Product 78BD9005-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Barcode
EAN13 Code
8424073149084
QR Code
Url
https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD9005-2
Weight (gr.)
18448
R90 Homologation
R90 90R-02C0433/0096
Measures
Ø313.5x28x44.8
Brake Disc Type: Vented
Minimum thickness [mm]: 26
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 110
Wheel Hub Diameter [mm]: 70
Reference applications
Brand OE Reference
OPEL 1 842 193
OPEL 5 69 005
OPEL 93 175 606
SAAB 24 435 132
Maker Cross reference
ATE 24.0128-0164.1
ATE 428164
BENDIX ANTIGUO 562294B
BENDIX BRAKING-TMD BDS1890
BREMBO 09.9177.10
BREMBO 09.9177.11
DELPHI LOCKHEED BG3973
FERODO DDF1237
GIRLING 6045491
HELLA-PAGID 8DD 355 109-251
LETEC LBG038V
MINTEX MDC1674
NECTO WN1254
ROAD HOUSE 6944.10
TEXTAR 92118803
TEXTAR 98200 1188 0 1
TRW DF4549
VALEO 197361
CADILLAC
BLS () Saloon 04/2006-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 T

B284R

Z 28 NET

 1 12/2009-12/2010 2792 206 280 1
2.8 T AWD

Z 28 NET

 1 10/2008- 2792 206 280 3
BLS Wagon () Estate 12/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 T

B284R

 1 08/2010- 2792 206 280 1
2.8 T AWD

Z 28 NET

 1 10/2008- 2792 206 280 3
CHEVROLET
VECTRA II () Saloon 01/2005-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 1 10/2006- 2792 184 250 1
2.8 1 11/2005-09/2006 2792 188 256 1
OPEL
SIGNUM (Z03) Hatchback 05/2003-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 V6 Turbo (F48)

Z 28 NEL

 1 09/2005-12/2008 2792 169 230 1
2.8 V6 Turbo (F48)

Z 28 NET

 1 01/2006-12/2008 2792 184 250 1
3.2 V6 (F48)

Z 32 SE

 1 05/2003-07/2005 3175 155 211 1
3.0 V6 CDTI (F48)

Y 30 DT

 2 05/2003-07/2005 2958 130 177 1
3.0 V6 CDTI (F48)

Z 30 DT

 2 09/2005-12/2008 2958 135 184 1
VECTRA C (Z02) Saloon 04/2002-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 V6 Turbo (F69)

Z 28 NEL

 1 08/2005-10/2006 2792 169 230 1
2.8 V6 Turbo (F69)

Z 28 NET

 1 08/2005-08/2008 2792 184 250 1
2.8 V6 Turbo (F69)

Z 28 NET

 1 08/2005-09/2006 2792 188 255 1
3.2 V6 (F69)

Z 32 SE

 1 08/2002-07/2006 3175 155 211 1
3.0 CDTI (F69)

Y 30 DT

 2 02/2003-07/2005 2958 130 177 1
3.0 CDTI (F69)

Z 30 DT

 2 08/2005-08/2008 2958 135 184 1
VECTRA C (Z02) Hatchback 08/2002-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 V6 Turbo (F68)

Z 28 NEL

 1 08/2005-08/2008 2792 169 230 1
2.8 V6 Turbo (F68)

Z 28 NET

 1 08/2005-08/2008 2792 184 250 1
2.8 V6 Turbo (F68)

Z 28 NET

 1 08/2005-09/2008 2792 188 255 1
2.8 V6 Turbo (F68)

Z 28 NET

 1 08/2006-08/2008 2792 206 280 1
3.2 V6 (F68)

Z 32 SE

 1 08/2002-07/2006 3175 155 211 1
3.0 CDTI (F68)

Y 30 DT

 2 06/2003-07/2005 2958 130 177 1
3.0 CDTI (F68)

