Product 78BD8763-2

Description
Brake disc
Axe
Rear
No. of Pieces
2
Barcode
EAN13 Code
8424073193681
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD8763-2
Weight (gr.)
17412
R90 Homologation
R90 90R-02C0538/0082
Measures
Ø294x24x87.6
Brake Disc Type: Vented
Minimum thickness [mm]: 21
Hole Arrangement/Number: 8
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 84
Reference applications
Brand OE Reference
IVECO 2996043
IVECO 46393182
IVECO 7186485
Maker Cross reference
BREMBO 09.9761.60
FERODO FCR321C
ROAD HOUSE 61216.10
TEXTAR 92171700
TEXTAR 92171703
TRW DF4985S
VALEO 197974
VALEO 672834
IVECO
DAILY III () Platform/Chassis 03/1998-10/2009
Vehicle Engine Fuel Date CC KW CV Traction
35 C 10 V , 35 S 10 V (AMJA14A1, AMJA64A1, AMJA65A1,...

F1AE0481A

 2 09/2002-04/2006 2287 70 95 2
35 C 14, 35 S 14

F1AE0481M

 2 01/2005-04/2006 2287 100 136 2
DAILY IV () Bus 05/2006-12/2016
Vehicle Engine Fuel Date CC KW CV Traction
35S14, 35S14 /P

F1AE0481H

 2 05/2006-08/2011 2287 100 136 2
DAILY IV () Platform/Chassis 05/2006-03/2012
Vehicle Engine Fuel Date CC KW CV Traction
35C10, 35S10

F1AE0481F

 2 05/2006-08/2011 2287 70 95 2
35C11, 35S11, 35S11 D, 35S11 /P

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
35C12, 35S12

F1AE0481G

F1AE0481R

 2 05/2006-08/2011 2287 85 116 2
35C13, 35C13 /P, 35S13 D, 35S13, 35S13 /P

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
35C14, 35C14 /P, 35S14, 35S14 /P, 35S14 D, 35S14 D/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
35C14, 35S14, 35S14 /P

F1AE0481H

 2 05/2006-08/2011 2287 100 136 2
35C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
35C17, 35C17 /P, 35S17, 35S17 /P, 35S17 D

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
35C18, 35S18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
35S17 W, 35S17 WD

F1CE3481C

 2 07/2007-08/2011 2998 125 170 3
40C11, 40C11 D

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
40C12

F1AE0481G

 2 05/2006-08/2011 2287 85 116 2
40C13, 40C13 /P

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
40C14, 40C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
40C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
40C17, 40C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
40C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
45C14, 45C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
45C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
45C17, 45C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
45C18, 45C18 /P, 45C18 D, 45C18 D/P

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
50C14, 50C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
50C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
50C17, 50C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
50C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
55S17 W, 55S17 WD

F1CE3481C

 2 07/2007-08/2011 2998 125 170 3
60C14, 60C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
60C15, 60C15 /P, 60C15 D, 60C15 D/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
60C17, 60C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
60C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
65C14, 65C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
65C15, 65C15 /P, 65C15 D, 65C15 D/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
65C17, 65C17 /P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
65C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
70C14, 70C14 /P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
70C15

F1CE0481F

 2 07/2008-08/2011 2998 107 146 2
70C17, 70C17P

F1CE3481C

 2 09/2009-08/2011 2998 125 170 2
35C14 G, 35C14 G/P, 35S14 G, 35S14 G/P, 35C14 GD,...

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
40C14 G, 40C14 G/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
50C14 G, 50C14 G/P, 50C14 GD, 50C14 GD/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
65C14 G, 65C14 G/P, 65C14 GD, 65C14 GD/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
DAILY IV () Van 05/2006-03/2012
Vehicle Engine Fuel Date CC KW CV Traction
35C10, 35S10

F1AE0481F

 2 05/2006-08/2011 2287 70 95 2
35C11 V, 35S11 V

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
35C12 V, 35C12 V/P, 35S12 V, 35S12 V/P

F1AE0481G

F1AE0481R

 2 05/2006-08/2011 2287 85 116 2
35C13 V, 35C13 V/P, 35S13 V, 35S13 V/P

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
35C14 V, 35C14 V/P, 35S14 V, 35S14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
35C15 V, 35C15 V/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
35C17 V, 35C17 V/P, 35S17 V, 35S17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
35C18 V, 35C18 V/P, 35S18 V, 35S18 V/P

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
35S14 C, 35S14 C/P, 35S14 V, 35S14 V/P, 35C14 V,...

