Product 78BD9048-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073149183
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD9048-2
Weight (gr.): 17712

R90 Homologation: 90R-02C0452/0114
Measures: Ø296x29x52
: Brake Disc Type: Vented; Minimum thickness [mm]: 27.4; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 115; Wheel Hub Diameter [mm]: 70.7

Reference applications

Brand	OE Reference
CHEVROLET	4808 848
OPEL	96 625 948

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4		1	01/2011-	2384	122	165	1
2.4	LE5	1	03/2011-	2384	123	167	1
2.4	LE9(145CUL4)	1	01/2011-	2384	124	169	1
2.4	LE9(145CUL4)	1	11/2012-	2384	126	171	1
2.4	LD9(147CUL4)	1	06/2006-02/2011	2405	100	136	1
2.4	LD9(147CUL4)	1	12/2006-02/2011	2405	103	140	1
2.4 16V 4WD	LD9(147CUL4)	1	12/2006-02/2011	2405	105	143	3
2.4 4WD		1	06/2011-	2384	122	165	3
2.4 4WD	LE5	1	03/2011-	2384	123	167	3
2.4 4WD	LE9(145CUL4)	1	03/2011-	2384	124	169	3
2.4 4WD	LE9(145CUL4)	1	11/2012-	2384	126	171	3
2.4 4WD	LD9(147CUL4)	1	06/2006-02/2011	2405	100	136	3
2.4 4WD	LD9(147CUL4)	1	12/2006-02/2011	2405	103	140	3
3.0		1	01/2011-	2997	197	268	1
3.0		1	01/2011-	2997	197	268	1
3.0 4WD	LFW	1	01/2012-	2997	186	253	3
3.0 4WD	LF1 LFW	1	11/2010-09/2018	2997	190	258	3
3.0 4WD	LFW	1	01/2012-	2997	197	268	3
3.2 4WD	LU1	1	06/2006-	3195	169	230	3
2.4 LPG	LD9(147CUL4)	18	01/2007-	2405	100	136	1
2.4 LPG 4WD	LD9(147CUL4)	18	01/2007-02/2011	2405	100	136	3
2.4 Flexfuel		19	12/2012-	2384	121	165	1
2.4 Flexfuel 4WD		19	12/2012-	2384	121	165	3
3.0 Flexfuel 4WD	LFW	19	01/2011-	2997	197	268	3
2.0 D	LFS	2	01/2016-	1956	125	170	1
2.0 D	LLW	2	10/2006-12/2009	1991	93	126	1
2.0 D	LLW	2	09/2007-	1991	110	150	1
2.0 D	LNP	2	01/2011-	1998	120	163	1
2.0 D 4WD	LLW	2	10/2006-12/2009	1991	93	126	3
2.0 D 4WD	LLW	2	10/2006-	1991	110	150	3
2.0 D 4WD	LNP	2	01/2011-	1998	120	163	3
2.2 D	LNQ	2	03/2011-	2231	120	163	1
2.2 D	LNQ	2	07/2014-	2231	135	184	1
2.2 D 4WD	LNQ	2	03/2011-	2231	120	163	3
2.2 D 4WD	LNQ	2	03/2011-	2231	135	184	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
VCDi		2	10/2006-12/2009	1991	93	126	1
VCDi A las 4 ruedas		2	07/2006-02/2011	1991	110	150	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4	LEA	1	01/2012-	2384	134	182	1
2.4		1	01/2007-	2405	100	136	1
3.0		1	01/2012-	2997	194	264	1
3.0	LF1 LFW	1	01/2012-	2997	197	268	1
3.0 AWD	LF1 LFW	1	01/2012-	2997	197	268	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.4	LNJ	1	04/2003-09/2009	3350	138	188	1
3.4 AWD	LNJ	1	04/2003-09/2009	3350	138	188	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4	A 24 XE A 24 XF	1	12/2010-02/2015	2384	123	167	1
2.4	Z 24 XE	1	09/2008-12/2011	2405	103	140	1
2.4	Z 24 XE	1	08/2006-12/2011	2405	104	141	3
2.4 4x4	A 24 XE A 24 XF	1	12/2010-02/2015	2384	123	167	3
2.4 4x4	Z 24 XE	1	08/2006-12/2011	2405	103	140	3
3.0	A 30 XF A 30 XH	1	07/2013-12/2014	2997	183	249	3
3.0	A 30 XF A 30 XH	1	11/2010-12/2015	2997	190	258	3
3.2 V6	Z 32 SEE	1	08/2006-12/2011	3195	167	227	3
2.4 LPG	Z 24 XE	18	10/2008-08/2010	2405	103	140	1
2.4 LPG 4x4	Z 24 XE	18	08/2006-12/2010	2405	103	140	3
2.0 CDTi	B 20 DTH	2	01/2016-08/2017	1956	125	170	1
2.0 CDTi	Z 20 S	2	03/2007-12/2011	1991	93	127	3
2.0 CDTi	Z 20 DM	2	09/2008-12/2011	1991	93	127	1
2.0 CDTi	Z 20 DMH	2	08/2006-12/2011	1991	110	150	1
2.0 CDTI 4x4	B 20 DTH	2	01/2016-08/2017	1956	125	170	3
2.0 CDTI 4x4	Z 20 DMH	2	08/2006-12/2011	1991	110	150	3
2.2 CDTi	A 22 DM	2	12/2010-12/2015	2231	120	163	1
2.2 CDTi	A 22 DM	2	07/2014-12/2015	2231	122	166	1
2.2 CDTi 4x4	A 22 DM	2	12/2010-12/2015	2231	120	163	3
2.2 CDTi 4x4	A 22 DMH	2	12/2010-12/2015	2231	135	184	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.4	LNJ	1	08/2004-12/2009	3350	138	188	1
3.4 A las 4 ruedas	LNJ	1	08/2004-12/2009	3350	138	188	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.6 (JC636)	N36A	1	09/2006-12/2009	3564	188	256	1
3.6 A las 4 ruedas (JC636)	N36A	1	09/2006-12/2009	3564	188	256	3

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.4	A 24 XE A 24 XF	1	12/2010-04/2015	2384	123	167	1
2.4		1	08/2006-	2405	103	140	1
2.4	Z 24 XE	1	08/2006-04/2015	2405	103	140	1
2.4 4x4	A 24 XE A 24 XF	1	12/2010-04/2015	2384	123	167	3
2.4 4x4	Z 24 XE	1	08/2006-04/2015	2405	103	140	3
3.2 V6 4x4		1	11/2006-04/2015	3195	167	227	3
2.4 LPG 4x4	Z 24 XE	18	08/2006-04/2015	2405	103	140	3
2.0 CDTi		2	03/2007-	1991	93	126	2
2.0 CDTi	Z 20 DM	2	08/2006-04/2015	1991	93	126	1
2.0 CDTi		2	08/2006-	1991	110	150	2
2.0 CDTi	Z 20 DMH	2	08/2006-04/2015	1991	110	150	1
2.0 CDTI 4x4		2	08/2006-04/2015	1991	93	126	3
2.0 CDTI 4x4	Z 20 DMH	2	08/2006-04/2015	1991	110	150	3
2.2 CDTi 4x4	A 22 DM	2	12/2010-04/2015	2231	120	163	3
2.2 CDTi 4x4	A 22 DMH	2	12/2010-04/2015	2231	135	184	3
2.2 CDTi FWD	A 22 DM	2	12/2010-04/2015	2231	120	163	1