Z 30 DT

 2 08/2005-08/2008 2958 135 184 1
VECTRA C (Z02) Estate 10/2003-
Vehicle Engine Fuel Date CC KW CV Traction
2.8 V6 Turbo (F35)

Z 28 NEL

 1 08/2005-10/2008 2792 169 230 1
2.8 V6 Turbo (F35)

Z 28 NET

 1 08/2005-08/2008 2792 184 250 1
2.8 V6 Turbo (F35)

Z 28 NET

 1 08/2005-09/2008 2792 188 255 1
2.8 V6 Turbo (F35)

Z 28 NET

 1 07/2006-08/2008 2792 206 280 1
3.2 V6 (F35)

Z 32 SE

 1 10/2003-07/2005 3175 155 211 1
3.0 V6 CDTI (F35)

Y 30 DT

 2 10/2003-07/2005 2958 130 177 1
3.0 V6 CDTI (F35)

Z 30 DT

 2 08/2005-08/2008 2958 135 184 1
SAAB
9-3 II (YS3F, E79, D79, D75) Saloon 09/2002-02/2015
Vehicle Engine Fuel Date CC KW CV Traction
1,8t

B207E

 1 09/2002-02/2015 1998 110 150 1
1.8 i

Z 18 XE

 1 01/2004-02/2015 1796 90 122 1
2.0 T

B207G

 1 01/2007-02/2015 1998 120 163 1
2.0 T

B207L

 1 09/2002-02/2015 1998 129 175 1
2.0 T

B207R

 1 09/2002-02/2015 1998 154 210 1
2.0 T

A 20 NFT

 1 01/2011-02/2015 1998 162 220 1
2.0 T

B207R

 1 05/2009-02/2015 1998 177 241 1
2.0 t XWD

B207G

 1 01/2007-02/2015 1998 120 163 3
2.0 t XWD

A 20 NFT

 1 01/2008-02/2015 1998 162 220 3
2.0 t XWD

B207R

 1 05/2009-02/2015 1998 177 241 3
2.0 T16 1 06/2006-02/2015 1998 143 194 1
2.0 Turbo Performance

B207R

 1 04/2004-02/2015 1998 185 252 1
2.0 Turbo XWD

B207R

 1 01/2008-02/2015 1998 154 210 3
2.8 Turbo V6

LP9

 1 03/2005-02/2015 2792 169 230 1
2.8 Turbo V6

LP9

 1 03/2005-02/2015 2792 184 250 1
2.8 Turbo V6

B284L

 1 12/2007-02/2015 2792 188 256 1
2.8 Turbo V6

B284L

 1 04/2008-02/2015 2792 203 276 1
2.8 Turbo V6

B284R

 1 05/2008-12/2010 2792 206 280 1
2.8 Turbo V6 XWD

B284R

 1 05/2008-12/2011 2792 206 280 3
1,8t BioPower

B207L

 19 05/2009-02/2015 1998 129 175 1
2.0 t Biopower

B207H

 19 01/2007-02/2015 1998 120 163 1
2.0 t Biopower

B207L

 19 01/2007-02/2015 1998 129 175 1
2.0 t Biopower

B207R

 19 06/2007-02/2015 1998 145 197 1
2.0 t Biopower

B207M

 19 05/2009-02/2015 1998 147 200 1
2.0 t Biopower

B207R

 19 09/2002-02/2015 1998 154 210 1
2.0 t Biopower

A 20 NFT

 19 01/2011-02/2015 1998 162 220 1
2.0 t BioPower XWD

B207H

 19 01/2008-02/2015 1998 120 163 3
2.0 t BioPower XWD

B207R

 19 01/2008-02/2015 1998 154 210 3
2.0 t BioPower XWD

A 20 NFT

 19 01/2008-02/2015 1998 162 220 3
1.9 TiD

Z 19 DT

 2 09/2004-02/2015 1910 88 120 1
1.9 TiD

Z 19 DTH

 2 09/2004-02/2015 1910 110 150 1
1.9 TTiD

A 19 DTR

 2 12/2007-02/2015 1910 96 130 1
1.9 TTiD

A 19 DTR

 2 12/2007-02/2015 1910 118 160 1
1.9 TTiD

A 19 DTR

Z 19 DTR

 2 12/2007-02/2015 1910 132 180 1
2.2 TiD

D223L

 2 09/2002-02/2015 2171 92 125 1
9-3 II (YS3F) Convertible 08/2003-02/2015
Vehicle Engine Fuel Date CC KW CV Traction
1,8t