F1AE0481H

 2 05/2006-08/2011 2287 100 136 2
35S15

F1CE0481L

 2 06/2006-08/2011 2998 107 145 2
40C11 V

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
40C12 V, 40C14 V/P

F1AE0481G

 2 05/2006-08/2011 2287 85 116 2
40C13 V, 40C13 V/P

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
40C14 V, 40C14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
40C15 V, 40C15 V/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
40C17 V, 40C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
40C18 V, 40C18 V/P

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
45C15 V

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
45C17 V, 45C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
45C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
50C14 V, 50C14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
50C15 V, 50C15 V/P

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
50C17 V, 50C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
50C18 V, 50C18 V/P

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
55C17

F1CE3481C

 2 08/2007-03/2012 2998 125 170 2
60C15 V

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
60C17 V, 60C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
60C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
65C14 V, 65C14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
65C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
65C17 V, 65C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
65C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
70C14 V, 70C14 V/P

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
70C17V, 70C17 V/P

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
35C14 GV, 35C14 GV/P, 35S14 GV, 35S14 GV/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
40C14 GV, 40C14 GV/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
50C14 GV, 50C14 GV/P

F1CE0441A

 8 07/2007-08/2011 2998 100 136 2
DAILY IV () Dump Truck 05/2006-08/2011
Vehicle Engine Fuel Date CC KW CV Traction
35C10 K

F1AE0481F

 2 05/2006-08/2011 2287 70 95 2
35C11 K, 35C11 DK, 35S11 K, 35S11 DK

F1AE0481U

 2 07/2007-08/2011 2287 78 106 2
35C12

F1AE0481G

 2 05/2006-08/2011 2287 85 116 2
35C13 K, 35C13 DK, 35S13 K, 35S13 DK

F1AE0481V

 2 07/2007-08/2011 2287 93 126 2
35C14 K, 35C14 DK, 35S14 K, 35S14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
35C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
35C17 K, 35C17 DK, 35S17 K, 35S17 DK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
35C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
35S14 K, 35S14 DK

F1AE0481H

 2 07/2007-08/2011 2287 100 136 2
40C14 K, 40C14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
40C17 K, 40C17 DK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
50C14 K, 50C14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
50C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
50C17 K, 50C17 DK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
50C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
60C14 K, 60C14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
60C15

F1CE0481F

 2 05/2006-08/2011 2998 107 146 2
60C17 K, 60C17 DK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
60C18

F1CE0481H

 2 05/2006-08/2011 2998 130 176 2
65C14 K, 65C14 DK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
65C17 K, 65C17 DK, 65C17KK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
70C14 K, 70C14 DK, 70C14 KK

F1CE3481L

 2 09/2009-08/2011 2998 103 140 2
70C17 K, 70C17 DK, 70C17 KK

F1CE3481C

 2 07/2007-08/2011 2998 125 170 2
DAILY V () Platform/Chassis 09/2011-02/2014
Vehicle Engine Fuel Date CC KW CV Traction
26L11, 29L11, 29S11, 35C11D, 35S11, 40C11

F1AE3481A

 2 09/2011-02/2014 2287 78 106 2
29L15, 35S15, 35C15, 40C15, 50C15

F1AE3481C

 2 09/2011-02/2014 2287 107 146 2
29S13, 29L13, 29L13D, 35S13, 35C13D, 40C13

F1AE3481B

 2 09/2011-02/2014 2287 93 126 2
35C15, 35S15, 40C15, 45C15, 50C15, 60C15, 65C15, 70C15

F1CE3481B

F1CE3481J

 2 09/2011-02/2014 2998 107 146 2
35C17, 35S17, 40C17, 45C17, 50C17, 60C17, 65C17, 70C17

F1CE3481C

F1CE3481K

 2 09/2011-02/2014 2998 125 170 2
35C21, 35S21, 40C21, 45C21, 50C21, 60C21, 65C21, 70C21

F1CE3481D

 2 09/2011-02/2014 2998 150 205 2
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14

F1CE0441A

 8 09/2011-02/2014 2998 100 136 2
DAILY V () Van 09/2011-02/2014
Vehicle Engine Fuel Date CC KW CV Traction
29L15 V, 35S15 V, 35C15L V, 40C15L V, 50C15L V

F1AE3481C

 2 09/2011-02/2014 2287 107 146 2
29S11, 29L11, 35C11, 35S11, 40C11

F1AE3481A

 2 09/2011-02/2014 2287 78 106 2
29S13, 29L13, 35C13, 35S13, 40C13, 40S13

F1AE3481B

 2 09/2011-02/2014 2287 93 126 2
35C15 V, 40C15 V, 45C15 V, 50C15 V, 60C15 V,65C15 V

F1CE3481B

F1CE3481J

 2 09/2011-02/2014 2998 107 146 2
35C17, 35S17, 40C17, 45C17, 50C17, 60C17, 65C17, 70C17

F1CE3481C

F1CE3481K

 2 09/2011-02/2014 2998 125 170 2
35C21 V, 35S21 V, 40C21 V, 45C21 V, 50C21 V

F1CE3481D

 2 09/2011-02/2014 2998 150 204 2
35S14

F1CE3481L

 2 04/2012-02/2014 2998 110 150 2
35S60E Electric 11 09/2011-02/2014 60 82 2
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14

F1CE0441A

 8 09/2011-02/2014 2998 100 136 2
DAILY V () Dump Truck 09/2011-02/2014
Vehicle Engine Fuel Date CC KW CV Traction
35C11K, 35S11DKP

