 136 2
DAILY VI () Van 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
35S18, 35C18, 40C18, 50C18, 60C18, 65C18, 70C18 2 04/2016- 2998 132 180 2
40C15, 50C15, 65C15 2 03/2014-04/2016 2998 107 146 2
DAILY VI CITYS () Bus 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
40C15, 50C15, 60C15

F1CE3481J

F1CFL411E

 2 03/2014- 2998 107 146 2
50C18, 60C18 2 07/2021- 2998 129 175 2
DAILY VI LINE () Bus 06/2014-
Vehicle Engine Fuel Date CC KW CV Traction
40C15, 50C15, 60C15

F1CE3481J

F1CFL411E

 2 06/2014-10/2016 2998 107 146 2
Return