B207E

 1 08/2003-02/2015 1998 110 150 1
1.8 i

Z 18 XE

 1 01/2004-02/2015 1796 90 122 1
2.0 1 09/2004-12/2005 1998 130 177 1
2.0 T

B207G

 1 01/2011-02/2015 1998 120 163 1
2.0 T

B207L

 1 08/2003-02/2015 1998 129 175 1
2.0 T

B207R

 1 08/2003-02/2015 1998 154 210 1
2.0 T

A 20 NFT

 1 01/2011-02/2015 1998 162 220 1
2.0 t Biopower 1 06/2007- 1998 145 197 1
2.0 Turbo Performance

B207R

 1 04/2004-02/2015 1998 185 252 1
2.8 Turbo V6

LP9

 1 02/2006-02/2015 2792 169 230 1
2.8 Turbo V6

LP9

 1 02/2006-02/2015 2792 184 250 1
2.8 Turbo V6

B284L

 1 12/2007-02/2015 2792 188 256 1
2.8 Turbo V6

B284R

 1 02/2009-02/2015 2792 203 276 1
2.8 Turbo V6

B284R

 1 02/2009-02/2015 2792 206 280 1
2.0 t Biopower

B207H

 19 01/2011-02/2015 1998 120 163 1
2.0 t Biopower

B207L

 19 01/2007-02/2015 1998 129 175 1
2.0 t Biopower

B207L

 19 01/2007-02/2015 1998 129 175 1
2.0 t Biopower 19 06/2007-02/2015 1998 145 197 1
2.0 t Biopower

B207M

 19 06/2007-02/2015 1998 147 200 1
2.0 t Biopower

A 20 NFT

 19 01/2011-02/2015 1998 162 220 1
1.9 TiD

Z 19 DT

 2 09/2004-02/2015 1910 88 120 1
1.9 TiD

Z 19 DTH

 2 01/2006-02/2015 1910 110 150 1
1.9 TTiD

A 19 DTR

 2 12/2007-02/2015 1910 96 130 1
1.9 TTiD

A 19 DTR

 2 12/2007-02/2015 1910 118 160 1
1.9 TTiD

A 19 DTR

Z 19 DTR

 2 12/2007-02/2015 1910 132 180 1
9-3 II (E50) Estate 03/2005-02/2015
Vehicle Engine Fuel Date CC KW CV Traction
1.8 i