F1AE3481A

 2 09/2011-02/2014 2287 78 106 2
35C13K, 35C13DKP

F1AE3481B

 2 09/2011-02/2014 2287 93 126 2
35C15K, 35S15DKP, 50C15K, 60C15K, 65C15DK, 70C15K

F1CE3481B

 2 09/2011-02/2014 2998 107 146 2
35C17K, 35S17DKP, 50C17K, 65C17DK 70C17K

F1CE3481C

F1CE3481K

 2 09/2011-02/2014 2998 125 170 2
DAILY VI (40C_, 65C_, 70C_, 35C_, 35S_, 50C_, 33S_) Platform/Chassis 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
33S11, 35S11, 35C11

F1AFL411A

 2 03/2014-07/2021 2287 78 106 2
33S13, 35S13, 35C13

F1AFL411B

 2 03/2014- 2287 93 126 2
33S14, 35S14, 35C14, 38S14

F1AGL411J

 2 04/2016- 2287 100 136 2
33S15, 35S15, 35C15

F1AFL411C

 2 03/2014- 2287 107 146 2
35S14, 35S15, 35C15, 40S14, 40C15, 50C15, 60C5, 65C15,...

F1CE3481J

F1CFL411E

F1CFL411J

 2 03/2014- 2998 107 146 2
35S15, 35C15, 40C15, 50C15, 60C15, 65C15, 70C15 2 04/2016- 2998 110 150 2
35S17, 35C17, 40C17, 45S17,45C17, 50C17, 60C17, 65C17,...

F1CFL411F

F1CFL411H

 2 03/2014- 2998 125 170 2
35S18, 35C18, 40C18, 45C18, 50C18, 60C18, 65C18, 70C18

F1CFL411W

F1CGL411B

 2 04/2016- 2998 132 180 2
35S18, 35C18, 55C18, 55S18, 70C18, 70S18 2 06/2022- 2998 129 175 3
35S18, 55S18, 55C18, 70S18, 70C18 4x4

F1CFL411W

F1CGL411B

 2 04/2016- 2998 132 180 3
35S21, 35C21, 40C21, 45C21, 50C21, 60C21, 65C21, 70C21

F1CFL411G

F1CGL411C

 2 03/2014- 2998 150 204 2
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14

F1CFA401A

 8 03/2014- 2998 100 136 2
DAILY VI () Van 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
33S11, 35S11, 35C11

F1AFL411A

 2 03/2014-07/2021 2287 78 106 2
33S13, 35S13, 35C13

F1AFL411B

 2 03/2014- 2287 93 126 2
33S14, 35S14, 35C14, 42S14

F1AGL411J

 2 04/2016- 2287 100 136 2
33S15, 35S15, 35C15

F1AFL411C

 2 03/2014- 2287 107 146 2
35S15, 35C15, 40C15, 45C15, 50C15, 65C15, 70C15

F1CE3481J

F1CFL411E

F1CFL411J

 2 03/2014- 2998 107 146 2
35S15, 35C15, 40C15, 50C15, 60C15, 65C15, 70C15 2 04/2016- 2998 110 150 2
35S17, 35C17, 40C17, 50C17, 55C17, 60C17, 65C17, 70C17

F1CFL411F

F1CFL411H

 2 03/2014- 2998 125 170 2
35S18, 35C18, 40C18, 50C18, 60C18, 65C18, 70C18 2 04/2016- 2998 132 180 2
35S21, 35C21, 40C21, 42S21, 50C21, 60C21, 65C21, 70C21 2 07/2021- 2998 152 207 2
35S21, 35C21, 40C21, 50C21, 60C21, 65C21, 70C21

F1CFL411G

F1CGL411C

 2 03/2014- 2998 150 204 2
35S21, 35C21, 40C21, 50C21, 60C21, 65C21, 70C21 2 04/2019- 2998 155 211 2
55S18, 55C18, 70S18, 70C18 2 01/2018- 2998 132 180 3
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14

F1CFA401A

F1CFA401B

 8 03/2014- 2998 100 136 2
DAILY VI () Van 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
33S14, 35S14

F1AGL411J

 2 04/2016- 2287 100 136 2
35S15, 35C15, 40C15, 50C15, 60C15, 65C15, 70C15 2 04/2016- 2998 110 150 2
35S18, 35C18, 40C18, 50C18, 60C18, 65C18, 70C18 2 04/2016- 2998 132 180 2
40C15, 50C15, 65C15 2 03/2014-04/2016 2998 107 146 2
40C17, 50C17, 65C17 2 03/2014-04/2016 2998 125 170 2
50C16 2 03/2014- 2998 114 155 2
NaturalPower 35S14, 35C14, 40C14, 50C14, 65C14, 70C14 8 04/2016- 2998 100 136 2
DAILY VI CITYS () Bus 03/2014-
Vehicle Engine Fuel Date CC KW CV Traction
40C15, 50C15, 60C15

F1CE3481J

F1CFL411E

 2 03/2014- 2998 107 146 2
40C17, 50C17, 60C17

F1CFL411F

 2 03/2014- 2998 125 170 2
50C80E 11 04/2016- 80 109 2
NaturalPower 40C14, 50C14, 60C14 8 03/2014- 2998 100 136 2
Return