Z 18 XE

 1 03/2005-02/2015 1796 90 122 1
1.8t 2.0

B207E

 1 03/2005-02/2015 1998 110 150 1
2.0 1 04/2006-09/2007 1998 143 194 1
2.0 T

B207E

 1 03/2005-02/2015 1998 110 150 1
2.0 T

B207G

 1 01/2007-02/2015 1998 120 163 1
2.0 T

B207L

 1 03/2005-02/2015 1998 129 175 1
2.0 T

B207M

 1 02/2009-02/2015 1998 147 200 1
2.0 T

B207R

 1 03/2005-02/2015 1998 154 209 1
2.0 T

A 20 NFT

 1 01/2011-02/2015 1998 162 220 1
2.0 T

B207R

 1 05/2009-02/2015 1998 177 241 1
2.0 t XWD

B207G

 1 01/2007-02/2015 1998 120 163 3
2.0 t XWD

B207R

 1 06/2008-02/2015 1998 154 209 3
2.0 t XWD

A 20 NFT

 1 01/2011-02/2015 1998 162 220 3
2.0 t XWD

B207R

 1 05/2009-02/2015 1998 177 241 3
2.8 Turbo V6

B284L

 1 03/2005-02/2015 2792 169 230 1
2.8 Turbo V6

LP9

 1 03/2005-02/2015 2792 184 250 1
2.8 Turbo V6

B284L

 1 12/2007-02/2015 2792 188 256 1
2.8 Turbo V6

B284R

 1 05/2008-02/2015 2792 203 276 1
2.8 Turbo V6

B284R

 1 05/2008-12/2010 2792 206 280 1
2.8 Turbo V6 XWD

B284R

 1 05/2008-12/2011 2792 206 280 3
2.0 t Biopower

B207E

 19 01/2007-02/2015 1998 110 150 1
2.0 t Biopower

B207H

 19 01/2011-02/2015 1998 120 163 1
2.0 t Biopower

B207L

 19 01/2007-02/2015 1998 129 175 1
2.0 t Biopower

B207R

 19 06/2007-02/2015 1998 145 197 1
2.0 t Biopower

B207M

 19 02/2009-02/2015 1998 147 200 1
2.0 t Biopower

A 20 NFT

 19 01/2011-02/2015 1998 162 220 1
2.0 t BioPower XWD

B207H

 19 01/2007-02/2015 1998 120 163 3
2.0 t BioPower XWD

B207R

 19 06/2008-02/2015 1998 154 209 3
2.0 t BioPower XWD

A 20 NFT

 19 01/2011-02/2015 1998 162 220 3
1.9 TiD

Z 19 DT

 2 03/2005-02/2015 1910 88 120 1
1.9 TiD

Z 19 DTH

 2 03/2005-02/2015 1910 110 150 1
1.9 TTiD

A 19 DTR

 2 12/2007-02/2015 1910 96 130 1
1.9 TTiD

A 19 DTR

 2 12/2007-02/2015 1910 118 160 1
1.9 TTiD

Z 19 DTR

 2 12/2007-02/2015 1910 132 180 1
9-3X (YS3) Estate 02/2009-02/2015
Vehicle Engine Fuel Date CC KW CV Traction
2.0 t XWD

B207R

 1 02/2009-02/2015 1998 154 209 3
2.0 t BioPower XWD

B207R

 19 02/2009-12/2012 1998 154 209 3
2.0 t BioPower XWD

A 20 NFT

 19 01/2011-12/2012 1998 162 220 3
1.9 TTiD AWD

A 19 DTR

Z 19 DTR

 2 02/2009-12/2012 1910 132 180 3
VAUXHALL
SIGNUM (Z03) Hatchback 03/2003-10/2008
Vehicle Engine Fuel Date CC KW CV Traction
2.8 V6 Turbo

Z 28 NET

 1 05/2007-10/2008 2792 184 250 1
3.2 V6

Z 32 SE

 1 05/2003-05/2008 3175 155 211 1
3.0 CDTi

Y 30 DT

 2 05/2003-05/2008 2958 130 177 1
3.0 V6 CDTI

Z 30 DT

 2 07/2005-06/2008 2959 135 184 1
VECTRA Mk II (C) (Z02) Saloon 01/2000-10/2008
Vehicle Engine Fuel Date CC KW CV Traction
2.8 V6 Turbo 1 08/2005-07/2008 2792 169 230 1
VECTRA Mk II (C) GTS (Z02) Hatchback 08/2002-05/2009
Vehicle Engine Fuel Date CC KW CV Traction
2.8 V6 Turbo

Z 28 NEL

 1 08/2005-05/2009 2792 169 230 1
VECTRA Mk II (C) (Z02) Estate 10/2003-05/2009
Vehicle Engine Fuel Date CC KW CV Traction
2.8 V6 Turbo

Z 28 NEL

 1 08/2005-05/2009 2792 169 230 1
